Omnia Volt Quick Start Installation Manual

Stereo generator / sg version
Hide thumbs Also See for Volt:
1
2
3
4
5
6

Advertisement

Table of Contents

See also: Installer and User Manual
Quick-Start inStallation Guide
oMnia Volt
tHank You For purcHaSinG tHe oMnia Volt.
We have made this Omnia processor easy to set up and configure. This quick-start guide will take you through the
basic steps needed to configure your new Omnia VOLT. You're just a few steps away from being able to deliver cleaner,
clearer, louder, and more consistent FM sound. Before we get started, let's make sure you have what you need.

REQUIRED EQUIPMENT, CABLES, AND ACCESSORIES:

There are a few additional items required for a successful installation. Check the list below and make sure
you have what you need.
Included items:
• Omnia VOLT Audio Processor
• AC Power Cable
• RJ45 Studio Hub standard pinout AES Adaptors
• 4 rack screws
tM
(Stereo Generator / SG VerSion)
Items you need to supply:
• Rack with an EIA rack space for mounting
• Philips screwdriver or screw gun
• Standard XLR connectors if setting up a line-level
• Ethernet cable if setting up a Remote and/or Livewire
analog audio source
connection

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Volt and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omnia Volt

Summary of Contents for Omnia Volt

  • Page 1 We have made this Omnia processor easy to set up and configure. This quick-start guide will take you through the basic steps needed to configure your new Omnia VOLT. You’re just a few steps away from being able to deliver cleaner, clearer, louder, and more consistent FM sound.
  • Page 2 MountinG 1. Install the VOLT in your equipment rack using the 4 supplied screws. If only two screws are used for installation, they MUST be installed in the bottom holes (A) of the rack ears. As a best practice, leave a blank space above and below the unit for proper ventilation and cooling.
  • Page 3 VOLT” as the startup sequence progresses. A few seconds later, the main menu will be displayed. continue to audio conFiGuration The initial set-up of your Omnia VOLT is complete and ready to be configured. Continue to the "Audio Configuration" instructions.
  • Page 4 The Omnia VOLT can be set up directly from the front panel. Note that all of front panel functions, and more, can also be accessed via password protected login from networked computers, tablets or smartphones. For instructions on how to configure via networked devices, please refer to the Remote Control chapter in the Omnia VOLT manual.
  • Page 5 -12 LED. If there is some overshoot in the output of your external FM processor or the link between it and the VOLT SG, more than just the -12 LED may light. This should be OK as long as there is not more than a dB or so of overshoot.
  • Page 6 12. Read the complete user manual! There are many layers to Omnia VOLT, and our easy to read manual will help teach you how to shape your sound with the best in Omnia processing for your station and market.
