- Page 1 Smart Home Quick Installation Guide 84295 • 84297...
-
Page 2: Safety Precautions
Only use the supplied power adapter. Never try to repair ednet smart home system by yourself. Repair and maintenance work must be carried out by specialists. In case of problems contact our customer service. -
Page 3: Personal Information
Select a password with a high degree of safety for your ednet smart home account to protect it from unauthorized access. The password should contain at least 8 characters; we recommend case-sensitive letters and alphanumeric characters. -
Page 4: What's In The Box
Thank you for choosing ednet Smart Home, which can be up-and- running quick and easy without complicated network settings. Preparation 84295 and 84297 are the additional Sirens (actors) that you can add onto your ednet.home Starter Kit (84299) or the IP camera gateway (84302) as accessories. -
Page 5: Indoor Siren
Actors Connections Indoor Siren Please insert the Indoor Siren to your Power Socket with AC 100- 240V to power on and charge the internal battery in the Siren. Power ON/OFF switch Set button Power ON/OFF switch ON: means the Siren would consumes the internal battery energy when the Siren is removed from the AC power socket. - Page 6 Set Button: Short press: every short press can be used to adjust different volume levels (including mute) and also the alert light mode. Long press: press the “Set” button and hold it for more than 5 seconds, this would trigger the Siren to enter “Learning” mode.
- Page 7 Outdoor Siren Please power ON the Outdoor Siren with a Micro USB cable to the 5Vdc USB charger. This would also charge its internal battery. Back Side Illustration Input power 5Vdc MicroUSB Power ON/OFF switch Anti-tamper button Power ON/OFF switch ON: means the Siren would consumes the internal battery energy when the Siren is removed from the AC power socket.
- Page 8 Volume/Set Button Alarm Music/Time Button Volume / Set Button: Short press: every short press can be used to adjust different volume levels (including mute) and also the alert light mode. Long press: press the “Set” button and hold it for more than 5 seconds, this would trigger the Siren to enter “Learning”...
- Page 9 Then each short press on the “Set” button would change the alarm-time. 1x Beep: alarm time for 10 seconds 2x Beeps: alarm time for 1 minute 3x Beeps: alarm time for 2 minutes 4x Beeps: alarm time for 5 minutes To complete the alarm time setting, please short press the “Alarm time”...
- Page 10 Add Actors to the Gateway ednet Smart Home system provides Sensors (Transmitters) and Actors (Receivers). Transmitter sensors are Motion sensors and Contact sensors. Receiver devices are Siren, Power plug and others which can be activated in relation with the event triggered by Transmitter sensors such as motion sensor.
- Page 11 “learning” mode already. Please long press the “Set” button on the Siren (84295 or 84297) for 5 seconds until the LED is light-ON at the Siren. Then press “Yes” on the App side to start the “learning”. (4) Please press “Yes”...
- Page 12 Siren to exit and complete the learning process. Trademarks ednet is a registered trademark of ASSMANN Electronic GmbH. Apple, Apple App Store are registered trademarks of Apple Inc. Android, Google, Google play are registered trademarks of Google Inc.
- Page 13 Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the requirements of Directive 2014/53/EU and the Directive 2011/65/EU for RoHS compliance. The complete declaration of conformity can be requested by post under the below mentioned manufacturer address. Warning: This device is a class B product.
