Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Page 3
Important Safety Instructions CAUTION: These servicing instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualifi ed to do so. Refer to service manual for servicing instructions.
Page 4
To fi nd out how to properly dispose of this product, please go to www.polaroid. com and click on “Company“ or call the customer service number for your country listed in the instruction manual.
High-quality Audio and Video • Excellent Sound: Dolby Digital Decoder delivers great sound. • AV Input: External audio, video can be connected to most external AV sources. • AV Output: Analog audio output can be connected to external amplifi er. Advanced Playing Functions •...
ITEM ITEM Note: Accessories and their parts numbers are subject to change without prior notice. Accessories NAME NAME Remote Control (with battery) Power Supply Cord with AC Adaptor Rechargeable Battery Pack DC Adapter (Car Adapter) Audio/Video Cord Headphone Operation Manual...
Important Safety Instructions Features Accessories View of Front Panel View of Side Panels View of Bottom Panel Revolving LCD Screen Remote Control System Connections Power Supply Rechargeable Battery Notes on Discs Playback Operation DVD Playback CD Playback JPEG Playback System Setup Carrying Case Defi...
LCD screen / /+ button: press to select different items; press + button to increase the level of brightness, contrast, and color. / /- button: press to select different items; press press the (PLAY) button to resume playback from the stopped spot; press the MODE button and then press the - button to decrease the level of brightness, color, and contrast.
Ride Side View Volume Control Knob: Used to adjust the volume of headphones and speaker Headphone Jack: Used to connect to headphones for private listening. When headphone is plugged in, the speakers will automatically turnoff. Audio Input/Output Jack: For connecting to an external amplifi er or audio source Video Input/Output Jack: For connecting to an external monitor or video source AV IN/OUT Switch: Switch to “IN”...
Rechargeable Battery Contacts: For connecting the rechargeable battery pack Docking Jack: This portable DVD player is designed with a docking jack on the bottom. The docking jack is designed for connecting to external docking station to get more expanded functions. Docking station is a set of electrical connection interfaces that enables the portable DVD player to effectively serve as a desktop DVD player.
Revolving Steps The revolving LCD screen is one of the outstanding features about this product. Here are some suggested steps for proper operation: Revolving LCD Screen Open the screen cover to position (A) as shown at left, where the screen is vertical to the operation panel. Revolving the screen horizontally about its axis in the clockwise only.
POWER button: press to turn unit on or off INFO button: press repeatedly to display or cancel the detailed information of the disc during playback TITLE button: press to display the title menu if it exists on the disc Direction button: press to select different options ENTER button: press to access playback or confi...
Installing the Remote Control Battery Pull the battery holder out from the remote control as shown below. Load a new battery properly with the (+) side up. Insert the battery holder back into the remote control. Battery Type: CR2025 3V Battery service life: approximately 1 year under normal use (at room temperature) Using the Remote Control Point the remote control to the remote sensor on the unit within a 5-meter range and 60-degree angles, without...
• Always endure that the DVD player, TV, and any other electrical equipment to be connected are switched off and unplugged from the power supply. • Ensure that you observe the color coding when connecting audio and video cables. Connecting to a TV Follow the drawing below to connect the DVD player to the TV’s audio/video input with the audio/video cables.
Using the AC Adapter The player is supplied with an AC adapter for powering the unit and charging the batter. Connect the AC adapter to the left side of the DVD player in the pack marked DC 9.5/12V IN. Plug the two-prong end of the power cord into a grounded electrical outlet. The power indicator lights red when charging the battery and green when complete.
About Your Rechargeable Battery Pack Your portable DVD player comes with a lithium ion polymer rechargeable battery that attaches to the bottom of the DVD player. Charge the battery fully before initial use. Charging time is normally about 5 hours. A fully- charged battery delivers about 3 hours of use, but playing time varies disc to disc.
Attaching the Battery Pack With one hand on the DVD player to prevent it from moving, take the battery and align the plastic tabs on the battery pack with the holds on the player, and push the battery pack into the DVD player. Slide the battery pack until you hear it click and lock in place.
Compatible Disc Formats JPEG Operation methods of some DVD discs are specifi ed by the software manufacturer. Please follow the instructions of the disc. Care of Discs Holding Discs • When loading or removing discs, try not to touch their play surfaces. Cleaning Discs •...
Please read the following instructions carefully before using your Warning: To avoid damaging the lens, do not play poor quality discs. Pre-Operation Connect the unit to power supply through the provided AC adaptor. Switch POWER ON/OFF to ON to turn the DVD player on. Push the OPEN switch on the unit to open the disc tray cover.
Features are available on both the DVD player and remote control unless otherwise noted. DVD Playback ENTER/ENT button PAUSE/ button STOP/ button MENU button TITLE button ZOOM button & buttons & buttons SLOW button RED button A-B button GOTO button Playback Operation When you load a disc in, the player will search the disc and play it automatically.
DVD Playback (continued) INFO button AUDIO button SUBT button ANGLE button CD Playback PAUSE/ button STOP/ ■ button buttons & & buttons GOTO button INFO button REP button AUDIO button Playback Operation Press to display or cancel the detailed information of the disc during playback. (remote only) DVD discs can contain up to 8 audio bit streams.
JPEG Playback Pre-Operation Load a JPEG in the disc tray and the player will search and play the disc automatically. The screen displays the root folder with several subdirectories/subfolders. Use the desired folder. Then press the ENTER/ENT button or PLAY/ The screen enters the subfolder with several fi...
Page 23
Playback Operation JPEG Playback (continued) Rotating Pictures While viewing a picture, use the direction buttons to rotate the picture. Press the button to rotate the current picture clockwise: Press the button to rotate the current picture counterclockwise:...
You can change the default settings of this unit to customize its performance to your own preferences. Note: Program the system while playback is stopped completely or there is no disc in the payer. To Set up your system: Press the SETUP button and the setup menu will appear on the screen. It includes VIDEO SETUP, LANGUAGE SETUP, and PREFERENCES.
Page 25
Preferences System Setup AUDIO • This item is used to set the audio output language. • Press the buttons to highlight this item. • Press the button to access. • There are several languages for you to choose. • Press the buttons to choose the desired language.
Page 26
System Setup ANGLE MARK • This item is used to set the angle mark on or off. • Press the buttons to highlight this item. • Press the button to access. • Press the buttons to select ON or OFF. •...
INSTRUCTIONS FOR ATTACHING YOUR PORTABLE DVD PLAYER CASE IN A VEHICLE Please read and follow these instructions carefully when attaching this case inside your vehicle. For easy installation, do not place the DVD player in the case until the case is attached inside the vehicle.
Page 28
To attach the DVD player case to a seat back (fi gures 1 and 2) Unzip the main compartment that holds the player; locate the set of rings tucked inside the top edge of the case (A). Locate the two straps with hooks on each end. Hook one end of each strap to the rings at the top of the case (A).
Letterbox screen This refers to a screen on which the playback picture of wide-screen DVDs appears with black bands running along the top and bottom. Pan & Scan screen This refers to a screen on which the playback picture of wide-screen DVDs is cut off at the left and right sides. Title, Chapter (DVD) DVDs are divided into some large sections (titles) and some small sections (chapters).
If you suspect there is something wrong with the DVD player, immediately turn off the power. Disconnect the power connector and check that there is no smoke or excessive heat coming from the unit. Never open or try to repair the unit yourself. There are no user serviceable parts inside. PROBLEM The player cannot play There is no sound...
