POLARIS FREEDOM
CAB INSTALLATION INSTRUCTIONS
FOR THE POLARIS RANGER (p/n 2876196-067)
IMPORTANT: THIS ACCESSORY WEIGHS 340 POUNDS.
PLEASE ADJUST THE VEHICLE PAYLOAD ACCORDINGLY.
The contents of this manual are the property of the owner.
Be sure to leave with the owner when installation is complete.
Standard item with purchase of cab: one driver's side wiper.
Optional accessories available: passenger's side wiper, work lights, and strobe light.
Multiple U.S. and Foreign Patents Pending
Rev. K, p. 1 of 11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Curtis Cab
- Page 1 The contents of this manual are the property of the owner. Be sure to leave with the owner when installation is complete. Standard item with purchase of cab: one driver’s side wiper. Optional accessories available: passenger’s side wiper, work lights, and strobe light.
-
Page 2: General Information
DESIGN CONCEPT Curtis Cabs feature an assembly of parts designed for your vehicle which require adjustment and alignment of components to accommodate vehicle variations and provide proper weather protection. For accurate installation, proper operation, and years of satisfaction, please read and understand the installation instructions. - Page 3 Rev. K, p. 3 of 11 WARNING! Gasoline—Flammable! Explosive! Do not operate gasoline vehicle in an enclosed area with- out proper ventilation. The engine produces carbon monoxide, which is an odorless, deadly poison. This vehicle and enclosure will not provide protection from rollover, flying objects, lightening, or other hazards.
- Page 4 VEHICLE PREP. 1.1 Using a T27 Torx bit, remove three (3) original equipment screws on each side of the vehicle floorboard as shown in fig. 1.1. Save these six (6) bolts for re- installation in step 3.3. Note: these are self-tapping screws that were factory installed.
- Page 5 WARNING: do not travel with windshield in full open position. 5.2 Install the supplied nut covers (qty.: 4) on the lock- nuts inside the cab (front windshield hinge bolts). Ref.: hip restraint tube Ref. bent tab without hole slides into receiving slot Fig.
- Page 6 REAR WINDOW IMPORTANT INSTALLATION NOTICE! To facilitate the rear panel installation to the cab, it is recommended to lubricate the perimeter rubber seal of the rear panel with a silicone or Armor All protec- tant/lubricant (or similar) non-flammable lubricant.
- Page 7 ROOF & CONSOLE ASS’Y. (cont.) A driver’s side wiper is provided. Place the driver’s side wiper wire below the front tubular frame as shown in fig. 8.3. If installing an optional passenger’s side wiper, place that wire below the front tubular frame as well.
- Page 8 10.3 Install wiper per instructions included in the wiper kit. One wiper is included with the cab. A second wiper is available as an additional option. Caution: If install- ing a second wiper, double check that both wipers have a maximum 85 degree sweep to avoid interference.
- Page 9 4) Remove grease and oil with mineral spirits and a COTTON cloth or chamois. WARNING: do not travel with windshield in full open position. It is recommended that with a cab installed, the vehicle should be trailered facing backwards. Curtis Customer Service Hotline: 1-800-343-7676 (ext. 1)
