Coemar Softlite LED RGBW Instruction Manual

Hide thumbs Also See for Softlite LED RGBW:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Instruction manual
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Softlite LED RGBW and is the answer not in the manual?

Questions and answers

Related Manuals for Coemar Softlite LED RGBW

Summary of Contents for Coemar Softlite LED RGBW

  • Page 1 Instruction manual Version 1.1...
  • Page 3 Italiano Serial Number: ..................................Purchase date: ..................................Dealer: ..................................Address: ..................................Suburb: ..................................Country: ..................................Phone / Fax: ..................................Please note in the space provided above the relative service information of the model and the retailer from whom you purchased your Softlite LED: this information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.

  • Page 5: Table Of Contents

    Italiano Index General information ......................6 • 1.1 Description ........................... 6 • 1.2 Safety information ........................6 • 1.3 Warranty conditions ......................7 • 1.4 EC norms ............................7 • 1.5 Technical charateristics ......................8 • 1.6 Dimensions ..........................8 • 1.7 Fixture components ......................

  • Page 6: General Information

    This will assist in providing prompt and accurate advice from your Coemar service centre, which you can thoroughly trust and to which you can submit any requests for service or information.

  • Page 7: Warranty Conditions

    Italiano Safety: 1. The projector must always be installed with bolts, clamps, or other fixing devices which are suitably rated to support the weight of the projector. 2. Always use a secondary safety fixing device with chain or steel wire of a suitable rating to sustain the weight of the unit in case of failure of the principal fixing point.

  • Page 8: Technical Charateristics

    Italiano Technical charateristics Power supply 90-250Vac 50/60Hz autoregolante Maximum 0.81 A a 230 VaC - 2.07 A a 90 Vac Phase coefficient Cosϕ = 0.9 Light source power 168W Color temperature excursion da 2700k a 10000k >90 Weigh 11kg - 24lbs Maximum environment temperature 35°C IP rating...

  • Page 9: Fixture Components

    Italiano Fixture components Components description Locking knobs Yoke Cooling slots Front panel Back panel Accessories hooking Safety cable hooking Backpanel description DMX In and Out 3 and 5 poles connector Power supply Display and Neutrk PowerCon keyboard connector...

  • Page 10: Installation And Setup

    The safety chain must pass through the hole in the figure below and then attached to the structure. If you are using steel cables and chains that are not Coemar’s products, make sure they are suitable to support the weight of the unit according to normative UL/ETL ( required:...

  • Page 11: Supply Cable Charateristics

    Italiano In order to orientate the fixture direction loosen the side knob, orientate the fixture and tighten the knob again. Supply cable charateristics The supply cable complies to the most recent safety norms. Warning!! • The use of a thermal/magnetic circuit breaker is recommended. Strict adherence to regulatory norms is strongly recommended.

  • Page 12: Connecting The Conyrol Signal

    Italiano Connecting the control signal The digital control signal is transmitted to the projector via a two pole cable screened according to the International standards for the transmission of DMX 512 data. The connection must be serial, using connectors XL5 male and female located on the back of Softlite LED labeled DMX512 IN e OUT (see diagram).

  • Page 13: Setting The Dmx Address

    Italiano Setting the DMX address When powered up initially, each projector will show “A001”, which indicates that the fixture will start responding from the first DMX channel; Softlite LED also uses 12 DMX channels, which means that it will respond to the commands from channel 1 to channel 12 of your DMX 512 controller.

  • Page 14: Dmx Chart

    Italiano DMX chart channel type of number function effect description decimal percentage control 15ch 4ch master dimmer proportional adjust luminous output intensity from 0 to 100% 0 - 255 0% - 100% step WHITE 2700K 0 - 15 0% - 6% proportional proportional value from 2700k to 3200k 16 - 30...
  • Page 15 108 - 156 42% purple 157 - 205 62% cyan 206 - 255 81% 100% Product: Softlite LED RGBW Chart name: DMX 512 functions Software version: 0.10 or following Chart number: 343 Edition: 6 Date: 9/05/2016...

  • Page 16: Display Menu

    Changing the preset settings made by Coemar can vary the functions of the projector so that it will respond differently to the controller; therefore carefully read about the functions described here before carrying out any possible selection.

  • Page 17: Main Functions Menu (Func)

    Italiano Main Functions menu (FUNC) Dimmer: Choose the type of dimmer curve: dimm • Xeno: quick curve; XENO • Tungsten: mimics the slow [Xenon] dimming curve of tungsten lamps. [Dimmer] Color Mixing: TUNG Allows to simulate the CMY: [Tungsten] • RGB: the mixing system is the standard Red, Green, Blue;...
  • Page 18 Italiano Display functions: Changes the display settings: • Reverse: rotates the display of 180°; • Auto: Sets or disables the 4 CH automatic display turn off function, [4 Canali] [DMX channels] which would occour after 10 seconds of inactivity; • Hold Sets or disables the 14 CH automatic display lock function [14 Canali]...

  • Page 19: Measures Menu (Meas)

    Italiano Measures menu (MEAS) Temperature: Shows the current temperature TEMP T.LEd values: [LED Temperature] • LED: Shows the LED module [Temperature] temperature; • Board: shos the electronic board T.BRD temperature. [Board Temperature] Volt: Shows the power supply voltage. VOLT DMX Input: [Supply Voltage] Shows the value of the DMX channels received by the fixture on every...
  • Page 20 Italiano LED: Shows the percentage value of the LED status. Fre: Shows the operating frequency of the [LED Status] LED. Fan speed: Shows the percentage fan usage. Usage hours: Shows the hour counter of the fixture: • Unit: Shows the overall hours of life of the fixture;...

  • Page 21: Electronic Led Alignment

    The display panel of Softlite LED allows the electronic alignment of the LEDs, this procedure is performed by Coemar at the time of testing, this procedure may be useful for special effects or in case of replacement of internal components (PCBs, LEDs, etc...).

  • Page 22: Special Functions Of The Fixture

    If a malfunction occurs, Softlite LED has a self-diagnostic system that will show the error message on the display. The following table will explain in detail the most common errors. If, despite of suggested intervention, the problem persists, call the Coemar Service Center. Codice errore...

  • Page 23: Accessories

    Accessories Accessories and spare parts All the components of Softlite LED are available as spare parts from your Coemar dealer or service. Accurate description of the fixture model number and type will assist us in providing for your requirements in an efficient and effective manner.

  • Page 24: Maintenance And Problem Solving

    Maintenance and problem solving Firmware update The fimware of Softlite LED can be updated through the RDM protocol (ANSI E1.20). Contact Coemar assistance to receive the software and the device updater. Periodic cleaning Front panel Even a thin layer of dust can reduce the luminous output and alter the compactness of the beam.

  • Page 25: Faq And Answers

    FAQ and answers The following list shows common issues that may be simply solved. If issues persist, the unit must be repaired by qualified personnel or just contact your Coemar service near you. Question Possible solution Projector not powered on: •...
  • Page 26 User notes ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 27 Information on disposal of the equipment The equipment at the end of its useful life must be disposed of at an appropriate recycling center for waste electrical and electronic equipment. The treatment and disposal of environmentally friendly, helps prevent potential negative environmental and health and promote the reuse and / or recycling of materials making up the equipment.
  • Page 28 Coemar Lighting s.r.l. via Carpenedolo 90 46043 Castiglione delle Stiviere, Mantova, Italia tel. +39 0376/1514412 - fax +39 0376/1514380 info@coemar.com Coemar reserves the right to effect modifications without notification...
