Summary of Contents for Optimus 40
- Page 1 OWNERÕS MANUAL Model 40 AC-DC Video Cassette Player Please read before using this equipment. MODEL 40 VIDEO CASSETTE PLAYER AC /DC 12V OPERATION DIGITAL AUTO TRACKING POWER PLAY STOP EJECT REWIND FAST F - STILL FAST F - REPEAT POWER...
- Page 2 Freeze-Frame Ñ lets you pause the tape during playback so you can view a single frame. © 1999 Tandy Corporation. All Rights Reserved. Optimus and RadioShack are registered trademark used by Tandy Corporation.
- Page 3 Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK. NO USER-SERVICE- ABLE PARTS INSIDE.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS These simple precautions will help ensure that Power Sources Ð Operate product only from you get many years of safe enjoyment from your type of power source indicated on marking label. new product. If you are not sure of the type of power supply to your home, consult your product dealer or local Read Instructions Ð... - Page 5 Lightning Ð For added protection for this product Replacement Parts Ð When replacement part(s) during a lightning storm, or when product is left are required, be sure service technician has used unattended and unused for long periods of time, replacement part(s) specified by manufacturer or unplug it from the wall outlet and disconnect have same characteristics as original part(s).
-
Page 6: Table Of Contents
CONTENTS Preparation .........................5 Accessories......................5 Choosing a Location ....................5 Making Connections ....................6 Connecting a Standard TV................7 Connecting a TV Monitor .................8 Connecting a VCR ...................9 Setting the Channel Switch ..................10 Connecting Power....................10 Using AC Power.....................10 Using Vehicle Battery Power .................11 Dew Protection System..................12 Installing the Remote ControlÕs Batteries .............12 VCP Status Display....................13 How to Access Menu ...................13... -
Page 7: Preparation
PREPARATION ACCESSORIES AC Adapter Ñ lets you power the VCP from a standard AC outlet. Your VCP includes the following connec- tion accessories. Be sure to unpack all of them before you throw away the packing material. 300-to-75-ohm Adapter Ñ connects a 300-ohm antenna wire to the VCPÕs ANT.IN terminal. -
Page 8: Making Connections
This reminder is provided to call the CATV system installerÕs attention to arti- You can connect your VCP to a TV mon- cle 820-40 of the NEC that provides itor, a VCR (video cassette recorder), or guidelines for proper grounding and, in both. -
Page 9: Connecting A Standard Tv
Follow these steps to connect the VCP to a standard TV that has a 75-ohm cable jack (but does not have separate audio and video input jacks). VHF/UHF Antenna 300-ohm 75-ohm MODEL 40 ANT.IN 75-Ohm Coaxial Cable CHANNEL VIDEO RF.OUT... -
Page 10: Connecting A Tv Monitor
Video ANT.IN Video CHANNEL VIDEO RF.OUT AUDIO DC IN 12V Audio MODEL 40 Caution: You must use video-quality cable for this type of connection. Do not use standard audio cable. Your local RadioShack store sells the proper type of cable. -
Page 11: Connecting A Vcr
Connecting a VCR To connect your VCP to a VCR so you can copy video tapes, connect the VCPÕs AU- DIO and VIDEO OUT jacks to the VCRÕs audio and video input jacks using video- quality shielded cable (not supplied). Then see ÒCopying a Video TapeÓ on Page 17 to find out how to copy a tape. -
Page 12: Setting The Channel Switch
SETTING THE CHANNEL in and operate it. This allows any damaging moisture to completely SWITCH evaporate. CHANNEL, on the back of the VCP, de- ¥ If moisture has formed inside the termines on which channel (3 or 4) a VCP, it might not operate after you standard TV receives the VCPÕs signal. -
Page 13: Using Vehicle Battery Power
AC outlet. be sure to disconnect the DC adapter from the cigarette-lighter MODEL 40 socket when you are not using the VCP and TV, to prevent your vehi- cleÕs battery from being drained. -
Page 14: Dew Protection System
VCP does not let you 1. Remove the battery compartment play a tape. cover, by sliding it in the direction of the arrow. Indicator MODEL 40 VIDEO CASSETTE PLAYER AC /DC 12V OPERATION DIGITAL AUTO TRACKING POWER PLAY STOP... -
Page 15: Vcp Status Display
3. Replace the cover. Current mode of operation display STOP, PLAY, FF(Fast Forward) etc. Notes: Real-time tape counter display ¥ If you will not be using the remote control for a month or more, remove the batteries. Note: ¥ You can use the remote control up ¥... -
Page 16: Operation
VCPÕs front panel, then press the desired button(s). 3. To load a video cassette tape, insert MODEL 40 VIDEO CASSETTE PLAYER the tape halfway into the VCPÕs cas- AC /DC 12V OPERATION DIGITAL AUTO TRACKING... -
Page 17: Fast-Forward/Rewind
5. To eject the tape, press EJECT. The Or, to stop fast-forwarding and rewinding CST.IN indicator flashes then turns and automatically begin play, press off and the VCP ejects the tape. PLAY. The tape stops, the PLAY indicator lights, then the tape begins to play. -
Page 18: Freeze-Frame
Note: AUTO REPEAT PLAYBACK ¥ Tapes recorded at the EP (extended play) speed provide the best picture during visual search. You can set the VCP to continuously play, rewind, then repeat a tape. To set the VCP for auto repeat playback, before or during normal playback, press FREEZE-FRAME A-REPEAT so the A-REPEAT indicator... -
Page 19: Watching Broadcast Tv
For poor quality or worn tapes, you might 2. Load a blank video cassette, or one need to further adjust the VCPÕs tracking. you want to record over, into the To adjust the picture tracking manually, VCR. press and hold down TRACKING 3. -
Page 20: Troubleshooting
TROUBLESHOOTING GUIDE If your VCP is not performing as it should, these suggestions might help. If you still cannot solve the problem, take the VCP to your local RadioShack store for assistance. Symptom Possible Cause Remedy No power. Power is not connected. Plug the AC adapter into an AC outlet or connect the DC adapter to your vehicleÕs... - Page 21 Symptom Possible Cause Remedy Control buttons do not work Condensation on video Unplug the VCP for about 2 when the power is on and a heads/dew protection hours, or until DEW does not video cassette is inserted. system is active. turn on when you plug it in, then proceed.
-
Page 22: Care And Maintenance
CARE AND MAINTENANCE Your Optimus Model 40 AC-DC Video Cassette Player is an example of superior design and craftsmanship. The following suggestions will help you care for the VCP so you can enjoy it for years. Keep the VCP dry. If it gets wet, wipe it dry immediately. Liquids might contain minerals that can corrode the electronic circuits. -
Page 23: Cleaning The Video Heads
CLEANING THE VIDEO ¥ Store your video cassettes on their ends, not on their sides. This HEADS prevents improper setting of the cassetteÕs spools. Dirty video heads can cause the VCPÕs picture to be blurred during playback, even when the video signal is clear. We recommend that you clean the heads only when such problems occur. -
Page 24: Replacing The Fuse
REPLACING THE FUSE THE FCC WANTS YOU TO KNOW If the VCP does not operate when the DC adapter is connected, the fuse inside the Your VCP might cause TV or radio inter- adapter might be blown. Follow these ference even when it is operating proper- steps to replace it. -
Page 25: Specifications
Video S/N Ratio: SP ....................More than 43 dB LP/EP ...................More than 42 dB Audio S/N Ratio: SP ....................More than 42 dB LP/EP ...................More than 40 dB Specifications are typical; individual units might vary. Specifications are subject to change and improvement without notice. - Page 26 RadioShack Limited Warranty This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for ninety (90) days from the date of purchase from RadioShack companyowned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HAREIN, RadioShack MAKES NO EXPRESS WARRANTIES FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN.
