S80 with
• MLS Basic Card
• MLS Professional Card
Assembly and Operating Instructions
en
Door Control Unit
Important information for:
• Fitters
• Electricians
• Users
Please forward accordingly!
These instructions must be kept for future reference.
Becker-Antriebe GmbH
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Becker S80
Summary of Contents for Becker S80
- Page 1 S80 with • MLS Basic Card • MLS Professional Card Assembly and Operating Instructions Door Control Unit Important information for: • Fitters • Electricians • Users Please forward accordingly! These instructions must be kept for future reference. Becker-Antriebe GmbH 35764 Sinn/Germany...
-
Page 2: Table Of Contents
When installing the equipment and setting the functions, please observe the Operating and Installation Instructions. Note These Operating and Installation Instructions apply to the S80 Door Control Unit with MLS Basic Card and MLS Professional Card for actuating drives with mechanical limit switching. -
Page 3: Safety Instructions
Safety instructions The following safety instructions and warnings serve to avert dangers and to prevent personal injuries and damage to prop- erty. Please retain these instructions for future reference. Denotes a potentially hazardous situation. If this is not avoided, injuries can Caution result. -
Page 4: Intended Use
Intended use The control unit must be used as intended with Becker door drives with mechanical limit switches. If other controls are used, the warranty entitlement will become invalid! This control must not be used for doors which have not been designed for this... -
Page 5: Overview Of Functions
Overview of functions Function MLS Basic Card MLS Professional Card Setting mode (up/down in dead-man mode) Automatic ascent (UP) Automatic descent (DOWN) Anti-pull-in cable safety Slack rope switch debounced Button input: UP/STOP/DOWN/STOP Automatic closing Partial opening Pneumatic safety edge Electrical safety edge Safety edge switchover: 1.2 kOhm/8.2 kOhm Optoelectronic safety edge: FRABA OSE Photoelectric barrier... -
Page 6: Installing The Control Unit
Tighten up the housing cover screws carefully. Only then will the IP 65 degree of housing protection re- main intact. Fitting and removing a control card The S80 door control system for drives with mechanical limit switching can be con- verted/upgraded by changing plug-in control cards. The following control cards are available: •... -
Page 7: Electrical Connection
Installing the Mains Connection The working voltage of the S80 door control unit is 3-phase 400 V/230 V, 50 Hz. For connection to the main power supply, please use a 1,2 m long cable and a 16A/6h CEE socket outlet with direct access to the control unit to ensure that the plug is readily accessible. -
Page 8: Checking The Direction Of Movement
• Using the UP and DOWN buttons check whether the direction of door movement agrees with the buttons pressed. Also observe the UP and DOWN direction indicator lamps on the motherboard of the S80. If the direction of movement does not correspond to the button commands, proceed as follows: •... -
Page 9: Electrical Connection/Operation Of External Control Sensors And Safety Devices
Electrical connection/operation of external control sensors and safety devices Note Before connecting external control sensors you should first check the direction of door movement and set the end limits of the door drive. Voltage output for external control devices (MLS Basic + MLS Professional) A direct-current voltage is provided at terminals A- and B+ (24 V DC / 200 mA) for external control devices: U = 24 V DC, I = 200 mA. - Page 10 • If the photoelectric barrier responds during downward movement (Fault2 lamp flashes), the door stops instantly. After an internal time of 0.5 s (time Z0) has elapsed, the S80 opens the door again. Depending on the setting of DIP switch 1.3, the control unit moves the door clear of the obstacle or to the top end limit.
-
Page 11: Connection And Function Of The Switching Outputs
Connection and function of the switching outputs Switching Outputs The S80 door control unit has two potential free relay switching outputs (changeover contacts, see wiring diagram) each with a switching capacity of 250 V AC / 5 A. MLS Basic Card The relays are actuated by the operating cams S7 and S8 of the drive: •... -
Page 12: Retrofitting And Operation Of Radio Control System
For this disconnect the entire door control system from the mains. Insert the radio control receiver board in slot J1 at the top right of the S80 motherboard, as shown on the drawing. Make sure the board is the right way round. - Page 13 Deleting All the Transmitter Codes Programmed To delete the hand-held transmitter codes in the radio control receiver proceed as follows: • Press Program Channel 1 on the radio receiver and keep it pressed. The red signal LED begins to flash slowly. After approx. 5 s the red signal lamp flashes quickly.
-
Page 14: Setting The Dip Switches
Assembly and Operating Instructions Setting the DIP switches MLS Basic Card Switch Position Illustration Function DIP 1 Automatic mode in UP direction DIP 1 DIP 1 Dead-man mode in UP direction MLS Professional Card Switch Position Illustration Function DIP 1 DIP 2 Pneumatic (DW) safety edge connected, DW testing is activated 2 3 4 5 6 7 8... -
Page 15: Indicator Led's
Indicator LED’s Basic Control Unit S80 Illustration Indication Meaning Power supply connected POWER No power supply connected Door moves UP DOWN Door moves DOWN MLS Professional Card Illustration Indication Meaning Normal mode Betr contin. flash Setting mode (dead-man mode) Pilot In order to switch to normal mode (automatic), please push the pro- gramming button Prog. -
Page 16: Overview Of Control Times
• Check miniature fuse F2 (315 mA, slow blow). (24 V DC / 300 mA) Note Please also observe the indication of faults and errors by the LED’s on the pc board of the basic control unit S80 and MLS Professional Card. -
Page 17: Position Of Terminals And Components
Position of terminals and components Basic Control Unit S80 Cycle counter (optional) MLS Basic Card MLS Professional Card Prog Stör1 VES Sonder Betr Stör2 1 2 3 4 5 6 7 8 MLS-Basic-Card DIP 1 OSE 8K2... -
Page 18: General Wiring Diagram
Assembly and Operating Instructions General wiring diagram Drive with mechanical limit switching S1F - Safety limit switch OPEN S2F - Safety limit switch CLOSE Drive S3F - Safety limit switch Emergency Operation S4F - Thermal protection switch - Operation limit switch OPEN - Operation limit switch CLOSE - Pre-limit switch Testing - Function limit switch 1/2 door height... -
Page 19: Specifications
Specifications Type S80 with MLS Basic Card MLS Professional Card Power supply 3N~ 230/400 V 50/60 Hz Rated output of motor 2.0 kW max. Control voltage* 24 V DC Control circuit max. 125 mA Dimensions of housing 182 mm x 254 mm x 90 mm (W x H x D) Weight approx.
