  • Page 1 Internet Broadband Router XRT-412 User’s Manual...

  • Page 2: Fcc Compliance Statement

    PLANET Technology. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
  • Page 3 Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.

  • Page 4: Table Of Contents

    Chapter 1 Introduction ...1 1.1 Features ...1 1.2 Minimum Requirements...1 1.3 Package Contents ...1 1.4 Get to know XRT-412 ...2 1.5 Setup Diagram ...3 1.6 Getting started...4 Chapter 2 Quick Setup ...12 2.1 Cable Modem ...14 2.2 Fixed-IP xDSL ...15 2.3 PPPoE...16...
  • Page 5 4.3 Device Status ...54 4.4 System Log ...55 4.5 Security Log ...56 4.6 Active DHCP Client ...56 4.7 Statistics ...57 Chapter 5 Tools...58 5.1 Configuration Tools ...58 5.2 Firmware Upgrade...59 5.3 Reset ...60 Appendix A...61 Glossary ...63...

  • Page 6: Chapter 1 Introduction

    Congratulations on purchasing PLANET XRT-412. This Broadband Router is an IP Sharing Router that enables multiple users to share the Internet through an ADSL or cable modem. Simply configure your Internet connection settings in the Broadband Router and plug your PC to the LAN port and you're ready to share files and access the Internet.

  • Page 7: Get To Know Xrt-412

    (warning: your original configurations will be replaced with the factory default settings) Front Panel On XRT-412’s front panel there are LED lights that inform you of machine current status. Below is an explanation of each LED and its description. Figure 1.0...

  • Page 8: Setup Diagram

    Light Status USB1 Flash USB2 Flash 10/100M LNK/ACT Flashing 10/100M (Port 1-4) LNK/ACT (Port 1-4) Flashing 1.5 Setup Diagram Figure 1.2 below shows a typical setup for a Local Area Network (LAN). Description Router’s power supply is on Data is transmitting No data transmitted Data is transmitting No data transmitted...

  • Page 9: Getting Started

    Configure your PC to obtain an IP address automatically By default XRT-412’s DHCP is on, this means that you can obtain an IP address automatically once you’ve configured your PC to obtain an IP address automatically. This section will show you how to configure your PC’s so that it can obtain an IP address automatically for either Windows 95/98/Me, 2000 or NT operating systems.
  • Page 10 8: Reboot the PC. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-412’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to...
  • Page 11 5: Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-412’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to Step 3.
  • Page 12 6: Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-412’s DHCP server is the only DHCP server Note: available on your LAN.
  • Page 13 Routing: Let all fields are blank. 7: Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-412’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to...
  • Page 14 Quick Setup Wizard, General Setup, Status Information and Tools. Quick Setup Wizard (Chapter 2) If you only want to start using XRT-412 as an Internet Access device then you ONLY need to configure the screens in the Quick Setup Wizard section.
  • Page 15 Attack Prevention, DMZ, Special applications other functions requirements. In this section you can see XRT-412's system information, Internet Connection, Device Status, Security Log and DHCP client Log information. This section contains XRT-412’s Tools - Tools include Configuration tools, Firmware upgrade and Reset.
  • Page 16 7) Click on Quick Setup Wizard (see chapter 2) to start configuring settings required by your ISP so that you can start accessing the Internet. The other sections (General Setup, Status Information and Tools) do not need to be configured unless you wish to implement/monitor more advance features/information.

  • Page 17: Chapter 2 Quick Setup

    The Quick Setup section is designed to get you using XRT-412 as quickly as possible. In the Quick Setup you are required to fill in only the information necessary to access the Internet. Once you click on the Quick Setup Wizard in the HOME page, you should see the screen below.
  • Page 18 Different ISP’s require different methods of connecting to the Internet, please Note: check with your ISP as to the type of connection it requires. Menu 2.1 Cable Modem 2.2 Fixed-IP xDSL 2.3 PPPoE 2.4 PPTP 2.5 L2TP 2.6 Telstra Big Pond Click on one of the WAN type and then proceed to the manual’s relevant sub-section (2.1, 2.2, 2.3, 2.4, 2.5 or 2.6).

  • Page 19: Cable Modem

    2.1 Cable Modem Choose Cable Modem if your ISP will automatically give you an IP address. Some ISP’s may also require that you fill in additional information such as Host Name and MAC address (see screen below). The Host Name and MAC address section is optional and you can skip this section Note: if your ISP does not require these settings for you to connect to the Internet.

  • Page 20: Fixed-Ip Xdsl

    2.2 Fixed-IP xDSL Select Fixed-IP xDSL if your ISP has given you a specific IP address for you to use. Your ISP should provide all the information required in this section. Parameters Subnet Mask Gateway MAC Address Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the Fixed-IP x DSL connection.

  • Page 21: Pppoe

    2.3 PPPoE Select PPPoE if your ISP requires the PPPoE protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter User Name Password Service Name Connection Type Description Enter the User Name provided by your ISP for the PPPoE connection Enter the Password provided by your ISP for the PPPoE connection...
  • Page 22 Idle Time Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the PPPoE connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. WAN line breaks down and latter links again, the router will not auto-connect to the ISP.

  • Page 23: Pptp

    2.4 PPTP Select PPTP if your ISP requires the PPTP protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter Obtain an IP address Automatically Use the following IP Address IP address Subnet Mask Enter the Subnet Mask provided by your ISP (e.g.
  • Page 24 Password PPTP Gateway Connection ID BEZEQ-ISRAEL Connection Type Idle Time Out Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the PPTP connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. Enter the Password provided by your ISP for the PPTP connection.

  • Page 25: L2Tp

    2.5 L2TP Select L2TP if your ISP requires the L2TP protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter Obtain an IP address Automatically Use the following IP Address IP address Subnet Mask Enter the Subnet Mask provided by your ISP (e.g.
  • Page 26 L2TP Gateway Connection Type Idle Time Out Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the L2TP connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. If your LAN has a L2TP gateway, then enter that L2TP gateway IP address here.

  • Page 27: Telstra Big Pond

    2.6 Telstra Big Pond Select Telstra Big Pond if your ISP requires the Telstra Big Pond protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Telstra Big Pond protocol is used by the ISP in Australia. Parameters User Name Password...

  • Page 29: Chapter 3 General Settings

    Chapter 3 General Settings Description This section allows you to set XRT-412’s system Time Zone, Password and Remote Management Administrator. This section allows you to select the connection method in order to establish a connection with your ISP (same as the Quick Setup Wizard section) You can specify the LAN segment’s IP address, subnet Mask,...

  • Page 30: System

    3.1 System The system screen allows you to specify a time zone, to change the system password and to specify a remote management user for XRT-412. Parameters 3.1.1 Time Zone 3.1.2 Password Settings 3.1.3 Remote Management Select one of the above three system settings selections and proceed to the manual’s relevant sub-section 3.1.1 Time Zone...

  • Page 31: Password Settings

    (with the advance settings in place) 3.1.2 Password Settings You can change the password required to log into XRT-412's system web-based management. Passwords can contain 0 to 30 alphanumeric characters, and are case sensitive.

  • Page 32: Remote Management

    (with the advance settings in place) 3.1.3 Remote Management The remote management function allows you to designate a host in the Internet the ability to configure XRT-412 from a remote site. Enter the designated host IP Address in the Host IP Address field. Parameters...

  • Page 33: Wan

    3.2 WAN Use the WAN Settings screen if you have already configured the Quick Setup Wizard section and you would like to change your Internet connection type. The WAN Settings screen allows you to specify the type of WAN port connect you want to establish with your ISP. The WAN settings offer the following selections for the router’s WAN port, Dynamic IP, PPPoE, PPTP, Static IP Address, L2TP, Telstra Big Pond, DNS and DDNS.

  • Page 34: Dynamic Ip

    3.2.1 Dynamic IP Choose the Dynamic IP selection if your ISP will automatically give you an IP address. Some ISP’s may also require that you fill in additional information such as Host Name, Domain Name and MAC address (see chapter 2 “Cable Modem” for more detail) 3.2.2 Static IP Address Select Static IP address if your ISP has given you a specific IP address for you to use.

  • Page 35: Ddns

    Parameters Domain Name Server (DNS) Server Secondary DNS Address (optional) Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance sections or start using the router (with the advance settings in place) 3.2.8 DDNS DDNS allows you to map the static domain name to a dynamic IP address.

  • Page 36: Lan

    Parameters Default Enable/Disable Disable Provider Domain name Account/E-mail Password/Key Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance sections or start using the router (with the advance settings in place) 3.3 LAN The LAN Port screen below allows you to specify a private IP address for your router’s LAN ports as well as a subnet mask for your LAN segment.

  • Page 37: Nat

    Public IP Addresses for key services such as Websites and FTP. To meet various field applications, XRT-412 NAT function can be disabled to as a regular router. If NAT is disabled, all LAN side workstations must have valid IP addresses for Internet access. If the router is used for routing application, not for Internet access, then the NAT function can be disabled.
  • Page 38 Parameter 3.4.1 Port Forwarding 3.4.2 Virtual Server 3.4.3 Special Applications 3.4.4 UPnP Settings 3.4.5 ALG Setting Click on one of the three NAT selections and proceed to the manual's relevant sub-section. Description You can have different services (e.g. email, FTP, Web etc.) going to different service servers/clients in your LAN.

  • Page 39: Port Forwarding

    3.4.1 Port Forwarding The Port Forwarding allows you to re-direct a particular range of service port numbers (from the Internet/WAN Ports) to a particular LAN IP address. It helps you to host some servers behind the router NAT firewall. Parameter Enable Port Forwarding Private IP Type...

  • Page 40: Virtual Server

    You can now configure other advance sections or start using the router (with the advance settings in place) 3.4.2 Virtual Server Use the Virtual Server function when you want different servers/clients in your LAN to handle different service/Internet application type (e.g. Email, FTP, Web server etc.) from the Internet. Computers use numbers called port numbers to recognize a particular service/Internet application type.

  • Page 41: Special Applications

    Type Public Port Comment Add Virtual Server Remove Virtual Server You can now configure other advance sections or start using the router (with the advance settings in place) 3.4.3 Special Applications Some applications require multiple connections, such as Internet games, video conferencing, Internet telephony and others.
  • Page 42 Parameters Enable Trigger Port Trigger Port Trigger Type Public Port Public Type Comment Popular Applications Add Special Application Description Enable the Special Application function. This is the out going (Outbound) range of port numbers for this particular application. Select whether the outbound port protocol is “TCP”, “UDP” or both.

  • Page 43: Upnp Settings

    Remove Special Application If you want to remove some Special Application settings from the You can now configure other advance sections or start using the router (with the advance settings in place) Example: Special Applications If you need to run applications that require multiple connections, then specify the port (outbound) normally associated with that application in the "Trigger Port"...

  • Page 44: Alg Settings

    Parameters Default UPnP Feature Disable Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance sections or start using the router (with the advance settings in place) 3.4.5 ALG Settings You can select applications that need “Application Layer Gateway” to support. Description You can Enable or Disable UPnP feature here.

  • Page 45: Firewall

    (with the advance settings in place) 3.5 Firewall XRT-412 provides extensive firewall protection by restricting connection parameters, thus limiting the risk of hacker attack, and defending against a wide array of common Internet attacks.

  • Page 46: Access Control

    Internet applications URL Blocking allow you to specify which URLs can not be accessed by users. XRT-412's firewall can block common hacker attacks and can log the attack activities. The DMZ function allows you to re-direct all packets going to...
  • Page 47 Parameters Enable MAC Filtering Add PC Remove PC Enable IP Filtering Table Add PC Remove PC You can now configure other advance sections or start using the router (with the advance settings in place) Description Check “Enable MAC Filtering” to enable MAC Filtering, select “Deny”...
  • Page 48 Add PC Parameters Client PC Description Client PC IP Address Client PC Service Description The description for this client PC rule. Enter the IP address range that you wish to apply this Access Control rule. This is the user’s IP address that you wish to setup an Access Control rule.

  • Page 49: Url Blocking

    Protocol Port Range You can now configure other advance sections or start using the router (with the advance settings in place) 3.5.2 URL Blocking You can block access to some Web sites from particular PCs by entering a full URL address or just keyword of the Web site.

  • Page 50: Denial Of Service (Dos)

    3.5.3 Denial of Service (DoS) The XRT-412's firewall can block common hacker attacks, including Denial of Service, Ping of Death, Port Scan and Sync Flood. If Internet attacks occur the router can log the events. Parameters Ping of Death Discard Ping From WAN...
  • Page 51 Parameters Enable DMZ Public IP Address Client PC IP Address You can now configure other advance sections or start using the router (with the advance settings in place) Description Enable/disable DMZ Note: If there is a conflict between the Virtual Server and the DMZ setting, then Virtual Server function will have priority over the DMZ function.

  • Page 52: Print Server

    The print server provides LPR and IPP printing methods. You can enable/disable the print server function and change the print server name here. Please assign printer queue name for each printer connected to the USB port. XRT-412 does not support the GDI interface printer. Note: Example: Print server setup with utility Execute Client.exe and the “PrintServer Network driver Setup program”...
  • Page 53 Click “Next” and specify the destination folder where the utility will be installed. Click “Next” and specify the program folder where the program icons will be added.
  • Page 54 Click “Next” to start installation. In a while, the program will finish installing all the utilities and drivers. Thus far you have completed the installation phase and prepare to use the print server.
  • Page 55 Click “Continue”, and all the print server’s network ports detected on the network will be added to your PC. Finally, the “Installation complete” window is displayed to indicate that the Client Installation procedure is finished. Add a Network Printer After installing the print server client tool, you can then perform the standard “Add Printer” procedure to add network printer to your PC.
  • Page 56 Select “Use following port”, and choose XRT-412 printer name and Queue name, then to click “Next”.
  • Page 57 Select the suitable printer manufacturer and model, then click “Next” Complete the rest of the questions to finish the network printer setup.

  • Page 58: Chapter 4 Status

    The Status section allows you to monitor the current status of your router. You can use the Status page to monitor: the connection status of XRT-412's WAN/LAN interfaces, the current firmware and hardware version numbers, any illegal attempts to access your network, and information on all DHCP client PCs currently connected to your network.

  • Page 59: Internet Connection

    View XRT-412’s current Internet connection status and other related information Parameters Internet Connection 4.3 Device Status View XRT-412’s current configuration settings. The Device Status displays the configuration settings you’ve configured in the Quick Setup Wizard/General Setup section. Description You can see the router’s system information such as the router’s:...

  • Page 60: System Log

    Parameters Device Status 4.4 System Log View XRT-412’s system operation information. You can see the system start up time, connection process...etc. here. Parameters System Log Description This page shows XRT-412’s current device settings. This page displays XRT-412 LAN port’s current LAN IP Address, MAC Address and Subnet Mask.

  • Page 61: Security Log

    Parameters Security Log 4.6 Active DHCP Client View your LAN client's information that is currently linked to XRT-412's DHCP server or can be refreshed <Refresh> to get the most updated situation. The log only records the information of current session and will be cleared when this router shut down or restart.

  • Page 62: Statistics

    Parameters DHCP Client Log 4.7 Statistics View the statistics of packets sent and received on WAN and LAN. Parameters Statistics Description This page shows all DHCP clients (LAN PCs) currently connected to your network. The “Active DHCP Client” displays the IP address, MAC address and Time Expired of each LAN Client.

  • Page 63: Chapter 5 Tools

    This page includes the basic configuration tools, such as Configuration Tools (save or restore configuration settings), Firmware Upgrade (upgrade system firmware) and Reset. Parameters 5.1 Configuration Tools 5.2 Firmware Upgrade 5.3 Reset Select one of the above three Tools Settings selection and proceed to the manual’s relevant sub-section 5.1 Configuration Tools The Configuration Tools screen allows you to save (Backup) the router’s current configuration...

  • Page 64: Firmware Upgrade

    "config.bin" on your PC. You can then use the "Restore" tool to restore the saved configuration to XRT-412. Alternatively, you can use the "Restore to Factory Defaults" tool to force XRT-412 to perform a power reset and restore the original factory settings. Description This tool allows you to upgrade XRT-412’s system firmware.

  • Page 65: Reset

    Once you’ve selected the new firmware file, click <Apply> at the bottom of the screen to start the upgrade process. (You may have to wait a few minutes for the upgrade to complete). Once the upgrade is complete you can start using the router. 5.3 Reset You can reset the router’s system should any problem exist.

  • Page 66: Appendix A

    Appendix A How to Manually find your PC’s IP and MAC address 1) In Window’s open the Command Prompt program 2) Type ipconfig /all and <enter>...
  • Page 67 • Your PC’s IP address is the one entitled IP address (192.168.0.7) • The router’s IP address is the one entitled Default Gateway (192.168.0.1) • Your PC’s MAC Address is the one entitled Physical Address (00-48-54-12-41-44)

  • Page 68: Glossary

    Glossary Default Gateway (Router): Every non-router IP device needs to configure a default gateway’s IP address. When the device sends out an IP packet, if the destination is not on the same network, the device has to send the packet to its default gateway, which will then send it out towards the destination.
  • Page 69 NAT: Network Address Translation. This process allows all of the computers on your home network to use one IP address. Using XRT-412’s NAT capability, you can access the Internet from any computer on your home network without having to purchase more IP addresses from your ISP.
  • Page 70 Subnet Mask: A subnet mask, which may be a part of the TCP/IP information provided by your ISP, is a set of four numbers (e.g. 255.255.255.0) configured like an IP address. It is used to create IP address numbers used only within a particular network (as opposed to valid IP address numbers recognized by the Internet, which must be assigned by InterNIC).
