Summary of Contents for Frico PA1006
- Page 1 Original instructions PA1006 ..7 ..11 ..13 ..16 ..9 ..18 ..21...
- Page 2 PA1006 Dimensions Side Front Back 1,5 mm² 0,9m...
-
Page 3: Mounting And Installation
PA1006 Mounting and installation Fig. 1: Mounting with bracket PA1006 PA1006 14.5 ø5 Fig. 2: Bracket dimensions Fig. 3: To open... -
Page 4: Minimum Distance
PA1006 Minimum distance Min 50 mm Min 50 mm Min 25 mm Min 1,8 m Min 25 mm Fig. 4 Minimum distance... - Page 5 PA1006 Wiring diagrams PA1006 Internal PA1008E03 PA1006E03 °C °C 750W 750W 750W 750W + 1,5kW + 3kW...
- Page 6 PA1006 Electrical heat - PA1006 (IP20) ∆t*¹ Type Output Airflow Sound Sound Voltage Amperage Length Weight steps power*² pressure*² [kW] [m³/h] [°C] [dB(A)] [dB(A)] [mm] [kg] PA1006E03 0/1,5/3 230V~ 12,8 CE compliant. ) ∆t = temperature rise of passing air at maximum heat output and highest airflow.
-
Page 7: Operation
(1,5 mm², 0,9 m) without plug, at the rear of the unit. 16 A fuse protection is Application area required for 3 kW. PA1006 is a compact door heater The installation, which should be which heats the incoming air and preceded by an omnipolar switch with gives increased comfort on the inside. - Page 8 Maintenance Residual current circuit breaker (E) Since fan motors and other components When the installation is protected are maintenance free, no maintenance by means of a residual current other than regular cleaning is necessary. circuit breaker, which trips when The frequency of cleaning can vary the appliance is connected, this may depending on local conditions, but be due to moisture in the heating...
- Page 11 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
