Video outdoor station
Table of Contents
Pos: 30 /CNDEX/01 Heading/1.1 Heading/Heading_Terminal description @ 56\mod_1487747555712_15.docx @ 750072 @ 2 @ 1
5.3
Terminal description
Pos: 31 /CNDEX/05 Terminal description/Terminal description_H8137xPx-S_H8137xK-S_OS @ 57\mod_1488953435060_15.docx @ 759777 @ @ 1
H8137xK-S
Connector
Connector
Upgrade
Prog.
Connector
Fig. 2:
Terminal description of audio part
No.
1
2
3
4
5
6
7
8
9
10
Tab.2:
Description
Operating Instructions VER:1.0
H8137xPx-S
Connector
USB connector for software updating from PC.
Boot button
Press and hold this button for 3 s to enter upgrading mode when the power is on.
Set button
Press and hold this button for 3 s to enter configuration mode when the power is on.
And press and hold this button for 5 s to restore to factory setting after the power is
on.
Connector for software updating of this module
Connector for sensor used for door status detection
Connector for exit push-button
Connector for next module
Plug-in clamps (COM-NC-NO) for floating output, door opener (30 VAC/DC 1A)
Plug-in clamps (LOCK-GND) for door opener (18V 4A impulsive, 250 mA holding)
Plug-in clamps (DC+-GND) for standalone power supply
Product description
4
5
6
7
Function
1
2
SET BOOT
3
8
9
10
│7
