Summary of Contents for Planet Networking & Communication DTR-100DB
- Page 1 USB 2.0 Digital TV Receiver (ISDB-T) DTR-100DB Quick Install Guide 2011-K10050-000 Page 1...
-
Page 2: Table Of Contents
Table of Contents 1 SYSTEM REQUIREMENTS... 3 2 PACKAGE CONTENTS ... 3 3 BEFORE STARTUP... 3 3.1 Physical Specification... 3 3.2 Physical Installation ... 4 4 USER INTERFACE ... 7 4.1 Launch Presto! PVR Application ... 7 4.2 Main Monitor ... 7 4.3 Main screen &... -
Page 3: System Requirements
Microsoft DirectX 9 or above Windows 2000(SP4) / XP (SP2) / Vista (32bit) Windows Media Player 9 or above 2 Package Contents DTR-100DB USB 2.0 Digital TV Receiver Installation CD (Include User Manual, Quick Installation Guide, Utility and Driver) ISDB-T TV Antenna 3 Before Startup 3.1 Physical Specification... -
Page 4: Physical Installation
This chapter explains how to install DTR-100DB with your computer or notebook. 1. Connecting USB Port Connect USB connector of the DTR-100DB to the USB port on your computer or notebook. 2. Connecting Terrestrial Antenna Connect the supplied ISDB-T antenna to the VHF/UHF port on the backside of the DTR-100DB. - Page 5 There are three utilities in the supplied CD: Windows Media Player 9, Microsoft DirectX 9, and Presto! PVR. The installation procedure: Windows Media Player 9 soft DirectX 9 Presto! PVR DTR-100DB’s Driver. Micro- Page 5...
- Page 6 CPU Performance and may effect the DTR- Note 100DB’s operation). (2) Be sure, if you connect the antenna to the DTR-100DB and please adjust it to a better re- ception angle and location every time. Description Before installing DTR-100DB’s driver,...
-
Page 7: User Interface
4 User Interface Before you begin, make sure that the antenna is connected to the DTR-100DB device. 4.1 Launch Presto! PVR Application (1) Double-click Desktop Icon “Presto! PVR”. 4.2 Main Monitor NewSoft Presto! PVR is an application for turning your com- puter into a media center. - Page 8 Parameter Program Status Information Win- Full Screen Minimize Screen Close Screen EPG / Captions Settings / Help History Previous Channel Next Channel Last Channel Channel List Viewer Description At the top of the presentation area, the program status (Recording or playing), as well as the video qual- ity, will be listed.
- Page 9 Increase Volume Decrease Volume Mute Stop Backward Forward Record Pause The volume controls let you turn it up and down as well as off, and the indicator show the current volume level The program control buttons are used for going forward, going back- ward, or to stop time shifting and recording.
-
Page 10: Further Information
5 Further Information If you still have any problem on connecting, please check user’s manual on the bundled CD for detail configuration. If you have any other questions, please contact the dealer where you purchased this product or you can contact PLANET directly at the following email address: support@planet.com.tw Page 10...
