Summary of Contents for Planar PQ1910M
- Page 1 PQ1910M LCD Monitor USER’S GUIDE www.planar.com...
- Page 3 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced, translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
-
Page 5: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY For Your Safety -------------------------------------------------------------------------------------6 GENERAL NOTES 1. Introduction--------------------------------------------------------------------------------------8 1.1 General Information 1.2 Features 1.3 Check List 2. Installation --------------------------------------------------------------------------------------9 2.1 Installing the base 2.2 Installing the monitor 2.3 Self test pattern 2.4 Adjusting picture 3. -
Page 6: For Your Safety
FOR YOUR SAFETY Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 7 PRECAUTIONS 1. Unplug the monitor from the power source when you clean the monitor. Do not use liquid cleaners or aerosol cleaners. Use a cloth to clean it. If that doesn’t do, please use LCD screen cleaners. 2. Do not use attachment not recommended as they may cause hazards. 3.
-
Page 8: General Notes
GENERAL NOTES 1.Introduction 1.1 General Information This monitor is a high-performance intelligent multi-scanning color monitor utilizing active matrix TFT LCD display that uses amorphous silicon TFT as a switching device. With very low radiation, anti-glare surface treatment and small footprint, it is very suitable for home and office applications. 1.2 Features LCD TFT 19"... -
Page 9: Installation
2. Installation The following chapters explain how to install the base and connect the monitor to your personal computer. 2.1 Installing the Base Follow these steps to install the base: 1. Lay the monitor face down. 2. Assemble the base to the arm with screw. 3. -
Page 10: Self Test Pattern
2.3 Self Test Pattern If there is no horizontal or vertical signal, your monitor will display the self test pattern to indicate no signal input. After a few seconds, the monitor will enter into waiting and saving power mode. The LED will be red and flashing. Once the monitor receives the video signal, it will return to normal mode. -
Page 11: Operation Of The Monitor
3. Operation of the Monitor 3.1 Power On/Off Switch This is a light-touch digital-control key. It is used to turn the monitor on or off. 3.2 Power LED Indicator When the monitor is working, the power LED is green. If the monitor is in saving power mode, the power LED will be red and flashing. - Page 12 16. Selected function name 17. Resolution 18. H-frequency 19. V-frequency 20. Progressive bar of adjustment 21. Percentage of adjustment 22. Planar LOGO 3.3.5 Meaning of the Menu in DVI Mode 1. Brightness 2. Contrast 3. Sharpness 4. Volume 5. OSD menu display time 6.
- Page 13 3.3.6 Function Table Display contents AUTO ADJUSTMENT BRIGHTNESS CONTRAST H-POSITION V-POSITION CLOCK PHASE SHARPNESS COLOR 9300K COLOR TEMPERATURE 7800K COLOR TEMPERATURE 6500K COLOR TEMPERATURE USER MODE AUTO COLOR BALANCE VOLUME OSD DISPLAY TIME OSD ADJUSTMENT OSD H-POSITION OSD V-POSITION OSD TRANSPARENCY Signal source RECALL LANGUAGE...
- Page 14 3.3.7 Special Functions Auto Adjustment ( When you choose this function, the monitor will enter into automatically adjustment mode. After a few seconds, the monitor will be in the best visual display mode. Color Adjustment ( When the function is selected, the monitor will come into the sub-menu, there are five functions that can be selected: 9300k, 7800k, 6500k, USER,W-B.
-
Page 15: Safety Mode
3.4 Safety Mode When the video signal exceeds the frequency range of the MCU will stop horizontal and vertical scanning in order to protect the monitor the following image will be displayed on the screen. After a few seconds, the monitor will enter turn-off mode. -
Page 16: Plug & Play
3.6 Plug & Play This monitor meets the standard of VESA DDC. When using video card with VESA DDC1/2B, it will auto-scan video frequency, output power , function and other data to the PC when computer is on. It will go into the proper video mode and frequency. -
Page 17: Specifications
Storage temperature and humidity Operating temperature Humidity Unpacking dimension Packing dimension Net weight Gross weight Note: These specifications are subject to change without notice. PQ1910M 19″ 1280 x 1024 376 mm x 301mm 0.294mm x 0.294mm 700:1 300 cd/m 16.2 M H:140°V:140°... -
Page 18: Simple Troubleshooting
5. Simple Troubleshooting Symptom Solution Check if the power cord, the monitor and the power plug No picture / no LED are well connected. Check also if the monitor is off. Check if the PC video card and signal cable are well picture connected and check if signal cable is properly connected flashing... - Page 20 Tel：1-866-PLANAR-1 (1-866-752-6271) Hours：M-F, 8am-8pm Eastern Time (5am-5pm Pacific Time) © 2006 Planar Systems, Inc. Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
