Plantronics SupraPlus CS351N Setup Manual

Plantronics SupraPlus CS351N Setup Manual

Wireless headset system
Hide thumbs Also See for SupraPlus CS351N:
Table of Contents

Advertisement

Quick Links

See also: User Manual
4 Easy Steps
The fastest way to set up your Plantronics
®
SupraPlus
Base Power
Adapter
SupraPlus
Wireless
Headset
Base
Wireless Headset System
HL10
Automatic
Handset Lifter*
SupraPlus
Wireless
Headset
Plantronics SupraPlus Wireless
*Not included in all confi gurations
S
G
E T U P
U I D E

Advertisement

Table of Contents
loading

Related Manuals for Plantronics SupraPlus CS351N

Summary of Contents for Plantronics SupraPlus CS351N

  • Page 1 4 Easy Steps The fastest way to set up your Plantronics ® SupraPlus Wireless Headset System Base Power Adapter SupraPlus Wireless Headset Base HL10 Automatic Handset Lifter* SupraPlus Wireless Headset Plantronics SupraPlus Wireless *Not included in all confi gurations E T U P...
  • Page 2 HL10 Additional Parts Kit (if needed) HL10 Extender User Guide Setup Guide ireless ACKAGE ONTENTS 4 Easy Steps The fastest way to set up your Plantronics ® SupraPlus Wireless Headset System Alternative Ear Cushions Plantronics SupraPlus Wireless Setup Guide Removable...
  • Page 3 DJUST FIT A. Adjust the Headband 1. To adjust the headband, lengthen or shorten the band until it fi ts comfortably. The clickstop feature keeps the headband securely adjusted. Position the headset receivers so that the foam cushions sit comfortably over the center of your ears.
  • Page 4 You will use the Automatic Handset Lifter or… Your phone does NOT have built-in headset functionality (no Headset button). Confi guration A Handset Coil Cord Plantronics SupraPlus W ASE TO HONE Unplug the handset coil cord from the desk phone handset port [A], then plug it into the handset port [B] on the Headset Base.
  • Page 5 Use Confi guration B if: You will NOT use the Automatic Handset Lifter and… Your phone has built-in headset functionality (a Headset button). Confi guration B 1. Plug the short BLACK Phone Cable that is pre-installed on the Headset Base into the Headset port [C] on the desk phone.
  • Page 6 Status light on the base will fl ash to indicate the headset battery is charging. (See illustration on page 13.) A solid light indicates full charge. A full charge will take approximately 3 hours. Plantronics SupraPlus W OWER AND HARGE...
  • Page 7 The HL10™ Automatic Handset Lifter is included with certain SupraPlus Wireless confi gura- tions and is also available separately. See www.plantronics.com/SupraPlusWireless for a complete list of accessories. A. Connect Handset Lifter power cord to Headset Base .
  • Page 8 Press the Call Control Button to return the handset to the cradle. Please continue with section D “Mount the Lifter in permanent position” below. If you do not hear a dial tone continue with section C. Call Control Button Plantronics SupraPlus W Handset Lifter Arm Setup Guide ireless Start with Lifter...
  • Page 9 C. If you do not hear a dial tone If you do not hear a dial tone, the Lifter may not be raising the handset high enough or the Confi guration Dial may need adjusting. Check the Lifter height adjustment by moving the Lifter Height Switch to a higher position.

  • Page 10: Powering The Headset On And Off

    For your safety, do not use headset at high volumes for extended periods of time. Doing so can cause hearing loss. Always listen at moderate levels. For more information on headsets and hearing visit: www.plantronics.com/healthandsafety If your desk phone has a volume control, set it to mid-range.
  • Page 11 Adjust Listening Volume While on a call, adjust the listening volume by using the Listening Volume Switch on the back of the base. Listening Volume Switch Position 1 = Loudest Position 4 = Softest To Fine Tune Listening Volume On the headset, press the (+) on the Listening Volume Button to increase the volume.
  • Page 12 To disable the multi-shift pairing feature, press the speaking volume minor adjust for 5 seconds until the power indicator light fl ashes. Plantronics SupraPlus W Feature IntelliStand Switch position if you plan to wear your headset most of the time.

  • Page 13: Base Indicator Lights

    UPRA IRELESS Base Indicator Lights Tones Out of Range Warning: If you walk out of range of your base, your headset will issue audible tones at its operating limit. If you are on a call, you will hear two tones when reaching edge of range, and again when back in range.
  • Page 14 Plug the Power Adapter into the wall directly. Talk time performance is signifi cantly degraded even after a full recharge. • Battery is wearing out. Call Plantronics at (800) 544-4660 Ext. 5538 to order a new one. The Handset Lifter is installed but does not lift the handset.
  • Page 15 • Do not use solvents or other cleaning agents. Battery replacement The custom battery supplied in your headset should last 2–3 years. When talk time decreases signifi cantly, the battery may need replacing. Please call Plantronics at 800-544-4660 Ext. 5538 to order a new one. Still having problems? Given the hundreds of diff erent types of phones, it’s possible a trick or two may...
  • Page 16 © 2007 Plantronics, Inc. All rights reserved. Plantronics, the logo design, HL10, IntelliStand, Sound Innovation, and SupraPlus are trademarks or registered trademarks of Plantronics, Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc.
