Planet XRT-104D User Manual

Internet broadband router
Hide thumbs Also See for XRT-104D:
Table of Contents

Advertisement

Quick Links

Download this manual
Internet Broadband Router
XRT-402D/104D
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRT-104D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Planet XRT-104D

Summary of Contents for Planet XRT-104D

  • Page 1 Internet Broadband Router XRT-402D/104D User’s Manual...

  • Page 2: Fcc Compliance Statement

    PLANET Technology. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
  • Page 3 Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.

  • Page 4: Table Of Contents

    Chapter 1 Introduction...1 1.1 Features... 1 1.2 Minimum Requirements ... 1 1.3 Package Contents... 1 1.4 Get to know XRT-D... 1 1.5 Setup Diagram ... 3 1.6 Getting started ... 3 Chapter 2 Quick Setup...11 2.1 Cable Modem... 13 2.2 Fixed-IP xDSL... 14 2.3 PPPoE ...
  • Page 5 4.1 Status and Information ... 51 4.2 Internet Connection... 52 4.3 Device Status... 52 4.4 System Log ... 53 4.5 Security Log ... 54 4.6 Active DHCP Client... 54 4.7 Statistics... 55 Chapter 5 Tools ...56 5.1 Configuration Tools... 56 5.2 Firmware Upgrade ...

  • Page 6: Chapter 1 Introduction

    Access Private LAN Servers from the Public Network Equipped with four LAN ports (10/100M), two WAN ports (10/100M) for XRT-402D. Equipped with one LAN ports (10/100M), four WAN ports (10/100M) for XRT-104D. Support DHCP (Server/Client) for easy setup Support advance features such as: Special Applications, DMZ, Virtual Servers, Access Control, and Firewall.

  • Page 7: Front Panel

    (warning: your original configurations will be replaced with the factory default settings) Front Panel On XRT-D’s front panel there are LED lights that inform you of machine current status. Below is an explanation of each LED and its description. Figure 1.0 XRT-402D Figure 1.1 XRT-104D...

  • Page 8: Setup Diagram

    Light Status LNK/ACT Flashing LAN 100 (Port 1-4) LAN LNK/ACT (Port 1-4) Flashing 1.5 Setup Diagram Figure 1.2 below shows a typical setup for a Local Area Network (LAN). 1.6 Getting started This is a step-by-step instruction on how to start using the router and get connected to the Internet.
  • Page 9 2) You then need to set your LAN PC clients so that it can obtain an IP address automatically. All LAN clients require an IP address. Just like an address, it allows LAN clients to find one another. Configure your PC to obtain an IP address automatically By default XRT-D’s DHCP is on, this means that you can obtain an IP address automatically once you’ve configured your PC to obtain an IP address automatically.
  • Page 10 8: Reboot the PC. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-D’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to Step 3 2b) Windows XP 1: Click the Start button and select Settings, then click Network Connections.
  • Page 11 5: Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-D’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to Step 3.
  • Page 12 6: Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your Broadband Router’s DHCP server. Please make sure that XRT-D’s DHCP server is the only DHCP server available on your LAN. Note: Once you’ve configured your PC to obtain an IP address automatically, please proceed to Step 3.
  • Page 13 6: Check each of the tabs and verify the following settings: IP Address: Select Obtain an IP address from a DHCP server. DNS: Let all fields are blank. WINS: Let all fields are blank. Routing: Let all fields are blank. 7: Click OK to confirm the setting.
  • Page 14 4) Once your PC has obtained an IP address from your router, enter the default IP address (broadband router’s IP address 192.168.0.1) into your PC’s web browser and press <enter> 5) The login screen below will appear. Enter the “User Name” and “Password” and then click <OK>...
  • Page 15 Menu Quick Setup Wizard (Chapter 2) General Setup (Chapter 3) Status Information (Chapter 4) Tools (Chapter 5) 7) Click on Quick Setup Wizard (see chapter 2) to start configuring settings required so that you can start accessing the Internet. The other sections (General Setup, Status Information and Tools) do not need to be configured unless you wish to implement/monitor more advance features/information.

  • Page 16: Chapter 2 Quick Setup

    The Quick Setup section is designed to get you using XRT-D as quickly as possible. In the Quick Setup you are required to fill in only the information necessary to access the Internet. Once you click on the Quick Setup Wizard in the HOME page, you should see the screen below. Step 1) Time Zone The Time Zone allows your router to base its time on the settings configured here, this will affect functions such as Log entries and Firewall settings.
  • Page 17 In this section you have to select one of many types of connections that you used to connect your broadband router to your ISP (see screen below). Different ISP’s require different methods of connecting, please check with your ISP for the types required.. Note: Menu 2.1 Cable Modem...

  • Page 18: Cable Modem

    2.1 Cable Modem Choose Cable Modem if your ISP will automatically give you an IP address. Some ISP may also require you to fill in additional information such as Host Name and MAC address (see screen below). The Host Name and MAC address section is optional and you can skip it if your ISP does not require these settings for you to connect to the Internet.

  • Page 19: Fixed-Ip Xdsl

    2.2 Fixed-IP xDSL Select Static IP Address if your ISP has given you a specific IP address for you to use. Your ISP should provide all the information required in this section. Parameters Subnet Mask Gateway IP Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the Fixed-IP xDSL connection.

  • Page 20: Pppoe

    2.3 PPPoE Select PPPoE if your ISP requires the PPPoE protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter User Name Password Service Name Connection Type Idle Time Description The User Name provided by your ISP for PPPoE connection. The Password provided by your ISP for PPPoE connection.
  • Page 21 Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the PPPoE connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. The WAN “idle timeout”...

  • Page 22: Pptp

    2.4 PPTP Select PPTP if your ISP requires the PPTP protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter Obtain an IP address automatically Use the following IP address IP Address Subnet Mask Gateway User ID...
  • Page 23 PPTP Gateway Connection ID BEZEQ-ISRAEL Connection Type Idle Time Out Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the PPTP connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. The WAN “idle timeout”...

  • Page 24: L2Tp

    2.5 L2TP Select L2TP if your ISP requires the L2TP protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Parameter Obtain an IP address automatically MAC Address Use the following IP address IP Address Subnet Mask Description...
  • Page 25 Gateway User ID Password L2TP Gateway Connection Type Idle Time Out Click <OK> when you have finished the configuration above. Congratulations! You have completed the configuration for the L2TP connection. You can start using the router now, if you wish to use some of the advance features supported by this router see chapter 3, 4, 5. The WAN “idle timeout”...

  • Page 26: Telstra Big Pond

    2.6 Telstra Big Pond Select Telstra Big Pond if your ISP requires the Telstra Big Pond protocol to connect you to the Internet. Your ISP should provide all the information required in this section. Telstra Big Pond protocol is used by the ISP in Australia. Parameter User Name Password...

  • Page 27: Chapter 3 General Settings

    Chapter 3 General Settings Once you click on the General Setup button at the Home Page, you should see the screen below. If you have already configured the Quick Setup Wizard you do NOT need to configure anything thing in the General Setup screen for you to start using the Internet. The General Setup contains advanced features that allow you to configure the router to meet your network’s needs such as: Port Forwarding, Virtual Server, Access Control, DoS, Special Applications, DMZ and other functions.

  • Page 28: System

    3.1 System The system screen allows you to specify a time zone, to change the system password and to specify a remote management user for XRT-D. Parameters 3.1.1 Time Zone 3.1.2 Password Settings 3.1.3 Remote Management Select one of the above three system settings selections and proceed to the manual’s relevant sub-section.

  • Page 29: Password Settings

    Parameter Set Time Zone Time Server Address Enable Daylight Savings Start Daylight Savings Time End Daylight Savings Time Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 30: Remote Management

    Confirmed Password Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.1.3 Remote Management The remote management function allows you to designate a host in the Internet the ability to configure XRT-D from a remote site.

  • Page 31: Wan

    Select “Enabled” to enable the remote management function. Enabled Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 32: Dynamic Ip

    3.2.8 QoS 3.2.9 DNS 3.2.10 DDNS Once you have made a selection, click <More Configuration> at the bottom of the screen and proceed to the manual’s relevant sub-section. 3.2.1 Dynamic IP Choose the Dynamic IP selection if your ISP will automatically give you an IP address. Some ISP’s may also require that you fill in additional information such as Host Name, Domain Name and MAC address.

  • Page 33: Wan Policy

    3.2.7 WAN Policy The WAN policy for multi-homing can be setup here. You can setup policy for each WAN separately. The router will balance the loading between all active WAN ports according to the Send/Receive rate of the WAN ports. You can setup an IP for the router to detect if the WAN line is connected.

  • Page 34: Qos

    3.2.8 QoS The QoS can let you classify Internet application traffic by source/destination IP, MAC address and port number. You can assign priority for each type of application and reserve bandwidth for it. The packets of applications with higher priority will always go first. Lower priority applications will get bandwidth after higher priority applications get enough bandwidth.
  • Page 35 Edit a QoS rule Adjust QoS rule priority QoS Rule: You can assign packet classification criteria by its source IP range, source MAC address, destination IP range, traffic type, protocol, source port range and destination port range parameters. The parameters that you leave as blank will be ignored. The priority of this rule will be applied to packets that match classification criteria of this rule.

  • Page 36: Dns

    Source IP Address Destination IP Address Traffic Type Protocol Source Port Range Destination Port Range Save Reset Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 37: Ddns

    Parameters Domain Name Server (DNS) Server Secondary DNS Address (optional) Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 38: Lan

    Parameters Default WAN Port Enable/Disable disable Provider DynDNS Domain name Account/E-mail Password/Key Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).
  • Page 39 Parameters Default LAN IP IP address 192.168.0.1 IP Subnet Mask 255.255.255.0 802.1d Spanning Tree Disabled DHCP Server Enabled Lease Time Description This is the router’s LAN port IP address. (Your LAN clients default gateway IP address) Specify a Subnet Mask for your LAN segment. If 802.1d Spanning Tree function is enabled, this router will use the spanning tree protocol to prevent from network loop happened in the LAN...

  • Page 40: Nat

    IP Address Pool Domain Name Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.4 NAT Network Address Translation (NAT) through a single Public IP Address or multiple Public IP Addresses.

  • Page 41: Port Forwarding

    3.4.2 Virtual Server 3.4.3 Special Applications 3.4.4 UPnP 3.4.5 Protocol and Port Binding 3.4.6 ALG Setting Click on one of the three NAT selections and proceed to the manual's relevant sub-section. 3.4.1 Port Forwarding The Port Forwarding allows you to re-direct a particular range of service port numbers (from the Internet/WAN Ports) to a particular LAN IP address.

  • Page 42: Virtual Server

    Parameter Enable Port Forwarding Private IP Type Port Range WAN Port Comment Add Port Forwarding into the table Remove Port Forwarding into the table Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot”...
  • Page 43 Internet/WAN Port) to a particular LAN private IP address and its service port number. (See Glossary for an explanation on Port number) Parameters Enable Virtual Server Private IP Private Port Type Public Port WAN Port Comment Add Virtual Server Description Enable Virtual Server.

  • Page 44: Special Applications

    Remove Virtual Server Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.4.3 Special Applications Some applications require multiple connections, such as Internet games, video conferencing, Internet telephony and others.
  • Page 45 Trigger Type Public Port Public Type Comment Popular applications Add Special Application Remove Special Application Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 46: Upnp

    28800 6112 In the example above, when a user trigger’s port 28800 (outbound) for MSN Game Zone then the router will allow incoming packets for ports 2300-2400 and 47624 to be directed to that user. Note: Only one LAN client can use a particular special application at a time. 3.4.4 UPnP With UPnP, all PCs in you Intranet will discover this router automatically.

  • Page 47: Protocol And Port Binding

    Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.4.5 Protocol and Port Binding Protocol and Port Binding let you manually bind an application to a WAN port.

  • Page 48: Alg Settings

    Destination Port Range Protocol WAN Port Add a Rule Remove a Rule Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 49: Firewall

    Parameters Default Enable Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.5 Firewall XRT-D provides extensive firewall protection by restricting connection parameters, thus limiting the risk of hacker attack, and defending against a wide array of common Internet attacks.

  • Page 50: Access Control

    Click on one of the firewall selections and proceed to the manual’s relevant sub-section 3.5.1 Access Control If you want to restrict users from accessing certain Internet applications/services (e.g. Internet websites, email, FTP etc.), then this is the place to set that configuration. Access Control allows users to define the traffic type permitted in your LAN.
  • Page 51 After press “Apply and Reboot” to apply the configuration and reboot the XRT-D router, you can now configure other advance sections or start using the router (with the advance settings in place). Add PC Parameters Client PC Description Client PC IP Addresses and then click "Delete Selected".

  • Page 52: Url Blocking

    Client PC Service Protocol Port Range Apply Changes Reset Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 53: Denial Of Service (Dos)

    Remove URL / Keyword After press “Apply and Reboot” to apply the configuration and reboot the XRT-D router, you can now configure other advance sections or start using the router (with the advance settings in place). 3.5.3 Denial of Service (DoS) XRT-D's firewall can block common hacker attacks, including Denial of Service, Ping of Death, Port Scan and Sync Flood.

  • Page 54: Dmz

    Sync Flood Click <Save> at the bottom of the screen to save the above configurations and press “Apply and Reboot” to apply the configuration and reboot the XRT-D router. You can now configure other advance sections or start using the router (with the advance settings in place). 3.5.4 DMZ If you have a local client PC that cannot run an Internet application (e.g.
  • Page 55 Public IP Address Client PC IP Address Add DMZ Remove DMZ After press “Apply and Reboot” to apply the configuration and reboot the XRT-D router, you can now configure other advance sections or start using the router (with the advance settings in place).

  • Page 56: Chapter 4 Status

    The Status section allows you to monitor the current status of your router. You can use the Status page to monitor: the connection status of XRT-D's WAN/LAN interfaces, the current firmware and hardware version numbers, any illegal attempts to access your network, and information on all DHCP client PCs currently connected to your network.

  • Page 57: Internet Connection

    Parameters Information 4.2 Internet Connection View XRT-D’s current Internet connection status and other related information. Parameters Internet Connection 4.3 Device Status View XRT-D’s current configuration settings. The Device Status displays the configuration settings you’ve configured in the Quick Setup Wizard/General Setup section. Description You can see the router’s system information such as the router’s Hardware version, Serial Number, Boot code Version, Runtime...

  • Page 58: System Log

    Parameters Device Status 4.4 System Log View the operation log of the system. Parameters System Log Description This page shows XRT-D’s current device settings. This page displays XRT-D LAN port’s current LAN IP Address, MAC Address and Subnet Mask. It also shows whether the DHCP Server function is enabled or disabled.

  • Page 59: Security Log

    4.5 Security Log View any attempts that have been made to illegally gain access to your network. Parameters Security Log 4.6 Active DHCP Client View your LAN client's information that is currently linked to XRT-D's DHCP server Description This page shows the current security log of XRT-D. It displays any illegal attempts to access your network.

  • Page 60: Statistics

    Parameters DHCP Client Log 4.7 Statistics View the statistics of packets sent and received on each WAN and LAN interface. Parameters Statistics Description This page shows all DHCP clients (LAN PCs) currently connected to your network. The “Active DHCP Client” displays the IP address and the MAC address and Time Expired of each LAN Client.

  • Page 61: Chapter 5 Tools

    This page includes the basic configuration tools, such as Configuration Tools (save or restore configuration settings), Firmware Parameters 5.1 Configuration Tools 5.2 Firmware Upgrade 5.3 Reset Select one of the above three Tools Settings selection and proceed to the manual’s relevant sub-section 5.1 Configuration Tools The Configuration Tools screen allows you to save (Backup) the router’s current configuration...

  • Page 62: Firmware Upgrade

    Parameters Configuration Tools 5.2 Firmware Upgrade This page allows you to upgrade the router’s firmware Parameters Firmware Upgrade Description Use the "Backup" tool to save XRT-D current configuration to a file named "config.bin" on your PC. You can then use the "Restore"...

  • Page 63: Reset

    Once you’ve selected the new firmware file, click <Apply> at the bottom of the screen to start the upgrade process. (You may have to wait a few minutes for the upgrade to complete). Once the upgrade is complete you can start using the router. 5.3 Reset You can reset the router’s system should any problem exist.

  • Page 64: Appendix A

    Appendix A How to Manually find your PC’s IP and MAC address 1) In Window’s open the Command Prompt program 2) Type ipconfig /all and <enter>...
  • Page 65 Your PC’s IP address is the one entitled IP address (192.168.0.7) The router’s IP address is the one entitled Default Gateway (192.168.0.1) Your PC’s MAC Address is the one entitled Physical Address (00-48-54-12-41-44)

  • Page 66: Glossary

    Glossary Default Gateway (Router): Every non-router IP device needs to configure a default gateway’s IP address. When the device sends out an IP packet, if the destination is not on the same network, the device has to send the packet to its default gateway, which will then send it out towards the destination.
  • Page 67 ISP Gateway Address: (see ISP for definition). The ISP Gateway Address is an IP address for the Internet router located at the ISP's office. ISP: Internet Service Provider. An ISP is a business that provides connectivity to the Internet for individuals and other businesses or organizations.
  • Page 68 Subnet Mask: A subnet mask, which may be a part of the TCP/IP information provided by your ISP, is a set of four numbers (e.g. 255.255.255.0) configured like an IP address. It is used to create IP address numbers used only within a particular network (as opposed to valid IP address numbers recognized by the Internet, which must be assigned by InterNIC).
