Polaris Scrambler 400 4X4 Owner's Manual Supplement

OWNER'S MANUAL SUPPLEMENT
2002 SCRAMBLER 400 4X4
PN 9917466
IMPORTANT: This is a supplement to your owner's manual. This information should remain with your owner's manual at all
times.
Capacities
Body Style
Gross Vehicle Weight
Fuel Capacity
Gearcase Oil
Engine Oil Capacity
Front Rack (Maximum -
Capacity)
Rear Rack
Tongue Weight
Tow Hitch
Tow Capacity
Turn Radius
Ground Clearance
Height
Length
Seat Height
Dry Weight
Wheel Base
Width
Drive System
Drive System Type
Shift Type
Gear Reduction - Low
Gear Reduction - Reverse
Gear Reduction - Foward
Front Drive (ratio)
Final Drive (ratio)
Center Drive (ratio)
Drive Chain
Front Tire
Rear Tire
Tire Pressure (front)
Tire Pressure (rear)
IMPORTANT: After the first tank of pre-mixed fuel has been used please verify that the oil level in the oil tank
has dropped, indicating that the oil pump is functioning properly. If the level has not dropped, see your dealer
for oil pump bleeding and repeat the pre-mix procedure.
Gen III
845
4 U.S. Gallons
32 Ounces
2 Quarts
Accessory (30 Lbs.)
Accessory (60 Lbs.)
30 Lbs.
Accessory
850 Lbs.
60 inches
5.5 inches
47 inches
74.5 inches
34 inches
532 Lbs.
48.5 inches
45.5 inches
PVT
Side Lever (F-N-R)
Not Applicable
4.36 / 1
2.82 / 1
2:1
13/36 76P
Not Applicable
520 O-ring
23 x 7 - 10
22 x 11 - 10
4 PSI
3 PSI
1
Suspension and Brakes
Front Susp. - Mac Strut
Rear Susp. - Progressive
Rate Swing Arm
Shock Adjustment
Front Brake
Rear Brake
Auxiliary Brake
Park Brake
Engine & Cooling
Engine Model Number
Engine Type
Lubrication
Bore x Stroke
Displacement
Compression Ratio
Engine Cooling
Alternator Output (watts)
Carburetion
Main Jet
Pilot Jet
Needle Jet
Air Screw
Jet Needle
Ignition
Timing
Spark Plug Gap
Spark Plug Type
Exhaust
8.2 inches
10.5 inches
Thread Adjust
Fixed disc, hydraulic
floating caliper
Hydraulic, opposed
piston caliper, rear axle
fixed disc
Hydraulic, opposed pis-
ton caliper, rear axle,
fixed disc
Hydraulic lock all wheel
EC38PLE-09
2 cycle, single cylinder
Oil Injection
83 x 70
378
6.9:1 Effective
Liquid
150
VM34SS
240
25
(0-6) 480
1.25
6CEY6-4
CDI
23.5 @ 5000 2
.028 inches / .7 mm
NGK BR8ES
USFS Approved
