- Page 1 PL2011 LCD Monitor USER’S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Table of Contents Table of Contents...1 Preface ...2 Chapter 1 Installation...4 Unpacking ... 4 Height Adjustment Stand ... 5 Tilt, Swivel and Pivot Rotation ... 5 Connecting the Display to your Computer ... 5 Connecting the AC Power... 5 Connecting the Audio Cable ... 5 Optional Mounting Alternatives... -
Page 3: Preface
Preface This manual is designed to assist users in setting up and using the PL2011M LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. This document contains proprietary information protected by copyright. -
Page 4: Important Safety Instructions
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean LCD Monitor screen: -- Power off LCD Monitor and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a rag. -- Gently clean the screen with dampened rag. -
Page 5: Chapter 1 Installation
* Monitor-to-PC VGA Cable * Monitor-to-PC DVI-D Cable Planar Connections CD-ROM If you find that any of these items is missing or appears damaged, contact your dealer immediately. For future reference, write the following information about your monitor in the space below. -
Page 6: Height Adjustment Stand
Height Adjustment Stand To unlock the height adjustment feature of the stand, locate the pin on the back of the stand column and turn the pin knob counter-clockwise. (See fig.1-1 ) Tilt, Swivel and Pivot Rotation The LCD Monitor is designed to have a tilt range of -5°to +25°, a swivel range of -35°to +35°, and a 90°... -
Page 7: Optional Mounting Alternatives
Optional Mounting Alternatives Warning: The monitor stand base may forcefully extend and cause injury. Raise the monitor to its "Full Up" position before removing the monitor stand. Detaching LCD Monitor from Its Stand Unscrew screws the swivel base support column and pull down second. -
Page 8: Chapter 2 Display Controls
Chapter 2 Display Controls User Controls A brief description and the location of all LCD Monitor functions control and indicator: Stereo Speakers Speaker Volume Control Soft Power Switch Power-On Indicator Function Select Buttons Adjustment Control Buttons External Headphone Jack Adjusting the Monitor's Display The monitor has four function control buttons to select among functions shown on OSD menu, designed for easy user-viewing environments. -
Page 9: Function Description
Function Description Function Brightness Contrast Horizontal Position Vertical Position OSD Transparency Phase Clock Color Temperature Horizontal OSD Position This function moves the OSD menu window horizontally. Vertical OSD Position This function moves the OSD menu window vertically. Graph Text Recall Language Auto and Input Select Exit... -
Page 10: Chapter 3 Technical Information
Chapter 3 Technical Information Specifications LCD Panel Size Display Type Resolution Display Dot Display Area (mm) Display Color Brightness Contrast Ratio Response Time Lamp Voltage Lamp Current Viewing Angle Video Input Signal Input Impedance Polarity Amplitude Multi-mode Supported Audio Input Output Control Power switch (hard and soft types) -
Page 11: External Connection
Sync Input Signal Polarity Plug & Play External Connection Power Input (AC input) Video Cable Audio Cable Environment Operating Condition: Storage Condition: Power Supply (AC Input) Input Voltage Input Current Size and Weight Dimensions Net Weight Gross Weight Separate TTL compatible horizontal and vertical synchronization Digital TMDS Positive and negative Supports VESA DDC2B functions... -
Page 12: Standard Timing Table
Standard Timing Table If the selected timing is NOT included in table below, this LCD monitor will use the most suitable available timing. TIMING FH(KHZ) SYNC FV(HZ) POLARITY 640x350 31.469 VGA-350 70.087 – 640x400 24.83 – NEC PC9801 56.42 – 640x400 31.469 –... -
Page 13: Troubleshooting
Troubleshooting This LCD Monitor has pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market, users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected.
