DRM-6324X Six Disc CD-ROM Changer
GENERAL
Media Type
Media Diameter
Interface
Block Size
Data Transfer Rate
Capacity of Data Buffer
Average Seek/Access Tim
Disc Change Time (without
Spin-Up, Spin-Down)
MTBF
Regulatory Approvals
AUDIO PERFORMANCE
Frequency Response
Total Harmonic Distortion
Output Voltage
PHYSICAL CHARACTERISTICS
Dimensions (W x H x D)
Weight (Net)
Weight (Shipping)
Operating Voltage
Rated Current Consumption
Max. Current Consumption
ENVIRONMENTAL CONDITIONS
Operating Temperature
Storage Temperature
Humidity (non-condensing)
SPECIFICATIONS
CD-ROM, CD-Audio, XA Mode 2, Form 1 and 2
120 mm
SCSI-2
2048/512 Byte (selectable)
1800 ~ 3600 KB/s (Sustained): CAV/CLV Combination Mode
128 KB
70/90ms
Less than 5 seconds
100,000 POH (Duty 20%)
UL, CSA, FCC Class B, TUV, CE (European, Oceanian
models) UL, CSA, FCC Class B, FDA, (U.S., Canadian
models)
40 ~ 20,000 Hz
0.3% (Max)
1.7 Vr.m.s. (line out) 0.5V(10k )
210 x 88.3 x 370.5 mm (8-1/4" x 3-1/2" x 14-9/16")
3.5 kg (7lbs. 11 oz.)
4.8 kg (10lbs. 9 oz.)
AC 110 ~ 240V 50/60Hz (European, Oceanian models)
AC 120V 50/60Hz (U.S., Canadian models*)
AC 240V 0.12A (European, Oceanian models)
AC 120V 0.16A (U.S., Canadian models)
AC 240V 0.18A (European, Oceanian models)
AC 120V 0.27A (U.S., Canadian models)
5 ~ 35 C
-20 ~ 60 C
5 ~ 85%RH
* Multi Voltage compatible
