  • Page 3 WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. A card containing important ATV safety information should be attached to the owner's manual on the next page. If you cannot locate this card, or if it has been removed, please call 1-800-342- 3764 for assistance.
  • Page 4 • RANGER utility vehicles • Victory motorcycles We believe Polaris sets a standard of excellence for all utility and recre- ational vehicles manufactured in the world today. Many years of experi- ence have gone into the engineering, design, and development of your Polaris vehicle, making it the finest machine we’ve ever produced.
  • Page 5 POLARIS and POLARIS THE WAY OUT are registered trademarks of Polaris Indus- tries Inc. Copyright 2008 Polaris Sales Inc. All information contained within this publication is based on the latest product information at the time of publication. Due to constant...

  • Page 6: Table Of Contents

    Adjustments ......105 Polaris Products..... . . 109 Troubleshooting .

  • Page 7: Introduction

    INTRODUCTION The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is involved when these words and sym- bols are used. Become familiar with their meanings before reading the manual. The safety alert symbol indicates a potential personal injury hazard. WARNING A WARNING indicates a hazardous situation which, if not avoided, may result in death or serious injury.
  • Page 8 Failure to heed the warnings and safety precautions contained in this manual can result in severe injury or death. A Polaris ATV is not a toy and can be hazardous to operate. This vehicle handles differently than other vehicles, such as motorcycles and cars.

  • Page 9: Vehicle Identification Numbers

    Record your vehicle's identification numbers and key number in the spaces provided. Remove the spare key and store it in a safe place. An ignition key can be duplicated only by ordering a Polaris key blank (using your key number) and mating it with one of your existing keys.

  • Page 10: Safety

    Safety Training ATV safety training is a top priority for Polaris. When you purchased your new ATV, your dealer instructed you on the authorized ATV RiderCourse available to you and your eligible family members. This training is included in the purchase price of your ATV. Polaris strongly...

  • Page 11: Safe Riding Gear

    Boots Helmet Wearing a helmet can prevent a severe head injury. Whenever riding a Polaris vehicle, always wear a helmet that meets or exceeds established safety standards. Approved helmets in the USA and Canada bear a U.S. Department of Transportation (DOT) label.

  • Page 12: Eye Protection

    Eye Protection Do not depend on eyeglasses or sunglasses for eye protection. When- ever riding a Polaris vehicle, always wear shatterproof goggles or use a shatterproof helmet face shield. Polaris recommends wearing approved Personal Protective Equipment (PPE) bearing markings such as VESC 8, V-8, Z87.1, or CE.

  • Page 13: Safety Warnings

    SAFETY Safety Warnings WARNING Failure to operate the ATV properly can result in a collision, loss of control, accident or overturn, which may result in serious injury or death. Heed all safety warnings outlined in this section of the owner’s manual. See the OPERATION section of the owner’s manual for proper operating procedures.

  • Page 14: Handling Gasoline

    Safety Warnings Handling Gasoline Gasoline is highly flammable and explosive under certain conditions. • Always exercise extreme caution whenever handling gasoline. • Always refuel with the engine stopped, and outdoors or in a well ventilated area. • Do not smoke or allow open flames or sparks in or near the area where refu- eling is performed or where gasoline is stored.

  • Page 15: Protective Apparel

    SAFETY Safety Warnings Protective Apparel Riding in this vehicle without wearing an approved helmet and protective eyewear increases the risk of a serious injuries in the event of an accident. Operator and passenger must always wear an approved helmet that fits properly and eye protection (goggles or face shield).

  • Page 16: Operating On Pavement

    SAFETY Safety Warnings Operating on Pavement Operating an ATV on paved surfaces (including sidewalks, paths, parking lots and driveways) may adversely affect the handling of the ATV and could result in loss of control and accident or overturn. Avoid operating the ATV on pavement. ATV tires are designed for off-road use.

  • Page 17: Physical Control Of The Atv

    SAFETY Safety Warnings Physical Control of the ATV Removing a hand from the handlebars or feet from the footrests during operation can reduce your ability to control the vehicle or cause loss of balance and ejection from the ATV. If the operator's foot is not firmly planted on the footrest, it could also contact the rear wheels.

  • Page 18: Descending Hills Improperly

    Safety Warnings Descending Hills Improperly Improperly descending a hill could cause loss of control or overturn. • Always follow proper procedures for travel- ing down hills as described in the owner's manual. NOTE: A special technique is required when braking while traveling down- hill.

  • Page 19: Stalling While Climbing A Hill

    SAFETY Safety Warnings Stalling While Climbing a Hill Stalling, rolling backwards or improperly dismounting while climbing a hill could cause an overturn. • Always maintain a steady speed when climbing a hill. If all forward speed is lost: • Keep body weight uphill. •...

  • Page 20: Operating On Slippery Terrain

    SAFETY Safety Warnings Operating on Slippery Terrain Failure to use extra caution when operating on excessively rough, slippery or loose terrain could cause loss of traction, loss of control, accident or overturn. Do not operate on excessively rough, slippery or loose terrain.

  • Page 21: Improper Tire Maintenance

    SAFETY Safety Warnings Operating Improperly in Reverse Improperly operating in reverse could result in a collision with an obstacle or person. Always follow proper operating procedures as outlined in this manual. See page 55. Before shifting into reverse gear, always check for obstacles or people behind the ATV.

  • Page 22: Skidding Or Sliding

    Safety Warnings Operating Over Obstacles Improperly operating over obstacles could cause loss of control or overturn. Before operating in a new area, check for obstacles. Avoid operating over large obstacles such as rocks and fallen trees. If unavoidable, use extreme caution and always follow proper operating procedures as outlined in this manual.

  • Page 23: Improper Cargo Loading

    SAFETY Safety Warnings Improper Cargo Loading Overloading the ATV or carrying/towing cargo improperly may cause changes in handling, which could cause loss of control or an accident. • Never exceed the stated load capacity for this ATV. • Cargo should be properly distributed and securely attached. •...

  • Page 24: Operating A Damaged Atv

    SAFETY Safety Warnings Operating a Damaged ATV Operating a damaged ATV can result in an accident. After any overturn or accident, have a qualified service dealer inspect the entire machine for possible damage, including (but not limited to) brakes, throttle and steering systems. Physical Skills Safe operation of this rider-active vehicle requires good judgement and physical skills.

  • Page 25: General Warning

    If an informational or graphic label becomes illegible or comes off, con- tact your Polaris dealer to purchase a replacement. Replacement safety labels are provided by Polaris at no charge. The part number is printed on the label. General Warning...

  • Page 26: Discretionary Warning

    Safety Labels and Locations Discretionary Warning WARNING • Never operate this ATV on HILLS steeper than 25 degrees 25°. To prevent overturn on hilly terrain, use throttle and brakes gradually, and shift weight uphill. • REVERSE operation can be dangerous even at low speeds. Steering becomes difficult.
  • Page 27 SAFETY Safety Labels and Locations Age 16 Warning Rack Warning “No Passenger” Warning WARNING NEVER ride as a passenger. Passengers can cause a loss of control, resulting in SEVERE INJURY or DEATH. Tire Pressure/Load Warning WARNING Improper tire pressure or overloading can cause loss of control. Loss of control can result in severe injury or death.

  • Page 28: Age 16 Warning

    Safety Labels and Locations Age 16 Warning WARNING Operating this ATV if you are under the age of 16 increases your chance of severe injury or death. NEVER operate this ATV if you are under age 16. Rack Warning, Front and Rear WARNING •...

  • Page 29: Features And Controls

    FEATURES AND CONTROLS Switches Main Key Switch Headlight Switch Engine Mode/Reverse All Wheel Drive Stop Switch Override Switch Button Mode/Reverse Override Switch This vehicle is equipped with a reverse speed limiter system. To gain additional wheel speed while backing, release the throttle and depress the override button.

  • Page 30: Headlight Switch

    The throttle lever is spring loaded. Engine speed returns to idle when the lever is released. This ATV is equipped with Polaris Electronic Throttle Control (ETC), which is designed to reduce the risk of a frozen or stuck throttle. If the throttle cable should stick in an open position when the operator releases the throttle lever, the engine will stop, and power to the rear wheels will cease.

  • Page 31: Brake Lever

    FEATURES AND CONTROLS Brake Lever WARNING Operating the ATV with a spongy brake lever can result in loss of braking, which could cause an accident. Never operate the ATV with a spongy-feeling brake lever. Always contact your dealer for service before operating the vehicle. Squeeze the brake lever toward the handlebar to apply the front and rear brakes.

  • Page 32: Parking Brake

    Parking Brake Locking the Parking Brake 1. Place the transmission in gear. 2. Squeeze and release the brake lever two or three times, then squeeze and hold. 3. Push the parking brake lock forward to engage the lock. 4. Release the brake lever. 5.
  • Page 33 FEATURES AND CONTROLS Auxiliary Foot Brake WARNING Aggressively applying the auxiliary brake when backing down a hill may cause rear tipover, which could result in serious injury or death. Never back down a hill. Use caution when applying the auxiliary brake. Do not aggressively apply the auxiliary brake when going forward.

  • Page 34: Brake Fluid

    Always maintain brake fluid at the recommended level. Do not overfill. If the fluid level is low add DOT 4 brake fluid only. See page 109 for the part numbers of Polaris products. Under normal operation, the diaphragm extends into the reservoir as fluid level drops.
  • Page 35 FEATURES AND CONTROLS Brake Fluid Hand Brake The master cylinder is located on the left handlebar. Main- tain the fluid level 1/4" (6.3 mm) below the top edge of the master cylinder. Do not over- fill. 1. Position the vehicle on a level surface.

  • Page 36: Fuel Valve

    FEATURES AND CONTROLS Choke The choke assists in starting a cold engine. Refer to the engine starting procedure on page 43 for correct choke and throttle settings during start- ing. Fuel Tank Cap Fuel Tank Always refuel with the engine stopped, and outdoors or in a well ventilated area.
  • Page 37 FEATURES AND CONTROLS Automatic Transmission Gear Selector The transmission gear selector is located on the right side of the vehi- cle. H: High Gear N: Neutral R: Reverse To shift gears, brake to a complete stop. When the engine is idling, move the lever to the desired gear.

  • Page 38: Engaging Awd

    All Wheel Drive (AWD) System The All Wheel Drive system is controlled by the AWD switch. When the switch is on 2X4, the ATV is in two-wheel drive at all times. When the switch is on AWD, the ATV is in all wheel drive.

  • Page 39: Instrument Cluster

    FEATURES AND CONTROLS Instrument Cluster Your ATV is equipped with an instrument cluster that senses vehicle speed from the right front wheel. The instrument cluster measures distance in miles as well as hours of operation. It also includes a reverse speed limiter function that limits the ATV's speed to approximately 7-9 mph (11-14 km/h).

  • Page 40: Rider Information Center

    Instrument Cluster Rider Information Center The rider information center is located in the instrument cluster. All seg- ments will light up for 3 seconds at start-up. 1. Gear Indicator - This indicator displays gear shifter position. N = Neutral (Green) R = Reverse (Amber) 2.

  • Page 41: Operation

    Break-In Period The break-in period for your new Polaris ATV is the first ten hours of operation, or the time it takes to use the first two full tanks of gasoline. No single action on your part is as important as following the proce- dures for a proper break-in.
  • Page 42 Break-In Period Engine and Drivetrain Break-in 1. Fill the fuel tank with gasoline. See page 33. Always exercise extreme caution whenever handling gasoline. 2. Check the oil level on the dipstick. See page 65. Add oil if neces- sary to maintain the level between the safe and add marks. 3.

  • Page 43: Safe Operation Practices

    OPERATION Safe Operation Practices 1. Complete the recommended safety training before operating this vehicle. See page 7. 2. Do not allow anyone under 16 years of age to operate this vehicle. Do not allow anyone with cognitive or physical disabilities to oper- ate this vehicle.

  • Page 44: Trail Etiquette

    Respect the environment in which you ride. Find out where the designated riding areas are by con- tacting your Polaris dealer, a local riding club or local officials. Help keep our trails open for recreational vehicle use. As an off-road enthusiast, you represent the sport and can set a good example (or a poor example) for others to follow.
  • Page 45 Ensure proper operation Ensure operation Ensure proper operation Inspect, clean Drain deposits whenever visible Check operation, apply Polaris dielec- tric grease when lamp is replaced Check operation, apply Polaris dielec- tric grease when lamp is replaced Wear approved helmet, goggles, and...

  • Page 46: Starting The Engine

    Starting the Engine 1. Position the vehicle on a level surface outdoors or in a well-venti- lated area. 2. Place the transmission in neutral. 3. Lock the parking brake. Tip: The starter interlock will prevent the engine from starting if the transmission is in gear and the brake is not engaged.

  • Page 47: Cold Weather Operation

    Water in the bottom of the crankcase can lead to engine damage and must be drained. Water accu- mulation increases as outside temperature decreases. See your Polaris dealer for engine heater kits, which provide quicker warm-ups and easier starting in colder weather.

  • Page 48: Driving Procedures

    Driving Procedures 1. Wear a helmet and eye protection.See page 8. 2. Sit upright with both feet on the footrests and both hands on the handlebars. 3. Start the engine and allow it to warm up. 4. Shift the transmission into gear. 5.

  • Page 49: Turning The Vehicle

    OPERATION Turning the Vehicle Your ATV is equipped with a solid rear axle, which drives both rear wheels equally at all times. This means that the wheel on the outside of the turn must travel a greater distance than the inside wheel when turning and the inside tire must slip traction slightly.

  • Page 50: Driving On Slippery Surfaces

    Driving on Slippery Surfaces Whenever riding on slippery surfaces such as wet trails or loose gravel, or during freezing weather, follow these precautions: 1. Do not operate on excessively rough, slippery or loose terrain. 2. Slow down when entering slippery areas. 3.

  • Page 51: Driving Uphill

    OPERATION Driving Uphill Braking and handling are greatly affected when operating in hilly ter- rain. Improper procedure could cause loss of control or overturn. When- ever traveling uphill, follow these precautions: 1. Drive straight uphill. 2. Avoid steep hills (25° maximum). 3.
  • Page 52 OPERATION Driving on a Sidehill (Sidehilling) Driving on a sidehill is not recommended. Improper procedure could cause loss of control or overturn. Avoid crossing the side of any hill unless absolutely necessary. If crossing a sidehill is unavoidable, follow these precautions: 1.

  • Page 53: Driving Downhill

    OPERATION Driving Downhill When driving downhill, follow these precautions: 1. Avoid steep hills (25° maximum). 2. Shift body weight uphill. 3. Drive straight downhill. 4. Slow down. Excessive speed when traveling downhill can cause loss of control. 5. Squeeze the brake lever gradually. Applying the brakes too firmly may cause the rear wheels to lock, which could result in loss of con- trol.

  • Page 54: Parking On An Incline

    OPERATION Parking on an Incline Avoid parking on an incline if possible. If it's unavoidable, follow these precautions: 1. Stop the engine. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Always block the rear wheels on the downhill side. 5.
  • Page 55 OPERATION Turning Around on a Hill (K-Turn) If the vehicle stalls while climbing a hill, never back it down the hill! Use the K-turn to turn around. 8 ft. (2.4 m) 1. Stop and lock the parking brake while keeping body weight uphill. 2.

  • Page 56: Driving Through Water

    Driving Through Water Your ATV can operate through water with a maxi- mum recommended depth equal to the bottom of the footrests. Follow these pro- cedures when operating through water: 1. Determine water depths and current before entering water. 2. Choose a crossing where both banks have gradual inclines.

  • Page 57: Driving Over Obstacles

    OPERATION Driving Over Obstacles Follow these precautions when operating over obstacles: 1. Always check for obstacles before operating in a new area. 2. Look ahead and learn to read the terrain. Be constantly alert for haz- ards such as logs, rocks and low hanging branches. 3.

  • Page 58: Driving In Reverse

    Driving in Reverse Follow these precautions when operating in reverse: 1. Always check for obstacles or people behind the vehicle. 2. Always avoid backing downhill. 3. Back slowly. 4. Apply the brakes lightly for stopping. 5. Avoid turning at sharp angles. 6.

  • Page 59: Hauling Cargo

    OPERATION Hauling Cargo WARNING Overloading the vehicle or carrying or towing cargo improperly can alter vehicle handling and may cause loss of control or brake instability, which can result in serious injury or death. Always follow these precautions when hauling cargo: REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING WHEN HAULING CARGO.

  • Page 60: Towing Loads

    ATV warranty. Never install a hitch longer than 4" (10 cm). Never install automotive accessories on your Polaris ATV. Always install Polaris-approved (or equivalent) accessories designed for ATV use. OPERATION Maximum 4"...

  • Page 61: Emission Control Systems

    CFR 205) and local noise level requirements. Operation on Public Lands in the U.S.A. Your Polaris vehicle has a spark arrestor that was tested and qualified to be in accordance with the USDA Forest Service Standard 5100-1C. Fed- eral law requires that this spark arrestor be installed and functional when the vehicle is operated on public lands.

  • Page 62: Maintenance

    Inspect, clean, lubricate, adjust and replace parts as necessary. When inspection reveals the need for replacement parts, use genuine Polaris parts available from your Polaris dealer. Record maintenance and service in the Maintenance Log beginning on page 122.

  • Page 63: Periodic Maintenance Chart

    Improperly performing the procedures marked with a component failure and cause an accident, which may result in serious injury or death. Always have an authorized Polaris dealer perform these services. Maintenance Chart Key Perform these operations more often for vehicles subjected to severe use.
  • Page 64 Periodic Maintenance Chart Item Hours Calendar Air filter, main element Brake pad wear Battery Front gearcase oil (if equipped) Transmission oil Engine breather filter (if equipped) General lubrication Carburetor float bowl Throttle Cable/ ETC Switch Choke cable E Carburetor air intake ducts/flange Drive belt Cooling system...
  • Page 65 Spark arrestor Idle speed Toe adjustment Headlight aim Perform these procedures more often for vehicles subjected to severe use. E Emission-Related Service Have an authorized Polaris dealer perform these services. Maintenance Interval (whichever comes first) Miles (Km) 100 H 12 M 1000 (1600) Inspect;...

  • Page 66: Lubrication Guide

    Control Arm (front and rear) Bearing Carrier Transmission (upper pivot point) Front Prop Shaft Yoke Lube PS-4 PLUS Performance Synthetic 2W-50 DOT 4 Only Polaris AGL Synthetic Gearcase Lube Premium Demand Drive Hub Fluid Polaris Premium U-Joint Lube Bearing Carrier MAINTENANCE Method See page 64.

  • Page 67: Engine Oil

    Polaris recommends the use of Polaris PS-4 PLUS Performance Syn- thetic 2W-50 4-cycle oil or a similar oil for this engine. Oil may need to be changed more frequently if Polaris oil is not used. Always use 2W-50 oil. Follow the manufacturer's recommendations for ambient tempera- ture operation.

  • Page 68: Oil Level

    Engine Oil Oil Level The oil dipstick is located behind the left front tire. 1. Position the vehicle on a level surface. 2. Place the transmission in neutral. 3. Lock the parking brake. 4. Clean away all dirt and debris on the oil tank or in the wheel well area.

  • Page 69: Oil And Filter Change

    MAINTENANCE Oil and Filter Change Always change the oil and filter at the intervals outlined in the Periodic Maintenance Chart beginning on page 59. To change the oil properly, always drain the oil tank and change the oil filter. If oil contamination (water, mud, metal shavings) is suspected in the engine sump, the sump should also be drained.
  • Page 70 Oil and Filter Change 11. Place towels under the oil filter. Using an oil filter wrench, turn the filter counterclockwise to remove it. 12. Clean the filter sealing area on the engine. 13. Lubricate the filter o-ring. Check to make sure the o-ring is in good condition.

  • Page 71: Transmission Oil

    Periodic Maintenance Chart beginning on page 59. Maintain the oil level at the bottom of the fill plug hole. See page 109 for the part numbers of Polaris products. The fill plug is located on the left side of the ATV, under the rear fender, behind the wheel.
  • Page 72 Transmission Oil Oil Check 1. Position the vehicle on a level surface. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Remove the fill plug. Use a 15 mm wrench. 5. Check the oil level. 6. Add oil as needed. Do not overfill.

  • Page 73: Oil Change

    MAINTENANCE Transmission Oil Oil Change 1. Position the vehicle on a level surface. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Remove the fill plug. Use a 15 mm wrench. 5. Place a drain pan under the gearcase.
  • Page 74 Periodic Maintenance Chart beginning on page 59. We recommend the use of Polaris Premium Demand Drive Hub Fluid. Use of other oils may result in improper operation of compo- nents. See page 109 for the part numbers of Polaris products.
  • Page 75 MAINTENANCE Front Gearcase (Demand Drive) Fluid Fluid Check 1. Position the vehicle on a level surface. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Remove the fill plug. Use an 8 mm Allen wrench. 5. Check the oil level. 6.
  • Page 76 Front Gearcase (Demand Drive) Fluid Fluid Change 1. Position the vehicle on a level surface. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Remove the fill plug. Use an 8 mm Allen wrench. 5. Place a drain pan under the gearcase.

  • Page 77: Cooling System

    Polaris recommends the use of Polaris Premium 60/40 anti-freeze/cool- ant or a 50/50 mixture of high quality aluminum compatible anti-freeze/ coolant and distilled water. Polaris Premium 60/40 is already premixed and ready to use. Do not dilute with water. See page 109 for the part numbers of Polaris products.

  • Page 78: Radiator Coolant

    Radiator Coolant To ensure that the coolant maintains its ability to protect the engine, Polaris recommends that you drain the system completely every two years and add a fresh mixture of antifreeze and water. Replace the coolant any time the cooling system has been drained for maintenance or repair.

  • Page 79: Brake Inspections

    MAINTENANCE Brakes The front and rear brakes are hydraulic disc brakes, activated by moving the single brake lever toward the handlebar. The auxiliary foot brake is also hydraulic. Both brake systems are self-adjusting. Brake Inspections The following checks are recommended to keep the brake system in good operating condition.

  • Page 80: Toe Alignment

    1/8" to 1/4" (3-6 mm) toe out alignment. 5. Repeat the measurement procedure on the other side of the vehicle. 6. If you discover improper alignment, see your Polaris dealer for ser- vice. MAINTENANCE...

  • Page 81: Side Panel Removal

    MAINTENANCE Steering Assembly The steering assembly of the ATV should be checked periodically for loose nuts and bolts. If loose nuts and bolts are found, see your Polaris dealer for service before operating the vehicle. Side Panel Removal 1. Remove the seat.

  • Page 82: Tire Tread Depth

    Always replace tires when tread depth is worn to 1/8" (3 mm) or less. Front Wheel Hub Tightening Front wheel bearing tightness and spindle nut retention are critical com- ponent operations. All service must be performed by your authorized Polaris dealer.

  • Page 83: Wheel Removal

    4. Loosen the wheel nuts slightly. WARNING! Do not service axle nuts that have a cotter pin installed. See your Polaris dealer. 5. Place a suitable stand under the footrest frame to raise the wheel slightly off the ground. 6. Remove the wheel nuts.

  • Page 84: Wheel Installation

    Tires Wheel Installation 1. Place the wheel on the wheel hub with the valve stem toward the outside and the rotation arrows on the tire pointing toward forward rotation. 2. Install the wheel nuts finger tight. 3. Lower the vehicle to the ground. 4.

  • Page 85: Air Filter

    MAINTENANCE Air Filter 1. Position the vehicle on a level surface. Place the transmission in gear. 2. Lock the parking brake. 3. Remove the seat. 4. Release the air box cover clips, and remove the air box cover. 5. Loosen the clamp and remove the filter.
  • Page 86 Breather Filter/Hose 1. Remove the left side panel. See page 78. 2. Remove the hose clamps from the filter and pull the filter out of the hoses. Inspect the filter for debris. Blow gently through the filter in the direction of the arrow to check for clogging. Replace a damaged or clogged filter.

  • Page 87: Headlight Beam Adjustment

    MAINTENANCE Lights Headlight Beam Adjustment The headlight beam can be adjusted slightly upward or downward. Use the following procedure to make the adjustment. 1. Position the vehicle on a level surface with the headlight approxi- mately 25 ft. (7.6 m) from a wall. 2.

  • Page 88: Headlamp Replacement

    Lights Poor lighting can result in reduced visibility when driving. Headlight and taillight lenses become dirty during normal operation. Clean lights frequently and replace burned out lamps promptly. Always make sure lights are adjusted properly for best visibility. Headlamp Replacement When servicing a halogen lamp, don't touch the lamp with bare fingers.

  • Page 89: Spark Plugs

    Refer to the specifications section beginning on page 114 for the recom- mended spark plug type and gap for your vehicle. Torque spark plugs to specification. NOTICE: Using non-recommended spark plugs can result in serious engine damage. Always use Polaris-recommended spark plugs. Plug Condition New Spark Plug Previously Installed Spark Plug Spark Plug Inspection Spark plug condition is indicative of engine operation.

  • Page 90: Spark Plug Condition

    MAINTENANCE Spark Plugs Spark Plug Condition Normal Spark Plug The normal insulator tip is gray, tan or light brown. There will be few combustion deposits. The electrodes are not burned or eroded. This indi- cates the proper type and heat range for the engine and the service. The tip should not be flaky and white.

  • Page 91: Vehicle Immersion

    MAINTENANCE Vehicle Immersion If your vehicle becomes immersed, major engine damage can result if the machine is not thoroughly inspected. Take the vehicle to your dealer before starting the engine. If it's impossible to take your ATV to a dealer before starting it, follow the steps outlined below.

  • Page 92: Spark Arrestor

    Spark Arrestor WARNING Failure to heed the following warnings while servicing the spark arrestor could result in serious injury or death. Never run the engine in an enclosed area. Remove any combustible materials from the area. Wear eye protection and leather work gloves.

  • Page 93: Pvt System

    • Always follow all recommended maintenance procedures. See your dealer as outlined in the owner's manual. • This PVT system is intended for use on Polaris products only. Do not install it in any other product. • Always make sure the PVT housing is securely in place during operation.

  • Page 94: Pvt Drying

    PVT System PVT Drying There may be some instances when water is accidently ingested into the PVT system. Use the following instructions to dry it out before operating. 1. Move the vehicle out of the water. 2. Remove the PVT drain plug. Use a 17 mm wrench, a flat screw- driver, or the spark plug wrench.
  • Page 95 MAINTENANCE Battery WARNING Improperly connecting or disconnecting battery cables can result in an explosion and cause serious injury or death. When removing the battery, always disconnect the negative (black) cable first. When reinstalling the battery, always connect the negative (black) cable last. WARNING Battery electrolyte is poisonous.

  • Page 96: Battery Removal

    Battery Battery Removal 1. Place the transmission in gear. 2. Lock the parking brake. 3. Remove the splash shield behind the right front tire. 4. Remove the left side panel to access the battery hold- down bracket. Remove the screw at the bottom rear of the bracket and move the bracket aside.

  • Page 97: Battery Installation

    MAINTENANCE Battery Battery Installation Using a new battery that has not been fully charged can damage the bat- tery and result in a shorter life. It can also hinder vehicle performance. Follow the battery charging instructions on page 96 before installing the battery.

  • Page 98: Battery Storage

    Check battery voltage each month during storage and recharge as needed to maintain a full charge. Polaris recommends maintaining battery charge by using a Polaris Bat- tery Tender charger or by charging about once a month to make up for normal self-discharge.
  • Page 99 MAINTENANCE Battery Battery Charging (Conventional Battery) 1. Remove the battery from the vehicle to prevent damage from leak- ing or spilled electrolyte during charging. See page 93. 2. Charge the battery with a charging output no larger than 1/10 of the battery’s amp/hr rating.
  • Page 100 Battery Battery Charging (Sealed Battery) For a refresh charge, follow all instructions carefully. 1. Measure battery voltage at the starting solenoid (near the radiator cap) under the front storage cover. Check the battery voltage with a voltmeter or multimeter. 2. To recharge, carefully attach the RED charger clamp to the red cable on the solenoid.

  • Page 101: Cleaning And Storage

    Do not allow these types of products to contact the vehicle. The best and safest way to clean your Polaris vehicle is with a garden hose and a pail of mild soap and water. 1. Use a professional-type washing cloth, cleaning the upper body first and the lower parts last.

  • Page 102: Washing The Vehicle

    Polishing the Vehicle Polaris recommends the use of common household aerosol furniture polish for polishing the finish on your Polaris vehicle. Follow the instructions on the container. Polishing Tips • Avoid the use of automotive products, some of which can scratch the finish of your vehicle.
  • Page 103 MAINTENANCE Cleaning and Storage Chrome Wheel Care (if equipped) Proper maintenance will protect chrome wheels from corrosion, pre- serve wheel life and ensure a "like new" appearance for many years. Chrome wheels exposed to road salt (or salt in the air in coastal areas) are more susceptible to corrosion if not properly cleaned.

  • Page 104: Storage Tips

    98. Stabilize the Fuel 1. Fill the fuel tank. 2. Add Polaris Carbon Clean Fuel Treatment or Polaris Fuel Stabilizer. Follow the instructions on the container for the recommended amount. Carbon Clean removes water from fuel systems, stabilizes fuel and removes carbon deposits from pistons, rings, valves and exhaust systems.
  • Page 105 7. If Polaris fuel system additive is not used, the fuel tank, fuel lines, and carburetor should be completely drained of gasoline.
  • Page 106 Set the tire pressure and safely support the ATV with the tires slightly off the ground. Be sure the storage area is well ventilated. Cover the vehicle with a genuine Polaris cover. Do not use plastic or coated mate- rials. They do not allow enough ventilation to prevent condensation, and may promote corrosion and oxidation.

  • Page 107: Transporting The Vehicle

    MAINTENANCE Transporting the Vehicle Follow these procedures when transporting the vehicle. 1. Stop the engine. 2. Place the transmission in gear. 3. Lock the parking brake. 4. Turn the fuel valve off. 5. Secure the fuel cap, oil cap and seat. 6.

  • Page 108: Adjustments

    Spring Adjustments The front and rear shock absorber springs are adjustable. Rotate the adjuster either clockwise or counterclockwise to increase or decrease spring tension. Always adjust both sides equally. Accessory springs are available through your Polaris dealer. Rear Adjuster Front...
  • Page 109 Follow the adjustment procedures exactly, or see your Polaris dealer for service. 1. Loosen the four handlebar bolts.
  • Page 110 Carburetor Your Polaris ATV is calibrated at the factory for optimal performance at altitudes ranging from zero to 6,000 feet (1800 m) and temperatures of +40 degrees F. (4 degrees C.) or higher. Above 6000 feet (1800 m) the engine air/fuel mixture becomes overly rich and the engine loses approximately 3% of its power for each 1000-foot (304.8 m) increase in...

  • Page 111: Throttle Cable Freeplay

    ADJUSTMENTS Throttle Cable Freeplay Adjust throttle cable freeplay at the handlebar. 1. Locate the throttle cable adjuster at the handlebar. 2. Squeeze the end of the rub- ber boot and slide it far enough to expose the end of the inline cable adjuster. 3.

  • Page 112: Polaris Products

    Chain Lube, Aerosol (16 oz.) 2871326 Carbon Clean Plus (12 oz.) 2870652 Fuel Stabilizer (16 oz.) 2872189 DOT4 Brake Fluid (12 oz.) 2871956 Loctite 2859044 Polaris Battery Tender POLARIS PRODUCTS Engine Lubricant Coolant Additives / Miscellaneous 565 Thread Sealant Charger...

  • Page 113: Troubleshooting

    Dry out the PVT. See page 91. Inspect clutch seals for damage if repeated leaking occurs. See your Polaris dealer. Check for fouled plugs or foreign material in gas tank or fuel lines. See your dealer.
  • Page 114 Replace with fresh recommended fuel Inspect plugs and replace if necessary Inspect plugs, verify stop switch is on Inspect, clean and/or replace spark plugs Immediately see your Polaris dealer Recharge the battery to 12.8 VDC See your dealer Solution Inspect, clean and/or replace spark...
  • Page 115 TROUBLESHOOTING Engine Pings or Knocks Possible Cause Poor quality or low octane fuel Incorrect ignition timing Incorrect spark plug gap or heat range Idle set too low Engine Runs Irregularly, Stalls or Misfires Possible Cause Fouled or defective spark plug(s) Worn or defective spark plug wires Incorrect spark plug gap or heat range Loose ignition connections...

  • Page 116: Engine Overheating

    Engine Stops or Loses Power Possible Cause Out of fuel Kinked or plugged fuel vent line Water is present in fuel Overuse of choke Fouled or defective spark plug(s) Worn or defective spark plug wires Incorrect spark plug gap or heat range Loose ignition connections Low battery voltage Incorrect fuel...

  • Page 117: Specifications

    SPECIFICATIONS Maximum Weight Capacity Dry Weight Fuel Capacity Engine Oil Capacity Coolant Capacity Transmission Oil Demand Drive Fluid Front Rack Capacity Rear Rack Capacity Hitch Tongue Weight Capacity Hitch Towing Rating Unbraked Trailer Towing Capacity* Overall Length Overall Width Overall Height Wheelbase Ground Clearance Minimum Turning Radius...

  • Page 118: Jetting Chart

    Altitude Meters (Feet) 0-1500 (0-5000) 1500-3000 (5000-10000) 3000+ (10000+) Sportsman 400 HO 4X4 Automatic PVT (Polaris Variable Transmission) Side Lever (H/N/R) 3.6:1 15.18:1 Front 24x8-12 / 5 psi (34.5 KPa) Rear 24x11-12 / 5 psi (34.5 KPa) MacPherson strut with 7" (18 cm) travel Progressive rate with 8"...

  • Page 119: Warranty

    WARRANTY LIMITED WARRANTY Polaris Sales Inc., 2100 Highway 55, Medina, MN 55340, gives a SIX MONTH LIM- ITED WARRANTY on all components of the Polaris All Terrain Vehicle (ATV) against defects in material or workmanship. Polaris also gives a one year limited warranty on the final drive chain for failure due to defects.
  • Page 120 WARRANTY COVERAGE AND EXCLUSIONS: LIMITATIONS OF WARRANTIES AND REMEDIES The Polaris limited warranty excludes any failures that are not caused by a defect in material or workmanship. This warranty does not cover accidental damage, normal wear and tear, abuse or improper handling. This warranty also does not cover any ATV that...
  • Page 121 HOW TO OBTAIN WARRANTY SERVICE If your ATV requires warranty service, you must take it to a Polaris dealer authorized to repair Polaris ATVs. When requesting warranty service you must present your copy of the Warranty Registration form to the dealer.
  • Page 122 How to Get Service In the Country where your vehicle was purchased: Warranty or Service Bulletin repairs must be done by an authorized Polaris dealer. If you move or are traveling within the country where your vehicle was purchased, Warranty or Service Bulletin repairs may be requested from any authorized Polaris dealer who sells the same line as your vehicle.
  • Page 123 Exported Vehicles How to Get Service If Purchased From A Private Party: If you purchase a Polaris product from a private citizen outside of the country in which the vehicle was originally purchased, all warranty coverage will be denied. Notice...
  • Page 124 Polaris standard limited warranty for this vehicle. Polaris warrants that this vehicle is; (1) designed, built, and equipped to conform at the time of initial sale with the requirements of 40 CFR 1051 and, (2) free from defects in materials and workmanship that may keep it from meeting these requirements.

  • Page 125: Maintenance Log

    MAINTENANCE LOG Present this section of your manual to your dealer each time your vehicle is serviced. This will provide you and future owners with an accurate log of maintenance and ser- vices performed. DATE MILES (KM) TECHNICIAN SERVICE PERFORMED / COMMENTS OR HOURS...
  • Page 126 MAINTENANCE LOG DATE MILES (KM) TECHNICIAN SERVICE PERFORMED / COMMENTS OR HOURS...

This manual is also suitable for:

2009 sportsman 400

Table of Contents
