- Page 1 PLANAR LCD MONITOR PE150 MANUAL www.planar.com...
-
Page 3: Table Of Contents
Table of Contents Preface ...2 Chapter 1 Installation...4 Unpacking ... 4 Connecting the LCD Monitor and Base ... 4 Viewing Angle Adjustment... 4 Detaching LCD Monitor from Its Stand... 5 Interface for Arm Applications... 5 Connecting the Display to your Computer ... 5 Connecting the AC Power... -
Page 4: Preface
Preface This manual is designed to assist users in setting up and using the LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean LCD Monitor screen; -- Power off LCD Monitor and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a rag. -- Gently clean the screen with dampened rag. -
Page 6: Chapter 1 Installation
Chapter 1 Installation Unpacking Before unpacking the LCD Monitor, prepare a suitable workspace for your Monitor and computer. You need a stable and clean surface near a wall power outlet. Make sure that LCD Monitor has enough space around it for sufficient airflow. Though the LCD Monitor uses very little power, some ventilation is needed to ensure that the Monitor does not become too hot. -
Page 7: Detaching Lcd Monitor From Its Stand
Detaching LCD Monitor from Its Stand 1. Unscrew screws of the hinge bracket 2. Remove the stand from LCD monitor Interface for Arm Applications Before installing to mounting device, please refer to Fig.1-3. The rear of this LCD display has four integrated 4 mm, 0.7 pitches threaded nuts, as well as four 5 mm access holes in the plastic covering as illustrated in Figure 1-4. -
Page 8: Power Management System
Power Management System This LCD Monitor complies with the VESA DPMS (version 1.0) Power Management guidelines. The VESA DPMS provides four power saving modes through detecting a horizontal or vertical sync. signal. When the LCD Monitor is in power saving mode, the monitor screen will be blank and the power LED indicator will light yellow. -
Page 9: Function Description
Function Description Icon Function Brightness This function increases or decreases the brightness of the image. This function increases or decreases the difference between the dark and light Contrast color. H-Position This function shifts the entire display image left or right. V-Position This function shifts the entire display image up or down. -
Page 10: Chapter 3 Technical Information
Chapter 3 Technical Information Specifications LCD Panel Size 15.0" (38 cm) Display Type Active matrix color TFT LCD Resolution 1024 x 768 Display Area (mm) 304 x 228 (H x V) Brightness 200 cd/m Contrast Ratio 400:1 (typical) Response Time 35 ms (typical) Viewing Angle Vertical: -55°... -
Page 11: Standard Timing Table
Sync Input Signal Separate TTL compatible horizontal and vertical synchronization Polarity Positive and negative Supports VESA DDC1 and DDC2B functions Power Input (AC input) AC socket Video Cable 1.5M with 15-pin D-sub connector Operating Condition: Temperature Relative Humidity Storage Condition: Temperature Relative Humidity Input Voltage... -
Page 12: Troubleshooting
Troubleshooting This LCD Monitor has pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market, users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected. Attention This LCD Monitor Supports Multiple VGA Modes. - Page 13 Tel: 1-866-PLANAR-1 (1-866-752-6271) Hours: M-F, 8am - 9pm Eastern Time © 2003 Planar Systems, Inc. 05/03 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
