Pitco E24 Specifications

Model E24 & E34
Electric Donut Fryer
STANDARD ACCESSORIES
Tank - stainless steel construction
Cabinet - stainless front, door, back and sides
Electric Thermostat
On/Off Switch
Indicating lights
Drainboard (also used as fryer cover)
Hinged wire mesh submerger screen wtih safety grid
handles
Two nickle plated wire mesh screens with handles
Wire mesh tube screen
6" (15.2 cm) legs adjustable
One drain extension
One drain line clean-out rod
Donut turner sticks (2)
AVAILABLE OPTIONS & ACCESSORIES
Cover
6" (15.2 cm) adjustable casters, front locking
Donut dropper bracket
(includes flanged bolt-down leg assembly)
480 Volt Service
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 1509 Route 3A, Bow NH 03304, USA
Project
Item No.
Quantity
STANDARD SPECIFICATIONS
CONSTRUCTION
CONTROLS
OPERATIONS
APPROVALS
(At Additional Cost)
(603) 225-6684 Fax (603) 225-8472 www.pitco.com
L10-029 Rev 8 (06/07)
Tank constructed of durable stainless steel with an
extra smooth peened finish for easy cleaning.
Immersion type; sealed construction heating
elements with high temperature alloy stainless
sheath.
Element design makes cleaning easy.
Provision for tie-in with fire protection systems.
Temperature limit automatically shuts off all power
to the heating elements if the fryer temperature
exceeds the upper limit.
Three position switch (OFF/ON/START) for fryer
control.
Two position switch (MELT ON/MELT OFF) for melt
cycle control.
White power ON light.
Amber temperature light indicates when elements
are heating.
Thermostat maintains temperature automatically at
selected temperature (between 200 F (93 C) and
400 F (204 C))
Front 1" NPT drain, for quick draining.
Selected fryer operating mode (on or melt cycle)
from the front control switch.
NSF Listed
MEA Approved
UL Listed
CSA Certified
