Infrared Dynamics Sunpak S25 Installation, Operation And Maintenance Instructions

Outdoor gas infrared patio heater
Hide thumbs Also See for Sunpak S25:

Advertisement

Quick Links

Download this manual See also: Installation, Operation & Maintenance Manual
Installer: Please take the time to read and understand these instructions prior to installation. Installer
must provide a copy of this manual to the owner.
Owner: Keep this manual in a safe place in order to provide your service technician with the
necessary information.
Warning:
These instructions are intended for qualified personnel, specifically trained and experienced in the
installation and repair of this type of equipment and related system components.
IF NOT INSTALLED, OPERATED AND MAINTAINED IN ACCORDANCE WITH THE
MANUFACTURER'S INSTRUCTIONS, THIS PRODUCT COULD EXPOSE YOU TO
SUBSTANCES IN THE FUEL OR FROM COMBUSTION INCLUDING CARBON
MONOXIDE WHICH CAN CAUSE DEATH OR SERIOUS ILLNESS AND WHICH
ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH
DEFECTS OR REPRODUCTIVE HARM.
For more information go to www.P65WARNINGS.CA.GOV
Infrared Dynamics, Inc © Copyright 2017
Printed in USA
Installation, Operation and & Maintenance Instructions
WARNING: California Proposition 65
Infrared Dynamics, Inc
3830 Prospect Avenue
Yorba Linda, CA 92886
Sunpak Models S25 & S34
Outdoor Gas Infrared Patio Heater
NOT FOR USE IN RESIDENTIAL DWELLINGS
Form No 62047 – 8/17
