- Page 1 User’s manual External wireless transmission system of video and audio for IP cameras HD and UHD in the band 5.1 - 5.8 GHz www.camsat.com www.camsat.com...
- Page 2 Thank you for choosing the CDS-6IPeco. We trust that its unique features will come in very handy. Please, read this instruction manual to ensure safe operation and maximise efficiency of the device. The contents of this manual comprise proprietary information of CAMSAT and are intended only for use by purchasers of the equipment described herein.
-
Page 3: Table Of Contents
9. The list of available frequencies for the default channel width of 40 MHz....16 10. Table with technical parameters................17 Trouble solving.........................18 Appendix A........................18 Warranty general conditions...................19 Used equipment storage....................20 Declaration of conformity....................21 VIII CDS-6IPECO User’s manual POLISH POLISH MARK MARK... - Page 4 Note: This device can operate within the frequency and power ranges which might be contradictory to laws applicable in selected countries. The CDS-6IPeco module is maintenance-free. We recommend installing it on a stable structure and connecting its power cables in a manner which would prevent them from being accidentally damaged by the operator or any bystanders.
- Page 5 (Directive 1999/5/CE of the European Parliament and the Council of Europe, March 1999). The CDS-6IPeco module is compliant with provisions related to the safety in using electrical devices. Observe the following guidelines: the power outlet must be earthed in compliance with applicable provisions,...
- Page 6 II Contents 1. Basic information The CDS-6IPeco device is a small wireless module for video streaming from IP HD and 4K (5.1-5.8 Ghz) megapixel cameras. The most important features of the CDS-6IPeco: device is intended for streaming the signal from high-resolution IP cameras (up to...
-
Page 7: System Configuration
LAN+PoE24V Scheme 1- Power and connect CDS-6IPeco unit to the computer o log on to the wireless CDS-6IPeco module, set the IP address of the computer on the same subnet as the device CDS-6IPeco (default address 192.168.1.1), then open a Web browser (preferably Internet Explorer) and enter the IP address of the module. -
Page 8: Menu Structure
Remember to loosen the mounting clamps with a screwdriver before pushing them through the openings in the device body. Stably fix the CDS-6IPeco module to the pole, firmly tightening the bolts of the moun- ting clamps. The clamps are suitable for the assembly on poles with diameters between 32 and 70 mm. -
Page 9: Connection To The System
5. Connection to the system. Option 1 (Power CDS-6IPeco module by PoE, connect the camera to the module) Plug the power cord with a standard RJ45 connector tip to WAN PoE 24V in CDS-6IP- eco module (A), the other end is connected to the connector labeled POE in the supplied PoE power supply (B). - Page 10 Option 3 (Power CDS-6IPeco Module with an AC adapter, connecting two cameras to the module) Plug in the AC adapter (B) to the 12V DC in CDS-6IPeco module (A). Connect camera (C) using a standard network cable with RJ45 connector tip to WAN PoE 24V. The second camera (D) should be connected to the LAN 24V PoE in CDS-6IPeco module (A).
-
Page 11: First System Start-Up
IP camera, install it on your PC and validate the receipt image. a) Knowing the IP addresses of the cameras and the address of the CDS-6IPeco module must set the IP address of the computer in such a way that all these devices worked in one subnet (recommended IP addresses from the range 192.168.1.2 - 192.168.1.254). -
Page 12: Scanning The Usage Of Operation Channels
Settings recommended Modules CDS-6IPeco allow you to scan the ether for use in the vicinity of the frequen- cy. When setting the operating channel it is a very useful tool. It shows which chan- nels to avoid, and which ones are free and can be used to transmit wireless signals from IP cameras. -
Page 13: Operating Mode Setting
The next step is to configure the basic parameters of the radio connection to be set in the menu CAMERA CONNECTION SETTINGS → Wireless. CDS-6IPECO User’s manual POLISH POLISH MARK... -
Page 14: Ssid Radio Link Name
The basic information about the wireless connection will appear in the Wireless Status tab. In addition, the unit operating in MASTER mode (NVR / DVR) in the Wireless Clients tab a list of wireless units CDS-6IPeco connected to the module will be visible. CDS-6IPECO User’s manual... -
Page 15: Password Changing
In the New Password field, enter the new password and confirm it in the Con- firm Password field. Confirm the change with Save Changes button. CDS-6IPECO User’s manual POLISH POLISH... -
Page 16: Link Testing With Ping Command
The response time of the device shorter than 200-400ms means correct configura- tion of the devices. To make sure that all devices are correctly configured, you can execute the command PING with the address of each device in the system (CDS-6IPeco, IP cameras, routers, recorders). 8. Radio transmission security. -
Page 17: The List Of Available Frequencies For The Default Channel Width Of 40 Mhz
Selecting other frequencies depends on legal regulations applicable in the coun- try of use. If not sure what regulations are applicable in the country of use, con- sult with the CDS-5IP mini module seller. CDS-6IPECO User’s manual POLISH POLISH MARK... - Page 18 Power supply Power consumption 12 Watt Power supply Product specification Casing dimensions 238mm(L)×88mm(W)×40mm(H) Weight Casing ingress protection IP55 -20°~ 70° C Storage temperature -40° ~ 85° C Humidity Environmental directives Warranty 24 months CDS-6IPECO User’s manual POLISH POLISH MARK MARK...
-
Page 19: Trouble Solving
To change the IP address of the computer, go to Control Panel -> Network and Internet -> Network Connections. Then select the current network adapter, which is connected to the module CDS-6IPeco. Click on Internet Protocol Version 4 (TCP / IPv4) on the list, and then click Properties. -
Page 20: Warranty General Conditions
Camsat grants a 24 month warranty for the CDS-6IPeco transmission kit 1. If the device is not be operating properly, make sure, before returning the device for servicing, that everything was done according to the operating manual 2. -
Page 21: Used Equipment Storage
VII Device disposal The mark presented to the left informs that this electrical or electronic device, after its use has ended, cannot be thrown together with household refuse The device should be delivered to a specialised collection point Detailed information about the closest collection point is available from local authorities. -
Page 22: Declaration Of Conformity
VIII Declaration of conformity... - Page 23 Hereby, CAMSAT Gralak Przemyslaw declares that the product series CDS-6IPeco meets the essential requirements and other relevant provisions of Directive 1999/5 / WE. The device is CE marked, which indicates compliance with the guidelines of the Directive. The device can be sold and used for transmission in the 5 GHz band.
