Pogo Radio YourWay PRY900M2 User Manual

Am/fm radio recorder/voice recorder/mp3 player
Hide thumbs Also See for Radio YourWay PRY900M2:
Table of Contents

Advertisement

Quick Links

Download this manual
AM/FM Radio Recorder/Voice Recorder/MP3 Player
MODEL: PRY900M2
Thank you for purchasing RADIO YourWay
information in this User manual carefully prior to using RADIO
YourWay
TM
and keep this guide handy for future reference.
User's Manual
TM
. Please read all the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Radio YourWay PRY900M2 and is the answer not in the manual?

Questions and answers

Related Manuals for Pogo Radio YourWay PRY900M2

Summary of Contents for Pogo Radio YourWay PRY900M2

  • Page 1 AM/FM Radio Recorder/Voice Recorder/MP3 Player MODEL: PRY900M2 Thank you for purchasing RADIO YourWay information in this User manual carefully prior to using RADIO YourWay and keep this guide handy for future reference. User’s Manual . Please read all the...
  • Page 2 www.pogoproducts.com...
  • Page 3 All rights regarding the information in this manual are reserved for PoGo! Products, Inc., No part of this manual may be copied or distributed or commercially used without the prior written permission from PoGo! Products, Inc., and any violation of that may result in severe legal penalties.

  • Page 4: Table Of Contents

    Table of Contents 1. RADIO YourWay Series 1) Precautions 2) Player Functions 3) Components and LCD Display 4) Battery Use and Description of Components 5) Basic Functions 6) VOICE/AM/FM/MP3 Buttons 7) Timer and Recording 8) External Memory 9) Play Modes 10) Erasing Files 11) Reserved Recording 12) Line In...

  • Page 5: Radio Yourway

    Radio YourWay 1) Precautions Do not drop RADIO YourWay , it may cause a malfunction. Do not leave RADIO YourWay in the following areas: - Place of high temperature (above 60 ) - Exposed to direct sunlight or near heating appliances. - Inside a car;...

  • Page 6: Player Functions

    Radio YourWay Series 2) Player Functions RADIO YourWay is manufactured under strict quality control procedures to ensure the best performance and customer experience. Elegant Design and Exterior Finishing AM/FM/Voice Recording and MP3 WMA PLAYER RADIO YourWay can record AM/FM/Voice and play MP3 WMA PLAYER files.
  • Page 7 Radio YourWay Automatic power OFF after 3 minutes of no use.(SLEEP MODE) MONITOR Function allows the user to listen to what is being recorded using an earphone (MONITOR) H/D Function may be used as a portable hard disk (32MB) Volume adjustable 30 levels EQ equalizer modes (NORMAL,ROCK,LIVE,CLASSIC,POP) Repeat (NORMAL/SECTION REPEAT/1 TRACK/ALL TRACK) Download and playback of MP3 Files...

  • Page 8: Components And Lcd Display

    Radio YourWay Series 3) Components and LCD Display...

  • Page 9: Battery Use And Description Of Components

    Radio YourWay 4) Battery Use and Description of Components Open the Battery Cover. Close the cover after inserting two AAA batteries corresponding to the correct ( ) ( ) polarities. Battery: (SIZE "AAA" or UM 4) Check the battery strength by pressing the PLAY/STOP or record mode button.
  • Page 10 Radio YourWay Series Battery Life Recording Battery Type Excepting Radio (Volume: Middle) Alkaline "AAA" LR-03 Approx 10hr Battery Life may be different from above mentioned time according to the battery & operating conditions. Caution when Using the Battery Do not use different types of batteries together. If you do not use this recorder &...

  • Page 11: Basic Functions

    Radio YourWay 5) Basic Functions Turning the Power ON/OFF To turn the player on, hold the PLAY button for 1-3 seconds. If no key is pressed for more than 3 minutes, the power is automatically shut OFF. To turn the player off, hold the STOP button for 1-3 seconds If you put in the provided batteries after purchasing RADIO YourWay, the Power should turn ON and the initial display screen appears When the power is OFF, you may turn the power ON by pressing...

  • Page 12: Voice/Am/Fm/Mp3 Buttons

    Radio YourWay Series 6) VOICE/AM/FM/MP3 Buttons VOICE MODE (VOICE) Upon operating the keys, means a short press and pressing and holding (longer than 1 sec). Buttons Stopped Upon Recording Operations Plays the beginning of a file Moves to the next file Moves to the previous file S-FORWARD current file very fast S-REWIND current file very fast...
  • Page 13 Radio YourWay AM/FM Radio MODE (RADIO/KEY Operation) Receiving Buttons Key Operations PRESET the station Checks TIME and reserved settings TIMER Sets and modifies TIME VOL+ VOLUME + VOLUME - HOLD ON/OFF Note The earphone plays the role of the antenna in the FM Radio. If the earphone wire is longer, receiving sensitivity is improved.

  • Page 14: Timer And Recording

    Radio YourWay Series 7) Timer and recording You need to set the current date and time prior to initiating a recording. Press and hold the TIMER Button while the player is stopped. When you hold the TIMER Button, the day will be flickering and then if you press you can change the day.
  • Page 15 Radio YourWay Note Perform a test recording to avoid any errors while recording. If the battery is completely run down during a recording, the message "low batteries (BAT)" will display on the screen and the power will be automatically shut OFF. Replace the batteries with new set.

  • Page 16: External Memory

    Radio YourWay Series 8) External Memory Inlet If you press the A-B Button in the stop status after inserting an external memory card, the display screen of INT/CARD will be converted and the internal and external memory mode will be separated. You may record, play, save from the PC and transfer files with the external memory.

  • Page 17: Play Modes

    Radio YourWay 9) Playback mode Playing a VOICE file Select the message you want to listen to. (Select the file you want 01-99 using You may play by pressing the PLAY ( ) Button. Adjust the volume with the DIGITAL VOLUME button.
  • Page 18 Radio YourWay Series of about 10 seconds per second. Used to fast-forward or rewind a specific section. If you press the Button when the player is stopped, (showing the file number) S-REWIND/S-FORWARD is initiated at a faster speed of about 1 minute per second. Pressing REWIND from the end of the file (Exp a 1 hour file will rewind from 1:00:00 59:00:00 etc).
  • Page 19 Radio YourWay Repeat a Section A B If you want to repeat playing a specific section, press the A-B button to select the beginning of that section and then press A-B again to select the end of that section. The selected section will continue repeating until you push A-B or PLAY.

  • Page 20: Erasing Files

    Radio YourWay Series 10) Erasing files Deleting is only available when the player is stopped. Deleting a Message One by One Select the file to delete using the If you press ERASE, "ERASE" will be flickering on the LCD and the message to be deleted is displayed for confirmation.

  • Page 21: Reserved Recording

    Radio YourWay 11) Reserved Recording To set a reserved (future) recording, the TIME Setting must be set. If you press the TIMER Button, the time (Hour/Minute/Day) displays. If the time setting is done, the correct Day/Hour/Minute/Second will appear on thedisplay screen. To change it: 1.
  • Page 22 Radio YourWay Series After the minutes are set, the start time will flicker but you will be setting the ending time now. Set the hour by using before) to select the desired hour (do the same for minutes). When you finish, you will see the main screen and your unit is ready to record on the selected day(s) &...

  • Page 23: Line In

    Radio YourWay 12) Line in Connecting an External Microphone - Plug a pre-amplified microphone in the line in terminal of the body. When an external microphone is connected to the line in, the built-in microphone is not operational. Connecting to External Devices You may record from almost any device using the line in and audio cable.

  • Page 24: Am/Fm Radio

    Radio YourWay Series 13) AM/FM Radio When listening to the FM Radio, use earphones. They act as the antenna. You can also plug an antenna in the headphone jack of the player and use the speaker. It is very convenient for you to listen to a broadcast using the AUTO SEEK Function.
  • Page 25 Radio YourWay AM/FM Reserved Recording Make sure you are in tuned to the desired AM/FM station prior to setting a reserved (future) recording. Press the TIMER Button twice and the reserved recording screen appears. The minute needle clock indicator and setting channel should be flickering. Press to select the file number and then push PLAY.

  • Page 26: Ryw(Radio Your Way)-Explorer

    RYW Explorer 1) RYW-Explorer RYW-Explorer is a management program for uploading and downloading files to RADIO YourWay You can (Download/Upload) MP3, RVF and other data files The Function of controlling files is the same as in window Explorer Plays MP3, WAV, RVF files and playing lists Inter-conversion function between RVF/WAV Convenient file transmission User-friendly interface...

  • Page 27: Quick Software & Drivers Installation Guide

    2) Quick Software & Drivers Installation Guide Follow these instructions to load the software and drivers for RADIO YourWay 1. Place the software CD label side up into your computer’s CD- ROM drive. After a few seconds you should see the software selection screen.
  • Page 28 RYW Explorer Click finish and restart your computer. 2. Plug in RADIO YourWay into your computer’s USB port and power it on. Tip> To power on your unit hold play for 2-3 seconds Your computer now should display "Found new hardware" and RADIO YourWay should display USB on its LCD.
  • Page 29 RYW Explorer Click continue anyways (Do not worry this will not HARM your PC we have tested this software to be compatible with your OS) If you see the screen below click ok. When you see the screen below, type or browse toC:\windows\system32\drivers When you see the screen below, type or browse to C:\windows\inf and select retry...
  • Page 30 RYW Explorer When you see the screen below, type or browse to C:\windows\inf and select retry When you see the screen below click finish. Click the Mp3 manager icon on your desktop (with the player plugged in) Congratulations your unit is installed and ready to use.

  • Page 31: Ryw-Explorer User Interface

    3) RYW-Explorer User Interface Man- aging Files Play Man- ager Memory Man- aging Window Memory Status Window (1) MP3, WAV and RVF Playing After selecting an MP3, WAV or RVF File to play in the File Managing Window, if you double click the PLAY Button, playing will begin. At this time, you may check some information of the selected file like bit rate, sampling frequency, file size, file name, version of file and total running times of files.
  • Page 32 RYW Explorer (2) Managing MP3 and RVF Files The file managing part of RYW-Explorer looks very similar to the one of Windows Explorer. The hard disk, CD-ROM Driver and folder installed are in the system display on the window on the left and numbers of files in the folder displayed are on the window on the right.
  • Page 33 (4) Descriptions of Buttons Buttons Functions Refresh Transmit to RADIO YourWay (Download) Transmit to the Computer (Upload) Memory Card Flash Memory Copyrighted MP3 Files can not be uploaded. Buttons Functions Selects MP3 Selects the RECORD Folder Selects the HD Folder You may divide and use the memories in 3 folders and play each folder in RADIO YourWay RYW Explorer...

  • Page 34: Transmitting Mp3 Files

    RYW Explorer 4) Transmitting MP3 Files Way of transmitting MP3 files to RADIO YourWay As previously stated, select the file and Click and then click start downloading Select the MP3 files to transmit in the file managing window. Click button and then click The selected MP3 File is being transmitted.

  • Page 35: Transmitting Rvf Files To The Pc

    5) Transmitting RVF Files to the PC Way of transmitting RVF files from RADIO YourWay very simple. As previously stated, click window and then select the RVF files to transmit and click Click and then select RVF files to upload. Click to start uploading.

  • Page 36: Deleting Mp3 & Rvf Files

    RYW Explorer 6) Deleting MP3 & RVF Files Deleting MP3 and RVF Files in RADIO YourWay files in Windows Explorer. You may delete the files by selecting ’DELETE’ after right clicking your mouse. You may delete MP3 and RVF Files stored in the memory the following way: Select files to delete and then right click your mouse and select ’DELETE’...

  • Page 37: Initiating The Flash Memory

    7) Initializing the Flash Memory Just like formatting a hard disk, you may initializ (format) the memory used in RADIO YourWay . If you format the flash memory, all data stored in the memory will be lost. Select File Flash Memory Format in the menu of RADIO YourWay If you right click the mouse on any empty space in the flash memory managing window, you will see this Flash Memory Format command.

  • Page 38: General Specification

    32Kbps-320Kbps(MPEG 1/2 LAYER 3) 85db up(1kHz input 0db) Distortion 0.3% 0.05 (1kHz input 0db) Freq,Response Earphone EQ : NORMAL, ROCK, POP, CLASSIC, LIVE PRY900M2 VOICE : 99 / MP3 530kHz - 1710kHz 400Hz-3.2kHz(-6db) 5uV at S/N=26db 10 Radio station 35db...
  • Page 39 General Specification Repeat Play NOR/NOR1/1ALL/ALL Communication System CPU200MHz more than, RAM 64MB more than, 20MB of free space Windows 98SE, 2000, ME, XP Interface Sound Card Sound Blaster 16 compatible Display 640X480 more than Ext Line in 3.5 plug-in power microphone(mini plug/stereo) IMP less than 3K IN/OUT Earphone 3.5 earphone(mini plug/stereo) IMP less than 16...

  • Page 40: Warranty

    Warranty If any defect or error occurs, stop using the product and contact the shop you purchased or Pogo! Products, Inc., General Directory Number: (714) 671-1854 Warranty (Warranty Regulation) Pogo! Products guarantees a free repair or service for a period of one year from the original date of purchase only.
  • Page 41 (Caution Upon Shipping or Transporting) Upon shipping or transporting the product, please be careful about the following: 1. Enclose the original dated purchase order/receipt with the product during the warranty period. 2. Avoid damage to the product during shipping/transportation using proper packing materials.
  • Page 42 M E M O...
