Manual de instrucciones High power CD/MP3/WMA/AAC player with Bluetooth Wireless Technology, FM/AM tuner and Multi CD con- trol Reproductor de CD/MP3/WMA/ACC de alta potencia con tecnología inalámbrica Bluetooth, sintonizador FM/AM y control de CD múltiple DEH-P7850BT Black plate (1,1) <CRD4060-A/N>1...
Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man- ual in a safe place for future reference.
Page 3
Contents Pausing MP3/WMA/AAC/WAV playback 28 Using compression and BMX 28 Selecting the search method 29 Searching every 10 tracks in the current folder 29 Displaying text information on MP3/WMA/ AAC/WAV disc 29 – When playing back an MP3/WMA/AAC disc 29 –...
Page 4
Contents Pausing a song 50 Stopping playback 51 Disconnecting a Bluetooth audio player 51 Displaying BD address of this unit 51 Displaying system version for repair 51 Multi-CD Player Playing a CD 52 Selecting a track directly 52 50-disc multi-CD player 53 Introduction of advanced multi-CD player operation 53 Repeating play 54...
Page 5
Contents – Recalling equalizer curves 72 – Adjusting equalizer curves 72 – Adjusting 7-band graphic equalizer 72 Adjusting loudness 73 Using subwoofer output 73 – Adjusting subwoofer settings 73 Boosting the bass 74 Using the high pass filter 74 Adjusting source levels 74 Initial Settings Adjusting initial settings 76 Selecting the display language 76...
! If the battery is disconnected or discharged, the preset memory will be erased and must be reprogrammed. ! If this unit does not operate properly, contact your dealer or nearest authorized Pioneer Ser- vice Station. About this manual This unit features a number of sophisticated functions ensuring superior reception and op- eration.
Before You Start ® iPod compatibility When you use this unit with a Pioneer iPod adapter (CD-IB100), you can control an iPod with Dock Connector. ! iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
Section Before You Start Resetting the microprocessor The microprocessor must be reset under the following conditions: ! Prior to using this unit for the first time after installation ! If the unit fails to operate properly ! When strange or incorrect messages ap- pear on the display % Press RESET with a pen tip or other pointed instrument.
Before You Start Removing the front panel Press and hold EJECT to open the front panel. Slide and remove the front panel to- ward you. Take care not to grip it too tightly or to drop the front panel and protect it from contact with water or other fluids to prevent perma- nent damage.
Section Before You Start Use and care of the remote control Installing the battery Slide the tray out on the back of the remote control and insert the battery with the plus (+) and minus (–) poles pointing in the proper di- rection.
Page 11
Black plate (11,1) Section Before You Start Fader (balance adjustment)—PWRFL (graphic equalizer adjustment)—50Hz (7-band graphic equalizer adjustment)—LOUD (loudness)— Sub W.1 (subwoofer on/off setting)—Sub W.2 (subwoofer setting)—Bass (bass boost)—HPF (high pass filter)—SLA (source level adjust- ment) Note Refer to Introduction of audio adjustments on page 71.
Section What’s What 1 1 1 c c c Head unit 1 BAND button Press to select among three FM bands and one AM band and to cancel the control mode of functions. 2 SOURCE button This unit is turned on by selecting a source. Press to cycle through all the available sources.
Page 13
What’s What d d d 1 1 1 e e e m m m 2 2 2 l l l c c c k k k j j j i i i d VOLUME buttons Press to increase or decrease the volume. e FUNCTION button Press to select functions.
— When the BT Audio source is set to off (refer to Activating the BT Audio source on page 80). ! External unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this unit.
Basic Operations ! If you cannot insert a disc completely or if after you insert a disc the disc does not play, check that the label side of the disc is up. Press EJECT to eject the disc, and check the disc for damage before inserting it again.
Section Tuner Listening to the radio 1 1 1 1 2 2 2 2 6 6 6 These are the basic steps necessary to operate the radio. More advanced tuner operation is explained starting on the next page. Important If you are using this unit in North, Central or South America, reset the AM tuning step (see Setting the AM tuning step on page 78).
Tuner Introduction of advanced tuner operation 1 1 1 1 Function display Shows the function status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION. Turn to change the menu option; press to se- lect.
Section Tuner Use MULTI-CONTROL to select BSM in the function menu. BSM appears in the display. Press MULTI-CONTROL to turn BSM on. Searching is displayed. While Searching is displayed, the six strongest broadcast frequen- cies will be stored under 0-9 (1-6) on the re- mote control in the order of their signal strength.
Built-in CD Player Playing a CD 3 3 3 These are the basic steps necessary to play a CD with your built-in CD player. More ad- vanced CD operation is explained starting on the next page. 1 Track number indicator Shows the track number currently playing.
Section Built-in CD Player Introduction of advanced built-in CD player operation 1 1 1 1 Function display Shows the function status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION.
Built-in CD Player Scanning tracks of a CD Scan play lets you hear the first 10 seconds of each track on the CD. Use MULTI-CONTROL to select Scan mode in the function menu. Scan mode appears in the display. Press MULTI-CONTROL to turn scan play The first 10 seconds of each track is played.
Section Built-in CD Player Searching every 10 tracks in the current disc If a disc contains over 10 tracks, you can search every 10 tracks. When a disc contains many tracks, you can roughly search for the track you want to play. Select the search method Rough search.
Built-in CD Player Move the cursor to the last position by pushing MULTI-CONTROL right after enter- ing the title. When you push MULTI-CONTROL right one more time, the entered title is stored in mem- ory. Press BAND to return to the playback display.
Page 24
Section Built-in CD Player Press LIST to switch to the track title list mode. Use MULTI-CONTROL to select the de- sired track title. Turn to change the track title; press to play. # You can also change the track title by pushing MULTI-CONTROL up or down.
MP3/WMA/AAC/WAV Player Playing MP3/WMA/AAC/ WAV files 1 1 1 1 2 2 2 2 6 6 6 5 5 5 These are the basic steps necessary to play an MP3/WMA/AAC/WAV with your built-in CD player. More advanced MP3/WMA/AAC/WAV operation is explained starting on page 27. 1 MP3/WMA/AAC/WAV indicator Shows the type of file currently playing.
Section MP3/WMA/AAC/WAV Player ! The built-in CD player can play back an MP3/ WMA/AAC/WAV file recorded on CD-ROM. (Refer to page 85 for files that can be played back.) ! Playback is carried out in order of file number. Folders are skipped if they contain no files. (If folder 01 (ROOT) contains no files, playback commences with folder 02.) ! When playing back files recorded as VBR...
MP3/WMA/AAC/WAV Player Introduction of advanced built-in CD player (MP3/ WMA/AAC/WAV) operation 1 1 1 1 Function display Shows the function status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION.
Section MP3/WMA/AAC/WAV Player Press MULTI-CONTROL to turn random play on. Tracks will play in a random order within the previously selected Folder repeat or Disc repeat ranges. # To turn random play off, press MULTI-CONTROL again. Scanning folders and tracks While you are using Folder repeat, the begin- ning of each track in the selected folder plays for about 10 seconds.
MP3/WMA/AAC/WAV Player Selecting the search method You can switch the search method between fast forward/reverse and searching every 10 tracks. Use MULTI-CONTROL to select Search mode in the function menu. Search mode appears in the display. Press MULTI-CONTROL to select the search method.
Section MP3/WMA/AAC/WAV Player When playing back a WAV disc % Press DISPLAY. Press DISPLAY repeatedly to switch between the following settings: Play time— : folder name and play time— : file name and play time— : file name # If specific information has not been recorded on a WAV disc, name is not displayed.
Bluetooth Telephone Hands-free phoning with cellular phones featuring Bluetooth wireless technology 8 7 6 If your cellular phone features Bluetooth wire- less technology, you can connect to this unit for hands-free, wireless calls, even while driving. Important Since this unit is on standby to connect with your cellular phones via Bluetooth wireless technol- ogy, using this unit without running the engine can result in battery drainage.
Section Bluetooth Telephone — SDP (Service Discovery Protocol) — OPP (Object Push Profile) — HSP (Head Set Profile) — HFP (Hands Free Profile) — A2DP (Advanced Audio Distribution Pro- file) — AVRCP (Audio/Video Remote Control Pro- file) ! When phone is selected as a source, volume and equalizer curve are automatically chan- ged to suitable settings for the phone source.
Bluetooth Telephone Basic operation of hands- free phoning These are the basic operations to use hands- free phoning via Bluetooth wireless technol- ogy. More advanced hands-free phoning op- erations are explained starting on Introduction of advanced hands-free phoning operation on page 35.
Section Bluetooth Telephone Taking a phone call Answering an incoming call Even when a source other than Telephone is selected or when this unit itself is turned off, you can still answer incoming calls. If you set this unit to automatically answering incoming calls, refer to Setting the automatic answering on page 46.
Bluetooth Telephone Introduction of advanced hands-free phoning operation 1 Function display Shows the function status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO, ENTERTAINMENT and RECEIVING MOVIE appear in the display. Use MULTI-CONTROL to select FUNCTION. Turn to change the menu option; press to se- lect.
Press MULTI-CONTROL to connect the selected cellular phone. While connecting, Connecting is displayed. To complete the connection, please check the device name (Pioneer BT Unit) and enter the link code on your cellular phone. If the con- nection is established, Connected is dis- played.
Bluetooth Telephone # The link code is set to 0000 as default. You can change this code in the initial setting. Refer to Entering PIN code for Bluetooth wireless con- nection on page 80. Disconnecting a cellular phone When you are done using your phone with this unit, you can close the Bluetooth wireless con- nection.
Section Bluetooth Telephone Push MULTI-CONTROL up or down to select a registration assignment. Each time MULTI-CONTROL is pushed up or down, the registration assignment is switched in the following order: P1 (user phone 1)—P2 (user phone 2)—P3 (user phone 3)—G1 (guest phone 1)—G2 (guest phone 2) # If the assignment is empty, No data is dis- played and the operation is not possible.
Bluetooth Telephone Use MULTI-CONTROL to select Auto connect in the function menu. Auto connect appears in the display. Press MULTI-CONTROL to turn auto- matic connection on. ON appears in the display. If your cellular phone is set ready for Bluetooth wireless connection, the connection to this unit will be automatically established.
Section Bluetooth Telephone Use MULTI-CONTROL to select PH.B.Name view in the function menu. Invert Names YES appears in the display. Press MULTI-CONTROL to change the name view order. Inverted is displayed and the name view order is changed. Pressing MULTI-CONTROL repeatedly changes the name view order between first name and last name.
Bluetooth Telephone Press MULTI-CONTROL to assign the genre to the phone number. The selected genre is assigned to the phone number, and the display reverts to the detailed list. Editing the name of a Phone Book entry You can edit the names of Phone Book entries. Each name can be up to 40 characters long.
Section Bluetooth Telephone Turn MULTI-CONTROL clockwise or counterclockwise to switch to the number input screen. Turning MULTI-CONTROL switches input screens in the following order: Edit genre (genre input screen)—Edit name (name input screen)—Edit number (number input screen)—Clear memory (clear memory screen) Push MULTI-CONTROL left or right to move the cursor to the number you want...
Bluetooth Telephone Press and hold one of 0-9 on the remote control to store the selected phone number in that preset. Press 1 to store in P 1; 4 to store in P 4, etc. Press 0 to store in preset P10. Hold the button down until you hear a beep.
Section Bluetooth Telephone Push MULTI-CONTROL right to display the detailed list. Calling time and date, and phone number are displayed in the detailed list. # If the number is already in the Phone Book then the name is also displayed. # Turning MULTI-CONTROL clockwise or coun- terclockwise switches to the previous or next phone number diplayed in the detailed list.
Bluetooth Telephone Making a call by entering phone number You can make a call by directly entering phone numbers on this unit. Use MULTI-CONTROL to select Number dial in the function menu. Number dial appears in the display. # You can also enter in this menu from the standby display by pressing DIRECT on the re- mote control.
Press BAND to return to the standby display. Displaying BD address of this unit Use MULTI-CONTROL to select Device info in the function menu. The device name (Pioneer BT Unit) of this unit appears in the display. <CRD4060-A/N>46...
Use MULTI-CONTROL to select Device info in the function menu. The device name (Pioneer BT Unit) of this unit appears in the display. Push MULTI-CONTROL down to switch to the system version of this unit.
Section Bluetooth Audio Listening to songs on BT Audio (Bluetooth audio player) 1 1 1 1 2 2 2 2 You can use this unit to control a separately sold portable audio player featuring Bluetooth wireless technology (Bluetooth audio player). Even though your audio player does not con- tain a Bluetooth module, you can still control it from this unit via Bluetooth wireless technol-...
Bluetooth Audio Setting up for Bluetooth audio player Before you can use Bluetooth audio player you will need to set up the unit for use. Activation Refer to Activating the BT Audio source on page 80 for instructions on how to turn the BT Audio on.
Section Bluetooth Audio Function operation 1 1 1 1 Function display Shows the function status. Once connected via Bluetooth wireless tech- nology, “Play”, “Stop” and other functions on Bluetooth audio player can be controlled from this unit’s function menu. Press MULTI-CONTROL to display the main menu.
You can display the BD address of this unit. Use MULTI-CONTROL to select Device info in the function menu. The device name (Pioneer BT Unit) of this unit appears in the display. Push MULTI-CONTROL left to switch to the BD address.
Section Multi-CD Player Playing a CD 1 1 1 1 4 4 4 You can use this unit to control a multi-CD player, which is sold separately. These are the basic steps necessary to play a CD with your multi-CD player. More advanced CD operation is explained starting on the next page.
Multi-CD Player Press 0-9 buttons to enter the desired track number. # You can cancel the input number by pressing CLEAR. Press DIRECT. The track of entered number will play. Note After entering the number input mode, if you do not perform an operation within about eight sec- onds, the mode is automatically canceled.
Section Multi-CD Player Notes ! When playing a CD TEXT disc on a CD TEXT compatible multi-CD player, you cannot switch to disc title input. The disc title will have already been recorded on a CD TEXT disc. ! If you do not operate the function within about 30 seconds, the display is automatically re- turned to the playback display.
Multi-CD Player When you find the desired track (or disc) press MULTI-CONTROL to turn scan play off. The track (or disc) will continue to play. # If the display has automatically returned to the playback display, select Scan mode again by using MULTI-CONTROL.
Section Multi-CD Player Use MULTI-CONTROL to select ITS play mode in the function menu. ITS play mode appears in the display. Press MULTI-CONTROL to turn ITS play ITS play mode appears in the display. Play- back begins of those tracks from your playlist within the previously selected M-CD repeat or Disc repeat ranges.
Multi-CD Player Play the CD that you want to enter a title for. Push MULTI-CONTROL up or down to select the CD. Use MULTI-CONTROL to select TitleInput "A" in the function menu. TitleInput "A" appears in the display. Press DISPLAY to select the desired character type.
Section Multi-CD Player # If no title has been entered for a disc, No D.Title will be displayed. # No disc is displayed next to the disc number when there is no disc in the magazine. Using CD TEXT functions You can use these functions only with a CD TEXT compatible multi-CD player.
Multi-CD Player Using compression and bass emphasis You can use these functions only with a multi- CD player that supports them. Using COMP (compression) and DBE (dy- namic bass emphasis) functions lets you ad- just the sound playback quality of the multi- CD player.
Section Playing songs on iPod Listening to songs on your iPod 1 1 1 1 3 3 3 You can use this unit to control an iPod adapter, which is sold separately. These are the basic steps necessary to operate an iPod adapter.
Playing songs on iPod Searching for a song Press LIST to switch to the top menu of the list search. Use MULTI-CONTROL to select a GENRE, ARTIST, ALBUM or SONG from among the categories. Turn to change the category; press to select. List from the selected category is displayed.
Section Playing songs on iPod Introduction of advanced iPod adapter operation 1 1 1 1 Function display Shows the function status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION.
Playing songs on iPod Pausing a song Pause lets you temporarily stop playback of a song. Use MULTI-CONTROL to select Pause in the function menu. Pause appears in the display. Press MULTI-CONTROL to turn pause Playback of the current song pauses. # To turn pause off, press MULTI-CONTROL again.
Section TV tuner Watching the television 1 1 1 1 You can use this unit to control a TV tuner, which is sold separately. For details concerning operation, refer to the TV tuner’s operation manual. This section pro- vides information on TV operations with this unit which differs from that described in the TV tuner’s operation manual.
TV tuner Introduction of advanced TV tuner operation 1 1 1 1 Function display Shows the function names. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION. BSSM appears on the display. # To return to the channel display, press BAND.
Section TV tuner # If you do not operate the list within about 30 seconds, the preset channel list mode is can- celed automatically. Note Storing broadcast stations with BSSM may re- place broadcast stations you have saved using P 1—P12. Selecting stations from the preset channel list The preset channel list lets you see the list of...
DVD Player Playing a disc 1 1 1 1 2 2 2 2 3 3 3 3 6 6 6 You can use this unit to control a DVD player or multi-DVD player, which is sold separately. For details concerning operation, refer to the DVD player’s or multi-DVD player’s operation manual.
Section DVD Player Introduction of advanced DVD player operation 1 1 1 1 Function display Shows the function names. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select FUNCTION. Turn to change the menu option; press to se- lect.
DVD Player ! During video CD or CD playback, if you per- form track search or fast forward/reverse dur- ing Track repeat, the repeat play range changes to Disc repeat. ! During MP3/WMA playback, if you select an- other folder during repeat play, the repeat play range changes to Disc repeat.
Section DVD Player Entering disc titles Disc title input lets you input CD titles up to 10 letters long into the DVD player. For details concerning operation, refer to Entering disc ti- tles on page 56. ! You can operate this function only when a DVD player is connected to this unit.
Audio Adjustments Introduction of audio adjustments 1 1 1 1 Audio display Shows the audio adjustment status. Press MULTI-CONTROL to display the main menu. FUNCTION, AUDIO and ENTERTAINMENT appear on the display. Use MULTI-CONTROL to select AUDIO. Turn to change the menu option; press to se- lect.
Section Audio Adjustments Using the equalizer The equalizer lets you adjust the equalization to match car interior acoustic characteristics as desired. Recalling equalizer curves There are seven stored equalizer curves which you can easily recall at any time. Here is a list of the equalizer curves: Display Equalizer curve...
Audio Adjustments Recall the equalizer curve you want to adjust. See Recalling equalizer curves on the previous page. Use MULTI-CONTROL to select 7-band graphic equalizer adjustment. Frequency and the level (e.g., 50Hz +4) ap- pears in the display. Push MULTI-CONTROL left or right to select the equalizer band to adjust.
Section Audio Adjustments Push MULTI-CONTROL left or right to select cut-off frequency. Each time MULTI-CONTROL is pushed left or right, cut-off frequencies are selected in the following order: 50Hz—63Hz—80Hz—100Hz—125Hz Only frequencies lower than those in the se- lected range are outputted from the subwoo- fer.
Page 75
Audio Adjustments Push MULTI-CONTROL up or down to adjust the source volume. Each time MULTI-CONTROL is pushed up or down, source volume increases or decreases. SLA +4 to SLA –4 is displayed as the source volume is increased or decreased. Notes ! The AM tuner volume level can also be ad- justed with source level adjustments.
Section Initial Settings Adjusting initial settings 1 1 1 Using the initial settings, you can customize various system settings to achieve optimal per- formance from this unit. 1 Function display Shows the function status. Press SOURCE and hold until the unit turns off.
Initial Settings Push MULTI-CONTROL up or down to set the date. Pushing MULTI-CONTROL up will increase the selected day, month or year. Pushing MULTI-CONTROL down will decrease the se- lected day, month or year. Setting the clock Use these instructions to set the clock. Use MULTI-CONTROL to select Clock.
Section Initial Settings Setting the AM tuning step The AM tuning step can be switched between 9 kHz, the preset step, and 10 kHz. When using the tuner in North, Central or South America, reset the tuning step from 9 kHz (531 kHz to 1 602 kHz allowable) to 10 kHz (530 kHz to 1 640 kHz allowable).
Initial Settings Use MULTI-CONTROL to select Brightness. Brightness appears in the display. Push MULTI-CONTROL left or right to adjust the brightness level. Each time MULTI-CONTROL is pushed left or right, brightness level increases or decreases. 0 to 15 is displayed as the level is increased or decreased.
Section Initial Settings # To turn the feature demo off, press MULTI-CONTROL again. Notes ! Remember that if the feature demo continues operating when the car engine is turned off, it may drain battery power. ! You can also turn on or off feature demo by pressing DISPLAY while this unit is turned off.
Initial Settings Push MULTI-CONTROL up or down to select a number. Pushing MULTI-CONTROL up or down changes the number. Push MULTI-CONTROL right to move the cursor to the next position. When the number you want is displayed, push MULTI-CONTROL right to move the cursor to the next position and then select the next number.
Section Other Functions Turning the clock display on or off You can turn the clock display on or off. % Press CLOCK to turn the clock display on or off. Each press of CLOCK turns the clock display on or off. Note Even when the sources are off, the clock display appears on the display.
Other Functions Push MULTI-CONTROL up or down to select a letter of the alphabet. Each time MULTI-CONTROL is pushed up, al- phabet, numbers or symbols are displayed in ascending order (A B C ...). Each time MULTI-CONTROL is pushed down, letters are displayed in descending order.
Appendix Additional Information Understanding built-in CD player error messages When you contact your dealer or your nearest Pioneer Service Center, be sure to record the error message. Message Cause ERROR-11, 12, Dirty disc 17, 30 ERROR-11, 12, Scratched disc 17, 30...
Additional Information ! If the heater is used in cold weather, moist- ure may form on components inside the CD player. Condensation may cause the CD player to malfunction. If you think that con- densation is a problem turn off the CD player for an hour or so to allow it to dry out and wipe any damp discs with a soft cloth to remove the moisture.
Appendix Additional Information ! Depending on the version of Windows Media Player used to encode WMA files, album names and other text information may not be correctly displayed. ! There may be a slight delay when starting playback of WMA/AAC files encoded with image data.
Additional Information WMA additional information ! This unit plays back WMA files encoded by Windows Media Player version 7, 7.1, 8, 9 and 10. ! You can only play back WMA files in the fre- quencies 32, 44.1 and 48 kHz. ! The sound quality of WMA files generally becomes better with an increased bit rate.
Page 88
Appendix Additional Information 1 First level 2 Second level 3 Third level Notes ! This unit assigns folder numbers. The user cannot assign folder numbers. ! It is not possible to check folders that do not include MP3/WMA/AAC/WAV files. (These folders will be skipped without displaying the folder number.) ! MP3/WMA/AAC/WAV files in up to 8 tiers of...
Additional Information Terms A2DP A2DP is short for Advanced Audio Distribution Profile. This profile allows the high quality audio data of either stereo or monaural to be transmitted via Bluetooth wireless technology. AAC is short for Advanced Audio Coding and refers to an audio compression technology standard used with MPEG 2 and MPEG 4.
Page 90
Appendix Additional Information Linear PCM (LPCM)/Pulse code modulation This stands for linear pulse code modulation, which is the signal recording system used for music CDs and DVDs. Playlists created using the “WINAMP” soft- ware have a playlist file extension (.m3u). MP3 is short for MPEG Audio Layer 3.
Additional Information Specifications General Power source ... 14.4 V DC (12.0 V to 14.4 V allowable) Grounding system ... Negative type Max. current consumption ... 10.0 A Dimensions (W × H × D): Chassis ... 178 × 50 × 161 mm Nose ...
Page 92
Black plate (92,1) Appendix Additional Information Infrared remote control Wavelength ... 940 nm ±50 nm Output ... typ; 12 mw/sr per Infrared Note Specifications and the design are subject to pos- sible modifications without notice due to im- provements. <CRD4060-A/N>92...
Page 93
Contenido Gracias por adquirir este producto Pioneer. Lea con detenimiento estas instrucciones sobre el funcionamiento del aparato, para que pueda darle el mejor uso posible. Una vez que las haya leído, conserve este manual en un lugar seguro para consultarlo en el futuro.
Page 94
Contenido Uso de la compresión y BMX 123 Selección del método de búsqueda 123 Búsqueda cada 10 pistas en la carpeta actual 123 Visualización de la información de texto de un disco MP3/WMA/AAC/WAV 124 – Al reproducir un disco MP3/WMA/ AAC 124 –...
Page 95
Contenido Selección de la pantalla de llamadas entrantes 144 Bluetooth Audio Escuchar canciones en BT Audio (reproductor de audio Bluetooth) 145 Ajuste del reproductor de audio Bluetooth 146 Conexión de un reproductor de audio Bluetooth 146 Función 147 Reproducción de canciones en el reproductor de audio Bluetooth 147 Para poner en pausa una canción 148 Para detener la reproducción 148...
Page 96
Contenido Selección de emisoras de la lista de canales presintonizados 165 Reproductor de DVD Reproducción de un disco 166 Selección de un disco 166 Selección de una carpeta 166 Introducción a las funciones avanzadas del reproductor de DVD 167 Repetición de reproducción 167 Pausa de la reproducción de un disco 168 Reproducción de las pistas en orden aleatorio 168...
Page 97
Contenido Ficheros MP3, WMA, AAC y WAV 186 – Información adicional sobre MP3 187 – Información adicional sobre WMA 187 – Información adicional sobre AAC 187 – Información adicional sobre WAV 187 Acerca de las carpetas y los ficheros MP3/ WMA/AAC/WAV 188 Glosario 189 Especificaciones 192...
! Si esta unidad no funciona correctamente, co- muníquese con su concesionario o el servicio técnico oficial de Pioneer más próximo a su domicilio. Acerca de este manual Esta unidad viene con diversas funciones so- fisticadas que garantizan una recepción y un...
Bluetooth. Compatibilidad iPod® Cuando usa esta unidad con un adaptador Pioneer para iPod (CD-IB100), puede controlar un iPod con un conector del Dock. ! iPod es una marca comercial de Apple Computer, Inc., registrada en los EE.UU. y otros países.
Sección Antes de comenzar Bluetooth es una tecnología inalámbrica de conectividad por radio de corto alcance, desa- rrollada para sustituir los cables de los teléfo- nos móviles, ordenadores de bolsillo y otros dispositivos. Bluetooth opera a una frecuencia de 2,4 GHz y permite transmitir voz y datos a velocidades de hasta 1 megabit por segundo.
Antes de comenzar Pulse MULTI-CONTROL para borrar la memoria. Todos los datos de la fuente de teléfono, inclui- das las entradas en el Directorio de teléfonos, los números preajustados y el Historial de lla- madas, se borrarán. Protección del producto contra robo La carátula puede extraerse de la unidad prin- cipal y almacenarse en la carcasa protectora...
Sección Antes de comenzar Acerca del modo demo Esta unidad ofrece dos modos de demostra- ción. Uno es el modo inverso y el otro es la ca- racterística de modo demo. Importante El cable rojo (ACC) de esta unidad se debe co- nectar al terminal acoplado con las funciones de activación/desactivación de la llave de encendido del automóvil.
Antes de comenzar Uso del mando a distancia Apunte el mando a distancia hacia la carátula para utilizarlo. ! Es posible que el mando a distancia no funcione correctamente si lo expone a la luz solar directa. Importante ! No guarde el mando a distancia en lugares ex- puestos a altas temperaturas o a la luz solar directa.
Sección Qué es cada cosa 1 1 1 c c c Unidad principal 1 Botón BAND Pulse este botón para seleccionar entre tres bandas FM y una banda AM, y para cance- lar el modo de control de funciones. 2 Botón SOURCE Esta unidad se enciende al seleccionar una fuente.
Qué es cada cosa d d d 1 1 1 e e e m m m 2 2 2 l l l c c c k k k j j j i i i c Botón ATT Pulse este botón para bajar rápidamente el nivel de volumen, aproximadamente el 90%.
BT Audio en la página 180). Black plate (106,1) ! Por unidad externa se entiende un producto Pioneer (como el que pueda estar disponible en el futuro) que, si bien es incompatible como fuente, permite que este sistema con- trole funciones básicas. Dos unidades exter- nas se pueden controlar con este sistema.
Funciones básicas Notas ! El reproductor de CD incorporado reproduce un CD estándar de 12 cm u 8 cm. No utilice un adaptador cuando reproduzca un CD de 8 ! No coloque ningún otro elemento que no sea un CD en la ranura de carga de CD. ! A veces se produce una demora entre el co- mienzo de la reproducción de un CD y la emi- sión del sonido.
Sección Sintonizador Para escuchar la radio 1 1 1 1 2 2 2 2 6 6 6 A continuación se indican los pasos básicos necesarios para hacer funcionar la radio. En la página siguiente se explican las funciones más avanzadas del sintonizador. Importante Si se utiliza esta unidad en América del Norte, América Central o América del Sur, se deberá...
Sintonizador Introducción a las funciones avanzadas del sintonizador 1 1 1 1 Visualización de función Muestra el estado de la función. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display. Utilice MULTI-CONTROL para seleccio- nar FUNCTION.
Sección Sintonizador Almacenamiento de las frecuencias de radio más fuertes La función BSM (memoria de las mejores emi- soras) le permite almacenar automáticamente seis frecuencias de las emisoras más fuertes en los botones 0-9 (1–6) en el mando a distan- cia.
Page 111
Sintonizador Utilice MULTI-CONTROL para seleccio- nar Local en el menú de funciones. Local aparece en el display. Pulse MULTI-CONTROL para activar la sintonización por búsqueda local. La sensibilidad de búsqueda local (p. ej., Level 2) aparece en el display. # Vuelva a pulsar MULTI-CONTROL para desac- tivar la sintonización por búsqueda local.
Sección Reproductor de CD incorporado Reproducción de un CD 3 3 3 A continuación se indican los pasos básicos necesarios para reproducir un CD con el re- productor de CD incorporado. En la página si- guiente se explican las funciones más avanzadas del reproductor de CD.
Reproductor de CD incorporado Pulse DIRECT. Se reproducirá la pista seleccionada. Nota Después de acceder al modo de ingreso de nú- meros, si no realiza una operación en unos ocho segundos, el modo se cancelará auto- máticamente. Black plate (113,1) Introducción a las funciones avanzadas del reproductor de CD incorporado...
Sección Reproductor de CD incorporado Nota Si no se utiliza la función en unos 30 segundos, el display volverá automáticamente a la visualiza- ción de reproducción. Repetición de reproducción Hay dos gamas de repetición para la reproduc- ción de un reproductor de CD incorporado: Disc repeat (repetición de disco) y Track repeat (repetición de una pista).
Reproductor de CD incorporado Pausa de la reproducción de un CD La pausa le permite detener temporalmente la reproducción del CD. Utilice MULTI-CONTROL para seleccio- nar Pause en el menú de funciones. Pause aparece en el display. Pulse MULTI-CONTROL para activar la pausa.
Sección Reproductor de CD incorporado # Si un disco tiene menos de 10 pistas, al man- tener pulsado MULTI-CONTROL izquierda se re- cupera la primera pista del disco. También si después de realizar una búsqueda cada 10 pistas, quedan menos de 10 pistas, al mantener pulsado MULTI-CONTROL izquierda se recupera la prime- ra pista del disco.
Reproductor de CD incorporado ! Después que los datos para 48 discos han sido almacenados en la memoria, los datos para un nuevo disco se sobreponen a los datos más antiguos. ! Si conecta un reproductor de CD múltiple, podrá ingresar los títulos de hasta 100 discos. ! Cuando se conecta un reproductor de CD múltiple que no es compatible con las funcio- nes de título de disco, no es posible ingresar...
Page 118
Sección Reproductor de CD incorporado Pulse LIST para cambiar al modo de lista de títulos de las pistas. Utilice MULTI-CONTROL para seleccio- nar el título de la pista deseada. Haga girar el control para cambiar el título de la pista y pulse para seleccionarlo. # También puede cambiar el título de la pista pulsando MULTI-CONTROL arriba o abajo.
Reproductor de MP3/ WMA/AAC/WAV Reproducción de ficheros MP3/WMA/AAC/WAV 1 1 1 1 2 2 2 2 6 6 6 5 5 5 A continuación se indican los pasos básicos necesarios para reproducir un MP3/WMA/ AAC/WAV con el reproductor de CD incorpora- do.
Sección Reproductor de MP3/ WMA/AAC/WAV Notas ! Al reproducir discos con ficheros MP3/WMA/ AAC/WAV y datos de audio (CD-DA), tales como CD-EXTRA y CD de MODO MIXTO (MIXED-MODE CD), los dos tipos de discos se pueden reproducir sólo si se cambia el modo entre MP3/WMA/AAC/WAV y CD-DA con BAND.
Reproductor de MP3/ WMA/AAC/WAV Introducción a las funciones avanzadas del reproductor de CD incorporado (MP3/ WMA/AAC/WAV) 1 1 1 1 Visualización de función Muestra el estado de la función. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display.
Sección Reproductor de MP3/ WMA/AAC/WAV Reproducción de las pistas en orden aleatorio La reproducción aleatoria le permite reprodu- cir las pistas en un orden aleatorio dentro de la gama de repetición Folder repeat y Disc repeat. Seleccione la gama de repetición. Consulte Repetición de reproducción en la pági- na anterior.
Reproductor de MP3/ WMA/AAC/WAV Uso de la compresión y BMX El uso de las funciones COMP (compresión) y BMX le permiten ajustar la calidad de repro- ducción de sonido de este reproductor. Cada una de las funciones tiene un ajuste de dos pasos.
Sección Reproductor de MP3/ WMA/AAC/WAV Visualización de la información de texto de un disco MP3/WMA/AAC/WAV Es posible visualizar la información de texto grabada en un disco MP3/WMA/AAC/WAV. Al reproducir un disco MP3/ WMA/AAC % Pulse DISPLAY. Pulse DISPLAY repetidamente para cambiar entre los siguientes ajustes: Tiempo de reproducción—...
Reproductor de MP3/ WMA/AAC/WAV ! Si se activa la función de desplazamiento con- tinuo en el ajuste inicial, la información de texto se desplazará de manera ininterrumpida por el display. Consulte Cambio del desplaza- miento continuo en la página 180. Selección de pistas de la lista de nombres de ficheros Esta función le permite ver la lista de los nom-...
Page 126
Sección Teléfono Bluetooth Función manos libres con teléfonos móviles provistos de tecnología inalámbrica Bluetooth Si su teléfono móvil posee tecnología inalámbri- ca Bluetooth, puede conectarse a esta unidad para hacer llamadas inalámbricas de manos li- bres, incluso al conducir. Importante Puesto que esta unidad se encuentra en espera para conectar con sus teléfonos móviles median- te la tecnología inalámbrica Bluetooth, utilizarla...
Teléfono Bluetooth ! La distancia de visibilidad entre esta unidad y su teléfono móvil deber ser de 10 metros o in- ferior para el envío y recepción de voz y datos mediante la tecnología inalámbrica Bluetooth. Sin embargo, la distancia de transmisión puede llegar a ser más corta que la distancia estimada, dependiendo del ambiente en que se utilice.
Sección Teléfono Bluetooth # El volumen de voz de la persona que llama y el volumen del timbre pueden variar según el tipo de teléfono móvil. # Si la diferencia entre el volumen del timbre y el volumen de la persona que llama es demasia- do grande, el nivel de volumen general puede vol- verse inestable.
Teléfono Bluetooth ! El funcionamiento es diferente según el tipo de teléfono móvil. Consulte el manual de su teléfono móvil para ver más instruc- ciones. ! Esta función se puede utilizar únicamente cuando la conexión se establece mediante un HFP (Hands Free Profile). Mantenga pulsado BAND hasta que Voice dial aparezca en el display.
Sección Teléfono Bluetooth Respuesta de una llamada entrante Si, mientras está hablando por teléfono, se produce otra llamada entrante, el número (o nombre si figura en el directorio de teléfonos) de la persona que llama aparecerá en el dis- play para indicarle que tiene una llamada en- trante.
Teléfono Bluetooth Search & Connect (buscar y conectar)— Connection open (conexión abierta)— Connect phone (conectar teléfono)— Delete phone (eliminar teléfono)— PH.B.Transfer (transferencia del directorio de teléfonos)—Refuse calls (ajuste de rechazo automático)—Auto answer (ajuste de res- puesta automática)—Ring tone (selección de tono de llamada—Auto connect (ajuste de conexión automática)—Echo cancel (cancela- ción de eco)—Device info (información del...
Mientras se realiza la conexión, se mostrará Connecting. Para completar la conexión, veri- fique el nombre del dispositivo (Pioneer BT Unit) e ingrese el código de enla- ce de su teléfono móvil. Si la conexión se esta- blece, se visualizará Connected.
Teléfono Bluetooth Utilice MULTI-CONTROL para seleccio- nar Disconnect phone en el menú de fun- ciones. El nombre del dispositivo del teléfono conec- tado se visualiza en el display. Pulse MULTI-CONTROL para desco- nectar un teléfono móvil de esta unidad. Una vez completada la desconexión, aparece Disconnected.
Sección Teléfono Bluetooth Pulse MULTI-CONTROL derecha para se- leccionar Delete YES. Se visualiza Delete YES. El borrado del teléfo- no se ajustará ahora en modo en espera. Pulse MULTI-CONTROL para eliminar el teléfono. Una vez que se borre el teléfono, se visualizará Deleted.
Teléfono Bluetooth Pulse MULTI-CONTROL para activar la conexión automática. ON aparece en el display. Si su teléfono móvil está preparado para la co- nexión inalámbrica Bluetooth, se establecerá automáticamente la conexión a esta unidad. # Para desactivar la conexión automática, vuel- va a pulsar MULTI-CONTROL.
Sección Teléfono Bluetooth Utilice MULTI-CONTROL para seleccio- nar PH.B.Name view en el menú de funcio- nes. Invert Names YES aparece en el display. Pulse MULTI-CONTROL para cambiar el orden de visualización de nombres. Se mostrará Inverted y se cambiará el orden de visualización de nombres.
Teléfono Bluetooth Asignación de géneros a números de teléfono Si hay muchas entradas en el Directorio de te- léfonos, puede resultar útil asignarlos a géne- ros (categorías) específicos para que la búsqueda sea más fácil. Existen cuatro géne- ros preajustados a los que puede asignar en- tradas: Home, Mobile, Office y Other.
Sección Teléfono Bluetooth # Los caracteres europeos y los caracteres rusos no se pueden combinar. Pulse MULTI-CONTROL arriba o abajo para seleccionar una letra. # Para eliminar un carácter y dejar un espacio, seleccione “_” (subrayado). Pulse MULTI-CONTROL derecha para mover el cursor a la siguiente posición de carácter.
Teléfono Bluetooth Mantenga pulsado MULTI-CONTROL para visualizar la pantalla de ingreso de gé- nero. Se visualiza Edit genre. Haga girar MULTI-CONTROL hacia la de- recha o hacia la izquierda para cambiar a la pantalla de borrado de memoria. Al girar MULTI-CONTROL se cambiarán las pantallas de entrada en el siguiente orden: Edit genre (pantalla de ingreso de género)—...
Sección Teléfono Bluetooth # Si selecciona All clear, se borrará toda la me- moria, con independencia de los elementos. Pulse MULTI-CONTROL derecha para se- leccionar el elemento que desea eliminar de esta unidad. Se visualiza Clear memory YES. El borrado de memoria se ajustará...
Teléfono Bluetooth Pulse MULTI-CONTROL para hacer una llamada. Para finalizar la llamada, pulse PHONE. El tiempo estimado de la llamada aparece en el display (esto puede diferir ligeramente del tiempo de llamada real). # También puede realizar esta operación pulsan- do ON HOOK en el mando a distancia.
Sección Teléfono Bluetooth Pulse MULTI-CONTROL derecha para mover el cursor a la siguiente posición. Cuando visualice el número deseado, pulse MULTI-CONTROL derecha para mover el cur- sor a la siguiente posición y seleccione el nú- mero siguiente. Pulse MULTI-CONTROL izquierda para mover el cursor hacia atrás en el display.
Visualización de la dirección BD de esta unidad Utilice MULTI-CONTROL para seleccio- nar Device info en el menú de funciones. El nombre del dispositivo (Pioneer BT Unit) de esta unidad se mostrará en el display. Pulse MULTI-CONTROL izquierda para visualizar la dirección BD.
Puede visualizar las versiones y confirmarlas. Utilice MULTI-CONTROL para seleccio- nar Device info en el menú de funciones. El nombre del dispositivo (Pioneer BT Unit) de esta unidad se mostrará en el display. Pulse MULTI-CONTROL abajo para cam- biar a la versión del sistema de esta uni- dad.
Bluetooth Audio Escuchar canciones en BT Audio (reproductor de audio Bluetooth) 1 1 1 1 2 2 2 2 Puede utilizar esta unidad para controlar un re- productor portátil de audio, vendido por separa- do, provisto de tecnología inalámbrica Bluetooth (reproductor de audio Bluetooth). Aunque su reproductor de audio no esté...
Sección Bluetooth Audio % Pulse SOURCE para seleccionar el repro- ductor de audio Bluetooth. # Si no puede visualizar BT Audio, en primer lugar active la fuente de audio BT en el ajuste ini- cial. Para obtener más información, consulte Ac- tivación de la fuente BT Audio en la página 180.
Bluetooth Audio Función 1 1 1 1 Visualización de función Muestra el estado de la función. Cuando esté conectado a través de tecnología inalámbrica Bluetooth, las funciones “Repro- ducir”, “Parar” y otras funciones del reproduc- tor de audio Bluetooth se pueden controlar desde el menú...
Puede visualizar la dirección BD de esta uni- dad. Utilice MULTI-CONTROL para seleccio- nar Device info en el menú de funciones. El nombre del dispositivo (Pioneer BT Unit) de esta unidad se mostrará en el display. Pulse MULTI-CONTROL izquierda para visualizar la dirección BD.
Puede visualizar las versiones y confirmarlas. Utilice MULTI-CONTROL para seleccio- nar Device info en el menú de funciones. El nombre del dispositivo (Pioneer BT Unit) de esta unidad se mostrará en el display. Pulse MULTI-CONTROL abajo para cam- biar a la versión del sistema de esta uni- dad.
Sección Reproductor de CD múltiple Reproducción de un CD 1 1 1 1 4 4 4 Se puede usar esta unidad para controlar un re- productor de CD múltiple, que se vende por se- parado. A continuación se indican los pasos básicos necesarios para reproducir un CD con el re- productor de CD múltiple.
Reproductor de CD múltiple ! Cuando se selecciona un disco CD TEXT en un reproductor de CD múltiple compatible, los títulos del disco y de las pistas comienzan a desplazarse automáticamente por el display. Si se activa la función de desplazamiento con- tinuo en el ajuste inicial, los títulos de disco y pista se desplazan continuamente.
Sección Reproductor de CD múltiple Introducción a las funciones avanzadas del reproductor de CD múltiple 1 1 1 1 Visualización de función Muestra el estado de la función. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display.
Reproductor de CD múltiple Reproducción de las pistas en orden aleatorio La reproducción aleatoria le permite reprodu- cir las pistas en orden aleatorio dentro de la gama de repetición M-CD repeat y Disc repeat. Seleccione la gama de repetición. Consulte Repetición de reproducción en la pági- na anterior.
Sección Reproductor de CD múltiple Uso de listas de reproducción ITS La función ITS (selección instantánea de pista) le permite crear una lista de reproduc- ción de las pistas favoritas incluidas en el car- gador del reproductor de CD múltiple. Después de añadir sus pistas favoritas a la lista de reproducción, puede activar la repro- ducción ITS y reproducir sólo las pistas selec-...
Reproductor de CD múltiple Si la reproducción ITS ya está activada, vaya al paso 2. Si la reproducción ITS todavía no está activada, utilice MULTI-CONTROL. Reproduzca el CD que tiene la pista que desea eliminar de la lista de reproducción ITS y active la reproducción ITS.
Sección Reproductor de CD múltiple Alfabeto (mayúsculas), números y símbolos— Alfabeto (minúsculas)—letras de idiomas eu- ropeos, tales como aquéllas con acentos (p. ej., á, à, ä, ç)—Números y símbolos Pulse MULTI-CONTROL arriba o abajo para seleccionar una letra del alfabeto. Cada vez que se pulsa MULTI-CONTROL arri- ba, se visualizan las letras del alfabeto, núme- ros o símbolos en orden ascendente (A B C...
Reproductor de CD múltiple Uso de las funciones CD TEXT Estas funciones sólo se pueden usar con un re- productor de CD múltiple compatible con CD TEXT. Algunos discos incluyen información cifrada en el disco durante su fabricación. Estos dis- cos pueden incluir información, tal como el tí- tulo del CD, el título de pista, el nombre del artista y el tiempo de reproducción, y se deno-...
Sección Reproductor de CD múltiple Utilice MULTI-CONTROL para seleccio- nar el título de la pista deseada. Haga girar el control para cambiar el título de la pista y pulse para seleccionarlo. # También puede cambiar el título de la pista pulsando MULTI-CONTROL arriba o abajo.
Para reproducir canciones en el iPod Para escuchar canciones en su iPod 1 1 1 1 3 3 3 Se puede utilizar esta unidad para controlar un adaptador de iPod, que se vende por separado. A continuación se indican los pasos básicos necesarios para hacer funcionar un iPod.
Sección Para reproducir canciones en el iPod Para buscar una canción Para ir al menú superior de la búsqueda de listas, pulse LIST. Utilice MULTI-CONTROL para seleccio- nar GENRE, ARTIST, ALBUM o SONG de entre las categorías. Haga girar el control para cambiar la catego- ría y pulse para seleccionarla.
Para reproducir canciones en el iPod Introducción a las funciones avanzadas del adaptador de iPod 1 1 1 1 Visualización de función Muestra el estado de la función. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display.
Sección Para reproducir canciones en el iPod ! Shuffle Songs – Reproduce canciones en un orden aleatorio dentro de la lista selec- cionada ! Shuffle Albums – Selecciona un álbum de manera aleatoria y luego reproduce todas las canciones en el orden en que se en- cuentran en el álbum ! Shuffle OFF –...
Sintonizador de TV Uso del televisor 1 1 1 1 Se puede utilizar esta unidad para controlar un sintonizador de TV, que se vende por separado. Para obtener más información, consulte el manual de instrucciones del sintonizador de TV. Esta sección proporciona información acerca de las funciones de TV con esta unidad que difieren de las descritas en el manual de instrucciones del sintonizador de TV.
Sección Sintonizador de TV Introducción a las funciones avanzadas del sintonizador de TV 1 1 1 1 Visualización de función Muestra los nombres de las funciones. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display. Utilice MULTI-CONTROL para seleccio- nar FUNCTION.
Sintonizador de TV Utilice MULTI-CONTROL para seleccio- nar la emisora deseada. Haga girar el control para cambiar la emisora y pulse para seleccionarla. # También puede cambiar la emisora pulsando MULTI-CONTROL arriba o abajo. # Si no se utiliza la lista en unos 30 segundos, el modo de lista de canales presintonizados se cancelará...
Sección Reproductor de DVD Reproducción de un disco 1 1 1 1 2 2 2 2 3 3 3 3 6 6 6 Se puede utilizar esta unidad para controlar un reproductor de DVD o un reproductor de DVD múltiple, que se vende por separado. Para obtener más información sobre el funcio- namiento, consulte el manual de funciona- miento del reproductor DVD o del reproductor...
Reproductor de DVD Introducción a las funciones avanzadas del reproductor de DVD 1 1 1 1 Visualización de función Muestra los nombres de las funciones. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display. Utilice MULTI-CONTROL para seleccio- nar FUNCTION.
Sección Reproductor de DVD Notas ! Si se seleccionan otros discos durante la repe- tición de reproducción, la gama de repetición cambia a Disc repeat. ! Durante la reproducción de un vídeo CD o un CD, si se realiza una búsqueda de pistas o el avance rápido/retroceso durante la repetición Track repeat, la gama de repetición cambia a Disc repeat.
Reproductor de DVD Uso de la lista de reproducción ITS y las funciones de títulos de discos ! Se pueden utilizar estas funciones sólo si un reproductor de DVD múltiple está co- nectado a esta unidad. ! Esta función es ligeramente diferente de la reproducción ITS con un reproductor de CD múltiple.
Sección Ajustes de audio Introducción a los ajustes de audio 1 1 1 1 Visualización de audio Muestra el estado de los ajustes de audio. Pulse MULTI-CONTROL para visualizar el menú principal. FUNCTION, AUDIO y ENTERTAINMENT apa- recen en el display. Utilice MULTI-CONTROL para seleccio- nar AUDIO.
Ajustes de audio Pulse MULTI-CONTROL izquierda o de- recha para ajustar el balance entre los alta- voces izquierdos/derechos. Cada vez que se pulsa MULTI-CONTROL iz- quierda o derecha, se mueve el balance entre los altavoces izquierdos/derechos hacia la iz- quierda o hacia la derecha. Se visualiza L 15 a R 15 mientras el balance entre los altavoces izquierdos/derechos se mueve desde la izquierda hacia la derecha.
Sección Ajustes de audio # No se puede ajustar una curva de ecualiza- ción con todas las frecuencias definidas en 0. Ajuste del ecualizador gráfico de 7 bandas Para la curva Custom1 o Custom2, se puede ajustar el nivel de cada banda. ! Se puede crear una curva Custom1 separa- da por cada fuente.
Ajustes de audio Uso de la salida de subgraves Esta unidad está equipada con una salida de subgraves que se puede activar o desactivar. Utilice MULTI-CONTROL para seleccio- nar Sub W.1. Sub W.1 aparece en el display. Pulse MULTI-CONTROL para activar la salida de subgraves.
Sección Ajustes de audio Uso del filtro de paso alto Cuando no desea que se generen los sonidos bajos de la gama de frecuencias de salida de subgraves a través de los altavoces delanteros o traseros, active el filtro de paso alto (HPF). Sólo las frecuencias más altas que aquéllas en la gama seleccionada se generan a través de los altavoces delanteros o traseros.
Ajustes iniciales Configuración de los ajustes iniciales 1 1 1 Utilizando los ajustes iniciales, puede perso- nalizar varios ajustes del sistema para lograr un funcionamiento óptimo de esta unidad. 1 Visualización de función Muestra el estado de la función. Mantenga pulsado SOURCE hasta que se apague la unidad.
Sección Ajustes iniciales Ajuste de la fecha La visualización de calendario ajustada en este modo aparece cuando la fuente del telé- fono está seleccionada y las fuentes o la de- mostración de características están desactivadas. Utilice MULTI-CONTROL para seleccio- nar Calendar. Calendar aparece en el display.
Ajustes iniciales Ajuste del paso de sintonía de FM El paso de sintonía de FM que utiliza la sinto- nización por búsqueda se puede cambiar entre 100 kHz, el paso predefinido, y 50 kHz. Utilice MULTI-CONTROL para seleccio- nar FM step. FM step aparece en el display.
Sección Ajustes iniciales Cambio del ajuste de un equipo auxiliar Los equipos auxiliares conectados a esta uni- dad se pueden activar por separado. Al utili- zarla, fije en ON cada fuente AUX. Para obtener información sobre cómo conectar o utilizar equipos auxiliares, consulte Uso de la fuente AUX en la página 182.
Ajustes iniciales # Cuando se conecta el altavoz de subgraves a la salida posterior, seleccione Rear SP :S/W para el altavoz. Notas ! Aunque cambie este ajuste, no se producirá ningún sonido a menos que active la salida de subgraves (consulte Uso de la salida de subgraves en la página 173).
Sección Ajustes iniciales Cambio del modo inverso Si no se realiza ninguna operación en unos 30 segundos, las indicaciones de la pantalla co- mienzan a invertirse y siguen haciéndolo cada 10 segundos. Utilice MULTI-CONTROL para seleccio- nar Reverse mode. Reverse mode aparece en el display. Pulse MULTI-CONTROL para activar el modo inverso.
Ajustes iniciales Pulse MULTI-CONTROL derecha para mover el cursor a la siguiente posición. Cuando visualice el número deseado, pulse MULTI-CONTROL derecha para mover el cur- sor a la siguiente posición y seleccione el nú- mero siguiente. Pulse MULTI-CONTROL izquierda para mover el cursor hacia atrás en el display.
Sección Otras funciones Activación y desactivación de la visualización del reloj Se puede activar y desactivar la visualización del reloj. % Pulse CLOCK para activar o desactivar la visualización del reloj. Cada vez que se presiona CLOCK, se activa o desactiva la visualización del reloj.
Otras funciones Alfabeto (mayúsculas), números y símbolos— Alfabeto (minúsculas)—letras de idiomas eu- ropeos, tales como aquéllas con acentos (p. ej., á, à, ä, ç)—Números y símbolos Pulse MULTI-CONTROL arriba o abajo para seleccionar una letra del alfabeto. Cada vez que se pulsa MULTI-CONTROL arri- ba, se visualizan las letras del alfabeto, núme- ros o símbolos en orden ascendente (A B C ...).
Información adicional Comprensión de los mensajes de error del reproductor de CD incorporado Cuando contacte con su concesionario o con el centro de servicio Pioneer más cercano, asegúrese de anotar el mensaje de error. Mensaje Causa ERROR-11, 12, Disco sucio...
Información adicional ! Para limpiar un CD, pásele un paño suave desde el centro hacia afuera. ! Si se usa un calefactor cuando hace frío, se puede condensar humedad en las pie- zas internas del reproductor de CD. La hu- medad condensada puede causar una mal funcionamiento del reproductor de CD.
Apéndice Información adicional Ficheros MP3, WMA, AAC y ! MP3 es la abreviatura de “MPEG Audio Layer 3” y alude a una norma de tecnología de compresión de audio. ! WMA es la abreviatura de Windows Media™ Audio, y se refiere a la tecnología de compresión de audio desarrollada por Microsoft Corporation.
Información adicional Información adicional sobre MP3 ! Los ficheros son compatibles con los for- matos de etiqueta ID3 Ver. 1.0, 1.1, 2.2, 2.3 y 2.4 que permiten visualizar el álbum (título del disco), la pista (título de la pista), el ar- tista (artista de la pista) y los comentarios.
Apéndice Información adicional ! La calidad del sonido de los ficheros WAV suele ser mejor cuando se utiliza una gran cantidad de bits de cuantificación. Esta unidad puede reproducir grabaciones con 8 y 16 bits de cuantificación (LPCM) o con 4 bits de cuantificación (MS ADPCM), pero para poder disfrutar de una determinada calidad de sonido, se recomienda utilizar...
Información adicional Glosario A2DP A2DP es la abreviatura de Advanced Audio Distribution Profile. Este perfil permite realizar la transmisión de los datos de audio de alta calidad estéreo o monoaural a través de tecno- logía inalámbrica Bluetooth. AAC es la abreviatura de “Advanced Audio Co- ding”...
Page 190
Apéndice Información adicional HSP es la abreviatura de Head Set Profile (Per- fil de audífono), el que se usa para conectar los audífonos con un terminal de comunica- ción mediante la tecnología inalámbrica Blue- tooth. Las listas de reproducción creadas con el pro- grama “WINAMP”...
Page 191
Black plate (191,1) Apéndice Información adicional Velocidad de grabación Expresa el volumen de datos por segundo o unidades bps (bits por segundo). Cuanto mayor sea la velocidad, más información habrá para reproducir el sonido. Si se utiliza el mismo método de codificación (tal como MP3), cuanto mayor sea la velocidad, la cali- dad del sonido será...
Apéndice Información adicional Especificaciones Generales Fuente de alimentación ... 14,4 V CC (12,0 V a 14,4 V permisible) Sistema de conexión a tierra ... Tipo negativo Consumo máximo de corriente ... 10,0 A Dimensiones (An × Al × Pr): Bastidor ... 178 × 50 × 161 mm Cara anterior ...
Page 193
Black plate (193,1) Apéndice Información adicional Potencia de salida ... +4 dBm Máx. (Clase de potencia 2) GAP (Generic Access Profile) SDP (Service Discovery Protocol) HSP (Head Set Profile) HFP (Hands Free Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Video Remote Control Profile) OPP (Object Push Profile) Nota Las especificaciones y el diseño están sujetos a...
