- Page 1 TECHNICAL MANUAL VIP SYSTEM Art.1456 FLOOR VIP SYSTEM GATEWAY SOLO CON CAVO ROSSO COMELIT 2E7T000500 ONLY WITH COMELIT RED CABLE 2E7T000500 FIXED POE SETTABLE POE NO POE HOME 1 HOME 2 HOME 3 HOME 4 Apartment gateway 1456 /1456S...
-
Page 2: Table Of Contents
Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products. -
Page 3: Description
• can be configured remotely from a web interface; • in the master version (Art. 1456), does not require door entry monitors to be connected. FLOOR VIP SYSTEM GATEWAY SOLO CON CAVO ROSSO COMELIT 2E7T000500 ONLY WITH COMELIT RED CABLE 2E7T000500... -
Page 4: Art. 1456 Functions
Master door entry monitor not required (already integrated in the 1456) • Up to 15 slaves devices can be added for each apartment, including: Smartphone / Tablet + Comelit App, PSTN / GSM Telephone, Door entry phone (configured as Slave) -
Page 5: Settable Poe
Only connect to the router or PC Only connect to the router or PC using the red Comelit cable 1449 using the red Comelit cable 1449 With the device powered by Art. 1440 via port VIP SYSTEM, there will be sufficient PoE power available to operate a maximum of 1 door as “POE”... -
Page 6: Technical Characteristics
Technical characteristics MAIN FEATURES Compatible system ViP DIN rail mounted Yes DIN modules (no.) 4 Power supply voltage 48Vdc - 56Vdc Min/max power consumption (mA) 50mA Operating temperature (°C) +5°C to +40°C Operating relative humidity 25% / 75% IP protection rating IP30 GENERAL DATA Product height (mm) 62 Product width (mm) 70... -
Page 7: Configuration Art.1456 / 1456S
Art. 1456S requires an internal unit assigned to a master monitor. 1) Connection f Article 1456/1456S has 2 network interfaces, HOME and VIP SYSTEM, labelled for easy identification, which can be configured separately to meet different system requirements. Depending on the type of system, connect the devices as... -
Page 8: Kit System
KIT SYSTEM Art.1441 Art.1441B VIP SYSTEM Art.1456 FLOOR VIP SYSTEM GATEWAY HOME INTERFACE SOLO CON CAVO ROSSO COMELIT 2E7T000500 ONLY WITH COMELIT RED CABLE 2E7T000500 FIXED POE SETTABLE POE NO POE STATIC IP ADDRESS HOME 1 HOME 2 HOME 3 HOME 4 192.168.1.200 (default) -
Page 9: Vip Manager Addressing
CASE 1: default address of the device (192.168.1.200) belonging to the same router network (e.g.: 192.168.1.1) Art.1456 FLOOR VIP SYSTEM GATEWAY HOME INTERFACE SOLO CON CAVO ROSSO COMELIT 2E7T000500 ONLY WITH COMELIT RED CABLE 2E7T000500 FIXED POE SETTABLE POE NO POE... - Page 10 3. Select art.1456 / 1456S [f], select Information/ViP address [g], assign an unequivocal ViP address to the device [h] and press Write page [i] to save the current settings. In the case of a system with 2 1456 / 1456S devices, it will be necessary to assign to interface HOME of one of the two devices a new “Static IP address”...
-
Page 11: Case 2: Default Address Of The Device (192.168.1.200) Not Belonging To The Same Router Network (E.g.: 192.168.0.1)
192.168.1.2)* that belongs to the same network as the IP address of interface HOME (default=192.168.1.200)and confirm [d]. * the last value must be within the range of 2 to 253 excluding: 200 (assigned to the gateway Art. 1456 /1456S) and the values already assigned to other devices connected to the network. - Page 12 ONLY for the interface connected to the router (interface HOME by default) » device 1456 / 1456S will now be in the same network as the router (192.168.0.X) Art.1456 FLOOR VIP SYSTEM GATEWAY HOME INTERFACE SOLO CON CAVO ROSSO COMELIT 2E7T000500...
- Page 13 3. Select art.1456 / 1456S [f], select Information/ViP address [g], assign an unequivocal ViP address to the device [h] and press Write page [i] to save the current settings.
-
Page 14: Dyndns Configuration For Remote Connection
DNS”) allows a DNS name to be permanently associated with the IP address of the same host, even if that address subsequently changes. A DynDNS must be registered in order to make the 1456 /1456S accessible from a remote web page and to allow operation of the ComelitViP remote / Comelit 1.0 application. -
Page 15: Port Forwarding Setting For Remote Connection
This procedure enables an external user (mobile phone) to access a device on a local network (1456 /1456S). The procedure for opening router ports for device 1456 /1456S is required in order to allow remote access to the system via a web page (port TCP 8080) and via an App (port TCP 64100*, port UDP 64100*). -
Page 16: Sip Settings
5 rows. A maximum of 15 SIP phone lines may be enabled. The lines are shared by all the system users connected to the device 1456 / 1456S and are managed according to the rule “First come, first served”. -
Page 17: Users Configuration (Devices)
Internal unit: Comelit ViP internal unit; App: Comelit App for Android or Apple devices (consult the relative manual for further details); Telephone: virtual ViP device controlled by the 1456 / 1456S and used to make phone calls to a landline or mobile phone. -
Page 18: App Directories Configuration
Cameras, External Units, Actuators, Lock releases, Lock release actions, Additional Actuators. Enable directory modifications 1. Select art. 1456 / 1456S and select App directories/Enable directory modifications [a]. 2. Tick Enable directory modifications [b] 3. Press Write page [c] to save the current settings. - Page 19 Intercoms f Configure the call to an entire apartment or to an individual device within the apartment, by completing the following fields: Description Enter the description. ViP address Enter the ViP address From the pull-down menu, choose whether to configure a call to the entire apartment or only to the Master/Slave master monitor or to a slave monitor, as required.
-
Page 20: Message Server Configuration
10) that you wish to control 8) Message server configuration The following procedure describes how to specify on the art. 1456 / 1456S the IP or ViP address of the art. 1952 device to be used as a message server (if present) 1. -
Page 21: Special Configurations
Video connection settings From the next configuration page you can: change the video connection limit on the network or on the App. 1. Select the device 1456 / 1456S and select Configuration/Video connections [a]. 2. Edit the values you wish to personalise. -
Page 22: Connection To The Configuration Web Pages
= 213.149.219.88 1B) Local connection √ With the PC connected via Ethernet cable to interface HOME of art. 1456 / 1456S and IP address belonging to the same network as interface HOME. 1B. Enter the IP address of interface HOME as in the following example, and press enter. -
Page 23: Backup And Restore
Backup and restore The backup function allows you to save the current configuration, which can then be subsequently called up at any using the restore function. The backup and restore functions are only available from the configuration web pages (to access the web pages, see Connection to the configuration web pages) -
Page 24: Reboot With Predetermined Network Settings
Reboot with predetermined network settings The function reboot with predetermined network settings allows you restart the device with the default network parameter settings (interface A= 192.168.1.200), while keeping the other settings unchanged. √ With the dip switches in the default positions (OFF). 1. -
Page 25: Wiring Diagrams
Wiring diagrams Wiring diagram for standard multi-residential system VIP INTERFACE HOME INTERFACE AUTO IP IP: 192.168.1.X APT. 4: 1456 INTERNET PROVIDER ROUTER PSTN 1456 HO HO HO HOME INTERFACE 1441 1440 IP: 192.168.0.X 100-240 V APT. 3: 1456S 6722W INTERNET... -
Page 26: Apartment Gateway Art. 1456S
RX - WHITE/GREEN WIRE RX + 120-230 V NC NO 4894HIM VIPK/004HIR VIP 100 System wiring for single-family kit Art. 8513IM /8513HIM with router and master apartment gateway Art. 1456 HOME INTERFACE IP: 192.168.0.X INTERNET PROVIDER ROUTER PSTN 1441B 1456... -
Page 27: Glossary
Glossary* • Autoip: Automatic Private IP Addressing (known as APIPA or Auto IP), is a method for automatically assigning IP addresses to the devices connected to the network. • Dynamic DNS: Dynamic DNS is a technology that allows a DNS name to be permanently associated with the IP address of the same host, even if that address subsequently changes. - Page 28 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
