NAMES OF OVEN PARTS AND ACCESSORIES

Remove the oven and all materials from the carton.
Your oven comes with the following accessories:
1 Turntable
1 Turntable roller rest
1 Instruction Manual
Safety interlock system
Shuts off oven power if door is
opened during operation

TURNTABLE INSTALLATION

Turntable
Roller rest
Receptacle
1. Place the roller rest on the cavity
bottom.
2. Place the turntable on top of the
roller rest as shown in the
diagram. Make sure the turntable
hub is securely locked in the
receptacle.
SET UP
Cabinet
Door
Door release button
• Press the button to open door.
• When you open the door during
cooking process, the cooking stops but
the program will not be canceled.
Touch START to resume cooking.
.
• Never place the turntable upside
down. The turntable should never
be restricted.
• Both turntable and roller rest
must always be used during
cooking.
• All food and containers of food
are always placed on the
Hub(underside)
turntable for cooking.
• The turntable returns to its
original starting position when
cooking is finished. The light and
fan will remain on but microwave
power is turned off.
• The turntable rotates clockwise
and counterclockwise; this is
normal.
• If turntable or roller rest cracks or
breaks, contact your nearest
authorized service center.
8
Interior light
Control panel
