** After purchase, please check the battery and charge the battery before use.
** Please refer to the FAQ section on the Aurender homepage for any information you do not find here.
Product Description
Portable DAC & Headphone Amplifier
- The Aurender FLOW is a portable High Fidelity Headphone Amp.
- Capable of playing up to 32bit/384KHz PCM and DSD128 (DoP).
Portable Storage Device Function
The USB2.0 and USB3.0 ports enable fast data transfers. In addition to video, audio, image files, the FLOW can
also be used to store business files, presentations, back-up and other data.
Can be used as a storage device with desktop PCs, laptops, notebooks and is compatible with a variety of OS
systems.
You can play music stored in FLOW's mSATA driver from PC or Mac
* You need to format the mSATA disk after you install. Please refer to the OS (Windows, Mac) manual for
formatting mSATA. The procedure is the same as formatting HDDs.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aurender FLOW
Summary of Contents for Aurender FLOW
-
Page 1: Product Description
- Capable of playing up to 32bit/384KHz PCM and DSD128 (DoP). Portable Storage Device Function The USB2.0 and USB3.0 ports enable fast data transfers. In addition to video, audio, image files, the FLOW can also be used to store business files, presentations, back-up and other data. - Page 2 You can change the settings by pressing the Menu button ⑤ Power button Press & hold the button for about 2 seconds. The FLOW will power up. It will show the current Host mode for a few seconds. * FLOW will automatically turn off if it's not used for about 15 seconds.
- Page 3 Please set the mode when used with the PC with the USB2.0. When FLOW is connected to PC with USB 3.0 port and the mode is set to USB3, the copy speed and charge speed becomes faster than USB2.0 mode. You need a USB3.0 cable to fully utilize the speed of USB3.0.
- Page 4 Can be used to play music from sources with optical outputs. * You can use the MENU button to change input when both USB and optical connection are connected. If only one connection is connected, FLOW will use the connection automatically.
- Page 5 Display The display shows the volume level, audio file data, battery and other information. On when USB Host is connected On when optical connection is connected On when the file played is DSD, it will show also the bit rate of DSD 64 or 128 Battery gauge meter.
-
Page 6: Operation
Section for details. Using the optical input When only the optical cable is plugged to the FLOW from the music player, FLOW's input mode will be set to Optical automatically. When both optical and USB connections are maintained, long press the On/Off Power button to access the menu to set the audio input to Optical. - Page 7 Drive installation *FYI, the SAMSUNG mSATA is an example of the mSATA drive which is compatible with the FLOW *Please follow the instructions below when installing a new mSATA SSD. Remove the 4 screws on the rear panel of the main case.
- Page 8 The FLOW driver for PCs with Windows OS can be downloaded from the Aurender website at (www.aurender.com). This USB Audio Driver enables the PCs with Windows OS to be connected to and used with the Aurender FLOW. Download the drive shown below which is for PCs using Windows OS, and install.
-
Page 9: Battery Charging
Using the USB 2.0 port of PC for charging will be very slow because it can draw only 500mA from the port. When the mode is iOS or anDR, FLOW will not be charged from the device not to draw current from the phones.
