Operation Manual
DVD AV RECEIVER
AVH-P4950DVD
English

Advertisement

Table of Contents
loading

Related Manuals for Pioneer Super Tuner III D AVH-P4950DVD

Summary of Contents for Pioneer Super Tuner III D AVH-P4950DVD

  • Page 1 Operation Manual DVD AV RECEIVER AVH-P4950DVD English...

  • Page 2: Table Of Contents

    Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man- ual in a safe place for future reference.

  • Page 3: Precautions

    Precautions IMPORTANT SAFEGUARDS Please read all of these instructions regarding your display and retain them for future refer- ence. 1 Read this manual fully and carefully be- fore operating your display. 2 Keep this manual handy as a reference for operating procedures and safety informa- tion.

  • Page 4: To Avoid Battery Exhaustion

    Section Precautions When you attempt to watch a DVD, Video CD or TV while driving, the warning VIDEO VIEW- ING IS NOT AVAILABLE WHILE DRIVING will appear on the front display. To watch a DVD, Video CD or TV on the front display, park your vehicle in a safe place and apply the parking brake.

  • Page 5: Playable Discs

    ! If the battery is disconnected or discharged, the preset memory will be erased and must be reprogrammed. ! If this unit does not operate properly, contact your dealer or nearest authorized Pioneer Ser- vice Station. Playable discs DVD, Video CD and CD discs that display the logos shown below can be played back on this player.

  • Page 6: Visit Our Website

    Dolby Digital/DTS compatibility When using this unit with a Pioneer multi- channel processor, you can enjoy the atmo- sphere and excitement provided by DVD movie and music software featuring 5.1 channel re-...

  • Page 7: About Wma

    Before You Start ! Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. ! “DTS” and “DTS Digital Out” are registered trademarks of DTS, Inc. ® iPod compatibility When you use this unit with an interface adap- ter for iPod (CD-IB100B) (sold separately), you can control an iPod with Dock Connector.

  • Page 8: When An Operation Is Prohibited

    Section Before You Start To protect the LCD screen ! Do not allow direct sunlight to fall on the display when this unit is not being used. Extended exposure to direct sunlight can result in LCD screen malfunction due to the resulting high temperatures.

  • Page 9: Resetting The Microprocessor

    Before You Start Removing the front panel % Push the release button downward and release the front panel. Take care not to grip it too tightly or to drop the front panel and protect it from contact with water or other fluids to prevent perma- nent damage.

  • Page 10: Using The Remote Control

    Section Before You Start CAUTION ! Use only one CR2025 (3 V) lithium battery. ! Remove the battery if the remote control is not used for a month or longer. ! Danger of explosion if battery is incorrectly re- placed. Replace only with the same or equiva- lent type.

  • Page 11: Operating This Unit

    Operating this unit What’s What Head unit 1 INFO button Press to turn the information bar on/off. 2 PGM button Press to operate the preprogrammed func- tions for each source. (Refer to Using the PGM button on page 48.) 3 Ambient light sensor Senses ambient light.
  • Page 12 Section Operating this unit c BOOKMARK (BM) button Press to bookmark a scene that you want to resume playback. d BAND/ESC button Press to select among three FM bands and one AM band and to cancel the control mode of functions. e EQ button Press to select various equalizer curves.

  • Page 13: Remote Control

    Operating this unit Remote control 1 Remote control selection switch Switch to change the setting of the remote control. For details, refer to Setting remote control code type on page 41. 2 VOLUME buttons Press to increase or decrease the volume. 3 REAR.S button Not used.
  • Page 14 Section Operating this unit 9 BAND/ESC button AVH mode: Press to select among three FM bands and one AM band and to cancel the control mode of functions. DVD mode: Press to switch mode between compressed audio and audio data (CD-DA) when playing discs with compressed audio and audio data (CD-DA) such as CD-EXTRA and MIXED-MODE CDs.

  • Page 15: Using The Remote Control Operation Mode Switch

    With the mode switched to DVD, you cannot use these buttons; BACK and ENTERTAINMENT (ENT). TV mode operation TV operations available with a Pioneer TV tuner (e.g. GEX-P5750TV(P)) can be controled with AVH mode. TV mode is not used with this unit.

  • Page 16: Basic Operations

    (refer to page 43). — When the AV (AV input) is not set to VIDEO (refer to page 45). ! External unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this unit.

  • Page 17: Touch Panel Key Basic Operation

    Operating this unit Touch panel key basic operation Activating the touch panel keys 1 Touch panel keys Touch to do various operations. Touch the screen to activate the touch panel keys corresponding to each source. The touch panel keys appear on the display. # To go to the next group of touch panel keys, touch d.

  • Page 18: Changing The Wide Screen Mode

    Section Operating this unit ! When the ignition switch is turned OFF after the LCD panel has been closed, turn- ing the ignition switch ON again (or turning it to ACC) will not open the LCD panel. In this case, press OPEN/CLOSE to open the LCD panel.

  • Page 19: Changing The Picture Adjustment

    Operating this unit FULL (full) A 4:3 picture is enlarged in the horizontal direc- tion only, giving you a 4:3 TV picture (normal pic- ture) without any omissions. JUST (just) The picture is enlarged slightly at the center and the amount of enlargement increases horizontally to the ends, enabling you to enjoy a 4:3 picture without sensing any disparity even on a wide screen.
  • Page 20 Section Operating this unit Touch c or d to adjust the selected item. Each time you touch c or d it increases or de- creases the level of selected item. +24 to –24 is displayed as the level is increased or de- creased.

  • Page 21: Tuner

    Operating this unit Tuner Basic Operations 1 Source icon 2 Band indicator 3 Preset number indicator 4 Frequency indicator 5 Preset list display 6 LOCAL indicator Shows when local seek tuning is on. 7 STEREO indicator Shows when the selected frequency is being broadcast in stereo.

  • Page 22: Tuning In Strong Signals

    Section Operating this unit # When P1 to P6 are not displayed, you can dis- play them by touching LIST. # You can also use a and b buttons to recall radio station frequencies assigned to preset tun- ing keys P1 to P6. Introduction of advanced tuner operation Press A.MENU button to display MENU.

  • Page 23: Built-In Dvd Player

    Operating this unit Built-in DVD player Basic Operations The built-in DVD player can play back DVD video, Video CD, audio CD (CD-DA) and com- pressed audio (WMA/MP3) recorded on CD- ROM. (Refer to page 75 for files that can be played back.) Read the precautions with discs and player on Handling guideline of discs and player on page...

  • Page 24: Operating The Dvd Menu

    Section Operating this unit # To return to folder 001 (ROOT), press and hold BAND/ESC. However, if folder 001 (ROOT) con- tains no files, playback commences with folder 002. # You can also select a folder by pressing a or b button.

  • Page 25: Skipping Back Or Forward To Another Title

    Operating this unit Touch ENTER. Playback starts from the selected menu item. # You cannot operate the DVD menu from a/b/ c/d buttons on the head unit. # The way to display the menu differs depending on the disc. Operating the DVD menu with 10 key Some DVDs allow you to select from the disc contents using 10key.
  • Page 26 Section Operating this unit Touch d until 10key appears in the dis- play. Touch 10key. Touch 0 to 9 corresponding to a desired title number when the disc is stopped. Title number is displayed for eight seconds and playback starts from the selected title. ! To select 3, touch 3.

  • Page 27: Stopping Playback

    Operating this unit Changing the viewing angle during playback (Multi-angle) With DVDs featuring multi-angle (scenes shot from multiple angles) recordings, you can switch among viewing angles during play- back. ! This function is available for DVD. ! During playback of a scene shot from mul- tiple angles, the angle icon played.

  • Page 28: Slow Motion Playback

    Section Operating this unit Slow motion playback This lets you slow down playback speed. ! This function is available for DVD and Video CD. Keep touching r until during playback. The icon is displayed, forward slow mo- tion playback begins. # To return to normal playback, touch f.

  • Page 29: Text Information

    Operating this unit Notes ! PBC playback of Video CD cannot be can- celled. ! During playback of Video CDs featuring PBC (Playback Control), PBC ON, search and time search functions cannot be used nor can you select the range for repeat play. Text information Text information recorded on CD TEXT and compressed audio disc can be displayed.

  • Page 30: Introduction Of Advanced Operations

    Section Operating this unit Introduction of advanced operations 1 Function display Shows the function names. Press A.MENU button to display MENU. MENU appears on the display. Touch FUNCTION to display the func- tion names. The function names are displayed and oper- able ones are highlighted.

  • Page 31: Scanning Tracks Of A Cd

    Operating this unit Scanning tracks of a CD Scan play lets you hear the first 10 seconds of each track on the CD. When playing the compressed audio disc, the first 10 seconds of each track of the current folder (or the first track of each folder) is played.

  • Page 32: Selecting Tracks From The Track Title List

    Section Operating this unit ! If no title has been entered for the currently playing disc, NO DISC TITLE is displayed. Play the CD that you want to enter a title for. Touch T. EDIT on the function menu. Touch ABC to select the desired charac- ter type.

  • Page 33: Audio Adjustments

    Operating this unit Audio Adjustments Introduction of audio adjustments 1 Audio display Shows the audio adjustment status. Important If the multi-channel processor (DEQ-P7650) is connected to this unit, the audio function will be changed to the multi-channel processor’s audio menu. For details, refer to Introduction of DSP ad- justments on page 58.

  • Page 34: Using The Equalizer

    Section Operating this unit Using the equalizer The equalizer lets you adjust the equalization to match car interior acoustic characteristics as desired. Recalling equalizer curves There are six stored equalizer curves which you can easily recall at any time. Here is a list of the equalizer curves: Display Equalizer curve...

  • Page 35: Adjusting Bass And Treble

    Operating this unit 2W—1W—1N—2N Note If you make adjustments, CUSTOM curve is up- dated. Adjusting bass and treble You can adjust bass and treble settings. ! If EQ-EX function has been selected and only when EQ-EX is turned on and CUSTOM is selected as the equalizer curve, you can adjust bass and treble set- tings.

  • Page 36: Using Nonfading Output

    Section Operating this unit Touch b and then touch c or d to se- lect the phase of subwoofer output. Touch d to select normal phase and NORMAL appears in the display. Touch c to select reverse phase and REVERSE appears in the display.

  • Page 37: Adjusting Source Levels

    Operating this unit Adjusting source levels SLA (source level adjustment) lets you adjust the volume level of each source to prevent ra- dical changes in volume when switching be- tween sources. ! Settings are based on the FM volume level, which remains unchanged.

  • Page 38: Setting Up The Dvd Player

    Section Operating this unit Setting up the DVD player Introduction of DVD setup adjustments You can use this menu to change audio, subti- tle, parental lock and other DVD settings. 1 DVD setup menu display Shows the DVD setup menu names. Touch g.

  • Page 39: Switching The Assist Subtitle On Or Off

    Operating this unit Touch SETUP and LANGUAGE and then touch AUDIO LANG. Audio language menu is displayed and the currently selected language is highlighted. # To switch to the second language select menu, touch NEXT. # To return to the first language select menu, touch PREV.

  • Page 40: Setting The Parental Lock

    Section Operating this unit ! When using a regular display, select either LETTER BOX or PANSCAN. Selecting 16 : 9 may result in an unnatural picture. ! If you select the TV aspect, the unit’s dis- play changes to the same setting. Touch SETUP and VISUAL and then touch TV ASPECT.

  • Page 41: Setting Remote Control Code Type

    Setting remote control code type When the remote control operation switch is set to DVD, changing the remote control code type enables you to operate the Pioneer DVD player with the supplied remote control. There are three remote codes, code type A, code type B and code type AVH.

  • Page 42: Initial Settings

    Section Operating this unit Initial Settings Adjusting initial settings Important Following function cannot be operated in your area. (Inoperable function is indicated in grays- cale.) — V.D.P. MIX Using the initial settings, you can customize various system settings to achieve optimal per- formance from this unit.

  • Page 43: Setting The Rear Output And Subwoofer Controller

    Operating this unit % Touch D. WARN on the initial menu to turn warning tone on. # To turn warning tone off, touch D. WARN again. Switching the auxiliary setting It is possible to use auxiliary equipment with this unit. Activate the auxiliary setting when using auxiliary equipment connected to this unit.

  • Page 44: Correcting Distorted Sound

    Section Operating this unit Notes ! Even if you change this setting, there is no output unless you turn the nonfading output (refer to Using nonfading output on page 36) or subwoofer output (refer to Using subwoofer output on page 35) in the audio menu on. ! If you change the subwoofer controller, sub- woofer output and nonfading output in the audio menu return to the factory settings.

  • Page 45: Other Functions

    Touching TV SIG switches TV signal settings in the following order: AUTO—PAL—NTSC—PAL-M—SECAM Note About your country TV signal, consult with your nearest Pioneer dealer. Other Functions Introduction of setup adjustments Important Following function cannot be operated in your area. (Inoperable function is indicated in grays- cale.)

  • Page 46: Setting For Rear View Camera

    S-DVD. Setting for rear view camera (back up camera) CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, other- wise screen image may appear reversed. Important Following functions cannot be operated in your area.

  • Page 47: Using The Aux Source

    Operating this unit Touch a to turn the set back on and the LCD panel slides to the back. # Touch b to turn the set back off and the LCD panel slides to the front. Touch c or d to select the display to open/close automatically or manually.

  • Page 48: Using The Pgm Button

    Section Operating this unit Alphabet (upper case), numbers and symbols —alphabet (lower case)—European letters, such as those with accents (e.g., á, à, ä, ç) # You can select to input numbers and symbols by touching 123. Touch a or b to select a letter of the al- phabet.

  • Page 49: Available Accessories

    Available accessories Playing songs on iPod Listening to songs on your iPod You can use this unit to control an interface adapter for iPod, which is sold separately. 1 Source icon 2 Song number indicator 3 Play time indicator 4 Song title indicator 5 Repeat indicator Shows when repeat range is selected to cur- rent track.

  • Page 50: Pausing A Song

    Section Available accessories Pausing a song % Touch f during playback. # To resume playback at the same point that you turned pause on, touch f again. Displaying text information on iPod % Touch DISP. Touch DISP repeatedly to switch between the following settings: T.

  • Page 51: Multi-Cd Player

    Available accessories Multi-CD Player Basic Operations You can use this unit to control a multi-CD player, which is sold separately. ! Only those functions described in this man- ual are supported by 50-disc multi-CD players. ! This unit is not designed to operate disc title list functions with a 50-disc multi-CD player.

  • Page 52: Using Its Playlists

    Section Available accessories Function and operation REPEAT, RANDOM, SCAN, PAUSE, Compression and T. EDIT operations are basi- cally the same as that of the built-in DVD player. Function name Operation Refer to Repeating play on page 30. But the repeat play ranges you can select are different from that of the built-in DVD player.

  • Page 53: Entering Disc Titles

    Available accessories Playback from your ITS playlist ITS play lets you listen to the tracks that you have entered into your ITS playlist. When you turn on ITS play, tracks from your ITS playlist in the multi-CD player will begin to play. Select the repeat range.

  • Page 54: Dvd Player

    Section Available accessories Displaying disc titles % Touch DISP. Touch DISP repeatedly to switch between the following settings: DISC LIST (disc list)—D.Title (disc title) When you select D.Title, the title of the cur- rently playing disc is shown in the display. # If no title has been entered for the currently playing disc, NO DISC TITLE is displayed.

  • Page 55: Selecting A Disc

    Available accessories Touch the screen to display the touch panel keys. To skip back or forward to another chapter/track, briefly touch c or d. To perform fast forward or reverse, keep touching c or d. Note If you do not use the touch panel keys within 30 seconds, they will be hidden automatically.

  • Page 56: Tv Tuner

    Section Available accessories Notes ! If you select other discs during repeat play, the repeat play range changes to DISC. ! When playing back Video CD or CD, if you per- form track search or fast forward/reverse dur- ing TRACK, the repeat play range changes to DISC.

  • Page 57: Storing And Recalling Broadcast Stations

    Available accessories # When the list of channels is not displayed, touch LIST. To perform manual tuning, briefly touch c or d. The channels move up or down step by step. To perform seek tuning, keep touching c or d for about one second and release. The tuner will scan the channels until a broad- cast strong enough for good reception is found.

  • Page 58: Digital Signal Processor

    Section Available accessories Note Storing broadcast stations with BSSM may re- place broadcast stations you have saved using P01 to P12. Selecting the area group Touch COUNTRY on the function menu. Touch c or d to select the area group. Touch c or d until the desired area group ap- pears in the display.

  • Page 59: Using The Sound Field Control

    Available accessories # To go to the next group of function names, touch NEXT. # To return to the previous group of function names, touch PREV. # When playing discs recorded with more than 96 kHz sampling frequency, you cannot use audio functions.
  • Page 60 Section Available accessories Using the position selector One way to assure a more natural sound is to accurately position the stereo image, putting you right in the center of the sound field. The position selector function lets you automati- cally adjust the speaker output levels and in- serts a delay time to match the number and position of occupied seats.

  • Page 61: Using The Direct Control

    Available accessories Notes ! The AM volume level can also be adjusted with source level adjustments. ! Video CD, CD and compressed audio are set to the same source level adjustment volume automatically. ! DVD and the optional DVD player are set to the same source level adjustment volume automatically.

  • Page 62: Setting The Speaker Setting

    Section Available accessories ! ADJUST – Adjust the Music mode # You can operate ADJUST only when MUSIC has been selected. Adjusting the Music mode You can adjust the Music mode with the fol- lowing three controls. ! Panorama (PANORAMA) extends the front stereo image to include the surround speakers for an exciting “wraparound”...
  • Page 63 Available accessories Touch a or b to select the speaker to be adjusted. Each time you touch a or b selects the speak- er in the following order: FRONT (front speakers)—CENTER (center speaker)—REAR (rear speakers)— SUB WOOFER (subwoofer)—PHASE (subwoo- fer setting) # You can switch to PHASE only when the sub- woofer has been set to ON.

  • Page 64: Adjusting The Speaker Output Levels Using A Test Tone

    Section Available accessories FRONT (front speakers)—CENTER (center speaker)—REAR (rear speakers)— SUB WOOFER (subwoofer) Touch c or d to select cross-over fre- quency. Each time you touch c or d selects cut-off fre- quencies in the following order: 63—80—100—125—160—200 (Hz) Note Selecting a cross-over frequency is to set a cross- over frequency of the subwoofer’s L.P .F.

  • Page 65: Using The Time Alignment

    Available accessories Touch c or d to adjust the speaker out- put level. Each time you touch c or d increases or de- creases the speaker output level. +10 to –10 is displayed as the level is increased or de- creased.
  • Page 66 Section Available accessories Using the equalizer The equalizer lets you adjust the equalization to match car interior acoustic characteristics as desired. Recalling equalizer curves There are seven stored equalizer curves which you can easily recall at any time. Here is a list of the equalizer curves: Display Equalizer curve...
  • Page 67 Available accessories LOW (low)—MID (mid)—HIGH (high) Touch b and then touch c or d to se- lect the center frequency of selected band. Touch c or d until the desired frequency ap- pears in the display. 40Hz—50Hz—63Hz—80Hz—100Hz—125Hz —160Hz—200Hz—250Hz—315Hz—400Hz— 500Hz—630Hz—800Hz—1kHz—1.25kHz— 1.6kHz—2kHz—2.5kHz—3.15kHz—4kHz— 5kHz—6.3kHz—8kHz—10kHz—12.5kHz Touch b and then touch c or d to ad- just the equalizer level.
  • Page 68 Section Available accessories Before operating the auto TA and EQ function ! Carry out auto TA and EQ in as quiet a place as possible, with the car engine and air conditioning switched off. Also cut power to car phones or portable telephones in the car, or remove them from the car be- fore carrying out auto TA and EQ.
  • Page 69 Available accessories # Press SOURCE to turn the source on if this unit is turned off. Select the position for the seat on which the microphone is placed. Refer to Using the position selector on page # If no position is selected before you start auto TA and EQ, FRONT-L is selected automatically.

  • Page 70: Additional Information

    Appendix Additional Information Troubleshooting Common Symptom Power doesn’t turn on. The unit doesn’t operate. Playback is not possible. No sounds are heard. The volume level will not rise. There is no picture. The icon is displayed, and op- eration is not possible. The picture stops (pauses) and the unit cannot be operated.
  • Page 71 Additional Information Problems during DVD playback Symptom Cause Playback is not possible. The loaded disc has a different re- gion number from this unit. A parental lock message is dis- Parental lock is on. played and playback is not pos- sible.

  • Page 72: Error Messages

    Appendix Additional Information Error messages When you contact your dealer or your nearest Pioneer Service Center, be sure to record the error message. Message ERROR-02 ERROR-05 DIFFERENT REGION DISC (RE- GION ERR) NON PLAYABLE DISC (NON- PLAY) THERMAL PROTECTION IN...

  • Page 73: Understanding Messages

    Additional Information Understanding messages Messages VIDEO VIEWING IS NOT AVAILABLE WHILE DRIVING YOU CANNOT USE THIS FUNCTION WHILE DRIVING Please source unit off Hold EQ button 2 sec, Set Auto EQ&TA Can`t adjust Time Alignment. Set Position FL or FR Press track list to play and title will ap- pear Translation...

  • Page 74: Handling Guideline Of Discs And Player

    Appendix Additional Information Handling guideline of discs and player ! Use only conventional, fully circular discs. Do not use shaped discs. ! Do not use cracked, chipped, warped, or otherwise damaged discs as they may da- mage the player. ! Do not touch the recorded surface of the discs.

  • Page 75: Dual Discs

    Additional Information ! Playback of discs recorded on a personal computer may not be possible, depending on the application settings and the environ- ment. Please record with the correct for- mat. (For details, contact the manufacturer of the application.) ! Playback of CD-R/CD-RW discs may be- come impossible in case of direct exposure to sunlight, high temperatures, or the sto- rage conditions in the vehicle.

  • Page 76: Using The Display Correctly

    ! If liquid or foreign matter should get inside this unit, turn off the power immediately and consult your dealer or the nearest authorized PIONEER Service Station. Do not use the unit in this condition because doing so may result in a fire, electric shock, or other failure.

  • Page 77: Keeping The Display In Good Condition

    — When the fluorescent tube reaches the end of its useful life, the screen will be dark and the image will no longer be projected. If this happens, consult your dealer or the nearest authorized PIONEER Service Station. Appendix...

  • Page 78: Language Code Chart For Dvd

    Appendix Additional Information Language code chart for DVD Language (code), input code Japanese (ja), 1001 English (en), 0514 French (fr), 0618 Spanish (es), 0519 German (de), 0405 Italian (it), 0920 Chinese (zh), 2608 Dutch (nl), 1412 Portuguese (pt), 1620 Swedish (sv), 1922 Russian (ru), 1821 Korean (ko), 1115 Greek (el), 0512...

  • Page 79: Terms

    Additional Information Terms Aspect ratio This is the width-to-height ratio of a TV screen. A regular display has an aspect ratio of 4:3. Wide screen displays have an aspect ratio of 16:9, providing a bigger picture for exceptional presence and atmosphere. Bit rate This expresses data volume per second, or bps (bits per second) units.
  • Page 80 Appendix Additional Information Linear PCM (LPCM)/Pulse code modulation This stands for linear pulse code modulation, which is the signal recording system used for music CDs and DVDs. Generally, DVDs are re- corded with higher sampling frequency and bit rate than CDs. Therefore, DVDs can provide higher sound quality.
  • Page 81 Appendix Additional Information Region number DVD players and DVD discs feature region numbers indicating the area in which they were purchased. Playback of a DVD is not pos- sible unless it features the same region num- ber as the DVD player. This unit’s region number is displayed on the bottom of the unit.

  • Page 82: Specifications

    Appendix Additional Information Specifications General Rated power source ... 14.4 V DC (allowable voltage range: 12.0 V to 14.4 V DC) Grounding system ... Negative type Max. current consumption ... 10.0 A Dimensions (W × H × D): Chassis ... 178 × 50 × 160 mm Nose ...
  • Page 83 Additional Information Signal-to-noise ratio ... 97 dB (1 kHz) (IEC-A net- work) (CD: 96 dB (1 kHz) (IEC-A network)) Dynamic range ... 95 dB (1 kHz) (CD: 94 dB (1 kHz)) Distortion ... 0.008 % (1 kHz) Output level: Video ... 1.0 Vp-p/75 W (±0.2 V) Audio ...

  • Page 84: Index

    Index Angle icon ...27,.39 Aspect ratio ...39,.79 Audio language ...26,.38 Bookmark ...31 Brightness ...19 Chapter ...79 Code number ...40 Color ...19 Contrast ...19 Direct search ...25 DTS ...6,.79 Hue ...19 Language code chart ...78 Linear PCM (LPCM) ...80 Menu language ...39 MPEG ...80 Multi-angle ...27,.80 Multi-audio ...26,.80...
  • Page 85 TEL: (03) 9586-6300 PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada TEL: 1-877-283-5901 PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270 先鋒股份有限公司...
