Digital 4K Video Camera Recorder
Digital HD Video Camera Recorder
Caméscope numérique 4K
Caméscope numérique HD
Videocámara Digital 4K
Videocámara Digital HD
Reference Guide
Guide de référence
Guía de referencia
FDR-X3000/HDR-AS300/HDR-AS50
English
Owner’s Record
Record the model and serial number (which are located on the product)
in the space provided below. Refer to these numbers whenever you call
your Sony dealer regarding this product.
Model No.
Serial No.
© 2016 Sony Corporation Printed in China
http://www.sony.net/
Note on using
Wi-Fi/Bluetooth function
Use the camera in accordance with the regulations of the area of use.
You cannot use the Wi-Fi/Bluetooth function of the camera
underwater.
On operating temperatures
The camera is designed for use in temperatures between -10 °C and
40 °C (14 °F and 104 °F). Shooting in extremely cold or hot places that
exceed this range is not recommended.
Notes on long-time recording
Camera body and battery may get warm with use – this is normal.
Avoid using the camera for a long time when holding the camera in
your hand or when it is directly touching your skin. It is recommended
that you use the supplied adhesive mounts or Underwater Housing,
or optional mount accessories.
Under high ambient temperatures, the temperature of the camera
rises quickly.
Leave the camera alone for 10 minutes or longer to allow the
temperature inside the camera to decrease to a safe level.
When the temperature of the camera rises, the image quality may
deteriorate. It is recommended that you wait until the temperature of
the camera drops before continuing to shoot images.
On the overheat protection
Depending on the camera and battery temperature, you may be unable
to record movies or the power may turn off automatically to protect the
camera.
will be displayed on the display panel of the camera before
the power turns off or you can no longer record movies. In this case,
leave the power off and wait until the camera and battery temperature
goes down. If you turn on the power without letting the camera and
battery cool enough, the power may turn off again or you may be
unable to record movies.
About dust-proof and waterproof performance
The camera is dust-proof and waterproof (Up to a depth of 60 m (197
feet) of water for 30 minutes continuously). For the notes on use of the
Underwater Housing, refer to the online Help Guide.
Note on optional accessories
Genuine Sony accessories may not be available in some countries/
regions.
Security in the use of wireless LAN devices
To avoid hacking, access by malicious third parties, and other
vulnerabilities, confirm that the wireless LAN is always secure.
It is very important to set up security on a wireless LAN.
If a problem occurs due to inadequate security measures or due to
foreseeable circumstances, Sony Corporation is not responsible for
any resulting damage.
Note on wireless network function
We assume no responsibility whatsoever for any damage caused by
unauthorized access to, or unauthorized use of, destinations loaded on
the camera, resulting from loss or theft.
Specifications
FDR-X3000
Signal format:
UHDTV
HDTV
NTSC color, EIA standards
PAL color, CCIR standards
Power requirements: Rechargeable battery pack, 3.6 V (NP-BX1)
USB, 5.0 V
Rechargeable battery pack NP-BX1:
Maximum charge voltage: DC 4.2 V
Maximum charge current: 1.89 A
USB Charging:
DC 5.0 V, 500 mA/800 mA
Splash-proof:
IPX4 (based on our tests)
Operating temperature: -10 °C to +40 °C (14 °F to 104 °F)
Storage temperature: -20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (Approx.):
29.4 mm × 47.0 mm × 83.0 mm (1 3/16 in. × 1 7/8
in. × 3 3/8 in.) (W/H/D, including protrusions and
excluding the supplied Underwater Housing)
Mass:
Approx. 89 g (3.2 oz) (main body only)
Total weight in use: Approx. 114 g (4.1 oz) (including the battery pack,
excluding the supplied Underwater Housing)
HDR-AS300
Signal format:
HDTV
NTSC color, EIA standards
PAL color, CCIR standards
Power requirements: Rechargeable battery pack, 3.6 V (NP-BX1)
USB, 5.0 V
Rechargeable battery pack NP-BX1:
Maximum charge voltage: DC 4.2 V
Maximum charge current: 1.89 A
USB Charging:
DC 5.0 V, 500 mA/800 mA
Splash-proof:
IPX4 (based on our tests)
Operating temperature: -10 °C to +40 °C (14 °F to 104 °F)
Storage temperature: -20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (Approx.):
29.4 mm × 47.0 mm × 83.0 mm (1 3/16 in. × 1 7/8
in. × 3 3/8 in.) (W/H/D, including protrusions and
excluding the supplied Underwater Housing)
Mass:
Approx. 84 g (3.0 oz) (main body only)
Total weight in use: Approx. 109 g (3.9 oz) (including the battery pack,
excluding the supplied Underwater Housing)
HDR-AS50
Signal format:
HDTV
NTSC color, EIA standards
PAL color, CCIR standards
Power requirements: Rechargeable battery pack, 3.6 V (NP-BX1)
USB, 5.0 V
Rechargeable battery pack NP-BX1:
Maximum charge voltage: DC 4.2 V
Maximum charge current: 1.89 A
USB Charging:
DC 5.0 V, 500 mA/800 mA
Operating temperature: -10 °C to +40 °C (14 °F to 104 °F)
Storage temperature: -20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (Approx.):
24.2 mm × 47.0 mm × 83.0 mm (31/32 in. × 1 7/8
in. × 3 3/8 in.) (W/H/D, including protrusions and
excluding the supplied Underwater Housing)
Mass:
Approx. 58 g (2.0 oz) (main body only)
Total weight in use: Approx. 83 g (2.9 oz) (including the battery pack,
excluding the supplied Underwater Housing)
Design and specifications are subject to change without notice for
future upgrades.
On trademarks
XAVC S and
are registered trademarks of Sony Corporation.
Memory Stick and
are trademarks or registered trademarks of Sony
Corporation.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI
Logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
Mac is a registered trademark of Apple Inc. in the United States and other
countries.
Android and Google Play are trademarks of Google Inc.
iPhone is a trademark or a registered trademark of Apple Inc.
Wi-Fi, the Wi-Fi logo, Wi-Fi PROTECTED SET-UP are registered trademarks of the
Wi-Fi Alliance.
The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the
United States and in other countries.
Adobe, the Adobe logo, and Adobe Acrobat are either registered trademarks or
trademarks of Adobe Systems Incorporated in the United States and/or other
countries.
microSDXC logo is a trademark of SD-3C, LLC.
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under
license. Other trademarks and trade names are those of their respective owners.
QR Code is registered trademark of DENSO WAVE INCORPORATED.
In addition, system and product names used in this manual are, in
general, trademarks or registered trademarks of their respective
developers or manufacturers. However, the ™ or
marks may not be
described in this manual.
On GNU GPL/LGPL applied software
The software that is eligible for the following GNU General Public
License (hereinafter referred to as “GPL”) or GNU Lesser General Public
License (hereinafter referred to as “LGPL”) are included in the camera.
This informs you that you have a right to have access to, modify, and
redistribute source code for these software programs under the
conditions of the supplied GPL/LGPL.
Source code is provided on the web. Use the following URL to
download it.
http://oss.sony.net/Products/Linux
We would prefer you do not contact us about the contents of source
code.
Copies of the licenses (in English) are stored in the internal memory of
your camera.
Establish a Mass Storage connection between your camera and a
computer, and read the files in the “LICENSE” folder in “PMHOME.”
WARNING
To reduce the risk of fire or electric shock,
1) do not expose the unit to rain or moisture.
2) do not place objects filled with liquids, such as vases, on the
apparatus.
Do not expose the batteries to excessive heat such as sunshine, fire or
the like.
CAUTION
Battery pack
If the battery pack is mishandled, the battery pack can burst, cause a
fire or even chemical burns. Observe the following cautions.
Do not disassemble.
Do not crush and do not expose the battery pack to any shock or force such as
hammering, dropping or stepping on it.
Do not short circuit and do not allow metal objects to come into contact with
the battery terminals.
Do not expose to high temperature above 60°C (140°F) such as in direct sunlight
or in a car parked in the sun.
Do not incinerate or dispose of in fire.
Do not handle damaged or leaking lithium ion batteries.
Be sure to charge the battery pack using a genuine Sony battery charger or a
device that can charge the battery pack.
Keep the battery pack out of the reach of small children.
Keep the battery pack dry.
Replace only with the same or equivalent type recommended by Sony.
Dispose of used battery packs promptly as described in the instructions.
AC Adaptor (sold separately)
Use the nearby wall outlet (wall socket) when using the AC Adaptor
(sold separately). Disconnect the AC Adaptor (sold separately) from the
wall outlet (wall socket) immediately if any malfunction occurs while
using the apparatus.
For customers in the U.S.A. and CANADA
The available scientific evidence does not show that any health
problems are associated with using low power wireless devices. There
is no proof, however, that these low power wireless devices are
absolutely safe. Low power Wireless devices emit low levels of radio
frequency energy (RF) in the microwave range while being used.
Whereas high levels of RF can produce health effects (by heating
tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF
exposures have not found any biological effects. Some studies have
suggested that some biological effects might occur, but such findings
have not been confirmed by additional research. This equipment has
been tested and found to comply with FCC/IC radiation exposure limits
set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines and RSS-102 of the IC radio
frequency (RF) Exposure rules.
This equipment should be installed and operated keeping the radiator
at least 5mm or more away from person’s body (excluding extremities:
hands, wrists, feet and ankles).
RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your
used rechargeable batteries to the collection and
recycling location nearest you.
For more information regarding recycling of rechargeable
batteries, call toll free
1-800-822- 8837, or visit http://www.call2recycle.org/
Caution: Do not handle damaged or leaking Lithium-Ion
batteries.
For supplied accessories
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
CAN ICES-3 B/NMB-3 B
For Customers in the U.S.A.
If you have any questions about this product, you may call:
Sony Customer Information Center
1-800-222-SONY (7669)
The number below is for the FCC related matters only.
Regulatory Information
Declaration of Conformity
Trade Name: SONY
Model No.: FDR-X3000, HDR-AS300, HDR-AS50
Responsible Party: Sony Electronics Inc.
Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone No.: 858-942-2230
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment must not be co-located or operated in conjunction with
any other antenna or transmitter.
CAUTION
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
Note
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
The supplied interface cable must be used with the equipment in order
to comply with the limits for a digital device pursuant to Subpart B of
Part 15 of FCC Rules.
For Customers in Canada
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
For Customers in Europe
Notice for the customers in the countries applying EU
Directives
Manufacturer: Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075
Japan
For EU product compliance: Sony Belgium, bijkantoor van Sony Europe
Limited, Da Vincilaan 7-D1, 1935 Zaventem, Belgium
Notice
If static electricity or electromagnetism causes data transfer to
discontinue midway (fail), restart the application or disconnect and
connect the communication cable (USB, etc.) again.
Hereby, Sony Corporation, declares that this equipment is in compliance
with the essential requirements and other relevant provisions of
Directive 1999/5/EC. For details, please access the following URL:
http://www.compliance.sony.de/
This product has been tested and found compliant with the limits set
out in the EMC regulation for using connection cables shorter than 3
meters (9.8 feet).
The electromagnetic fields at the specific frequencies may influence
the picture and sound of this unit.
Disposal of waste batteries and electrical and electronic
equipment(applicable in the European Union and other
European countries with separate collection systems)
This symbol on the product, the battery or on the
packaging indicates that the product and the battery shall
not be treated as household waste. On certain batteries
this symbol might be used in combination with a chemical
symbol.
The chemical symbols for mercury (Hg) or lead (Pb) are added if the
battery contains more than 0.0005% mercury or 0.004% lead. By
ensuring these products and batteries are disposed of correctly, you
will help prevent potentially negative consequences for the
environment and human health which could otherwise be caused by
inappropriate waste handling. The recycling of the materials will help to
conserve natural resources.
In case of products that for safety, performance or data integrity
reasons require a permanent connection with an incorporated battery,
this battery should be replaced by qualified service staff only. To ensure
that the battery and the electrical and electronic equipment will be
treated properly, hand over these products at end-of-life to the
applicable collection point for the recycling of electrical and electronic
equipment. For all other batteries, please view the section on how to
remove the battery from the product safely. Hand the battery over to
the applicable collection point for the recycling of waste batteries. For
more detailed information about recycling of this product or battery,
please contact your local Civic Office, your household waste disposal
service or the shop where you purchased the product or battery.
For Customers in Singapore
For Customers in U.A.E.
For Customers in Malaysia
For Customers in India
Battery Pack
Français
Remarque sur l’utilisation
Fonction Wi-Fi/Bluetooth
Utilisez le caméscope en respectant les règlements en vigueur à
l’endroit où vous vous trouvez.
Vous ne pouvez pas utiliser la fonction Wi-Fi/Bluetooth sous l’eau.
À propos des températures d’utilisation
Le caméscope est conçu pour être utilisé à des températures comprises
entre -10 °C et 40 °C (14 °F et 104 °F). Il n’est pas conseillé de prendre
des vues dans des endroits extrêmement froids ou chauds dont la
température n’est pas comprise dans cette plage.
Remarques sur l’enregistrement prolongé
Le boîtier du caméscope et la batterie peuvent chauffer en cours
d’utilisation. Cela est normal.
Évitez d’utiliser le caméscope pendant une période prolongée lorsque
vous le tenez en main ou lorsqu’il est au contact direct de la peau. Il
est conseillé d’utiliser les supports adhésifs fournis ou le boîtier
étanche, voire des supports en option.
La température du caméscope augmente rapidement lorsque la
température ambiante est élevée.
Laissez le caméscope de côté pendant 10 minutes ou davantage pour
permettre à sa température intérieure de redescendre jusqu’à un niveau sûr.
La qualité d’image risque de se détériorer lorsque la température du
caméscope augmente. Il est conseillé de patienter jusqu’à ce que la
température du caméscope ait diminué, avant de poursuivre la prise de vue.
À propos de la protection contre la surchauffe
Selon la température du caméscope et de la batterie, il est possible que
vous ne puissiez enregistrer aucun film ou que l’alimentation se coupe
automatiquement afin de protéger l’appareil.
s’affiche sur l’écran du
caméscope avant la mise hors tension ou avant que vous ne puissiez
plus enregistrer de film. Dans ce cas, laissez refroidir la batterie et le
caméscope, et ne le remettez pas sous tension. Si la batterie et le
caméscope ne sont pas suffisamment refroidis lorsque vous le mettez
sous tension, l’alimentation risque de se couper à nouveau ou vous
risquez de ne pouvoir enregistrer aucun film.
À propos de l’étanchéité à la poussière et à l’eau
Le caméscope est étanche à la poussière et à l’eau (jusqu’à une
profondeur de 60 m (197 pieds) pendant 30 minutes ininterrompues).
Pour consulter les remarques relatives à l’utilisation du boîtier étanche,
reportez-vous au Guide d’aide en ligne.
Remarque sur les accessoires en option
Il est possible que des accessoires Sony authentiques ne soient pas
disponibles dans certains pays/régions.
Sécurité d’utilisation des périphériques LAN sans fil
Pour éviter les risques de piratage, d’accès par des tiers malveillants ou
d’autres vulnérabilités, assurez-vous que le LAN sans fil est toujours sécurisé.
Il est très important de configurer la sécurité d’un LAN sans fil.
Si vous rencontrez problème consécutif à des mesures de sécurité
inappropriées ou à des circonstances prévisibles, Sony Corporation
n’assume aucune responsabilité en cas de dommages éventuels.
Remarque sur la fonction réseau sans fil
Nous n’assumons aucune responsabilité pour tout dommage provoqué
par un accès non autorisé ou une utilisation non autorisée des
destinations chargées sur le caméscope qui pourrait provoquer une
perte ou un vol.
Spécifications
FDR-X3000
Format de signal :
UHDTV
HDTV
Système couleur NTSC, normes EIA
Système couleur PAL, normes CCIR
Alimentation requise : Batterie rechargeable, 3,6 V (NP-BX1)
USB, 5,0 V
Batterie rechargeable NP-BX1 :
Tension de charge maximale : 4,2 V CC
Courant de charge maximal : 1,89 A
Charge USB :
5,0 V CC, 500 mA/800 mA
Résistance aux éclaboussures :
IPX4 (sur base de nos tests)
Température de fonctionnement :
-10 °C à +40 °C (14 °F à 104 °F)
Température de stockage :
-20 °C à +60 °C (-4 °F à +140 °F)
Dimensions (environ) : 29,4 mm × 47,0 mm × 83,0 mm (1 3/16 po ×
1 7/8 po × 3 3/8 po) (L/H/P, y compris les parties
saillantes, mais non compris le boîtier étanche
fourni)
Poids :
Environ 89 g (3,2 on) (corps principal uniquement)
Poids total en cours d’utilisation :
Environ 114 g (4,1 on) (batterie comprise, boîtier
étanche fourni non compris)
HDR-AS300
Format de signal :
HDTV
Système couleur NTSC, normes EIA
Système couleur PAL, normes CCIR
Alimentation requise : Batterie rechargeable, 3,6 V (NP-BX1)
USB, 5,0 V
Batterie rechargeable NP-BX1 :
Tension de charge maximale : 4,2 V CC
Courant de charge maximal : 1,89 A
Charge USB :
5,0 V CC, 500 mA/800 mA
Résistance aux éclaboussures :
IPX4 (sur base de nos tests)
Température de fonctionnement :
-10 °C à +40 °C (14 °F à 104 °F)
Température de stockage :
-20 °C à +60 °C (-4 °F à +140 °F)
Dimensions (environ) : 29,4 mm × 47,0 mm × 83,0 mm (1 3/16 po ×
1 7/8 po × 3 3/8 po) (L/H/P, y compris les parties
saillantes, mais non compris le boîtier étanche
fourni)
Poids :
Environ 84 g (3,0 on) (corps principal uniquement)
Poids total en cours d’utilisation :
Environ 109 g (3,9 on) (batterie comprise, boîtier
étanche fourni non compris)
HDR-AS50
Format de signal :
HDTV
Système couleur NTSC, normes EIA
Système couleur PAL, normes CCIR
Alimentation requise : Batterie rechargeable, 3,6 V (NP-BX1)
USB, 5,0 V
Batterie rechargeable NP-BX1 :
Tension de charge maximale : 4,2 V CC
Courant de charge maximal : 1,89 A
Charge USB :
5,0 V CC, 500 mA/800 mA
Température de fonctionnement :
-10 °C à +40 °C (14 °F à 104 °F)
Température de stockage :
-20 °C à +60 °C (-4 °F à +140 °F)
Dimensions (environ) : 24,2 mm × 47,0 mm × 83,0 mm (31/32 po ×
1 7/8 po × 3 3/8 po) (L/H/P, y compris les parties
saillantes, mais non compris le caisson de plongée
fourni)
Poids :
Environ 58 g (2,0 on) (corps principal uniquement)
Poids total en cours d’utilisation :
Environ 83 g (2,9 on) (parties saillantes comprises,
caisson de plongée fourni non compris)
La conception et les spécifications sont susceptibles d’être modifiées
sans avis préalable lors des mises à niveau ultérieures.
À propos des marques commerciales
XAVC S et
sont des marques déposées de Sony Corporation.
Memory Stick et
sont des marques commerciales ou des marques déposées
de Sony Corporation.
Les termes HDMI et HDMI High-Definition Multimedia Interface, ainsi que le
logo HDMI, sont des marques commerciales ou des marques déposées de HDMI
Licensing LLC aux États-Unis et dans d’autres pays.
Mac est une marque déposée d’Apple Inc. aux États-Unis et dans d’autres pays.
Android et Google Play sont des marques commerciales de Google Inc.
iPhone est une marque commerciale ou une marque déposée d’Apple Inc.
Wi-Fi, le Wi-Fi logo, Wi-Fi PROTECTED SET-UP sont des marques déposées de
Wi-Fi Alliance.
Suite au verso
Advertisement
