Daewoo DDC500 Service Manual

Daewoo DDC500 Service Manual

Hide thumbs

Advertisement

Quick Links

DDC5000001
Digital Camera
Model : DDC500
NOV. 2005

Advertisement

loading
Need help?

Need help?

Do you have a question about the DDC500 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DDC500

Summary of Contents for Daewoo DDC500

  • Page 1 DDC5000001 Digital Camera Model : DDC500 NOV. 2005...

  • Page 2: Table Of Contents

    Model Name: DS-5340 Contents Warning Function Test Troubleshooting Explode diagram Service Parts Lists Packing Diagram Firmware update procedure Premier confidential...

  • Page 3: Warning

    2. Warning If you are using AC power adapter, unplug the adapter from the AC power outlet after you have disconnected the camera. Do not touch the power plug during a thunderstorm if you are using the AC power adapter. This may cause an electrical shock. Do not insert or drop metallic or inflammable foreign objects into the camera through access points such as the memory card slot.

  • Page 4: Function Test

    3. Function Test TOOL/EQUIPMENT SD card*2, TV, AC adapter, lens-wiping paper USB cable, flower, accessory, computer OPERATION DESCRIPTION ITEM OPERATION DESCRIPTION Power on: Insert base, SD card and AC adapter and power on. Check if start-up sound and image are correct. Preview display test: Take photos towards beyond and vicinity separately in Capture Mode.
  • Page 5 Format SD card & internal memory (it can be done when connect to TV): Press MENU button in Playback Mode. Select Format in Setup and Format SD card; Take out SD card after format is ok and set SD card to lock state.

  • Page 6: Troubleshooting

    4. Troubleshooting Item NG point NG Analyzing solution Power system Power on fail 1>. Check if the connection between MCU (Without current) board and Power board is OK; 2>. Check if the fuse F801, F802 on power board are broken; 3>.
  • Page 7 Noise 1>. Check if lens is normal. Change another lens; 2>. Check if power wire of camera is OK. Display and TFT-LCD is too dark 1>. Check if the power, resistance and image system audion of LCD back light circuit are OK; 2>.
  • Page 8 Fail to trigger/ miss 1>. Check if the tube is offset, tube wire is flash cold soldering, insufficient soldering, and lampshade/ flash wire are insulated well; 2>. If 1> is normal, check if lampshade and copper foil contact is OK, contact resistance of lampshade and tube is infinite;...

  • Page 9: Explode Diagram

    5. Explode diagram Reference only Part order; please refer to Section 6 Service Parts List Any alteration of parts number is conducted by sales representative.

  • Page 10: Service Parts Lists

    6. Service Parts List Item Parts Name Pcs / set Premier P/N Remark Front Cover ASSY 9M744-4200 Rear Cover ASSY 9M744-4400 TOP Cover 9M734-400-3AG Main PCB ASSY 9M747-0101 Power PCB ASSY 9M747-8101 SW1 PCB 9M747-6000 Lens Module ASSY 1 9M746-6000 Main frame 9M744-4800 Battery Cover...

  • Page 11: Packing Diagram

    Packing Diagram...
  • Page 12 Part name Part number CE/FCC S/N LB 9M738-500 HDPE BAG 04039-023-1 POUCH 9M739-301-PRE STRAP 9E538-000 KIT PAD 9M739-200 KIT BOX 9M739-240-PRE PP BAG 04039-095A INSTRUCTION MANUAL 9M739-400 CD-ROM 9M739-A00 C/T PAD 9A339-694 C/T PAD 9A339-695 9A339-602...
  • Page 13 To update this camera firmware, you will need to have 1. The new firmware file from Premier. 2. One SD card. 3. One card reader. Please follow the steps below to perform the update process: 1. Prepare a formatted and empty SD card. 2.
