D
igital
User's Manual
Thank you very much for purchasing this DLP™ Technology Projector.
Please read this operating guide to ensure correct use of the device. After reading this manual, keep it
for future reference.
Outline
This DLP™ Technology Projector can display various
computer signals and NTSC/PAL/SECAM video signals.
Features
(1)
High brightness
(2)
High resolution
(3)
Compact size, light weight for portability
(4)
RGB input terminal
(5)
RS232 Communication
(6)
Mouse emulation
(7)
Complies with VESA DDC1/2B specifications
M
ultimedia
P
rojector
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Plus DLPTM Technology Projector
Summary of Contents for Plus DLPTM Technology Projector
- Page 1 igital User’s Manual Thank you very much for purchasing this DLP™ Technology Projector. Please read this operating guide to ensure correct use of the device. After reading this manual, keep it for future reference. Outline This DLP™ Technology Projector can display various computer signals and NTSC/PAL/SECAM video signals.
-
Page 2: Monitor Information
User’s Manual Copyright Copyright © 2002. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. -
Page 3: Table Of Contents
Table of Contents Introduction ...1 Projector Features ...1 Description ...2 FRONT ...2 REAR ...2 BOTTOM ...2 Installation...3 Positioning...3 Adjustable Feet...3 Moving the Projector ...4 Accessories...5 Connection...6 Connecting the Projector to Computer/Notebook...6 Connecting the Projector to Macintosh/Power Book...7 Operation ...8 Turn On/Off Procedure...8 Power on...8 Standby...8 External Control ...8... -
Page 5: Introduction
Projector Features A. Image Resolution Fully compatible with true SVGA/ XGA, and supports SXGA using advanced intelligent compression technology. The advanced intelligent compression technology enables it to present clear compression SVGA/XGA images without line omission. B. Brightness Provides superior brightness using TI’s Digital Micromirror Device (DMD) and our own optical design, with a geometric effect that increases light usage efficiency. -
Page 6: Description
User’s Manual SECAM France and Eastern Europe standard NTSC4.43 Middle East standard If users want to watch CATV, AV box will serve the need. Description A. FRONT Figure 1 Front view B. REAR Figure 2 Rear view C. BOTTOM Figure 3 Bottom view Introduction... -
Page 7: Installation
Installation A. Positioning This projector is basically designed to project on a flat projection surface. It can focus from 1m– 10m and adjust the screen size like figure below. 59" 44" 30" " 23" Projection screen Max. size (diagonal Zoom length) Min. -
Page 8: Moving The Projector
User’s Manual Moving the Projector Use the carrying handle when moving the projector. Replace the lens cover and rotate the feet fully clockwise (to shorten the feet) when moving the projector to prevent damage to the projector. Caution The carry bag (supplied) is intended to protect the projector from dust and scratches on the surface of the cabinet. -
Page 9: Accessories
User’s Manual Accessories Please check and make sure your box contains everything listed below. If any pieces are missing, contact your dealer. Please save the original box and packing materials in case you ever need to ship the unit. Projector Remote Control User's Guide Ma c Adapter... -
Page 10: Connection
User’s Manual Connection A. Connecting the Projector to Computer/Notebook Figure 8 Connection to PC Figure 9 Connection to notebook Connection... -
Page 11: Connecting The Projector To Macintosh/Power Book
User’s Manual B. Connecting the Projector to Macintosh/Power Book Figure 10 Connection to Macintosh Figure 11 Connection to Power Book Connection... -
Page 12: Operation
User’s Manual Turn On/Off Procedure A. Power on Press the Standby/On key to turn on the lamp. The LED will blink green during warm up and then light solid green. "INPUT SIGNAL DETECTED, ACTIVATING AUTO IMAGE" will be displayed on the screen after the projector has identified the input signal;... - Page 13 MAIN UNIT AUTO KEYSTONE + KEYSTONE - MENU Standby/On Standby/On indicator Lamp status indicator Menu operation When you press MENU button into OSD menu, all hot keys become manual operating buttons. Figure 13 Menu control pad MAIN UNIT Menu To call the OSD menu. To enter sub pages.
-
Page 14: Remote Control
User’s Manual B. Remote Control Stand by /on Menu Freeze L-Click Magnify Return Channel down Figure 14 Remote control Operation (LED) Laser Source -Keystone+ Drag Reverse Add/Erase scan Exit Blank R-Click Volume Mute Channel up Scan... - Page 15 Main Unit Standby/On To turn the projection lamp on and off. Freeze Pressing this button displays a still (frozen) picture. Magnify Pressing this button partially magnifies a displayed picture. (Move the picture with the Disk Pad after pressing the Magnify button.) When the OSD menu is active, Disk Pad acts as 56selecting device.
-
Page 16: Usage And Replacement Of Lamp
User’s Manual Remote Control Range The remote sensors are located on the back of the unit. It can function in a range 50 degrees horizontal and 30 degrees vertical relative to a line that is a right angle to the remote sensor. The distance between the remote control and remote sensor must be shorter than four meters (13 feet). -
Page 17: Replacing The Lamp
2. Lamp is not well attached If the LED blinks rapidly, it indicates that the lamp is not attached properly. 3. Temperature is too high If the projector’s internal temperature is too hot to operate safely, the LED will blink slowly for one minute and then the lamp will turn off automatically. - Page 18 User’s Manual Do not turn on power with lamp cover removed. Whenever the lamp is replaced, reset the total operation time of the lamp. Do not reset if the lamp has not been replaced. Do not reset the timer without changing the lamp, as this can cause the lamp to break. Lamp Replacement Procedure Lamp replacement Figure 20...
-
Page 19: Osd
Resetting Lamp Timer If replacing the lamp after 1500 hours of operation, please carry out the following operation within 10 minutes of powering on. Main OSD Menu Press the “Menu” key and the main OSD menu structure will display as shown at right hand (Fig. 21). -
Page 20: Display Page
User’s Manual A. Display Page When a PC is the input source, there will be only four items on this page: Keystone, Brightness, Contrast, and Color Balance (Fig. 22). On the other hand, when the input source are video, S-video, TV or CATV, there will be other 4 items on this page: Keystone, Brightness, Contrast, and Sharpness (Fig.23). -
Page 21: Control Page
Resize When Resize is 4:3 or 16:9, the projector determines the best fit of the image to the screen. If flicker occurs on a projected image, users may try to adjust the H. Phase H. Phase manually. H. Size If the projected image is too wide or too narrow for the screen, users may turn Auto Image off and adjust the H. -
Page 22: Source Page
User’s Manual Auto To reset display, image and control settings to factory settings. To select the OSD menu language. Eight languages are supported: English, French, Language German, Italian, Spanish, Korean, Simplified Chinese and Traditional Chinese. (See Figure 27). Mirror To select Normal projection, H-Invert projection, V-Invert projection, or H/V Invert projection. -
Page 23: Other Correspondent Remote Functions And Messages
Other Correspondent Remote Functions and Messages Source Freeze Mute Volume Magnify Laser Disk Pad Drag Blank FUNCTION The selected source will be displayed at the bottom right of the screen for 3 seconds after selecting the source. (PC, VIDEO, S-VIDEO). The image will be frozen when the “Freeze”... -
Page 24: Maintenance And Troubleshooting
User’s Manual A. Lamp Replacement Refer to Page 13. B. Cleaning the Lens Follow these steps to clean the projection lens: 1. Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth (abrasive cleaners, solvents or other harsh chemicals might scratch the lens). 2. -
Page 25: Specifications
A. Optical Lens Lamp Image size Projection Distance Contrast Ratio B. Electrical Inputs Video Color Reproduction Power Requirement C. Mechanical Dimensions Net Weight Operational Temperature projector 10℃ to 40℃ Remote control D. Preset Display Resolution Table Resolution H Sync (kHz) 640x350 640x400 720x400... -
Page 26: Appendix
User’s Manual Guideline to AV box Features and Connection AV Connection Port This box is compatible with RCA input, S-Video input and audio output. Figure 29 Connection of AV box Speaker RCA Jack S Video Port *AV box is sold separately and is not included in the standard configuration of accessories in the unit. -
Page 27: Connecting The Box
Connecting the Box Please follow the instructions here to place the AV box: Figure 30 Bottom View of AV box To attach the AV box to the unit： Figure 32 Connecting the Box Figure 31 Side View of AV box 1.
