Summary of Contents for Willy's RC Angel
- Page 1 -------------Angel --------------- Multi-rotors Aircraft manual...
- Page 2 01 工具 Tools Radio transmitter and electronic equipment required for assembly Transmitter (6-channel or more) Receiver (6-channel or more) 11.1V ( 3S) 2200~5500mA/h 11.1V 2200~5000ma/H Additional tools required for assembly Hexagon Screw Driver Sharp nose pliers 1.5mm/2mm/2.5mm Cross Screw Driver Screw Glue ATTENTION : These all screws of the product is not add glue, pls use the glue of screw to reinforce the track of screw before your application.
- Page 3 03 LED模 块 和 电 池 仓LED Plate and battery door 机 架 下 板 lower fuselage 插销 bolt 参数调整模块 电池仓门 parameter adjustment board battery door LED 灯罩 LED lampshade 04 电机和电调 Brushless Motor and ESC 注意： 电机分两种(CW和 安装 ),M1和 CW的电机，...
- Page 4 05 中心板和飞行控制器Centre board and Flight controller 自攻螺丝 Screw PA2*6 P A 2 自攻螺丝 中心板 Screw PA2*6 centre plate 注意： 包装袋上贴有CCW标识的电机 安装在M1、M3位置，贴有CW标 识的电机安装在M2、M4位置。 Warning: 飞行控制器 pls install the motors with Flight controller “CCW”sign in M1 and M3 location, while those with “CW”installed in M2 and M4 location 06 云台的组装Gimbal installment 减震球...
- Page 5 07 起落架的安装 Landing gear Assembling 螺丝 Screw M2 起落架 Landing Gear 螺丝 Screw M2 08 云台的安装 Gimbal Assembling 云台 Gimbal 螺丝 Screw M2...
- Page 6 09 螺旋桨的安装 Propeller Assembling 安装前请确认M1&M3位置安装的电机为CCW（反牙）,M1&M3位置电机旋转方向为逆时针旋 螺 旋桨 propeller 转;M2&M4位置安装的电机为CW（正牙）,M2&M4位置电机旋转方向为顺时针旋转， Before installing, Please make sure that motors( CCW )should put in M1&M3 place; M1&M3's rotation direction is counterclockwise. However, motors(CW) should put in M2&M4's direction is clockwise. 02 *************** 正牙电机 cw motor 银色...
