Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man- ual in a safe place for future reference.
! We offer the latest information about Pioneer Corporation on our website. Protecting your unit from theft The front panel can be detached to deter theft.
Section Before You Start Important ! Handle gently when removing or attaching the front panel. ! Avoid subjecting the front panel to excessive shocks. ! Keep the front panel out of direct sunlight and high temperatures. Removing the front panel Press DETACH to release the front panel.
Operating this unit What’s What Head unit 1 AUDIO button Press to select various sound quality con- trols. 2 EQ button Press to select various equalizer curves. 3 SOURCE button, VOLUME This unit is turned on by selecting a source. Press to cycle through all the available sources.
Shows the various information such as band, play time, and other setting. ! Tuner ! RDS ! Built-in CD Player (Audio CD) ! Built-in CD Player (WMA/MP3/WAV disc) ! Audio and initial setup 2 Preset number/track number indicator Shows the track number or preset number.
Turning the unit on and selecting a source You can select a source you want to listen to. To switch to the built-in CD player, load a disc in the unit (refer to page 10). % Press SOURCE to select a source.
Section Operating this unit Tuning in strong signals Local seek tuning lets you tune in only those radio stations with sufficiently strong signals for good reception. Press FUNCTION to select LOCAL. Press a or b to turn local seek tuning on or off.
Operating this unit ! When you recall a preset station, the tuner may update the preset station with a new fre- quency from the station’s AF list. (This is only available when using presets on the F1 or F2 bands.) No preset number appears on the dis- play if the RDS data for the station received differs from that for the originally stored sta- tion.
WAV files and audio CD-DA, playback starts at the first track on the disc. ! The built-in CD player can play back a WMA/ MP3/WAV file recorded on CD-ROM. (Refer to page 16 for files that can be played back.)
Operating this unit Repeating play Repeat play plays the same track/folder within the selected repeat play range. Press FUNCTION to select RPT. Press c or d to select the repeat range. DSC – Repeat all tracks TRK – Repeat just the current track FLD –...
Section Operating this unit Press FUNCTION to select FF/REV. # If the search method ROUGH has been pre- viously selected, ROUGH will be displayed. Press d to select ROUGH. ! FF/REV – Fast forward and reverse ! ROUGH – Searching every 10 tracks # To select FF/REV, press c.
Operating this unit Adjusting equalizer curves You can adjust the currently selected equalizer curve setting as desired. Adjusted equalizer curve settings are memorized in CUSTOM. Adjusting bass/mid/treble You can adjust the bass/mid/treble level. Press AUDIO to select BASS/MID/ TREBLE. Press a or b to adjust the level. +6 to –6 is displayed as the level is increased or decreased.
! When a call is made or received using a cellular telephone connected to this unit. ! When the voice guidance is output from a Pioneer navigation unit connected to this unit. The sound is turned off, MUTE is displayed and no audio adjustments, except volume con- trol, are possible.
Display indication is improper. leads are connected. Error messages When you contact your dealer or your nearest Pioneer Service Center, be sure to record the error message. Message Cause Action ERROR-11, 12, Dirty disc Clean disc.
Appendix Additional Information ! To clean a CD, wipe the disc with a soft cloth outward from the center. ! Condensation may temporarily impair the player’s performance. Leave it to adjust to the warmer temperature for about one hour. Also, wipe any dump discs with a soft cloth.
Additional Information Compressed audio compatibility ! Compatible format: WMA encoded by Windows Media Player Ver. 7, 7.1, 8, 9 or 10 ! Bit rate: 48 kbps to 320 kbps (CBR), 48 kbps to 384 kbps (VBR) ! Sampling frequency: 32 kHz to 48 kHz ! Windows Media Audio 9 Professional, Loss- less, Voice: No ! Bit rate: 8 kbps to 320 kbps...
Low ... +7 dB (100 Hz), +4 dB (10 kHz) High ... +10 dB (100 Hz), +6.5 dB (10 kHz) (volume: –30 dB) CD player System ... Compact disc audio system Usable discs ... Compact disc Signal format: Sampling frequency ... 44.1 kHz Number of quantization bits ...
Page 21
Перед началом эксплуатации Сведения об этом устройстве RDS ( RDS. Pioneer. О формате WMA Windows Media™, WMA, – Windows Media Corporation WMA. Windows Media Audio Microsoft. Windows Media Player 7 Windows Microsoft...
Page 22
Перед началом эксплуатации О формате MP3 http://www.mp3licensing.com. Посетите наш сайт Corporation Защита Вашего устройства от кражи ( . . Снятие передней панели Установка передней панели Pioneer DETACH,...
Page 23
Эксплуатация данного устройства Описание элементов устройства Основное устройство AUDIO , VOLUME 3 SOURCE EJECT 4 4 4 AUX ( 5 5 5 6 6 6 8 8 8 7 7 7 DETACH DISPLAY LOUD 1 - 6 a/b/c/d BAND MW/LW- FUNCTION...
Page 24
Эксплуатация данного устройства Дополнительный пульт дистанционного управления SR100 SOURCE VOLUME Жидкокристаллический дисплей ATT, ! RDS 90%. , PTY- (Audio CD) WMA/MP3/ WAV)
Page 25
Эксплуатация данного устройства MP3/WMA LOUD Основные операции Включение устройства и выбор источника сигнала . 29). SOURCE, SOURCE — — — “ Регулировка громкости Выключение устройства SOURCE, Тюнер Прослушивание радиоприемника MW/LW). —AUX AUX ( . 34). ”. . 34). VOLUME SOURCE, BAND, BAND, (F1, F2...
Page 26
Эксплуатация данного устройства Запоминание и повторный вызов радиочастот 6 MW/LW- Настройка на мощные сигналы FUNCTION, LOCAL. FM: LOCAL 1—LOCAL 2—LOCAL 3— LOCAL 4 MW/LW: LOCAL 1—LOCAL 2 Запоминание частот самых мощных трансляций 12 FM- LOCAL 4 BSM ( FUNCTION, BSM. BSM.
Page 27
Эксплуатация данного устройства Знакомство с работой RDS RDS ( RDS. RDS, Переключение режима RDS дисплея DISPLAY. DISPLAY — — PTY ( Прием радиопередач аварийного сигнала PTY ALARM). Выбор альтернативных частот AF ( RDS- . 29. Использование функции Поиск PI (по идентификатору программы) PI SEEK Использование...
Page 28
Эксплуатация данного устройства PI ( . 34. Ограничение станций региональными программами FUNCTION, REG. Прием дорожных сводок ( . . TA ( TA ( VOLUME. SOURCE, BAND, a, b, c (TP). FUNCTION.
Page 29
Эксплуатация данного устройства (TP). Список PTY NEWS AFFAIRS INFO SPORT WEATHER FINANCE POP MUS ROCK MUS EASY MUS OTH MUS JAZZ COUNTRY NAT MUS OLDIES FOLK MUS L.CLASS CLASSIC EDUCATE DRAMA CULTURE SCIENCE VARIED CHILDREN SOCIAL RELIGION PHONE IN TOURING LEISURE DOCUMENT Встроенный...
