1.1 Checklist Thank you for purchasing our POE-152S IEEE 802.3af Power over Ethernet Splitter, your Power over Ethernet Splitter package shall contain following contents: Check the contents of your package for following parts: Power over Ethernet Splitter x 1 User' s manual CD x 1 DC Plug Cable x 2 15cm UTP straight network cable x 1 If any of these pieces are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the orig...
1.4 Specification Model Ethernet Connector Ethernet Data Rate Output Voltage/Current Number of Device can be powered Ethernet Cable LED indicator Operating environment Storage environment Dimension (W x D x H) Weight Emission Standard Compliance 1.5 Product Outlook LED definition: Color PoE ready / in-use Green POE-152S...
2. HARDWARE INSTALLATION These products provide three different running speeds – 10Mbps, 100Mbps,1000Mbps. in the same device and auto- matically distinguish the speed of incoming connection. This section describes the hardware features of POE-152S. Before connecting any network device to the POE-152S, read this chapter carefully.
2.2 POE-152 and POE-152S, the IEEE 802.3af Injector and Splitter installation 1. Connect a standard network cable from “Ethernet+DC” of POE-152 to “Ethernet+DC” of POE-152S. The POE LED of POE-152 / POE-152S will light on continuance. The screen in Figure 1 appears. Figure 1: Connection to POE-152 or IEEE 802.3af POE equipment 2.
The POE-152S can also provide the alternative to make the non- IEEE 802.3af devices the possibility to connect with an IEEE 802.3af in-line power device like Power over Ethernet Switch, then connect proper DC plug from "DC OUT" of POE-152S to remote device. The screen in Figure 3 appears.
10/100/1000Base-T port link LED is lit, but the traffic is irregular Solution: Check that the attached device is not set to dedicate full duplex. Some devices use a physical or software switch to change duplex modes. Auto-negotiation may not recognize this type of full-duplex setting.
Page 11
There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight cable and crossover cable connection: Figure A-1: Straight-Through and Crossover Cable Please make sure your connected cables are with same pin assignment and color as above picture before deploying the cables into your network.
