Pioneer Super Tuner III DVH-P7050 Owner's Manual

Multi-cd control high power dvd/vcd/cd player with fm/am tuner.
Hide thumbs

Advertisement

Multi-CD control High power DVD/VCD/CD player with
FM/AM tuner
Owner's Manual
DVH-P7050
This product conforms to new cord colors

Advertisement

   Also See for Pioneer Super Tuner III DVH-P7050

   Related Manuals for Pioneer Super Tuner III DVH-P7050

   Summary of Contents for Pioneer Super Tuner III DVH-P7050

  • Page 1

    Multi-CD control High power DVD/VCD/CD player with FM/AM tuner Owner’s Manual DVH-P7050 This product conforms to new cord colors...

  • Page 2: Table Of Contents

    Section Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to oper- ate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.

  • Page 3: Table Of Contents

    Contents Slow motion playback 25 Changing audio language during playback (Multi-audio) 26 Changing the subtitle language during playback (Multi-subtitle) 26 Changing the viewing angle during playback (Multi-angle) 27 • About scenes that let you change the viewing angle 27 Operating from the information display 1 (DVH&DVD mode) 28 •...

  • Page 4: Table Of Contents

    Section Contents Multi-CD Player Playing a CD 45 Pausing playback 46 50-disc multi-CD player 46 Introduction of advanced multi-CD player operation 46 Repeating play 47 Playing tracks in a random order 47 Scanning CDs and tracks 48 Pausing CD playback 48 Using ITS playlists 48 •...

  • Page 5: Table Of Contents

    Contents Initial Settings Adjusting initial settings 71 Setting the time 71 Setting the FM tuning step 71 Setting the AM tuning step 72 Switching the warning tone 72 Switching the auxiliary setting 72 Switching the dimmer setting 73 Selecting the brightness 73 Setting the rear output and subwoofer controller 73 Switching the telephone...

  • Page 6: Precautions

    • Protect this product from moisture. • If the battery is disconnected or discharged, the preset memory will be erased and must be reprogrammed. • Should this product fail to operate properly, contact your dealer or nearest authorized Pioneer Service Station.

  • Page 7: Dvd Disc Region Numbers, Region Number, Video System Of A Connected Component

    Before You Start Video system of a connected component This product is NTSC/PAL system compatible. When connecting other components to this product, be sure components are compatible with the same video systems. If it is not, images will not be correctly reproduced. DVD disc region numbers DVDs that have incompatible region numbers cannot be played on this player.

  • Page 8: Disc Operation, When Using A Display Connected To Dvd Rear Monitor Output, Condition Memory

    Section Before You Start When using a display connected to DVD REAR MONITOR OUTPUT This product’s DVD REAR MONITOR OUTPUT is for connection of a display to enable passengers in the rear seats to watch the DVD or Video CD. WARNING •...

  • Page 9: Disc Organization

    Before You Start Disc organization On DVD-Video discs, the contents are divided into titles which are in turn divided into chap- ters. With video material, a single work (movie etc.) usually corresponds to a single title, with differ- ent scenes corresponding to separate chapters. With karaoke discs, one song corresponds to one title.

  • Page 10: Main Features

    Dolby* Digital/DTS** Compatibility (When combining this product with a Pioneer Multi-channel processor such as DEQ- P7050) When using this product with a Pioneer Multi-channel processor, you can enjoy the atmosphere and excitement provided by DVD movie and music software featuring 5.1 channel recordings.

  • Page 11: Protecting Your Unit From Theft, Removing The Front Panel, Attaching The Front Panel

    Before You Start Protecting your unit from theft The front panel can be detached from the head unit and stored in the protective case provided to discourage theft. • If the front panel is not detached from the head unit within five seconds of turning off the ignition, a warning tone will sound.

  • Page 12: Switching The Remote Control Operation Mode Switch, About The Demo Mode, Reverse Mode, Feature Demo

    Section Before You Start Switching the remote control operation mode switch There are two remote control operation modes on the supplied remote control. If you want to operate this product by remote control, turn the mode switch to this case, both the head unit’s buttons and remote control can control this unit.

  • Page 13: What's What, Head Unit

    Before You Start What’s what Head unit button ENTERTAINMENT Press to change to the entertainment dis- play. VOLUME When you press the VOLUME outward so that it becomes easier to turn. To retract the , press it again. VOLUME Rotate to increase or decrease the volume. button CLOCK Press to change to the clock display.

  • Page 14: Remote Control

    Section Before You Start Remote control 1 Remote control selection switch Switch to change the setting of the remote control (refer to page 70). (+/–) button VOLUME Press to increase or decrease the volume. button TOP MENU Press to return to the top menu while the built-in player is playing as the source.

  • Page 15: Before You Start

    Before You Start button ANGLE Press to change the viewing angle during playback when the built-in player is playing as the source. button PLAY/PAUSE ( Press to switch sequentially between play- back and pause play. button REVERSE ( Press to perform fast reverse playback or seek tuning while the tuner is playing as the source.

  • Page 16: Use And Care Of The Remote Control, Installing The Battery, Using The Remote Control

    Section Before You Start Use and care of the remote con- trol Installing the battery Slide the tray out on the back of the remote control and insert the battery with the plus and minus poles pointing in the proper direc- (–) tion.

  • Page 17: Power On/off Turning The Unit On, When The Remote Control Is Set To Dvh Mode

    — When the AUX (auxiliary input) is set to off (refer to page 72). • External unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this product. Two external units can be controlled by this product.

  • Page 18: Turning The Unit Off, When The Remote Control Is Set To Dvh Mode

    Section Power ON/OFF Turning the unit off When the remote control is set to DVH mode Press and hold for about one second SOURCE to turn the unit off. • Pressing and holding SOURCE unit also performs the same operation. When the remote control is set to DVD mode Press...

  • Page 19: Tuner Listening To The Radio

    Tuner Listening to the radio These are the basic steps necessary to operate the radio. More advanced tuner operation is explained starting on page 20. Important If you are using this unit in North, Central or South America, reset the AM tuning step (see Setting the AM tuning step on page 72).

  • Page 20: Introduction Of Advanced Tuner Operation, Storing And Recalling Broadcast Frequencies

    Section Tuner Introduction of advanced tuner operation display FUNCTION Shows the function status. Press to display the function names. Press repeatedly to switch between the follow- ing functions: (best stations memory)— seek tuning) • Pressing on the head unit also FUNCTION performs the same operation.

  • Page 21: Tuning In Strong Signals, Storing The Strongest Broadcast Frequencies

    Tuner Tuning in strong signals Local seek tuning lets you tune in only those radio stations with sufficiently strong signals for good reception. 1 Press to select LOCAL Press until appears in the display. Local • Pressing on the head unit also FUNCTION performs the same operation.

  • Page 22: Oel Display, Information Display

    Section Playing DVDs on the built-in player Playing a DVD OEL display These are the basic steps necessary to play a DVD with your built-in player. More advanced DVD operation is explained starting on page 28. indicator DVD.V Shows when a DVD disc is playing. indicator TITLE NUMBER Shows the title currently playing.

  • Page 23: Basic Operation Of Dvd

    Playing DVDs on the built-in player Basic operation of DVD 1 Press on the head unit to open the OPEN front panel. Disc loading slot appears. • After inserting a DVD, press SOURCE select the built-in player. • Pressing on the head unit also per- SOURCE forms the same operation.

  • Page 24: Specifying Title (dvd Mode), Specifying Chapter (dvd Mode)

    Section Playing DVDs on the built-in player 8 To perform fast forward or reverse, press and hold 1 or ¡. • Pressing and holding 2 or 3 on the head unit also performs the same operation. • If you continue pressing 1 or ¡ for 5 seconds, the color of the fast reverse/fast forward mark ( white to blue.

  • Page 25: Stopping Playback, Frame-by-frame Playback, Still Playback, Slow Motion Playback

    Playing DVDs on the built-in player Stopping playback • This function is operated by using the remote control. Press 7 . Note • When you stop DVD playback by pressing 7 , that location on the disc is memorized enabling playback from that point when you play the disc again.

  • Page 26: Changing Audio Language During Playback (multi-audio), Changing The Subtitle Language During Playback (multi-subtitle)

    Section Playing DVDs on the built-in player Changing audio language during playback (Multi-audio) DVDs can provide audio playback with different languages and different systems (Dolby Digital, DTS etc.). With DVDs featuring multi-audio recordings, you can switch between languages/audio systems during playback. •...

  • Page 27: Changing The Viewing Angle During Playback (multi-angle)

    Playing DVDs on the built-in player • With some DVDs, switching between subtitle languages may only be possible using a menu display. • You can also switch between subtitle languages using SET UP MENU see Setting the subtitle on page 63. •...

  • Page 28: Operating From The Information Display, Starting Playback From A Specified Time

    Section Playing DVDs on the built-in player Operating from the information display 1 (DVH & DVD mode) This display lets you use the search function to specify a title or chapter to search for a desired scene, use the time search function to specify a time to search for a desired scene, select the desired audio and subtitle language, and select the angle.

  • Page 29: Selecting Audio, Subtitle And Angle

    Playing DVDs on the built-in player 3 While the input number is displayed, click the joystick. This starts playback from the selected scene. Notes • With discs featuring a menu, you can also press and then make MENU TOP MENU selections from the displayed menu.

  • Page 30: Selecting Repeat Range, Operating From The Information Display, Selecting Audio Output

    Section Playing DVDs on the built-in player Operating from the information display 2 (DVH & DVD mode) In addition to the search and time search func- tions of the information display 1, this display lets you select the range for repeat play, and switch audio output.

  • Page 31: Repeating Play, Pausing Playback

    Playing DVDs on the built-in player Operating from the function dis- play (DVH mode) Repeat and pause functions can also be oper- ated from the head unit’s OEL display. display FUNCTION Shows the function status. Press to display the function names. Press repeatedly to switch between the follow- ing functions:...

  • Page 32: Information Display, Oel Display

    Section Playing Video CDs on the built-in player Playing a Video CD OEL display These are the basic steps necessary to play a Video CD with your built-in player. More advanced Video CD operation is explained start- ing on page 35. indicator Shows when a Video CD disc is playing.

  • Page 33: Basic Operation Of Video Cd

    Playing Video CDs on the built-in player Basic operation of Video CD 1 Press on the head unit to open the OPEN front panel. Disc loading slot appears. • After inserting a Video CD, press select the built-in player. • Pressing on the head unit also per- SOURCE forms the same operation.

  • Page 34: Specifying Track (dvd Mode), Stopping Playback

    Section Playing Video CDs on the built-in player 7 To perform fast forward or reverse, press and hold 1 or ¡. • Pressing and holding 2 or 3 on the head unit also performs the same operation. • If you continue pressing 1 or ¡ for 5 seconds, the color of the fast reverse/fast forward mark ( white to blue.

  • Page 35: Still Playback

    Playing Video CDs on the built-in player Still playback This lets you pause playback and view a still picture. Press 6 during playback. The still mark ( ) is displayed for 4 seconds and playback is paused letting you view a still image.

  • Page 36: Starting Playback From A Specified Time, Selecting Repeat Range

    Section Playing Video CDs on the built-in player Searching for a desired scene, starting playback from a specified time You can use the search function to search for a desired scene by specifying a track, and the time search function to specify the time on a disc at which play starts.

  • Page 37: Selecting Audio Output, Repeating Play

    Playing Video CDs on the built-in player 2 Move the joystick up/down to switch to the desired setting. This switches you to the selected setting. (disc)— (track) Disc Track • When you select (disc), playback of the Disc entire disc is repeated. When you select (track), playback of that track only is repeated.

  • Page 38: Pausing Playback

    Section Playing Video CDs on the built-in player 2 Press E to turn repeat play on. appears in the display. The track Repeat :ON presently playing will play and then repeat. • Pressing 5 on the head unit also performs the same operation.

  • Page 39: Playing Cds On The Built-in Player Playing A Cd, Oel Display, Information Display

    Playing CDs on the built-in player Playing a CD OEL display These are the basic steps necessary to play a CD with your built-in player. More advanced CD operation is explained starting on page 41. indicator Shows when the CD disc is playing. indicator TRACK NUMBER Shows the track currently playing.

  • Page 40: Basic Operation Of Cd

    Section Playing CDs on the built-in player Basic operation of CD 1 Press on the head unit to open the OPEN front panel. Disc loading slot appears. • After inserting a CD, press the built-in player. • Pressing on the head unit also per- SOURCE forms the same operation.

  • Page 41: Searching For A Desired Track

    Playing CDs on the built-in player Operating from the information display (DVH & DVD mode) This display lets you use the search function to specify a track to search for desired track, select the range for repeat play, and switch random play, scan play and pause playback on/off.

  • Page 42: Setting Random Play, Selecting Repeat Range, Setting Scan Play, Pausing Playback

    Section Playing CDs on the built-in player Selecting repeat range You can choose between repeat play of a disc or a track. 1 Move the joystick left/right to select the repeat range option. The repeat range option is indicated in blue. 2 Move the joystick up/down to switch to the desired setting.

  • Page 43

    Playing CDs on the built-in player Operating from the function dis- play (DVH mode) The following functions can also be operated from the head unit’s OEL display. display FUNCTION Shows the function status. Press to display the function names. Press repeatedly to switch between the follow- ing functions: (repeat play)—...

  • Page 44: Playing Tracks In A Random Order, Scanning Tracks Of A Cd, Pausing Cd Playback

    Section Playing CDs on the built-in player Playing tracks in a random order Random play lets you play back tracks on the CD in a random order. 1 Press to select Press until appears in the display. Random • Pressing on the head unit also FUNCTION performs the same operation.

  • Page 45: Playing A Cd

    Multi-CD Player Playing a CD You can use this unit to control a multi-CD player, which is sold separately. These are the basic steps necessary to play a CD with your multi-CD player. More advanced CD operation is explained starting on page 46. indicator DISC NUMBER Shows the disc currently playing.

  • Page 46: Disc Multi-cd Player, Pausing Playback, Introduction Of Advanced Multi-cd Player Operation

    Section Multi-CD Player Pausing playback Pause lets you temporarily stop playback of the Press 6 during playback. • Pressing on the head unit also per- PAUSE forms the same operation. • To return to normal playback, press 6 once more. 50-disc multi-CD player Only those functions described in this manual are supported for 50-disc multi-CD players.

  • Page 47

    Multi-CD Player Repeating play There are three repeat play ranges for the multi- CD player: (multi-CD player repeat), (one-track repeat), and (disc repeat). DISC 1 Press to select PMODE Press until appears in the display. Repeat • Pressing on the head unit also FUNCTION performs the same operation.

  • Page 48: Scanning Cds And Tracks, Pausing Cd Playback, Using Its Playlists

    Section Multi-CD Player Scanning CDs and tracks While you are using T.SCAN beginning of each track on the selected disc plays for about 10 seconds. When you are using (multi-CD player repeat), the beginning D.SCAN of the first track of each disc is played for about 10 seconds.

  • Page 49: Creating A Playlist With Its Programming, Playback From Your Its Playlist

    Multi-CD Player Creating a playlist with ITS program- ming You can use ITS to enter and playback up to 99 tracks per disc, up to 100 discs (with the disc title). (With multi-CD players sold before the CDX-P1250 and CDX-P650, up to 24 tracks can be stored in the playlist.) 1 Play a CD that you want to program.

  • Page 50: Erasing A Track From Your Its Playlist, Erasing A Cd From Your Its Playlist

    Section Multi-CD Player Erasing a track from your ITS playlist When you want to delete a track from your ITS playlist, you can if ITS play is on. If ITS play is already on, skip to step 2. If ITS play is not already on, press head unit).

  • Page 51: Entering Disc Titles

    Multi-CD Player Entering disc titles Disc title input lets you input CD titles up to 10 letters long and up to 100 disc titles (with ITS playlist) into the multi-CD player. 1 Play a CD that you want to enter the title. Press E or e to select a CD.

  • Page 52: Displaying Disc Titles, Selecting Discs From The Disc Title List, Using Cd Text Functions

    Section Multi-CD Player Displaying disc titles You can display the title of any disc that has had a disc title entered. Press on the head unit. DISPLAY Press on the head unit repeatedly to DISPLAY switch between the following settings: (play time)—...

  • Page 53: Using Compression And Bass Emphasis

    Multi-CD Player Using compression and bass emphasis You can use these functions only with a multi-CD player that supports them. Using COMP (compression) and DBE (dynamic bass emphasis) functions let you adjust the sound playback quality of the multi-CD player. Each of the functions have a two-step adjust- ment.

  • Page 54: Introduction Of Audio Adjustments

    Section Audio Adjustments Introduction of audio adjustments display AUDIO Shows the audio adjustments status. indicator SUBWOOFER Shows when the subwoofer in on. Press to display the audio function names. Press repeatedly to switch between the follow- ing audio functions: (balance adjustment)— adjustment)—...

  • Page 55: Setting The Sound Focus Equalizer, Using Balance Adjustment

    Audio Adjustments Setting the sound focus equal- izer Clarifying the sound image of vocals and instru- ments allows the simple staging of a natural, pleasant sound environment. Even greater listening enjoyment will be obtained if seating positions are chosen care- fully.

  • Page 56: Using The Equalizer, Recalling Equalizer Curves, Adjusting Equalizer Curves

    Section Audio Adjustments Using the equalizer The graphic equalizer lets you adjust the equal- ization to match car interior acoustic character- istics as desired. Recalling equalizer curves There are seven stored equalizer curves which you can easily recall at any time. Here is a list of the equalizer curves: Display SUPER BASS...

  • Page 57: Fine Adjusting Equalizer Curve, Adjusting Bass

    Audio Adjustments Fine adjusting equalizer curve You can adjust the center frequency and the Q factor (curve characteristics) of each currently selected curve band ( EQ Low/EQ Mid/EQ High Level (dB) Q=2N Center frequency Frequency (Hz) 1 Press and hold unitil frequency and the Q factor (e.g., ) appears in the dis- F 80 Q 1W...

  • Page 58: Adjusting Treble, Adjusting Loudness

    Section Audio Adjustments Adjusting treble You can adjust the cut-off frequency and the Treble level. • In modes, treble adjustment FRT1 FRT2 affects only the front output: rear output cannot be adjusted. 1 Press to select Treble Press until appears in the display. Treble •...

  • Page 59: Using Subwoofer Output, Adjusting Subwoofer Settings

    Audio Adjustments Using subwoofer output This unit is equipped with a subwoofer output which can be switched on or off. When a sub- woofer is connected to the rear output, first, switch the rear output setting to subwoofer, then turn the subwoofer output on. For more details, see Setting the rear output and subwoofer controller on page 73.

  • Page 60: Using Non Fading Output, Adjusting Non Fading Output Level, Using The High Pass Filter

    Section Audio Adjustments Using non fading output When the non fading output setting is on, the audio signal does not pass through this unit’s low pass filter (for the subwoofer), but is output through the RCA output. 1 Press to select non fading output on/off mode.

  • Page 61: Adjusting Source Levels

    Audio Adjustments Adjusting source levels SLA (Source level adjustment) lets you adjust the volume level of each source to prevent radi- cal changes in volume when switching between sources. • Settings are based on the volume level of the FM tuner, which remains unchanged. 1 Compare the FM tuner volume level with the level of the source you wish to adjust.

  • Page 62: Returning To The Previous Display

    Section Initial Settings for DVD player Calling up the SET UP MENU You can use this menu to change audio, subti- tle, parental lock and other DVD settings. This menu can be operated only by using the remote control when it is set to SET UP MENU Shows the set up menu status.

  • Page 63: Setting The Subtitle (subtitle Lang.), Setting Subtitles And Assist Subtitles On/off, Assist Subtitles

    Initial Settings for DVD player Setting the subtitle (SUBTITLE LANG.) You can set a desired subtitle language. If the selected subtitle language is recorded on the DVD, subtitles are displayed in that language. You can also switch subtitle and assist subtitle display ON/OFF.

  • Page 64: When You Select Others

    Section Initial Settings for DVD player Notes • If the selected language is not recorded on the disc, languages specified on the disc are displayed. • You can also switch the subtitle language during playback with SUBTITLE 26.) • Even if you use SUBTITLE tle language, this does not affect the settings here.

  • Page 65: Setting The Parental Lock (parental), Setting The Code Number And Level

    Initial Settings for DVD player Setting the menu language (MENU LANG.) You can set the preferred language for displays of menus recorded on a disc. 1 Move the joystick up/down to select MENU LANG is indicated in blue. MENU LANG. 2 Click the joystick.

  • Page 66: Changing The Level, When Playing Dvds Enabling Parental Lock

    Section Initial Settings for DVD player 6 Click the joystick. The parental lock level is set. Notes • We recommend to keep a record of your code number in case you forget it. • The parental lock level is recorded on the disc. You can confirm it by looking at the disc pack- age, included literature or on the disc itself.

  • Page 67: Setting Aspect Ratio (tv Aspect), Setting Angle Mark Display (angle)

    Initial Settings for DVD player Setting aspect ratio (TV ASPECT) There are two kinds of display. A wide screen display has a width-to-height ratio (TV aspect) of 16:9, while a regular display has a TV aspect of 4:3. Be sure to select the correct TV aspect for the display you use.

  • Page 68: Digital Output

    The selected digital output setting is set. Notes • Linear PCM output of DTS audio is not possi- ble. If you select put. • When using this unit with a Pioneer Multi- channel processor with digital input (DEQ- P7050), select • Pressing ous display.

  • Page 69

    • With discs do not feature a CSS (Content Scrambling System) copy guard signal, a 96 kHz digital signal is output. • When using this unit with a Pioneer Multi- channel processor (DEQ-P7050), select setting. If you select the sound will be output when playing discs fea- turing 96 kHz recordings.

  • Page 70: Setting Remote Control Code Type, If You Forget Your Code Number

    Setting remote control code type When the remote control operation switch is set , changing the remote control code type enables you to operate the Pioneer DVD player by the supplied remote control. There are three remote codes, code type...

  • Page 71: Adjusting Initial Settings, Setting The Time, Setting The Fm Tuning Step

    Initial Settings Adjusting initial settings Initial settings lets you perform initial set up of different settings for this unit. display FUNCTION Shows the function status. 1 Press and hold until the unit turns SOURCE off. • Pressing on the head unit also per- SOURCE forms the same operation.

  • Page 72: Setting The Am Tuning Step, Switching The Warning Tone, Switching The Auxiliary Setting

    Section Initial Settings 1 Press to select Press repeatedly until FM Step display. • Pressing on the head unit also FUNCTION performs the same operation. tuning step with 1 or ¡. 2 Select the Pressing 1 or ¡ will switch the FM tuning step between 50 kHz and 100 kHz.

  • Page 73: Switching The Dimmer Setting, Selecting The Brightness, Setting The Rear Output And Subwoofer Controller

    Initial Settings on or off with E or e. 2 Select Pressing E or e will switch and off and that status will be displayed (e.g., AUX :ON • Pressing 5 or ∞ on the head unit also per- forms the same operation. Switching the dimmer setting To prevent the display from being too bright at night, the display is automatically dimmed...

  • Page 74: Switching The Telephone Muting/attenuation, Switching The Automatic Disc Playback

    Section Initial Settings 1 Press to select Press repeatedly until Rear SP display. • Pressing on the head unit also FUNCTION performs the same operation. 2 Change the rear output setting with E or Pressing E or e will switch between (full-range speaker) and :FULL (subwoofer) and that status will be displayed.

  • Page 75: Other Functions Setting The Time Display On Or Off, Using Different Entertainment Displays

    Other Functions Setting the time display on or off You can display the clock on each sound source display. Press on the head unit to select the CLOCK time display. Each press of on the head unit turns CLOCK time display on or off. •...

  • Page 76: Using The Telephone Muting/attenuation, Telephone Muting/attenuation Function, Displaying Built-in Player Information

    (play time and digital output setting MODE B information) • You can only switch to when a Pioneer Multi-channel processor (DEQ- P7050) is connected. If of the digital output is set to LPCM, nothing will be displayed on the display.

  • Page 77: Compatible With Dvd, Video Cd And Cd Formats

    Additional Information Compatible with DVD, Video CD and CD Formats DVD, Video CD and CD discs that display the logos shown below can be played back on this product. For more information on discs compatible with this product, refer to the table below. Disc types and logos Diameter/Playable sides DVD VIDEO...

  • Page 78: Additional Information

    Section Additional Information Notes • With some DVD-Video discs, you may not be able to use certain functions. • Playback of some DVD-Video discs may not be possible. • With DVD-R/DVD-RW discs, only recordings made in the Video format (Video mode) can be played back.

  • Page 79: Care Of Discs

    Additional Information Care of discs • This product is designed for use with conven- tional, fully circular discs only. Use of shaped discs are not recommended for this product. • Check all discs before playing and discard cracked, scratched or warped discs. •...

  • Page 80: Language Code Chart For Dvd

    Section Additional Information Language code chart for DVD Language (code) Input code Japanese (ja) 1001 English (en) 0514 French (fr) 0618 Spanish (es) 0519 German (de) 0405 Italian (it) 0920 Chinese (zh) 2608 Dutch (nl) 1412 Portuguese (pt) 1620 Swedish (sv) 1922 Russian (ru) 1821...

  • Page 81: Troubleshooting, Common Problems

    Additional Information Troubleshooting Common problems Symptom Power doesn’t switch ON. The unit doesn’t operate. Operation with the remote control isn’t possible. The unit does not operate correctly even when the appropriate remote control buttons are pressed. Playback is not possible. There’s no sound.

  • Page 82

    Section Additional Information Common problems (continued) Symptom There’s no picture. The prohibited mark “ ” is displayed, and operation is not possible. The picture stops (pauses) and the unit cannot be operated. There’s no sound. Volume level is low. There’s audio and video skipping.

  • Page 83: Problems During Dvd Playback

    Additional Information Problems during DVD playback Symptom Playback is not possible. A Parental Lock message is displayed and playback is not possible. Parental Lock cannot be canceled. Dialog language (and subtitle language) cannot be switched. No subtitles are displayed. Cause Remedy The loaded disc has a different Replace the disc with one featuring the...

  • Page 84: Problems During Video Cd Playback

    Section Additional Information Problems during DVD playback (continued) Symptom Playback is not with the audio language and subtitle language settings selected in SET UP MENU. Switching the viewing angle is not possible. The picture is extremely unclear/distorted and dark during playback. Problems during Video CD playback Symptom The PBC (Playback Control)

  • Page 85: Error Messages

    Refer to the table below to identify the problem, then take the suggested corrective action. If the error persists, contact your dealer or your nearest PIONEER Service Center. Error massages on the OEL display Message Cause...

  • Page 86: Terms Of Dvd/video Cd

    Section Additional Information Terms of DVD/Video CD Aspect Ratio This is the width-to-height ratio of a TV screen. A regular display has an aspect ratio of 4:3. Wide- screen displays have an aspect ratio of 16:9, providing a bigger picture for exceptional pres- ence and atmosphere.

  • Page 87

    Additional Information Multi-Audio (Multilingual Dialog) Some DVDs feature dialog recorded in multiple languages. Dialog in up to 8 languages can be recorded on a single disc, letting you choose as desired. Multi-Subtitle Subtitles in up to 32 languages can be recorded on a single DVD, letting you choose as desired.

  • Page 88

    Section Connecting the units Notes • This unit is for vehicles with a 12-volt battery and negative grounding. Before installing it in a recreational vehicle, truck, or bus, check the battery voltage. • To avoid shorts in the electrical system, be sure to disconnect the ≠...

  • Page 89

    Connecting the units • This unit can not be installed in a vehicle that does not have an ACC (accessory) position on the ignition switch. ACC position No ACC position • The black lead is ground. Please ground this lead separately from the ground of high-cur- rent products such as power amps.

  • Page 90

    Section Connecting the units Power cable connection Multi-CD player (sold separately) When you connect separately sold Multi-channnel processor (DEQ-P7050) to this unit, do not connect anything to the speaker leads and system remote control (blue/white). Yellow/black If you use a cellular telephone, connect it via the Audio Mute lead on the cellular telephone.

  • Page 91

    Connecting the units Connection method Clamp the switch power supply side lead for the parking brake. Note • The position of the parking brake switch depends on the vehicle model. For details, consult the vehicle Owner’s Manual or dealer. Light green Used to detect the ON/OFF status of the parking brake.

  • Page 92: Connecting To Separately Sold Power Amp

    Section Connecting the units Connecting to separately sold power amp IP-BUS input (Blue) Refer to Power cable connection on page 90. Antenna jack Refer to Power cable connection on page 90. 23 cm Front output (FRONT OUTPUT) 23 cm 15 cm Subwoofer output or Non Fading Output (SUBWOOFER OUTPUT...

  • Page 93

    Connecting the units Connecting cords with RCA pin plugs (sold separately) Use this for connections when you have the separately available amplifier. Blue/white To system control terminal of the power amp or Auto-antenna relay control terminal (max. 300 mA 12 V DC). System remote control Subwoofer ≠...

  • Page 94: When Connecting With A Multi-channel Processor

    Section Connecting the units When connecting with a Multi-channel processor Black To audio inputs RCA cables (sold separately) Left (White) RCA cable (supplied with the multi-channel processor) Blue Multi-channel processor (DEQ-P7050) (sold separately) Blue Display with RCA input jacks To video input Hide-away TV Tuner (e.g.

  • Page 95

    Connecting the units Rear video output (REAR VIDEO OUTPUT) (Yellow) Subwoofer output or non fading output (SUBWOOFER OUTPUT or NON-FADING OUTPUT) Right (Red) Left (White) Front video 15 cm output (FRONT VIDEO OUTPUT) (Yellow) RCA cable (supplied) 1.5 m 15 cm Left (White) 15 cm...

  • Page 96: When Connecting The Display With Rca Input Jacks

    Section Connecting the units When connecting the display with RCA input jack This Product Front video output (FRONT VIDEO OUTPUT) 15 cm RCA cable (supplied) To video input Display with RCA input jacks 1.5 m...

  • Page 97: When Using A Display Connected To Rear Video Output

    Connecting the units When using a display connected to rear video output This product’s rear video output is for connection of a display to enable passengers in the rear seats to watch the DVD or Video CD. WARNING • NEVER install the display in a location that enables the Driver to watch the DVD or Video CD while Driving.

  • Page 98

    Section Installation Notes • Before finally installing the unit, connect the wiring temporarily, making sure it is all con- nected up properly, and the unit and the sys- tem work properly. • Use only the parts included with the unit to ensure proper installation.

  • Page 99: Din Front-mount, Installation With The Rubber Bush

    Installation DIN front-mount Installation with the rubber bush Dashboard Holder After inserting the holder into the dash- board, select the appropriate tabs according to the thickness of the dash-board material and bend them. (Install as firmly as possible using the top and bottom tabs.

  • Page 100: Removing The Unit

    Section Installation Removing the unit Frame Insert the supplied extraction keys into the unit, as shown in the figure, until they click into place. Keeping the keys pressed against the sides of the unit, pull the unit out. Insert the release pin into the hole in the bottom of the frame and pull out to remove the frame.

  • Page 101: Din Rear-mount, Installation Using The Screw Holes On The Side Of The Unit

    Installation DIN rear-mount Installation using the screw holes on the side of the unit 1 Remove the frame. Frame 2 Fastening the unit to the factory radio mounting bracket. Factory radio mounting bracket Insert the release pin into the hole in the bottom of the frame and pull out to remove the frame.

  • Page 102: Specifications

    Section Specifications Specifications General Power source ... 14.4 V DC (10.8 – 15.1 V allowable) Grounding system ... Negative type Max. current consumption ... 10.0 A Dimensions (W × H × D): (DIN) Chassis ... 178 × 50 × 161 mm Nose ...

  • Page 103

    Specifications DVD player System ... DVD-Video, Video CD, Compact disc audio system Region Number for Southeast Asian models: 3 for South American and Oceanian models: 4 Usable discs ... DVD-Video, Video CD, Compact disc Signal format: Sampling frequency ... 44.1/48/96 kHz Number of quantization bits ...

  • Page 104

    TEL: (03) 9586-6300 PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada TEL: (905) 479-4411 PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. San Lorenzo 1009 3er. Piso Desp. 302 Col. Del Valle Mexico, D.F. C.P. 03100 TEL: 55-5688-52-90 <KSNZF/02B00000>...

Comments to this Manuals

Symbols: 0
Latest comments:
