Summary of Contents for Phoenix Gold pmn

  • Page 3: Trademarks

    Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a Power Safety Warning Before you undertake •...

  • Page 9: Battery Precautions

    Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.

  • Page 13: Developing Good Work Habits

    Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Notice ...I Trademarks ... I FCC Statement ...II Instructions for Care and Operation ... IV Power Safety ... VI Battery Precautions ...VII Cleaning ... VIII Servicing ... VIII Travel Considerations ... IX Introduction Overview ...1-1 Advanced Users ...1-1 Beginners and Not-So-Advanced Users ...1-1 Warning Boxes ...1-2 Not Included ...1-2 System Software ...1-2...
  • Page 16 Preface 2 * USB 2.0/1.1 Ports ...1-15 PC Card Slot ...1-15 Right Side View ...1-16 USB 2.0/1.1 Port ...1-16 Serial Port ...1-16 Optical (CD/DVD) Device Bay ...1-17 DC-In Jack ...1-17 Rear View & Bottom Views ...1-18 Security Lock Slot ...1-18 Vent/Fan Intake ...1-19 Battery ...1-19 Hard Disk Drive ...1-19...
  • Page 17 Clone Mode ...3-8 Dualview Mode ...3-8 Attaching Other Displays ...3-9 Power Management Features ...3-13 Advanced Configuration and Power Interface ...3-13 Power Options ...3-14 The Power Sources ...3-15 AC Adapter ...3-15 Battery ...3-15 Power Schemes ...3-16 System Power Options ...3-18 Hibernate Mode vs. Shutdown ...3-18 Standby Mode vs.
  • Page 18 Preface Failing the POST ...5-3 Fatal Errors ...5-3 Non-Fatal Errors ...5-3 The Setup Program ...5-4 Entering Setup ...5-4 Setup Screens ...5-5 Main Menu ...5-6 System Time & Date ...5-6 IDE Channel 0 Master/Slave ...5-7 System/Extended Memory: ...5-7 Advanced Menu ...5-8 Advanced Chipset Control (Advanced Menu) ...5-8 National 383 SIO Control Sub-Menu (Advanced Menu) ...5-9...
  • Page 19 Backup and General Maintenance ...8-3 Viruses ...8-4 Upgrading and Adding New Hardware/Software ...8-5 Problems & Possible Solutions ...8-7 Power ...8-7 Display ...8-8 Boot Password ...8-9 Audio & CD Device ...8-10 Keyboard ...8-11 Operation ...8-11 Modules ...8-12 Specifications Processor Types ...A-2 Core Logic ...A-2 LCD ...A-2 Memory ...A-2...
  • Page 20 Preface XVIII...

  • Page 21: Introduction

    Chapter 1: Introduction Overview This manual refers to the hardware and essential software required to run your computer. Depending on how your system is configured, some or all of the features described may already be set up. This chapter covers: •...

  • Page 22: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safe- ty information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface . Not Included Operating Systems (e.g. Windows XP etc.) have their own manuals, as do ap- plications (e.g.

  • Page 23: Quick Start Guide

    Quick Start Guide This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key components are. If you are not that com- fortable with this type of device, then please refer to the following pages, which give an overview of the system.

  • Page 24: System Map

    Introduction System Map Your computer has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting to Know Your Computer The following graphics will help you to become familiar with the basic func- tions, and to learn the location of the various ports and components of your computer.

  • Page 25: Top View

    Top View To open the LCD display: Place the computer on a stable surface. Move the LCD latches in the direction of the arrows to release the top cover (the left latch will lock in position and is clearly marked with locked unlocked icons).

  • Page 26: Top View With Lcd Panel Open

    Introduction Figure 1 - 2 Top View (LCD Panel Open) Optional Built-In PC Camera LED Power & Communication Indicators Speakers Lid Sensor LED Status Indicators Power Button Keyboard Built-In Microphone 10. TouchPad and Buttons 11. Ap-Key Buttons 1 - 6 Top View Top View with LCD Panel Open...

  • Page 27: Pc Camera

    PC Camera If you have purchased the optional PC Camera, make sure you install the driv- er/software application (see “PC Camera” on page 7 - key combination to toggle power to the PC Camera (see and Numeric Keypad” on page 2 - LCD Panel The computer comes with a wide screen TFT (Thin Film Transistor), Liquid Crystal Display screen (see...

  • Page 28: Lid Sensor

    Introduction Forced Off If the system “hangs”, and the Ctrl + Alt + Del combination doesn’t work, press the power button for 4 sec- onds, or longer, to force the system to turn itself off. 1 - 8 Top View Lid Sensor This LCD lid sensor is activated when the LCD panel is closed.

  • Page 29: Keyboard

    Introduction Keyboard The computer has a “Win Key” keyboard including a numeric keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced with a different language keyboard should you desire. Microphone Record on your computer with the built-in microphone. TouchPad &...

  • Page 30: Front View

    Introduction Figure 1 - 3 Front View LCD Latches Mini-IEEE 1394 port 4-in-1 Card Reader S/PDIF Out Jack Microphone-In Jack Headphone-Out Jack Ap-Key Buttons 1 - 10 Front View Front View 4 5 6 4 5 6 Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g.

  • Page 31: 4-In-1 Card Reader

    4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards (SD/ MS/MS PRO/MMC). Push the card into the slot and it will appear as a remov- able device (refer to “4-in-1 Card Reader” on page 2 - Card Reader Cover Make sure you keep the cover in the card reader when not is use.

  • Page 32: Ap-Key Buttons

    Introduction Wireless Device Power Status If you restart/turn off the computer, the pow- er status of the mod- ule(s) will remain the same as it was before the restart/shut down. 1 - 12 Front View Ap-Key Buttons The three Ap-Key buttons allow you instant access to your default Internet browser and default e-mail program, and to toggle the power on/off to the op- tional Wireless LAN/Bluetooth modules (see below).

  • Page 33: Left Side View

    Left Side View Vent/Fan Intake This enables airflow to prevent the computer from overheating. Overheating To prevent your computer from overheating make sure nothing blocks the vent/fan intake while the computer is in use. External Monitor Port Connect an external monitor to this port to allow dual video or simultaneous display on the notebook’s LCD and external monitor (see Display Modes”...

  • Page 34: S-Video-Out Port

    Introduction S-Video-Out Port Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. You will need an S-Video cable to make the connection. Enable this port from the video driver controls. RJ-11 Phone Jack This port connects to the built-in modem.

  • Page 35: Usb 2.0/1.1 Ports

    2 * USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 36: Right Side View

    Introduction Figure 1 - 5 Right Side View USB 2.0/1.1 Port Serial Port Optical CD/DVD Device Bay DC-In Jack 1 - 16 Right Side View Right Side View USB 2.0/1.1 Port These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 37: Optical (Cd/Dvd) Device Bay

    Optical (CD/DVD) Device Bay The optical device bay will contain a 5.25" (12.7mm height) CD/DVD type device. The actual device will depend on your purchase option (see al” on page A - 5 for options). For more information on using the drive please refer to “The Optical (CD/DVD) Device”...

  • Page 38: Rear View & Bottom Views

    Introduction Figure 1 - 6 Rear View & Bottom Views Security Lock Slot Vent/Fan Intake Battery RAM Bay Cover Hard Disk, WLAN & Bluetooth Module Bay Cover Optical (CD/DVD) Device Screw Cover 1 - 18 Rear View & Bottom Views Rear View &...

  • Page 39: Vent/Fan Intake

    Vent/Fan Intake This enables airflow to prevent the computer from overheating. Battery “Battery Information” on page 3 - 21 care. Hard Disk Drive The internal hard disk drive is used to store your data. See page formation on upgrading/replacing your hard disk drive. Drive Warning Don’t try to remove the hard disk (HDD) while the system is on.

  • Page 40: Wireless Lan (Network) & Bluetooth Modules

    Introduction Wireless LAN & Bluetooth Modules The optional Wireless Bluetooth modules may be pow- ered ON/OFF pressing the button at the front of the comput- (see “Wireless Module Power Ap- Button” page 1 - 12 & “WLAN/ Bluetooth Toggle Power Order”...

  • Page 41: Chapter 2: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about using your computer, please read this chapter. This chapter includes: • LED Indicators • Auto Mail Checker • Hard Disk Drive • The Optical (CD/DVD) Device • PC Card Slot •...

  • Page 42: Led Indicators

    Using The Computer Table 2 - 1 LED Status Indicators 2 - 2 LED Indicators LED Indicators There are two sets of LED indicators (LED Status Indicators and LED Pow- er & Communication Indicators and) on your computer that will display helpful information about the current status of the computer.

  • Page 43: Led Power & Communication Indicators

    LED Power & Communication Indicators Icon Color Orange Green Blinking Green Orange Green Blinking Orange The battery has reached critically low power status Blinking Green Description DC power is plugged in The computer is on The computer is in standby mode The battery is being charged The battery is fully charged New mail has arrived...

  • Page 44: Auto Mail Checker

    Using The Computer Auto Mail Checker After you have installed the driver for the Auto Mail Checker program (see “AutoMail Checker (WinXP)” on page 4 - 10) you may then configure it to give you notification when you receive new mail. You must be online to re- ceive this notification (note that this program only supports the POP3 proto- col), and your default mail program does not need to be open.
  • Page 45 You may then configure the options for your mailserver, name, password, pro- gram and method(s) of notification. Using The Computer Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages.

  • Page 46: Hard Disk Drive

    Using The Computer Power Safety Before attempting to access any of the inter- components your computer please ensure that the ma- chine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral ca- bles, including phone lines, are disconnected from the computer.

  • Page 47: The Optical (Cd/Dvd) Device

    The Optical (CD/DVD) Device There is a bay for a 5.25" CD/DVD device (12.7mm height). The actual device will depend on the model you purchased (see CD Device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu”...

  • Page 48: Handling Cds Or Dvds

    Using The Computer CD Emergency Eject If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break...

  • Page 49: Dvd Regional Codes

    DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This can- not be altered even if you change your operating system or you use the module in another computer.

  • Page 50: Changing Dvd Regional Codes

    Using The Computer Table 2 - 3 DVD Regional Coding 2 - 10 The Optical (CD/DVD) Device Changing DVD Regional Codes Go to the Control Panel in WindowsXP and double-click System > Hard- ware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.

  • Page 51: Pc Card Slot

    Using The Computer PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Make sure you install the driver for the PC Card/Card Reader (see “PC- MCIA & Card Reader (WinXP)” on page 4 - Inserting and Removing PC Cards •...

  • Page 52: 4-In-1 Card Reader

    Using The Computer Figure 2 - 7 Removable Disks 2 - 12 4-in-1 Card Reader 4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. •...

  • Page 53: Ap-Key Buttons

    Ap-Key Buttons These buttons access the Internet and e-mail, and toggle the WLAN/Bluetooth module power ON/OFF with one quick button press. Make sure you install the Ap-Key driver (see “Ap-Key (WinXP)” on page 4 - Ap-Key Buttons Activate the default Internet browser Toggle the Wireless LAN/Bluetooth module power ON/OFF Wireless Module Power Ap-Key Button You can use this button to toggle the power ON/OFF for the optional Intel...

  • Page 54: Function Keys And Numeric Keypad

    Using The Computer Other Keyboards If your keyboard is damaged or you just want make change, you can use any standard USB key- board. The system will detect and enable it automatically. Howev- er special functions/hot keys unique to the sys- tem’s regular keyboard may not work.

  • Page 55: Numeric Keypad

    Numeric Keypad The keyboard has an embedded numerical keypad for easy numeric data input. The numeric keys are highlighted by a yellow typeface. Activate the Number Lock feature by pressing the Num Lock key at the top right of the keyboard. You may check if Number Lock is activated or not by looking at the LED status indicators (see Activate Scroll Lock by pressing and holding the Fn key, and then press the Scr Lk key at the top right of the keyboard.

  • Page 56: Touchpad And Buttons/Mouse

    Using The Computer Mouse Driver If you are using an ex- ternal mouse your op- erating system may be able to auto-configure your mouse during its installation or only en- able its basic functions. Be sure to check the device’s user docu- mentation for details.

  • Page 57: Audio Features

    Audio Features You can configure the audio options on your computer from the Sounds and Audio Devices Windows control panel, or from the Sound Effect Man- ager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus). The volume may also be adjusted by means of the Fn + F11/F10 key combination.

  • Page 58: Adding A Printer

    Using The Computer Parallel Printer After setting up the printer attach the paral- lel cable to the printer. Connect the printer’s parallel cable to the Parallel port. Turn ON the printer, then the computer. Windows will identify the printer and either load one of its own drivers or ask you to supply one.

  • Page 59: Chapter 3: Advanced Controls

    Chapter 3: Advanced Controls Overview This chapter covers: • Advanced Video Controls • NVIDIA Display Properties • Display Devices & Display Modes • Attaching Other Displays • Power Management Features • The Power Sources • Power Schemes • System Power Options •...

  • Page 60: Advanced Video Controls

    Advanced Controls Protecting the LCD Do not allow any for- eign objects (i.e. paper or plastic) to get be- tween the lid/LCD and the work panel. They could damage scratch the LCD and/or accidentally activate the close cover switch. Figure 3 - 1 Brightness Controls 3 - 2 Advanced Video Controls...

  • Page 61: Nvidia Display Properties

    NVIDIA Display Properties The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, video memory and the driver for your operating system. The driver interface shows the available options.

  • Page 62: Windows Display Properties

    Advanced Controls Desktop Access to GeForce Go 6600 Control Panel To access the Ge- Force Go 6600 control panel from the desk- top: 1. Right-click the desk- top. 2. Point to NVIDIA Dis- play and click Lap- top Display. Figure 3 - 2 Display Properties 3 - 4 NVIDIA Display Properties Windows Display Properties...

  • Page 63: Additional Properties

    Additional Properties The items listed in the Additional Properties window allow you to configure your display(s). If the items do not display you can either click the Additional Properties button, or click the icon . Click pin icon to push pin in to keep the menu open.
  • Page 64 Advanced Controls Figure 3 - 4 Screen Examples 3 - 6 NVIDIA Display Properties You may make changes to the Display Settings, Color Correction, Video Overlay, Resolutions, Refresh Rates and Screen Rotation etc. by clicking the appropriate tab and adjusting the setting. Right-click on a control panel item to bring up a Help...

  • Page 65: Nvidia Nview Desktop Manager

    NVIDIA nView Desktop Manager The nView Desktop Manager allows quick access to control panels for video features. The Control panel may be accessed as follows. Click Start, point to Settings and click Control Panel (or click Control Panel). Double-click NVIDIA nView Desktop Manager (icon) - Click "Switch to Classic View"...

  • Page 66: Display Devices & Display Modes

    Advanced Controls Display Wizard Use the Display Wiz- ard in the Desktop Management window to quickly setup and configure any attached displays (see Figure 3 - 5 on page 3 - Cyberlink Power Do not switch display modes (e.g. from Du- alview to Clone etc.) when playing DVDs in the Cyberlink Power...

  • Page 67: Attaching Other Displays

    Attaching Other Displays Connect an external display to the appropriate port and configure it as follows. Attach your external monitor to the external monitor port (or TV to the S- Video-Out port), and turn it on. Click Additional Properties in the GeForce Go 6600 Properties control panel tab (see “Additional Properties”...
  • Page 68 Advanced Controls nView Display Mode Options The display options listed under the Prima- ry display: / Secondary display: drop boxes will differ according to the displays attached, and the Display Mode cho- sen. Figure 3 - 7 Primary/Secondary Display Dropbox & Device Settings 3 - 10 Attaching Other Displays Select the display option from the Primary Display/ Secondary Display...

  • Page 69: Enabling Tv Display

    Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S-Video cable from the TV to computer’s S-Video-Out port. Enable the TV display from the nView Display Settings tab (see Other Displays” on page 3 - 9).
  • Page 70 Advanced Controls Set the TV format from the Select TV Format menu. The Advanced option at the bottom of the Select TV Format menu allows you to select TV format by country if you are unsure of your TV format. Figure 3 - 9 TV Settings and Adjustments...

  • Page 71: Power Management Features

    Power Management Features To conserve power, especially when using the battery, your computer uses the ACPI power management system. Power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. Advanced Configuration and Power Interface The ACPI interface provides the computer with enhanced power saving tech- niques and gives the operating system (OS) direct control over the power and...

  • Page 72: Power Options

    Advanced Controls Figure 3 - 10 Power Options Control Panel 3 - 14 Power Options Power Options When the computer is on, you can use the power button as a Standby/Hiber- nate/Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the com- puter down).

  • Page 73: The Power Sources

    The Power Sources The computer can be powered by either an AC adapter or a battery pack. AC Adapter Use only the AC adapter that comes with your computer. The wrong type of AC adapter will damage the computer and its components. Attach the AC adapter to the DC-in jack on the right of the computer.

  • Page 74: Power Schemes

    Advanced Controls Resuming Operation The system can re- sume from Monitor or Hard Disk Standby by pressing a key on the keyboard. Figure 3 - 11 Power Schemes 3 - 16 Power Schemes Power Schemes You can set your computer to conserve power through individual components by means of Power Schemes.
  • Page 75 (DC power) powered. Windows will use Porta- ble/Laptop as the default scheme. Windows will use Portable/Laptop as the default scheme. Power Schemes 3 - 17...

  • Page 76: System Power Options

    Advanced Controls System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 12 on page 3 -...

  • Page 77: Standby

    Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memo- ry.

  • Page 78: Configuring The Power Button

    Advanced Controls Figure 3 - 13 Power Options (Advanced - Power Buttons) 3 - 20 Configuring the Power Button Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 3 - 13).

  • Page 79: Battery Information

    Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see FAQ” on page 3 - 24 for instructions on how to do this). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and peripheral devices attached.

  • Page 80: Recharging The Battery With The Ac Adapter

    Advanced Controls Conserving Battery Power To conserve battery pow- Lower the brightness lev- el of the LCD display. The system will decrease LCD brightness slightly to save power when it is not pow- ered by the AC adapter. Close modem or commu- nication applications when they are not being...

  • Page 81: Proper Handling Of The Battery Pack

    Proper Handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 82: Battery Faq

    Advanced Controls Caution Danger of explosion if battery is incorrectly replaced. Replace only with the same equivalent type recommended by the manufacturer. Dis- card used battery ac- cording manufacturer’s structions. 3 - 24 Battery Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery.

  • Page 83: Chapter 4: Drivers & Utilities

    Chapter 4: Drivers & Utilities Overview This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware compo- nents for which the latest versions of most available operating systems haven’t built in drivers and utili- ties.
  • Page 84 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 85: Authorized Driver Message

    Authorized Driver Message If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- ture Not Found), just click Continue Anyway to ignore the message and continue the installation procedure. You will receive this message in cases where the driver has been released after the version of Win- dows you are currently using.

  • Page 86: Driver Installation

    Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Man- ual CD-ROM and the Notebook Driver Installa- tion application will run automatically. If you want to install the driver manually see Installation” on page 4 - Check the driver installation order from 1, on page 4 - 6 (the drivers must be installed...

  • Page 87: Manual Driver Installation

    Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Notebook Driver Installa- tion application, then follow the manual installa- tion procedure for each driver. The manual installation procedure begins with instructions on how to browse to the executable file;...

  • Page 88: Installation Procedure

    Drivers & Utilities Installation Procedure This section covers driver and utility installation in- structions for Windows XP (Professional & Home). Windows XP Driver (SP2) Chipset Audio Modem Network (LAN) Video Ap-Key Buttons TouchPad PC Card (PCMCIA) & Card Reader Wireless LAN Bluetooth PC Camera AutoMail Checker...

  • Page 89: Audio (Winxp)

    Audio (WinXP) 1. Double-click Audio from the Driver Installation menu. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ 01AUDIO\Setup.exe and click OK. 2. Click Next (click Cancel if The Found New Hardware Wizard appears). 3. Click Finish to restart the computer. 4.

  • Page 90: Lan (Winxp)

    Drivers & Utilities LAN (WinXP) 1. Double-click Lan from the Driver Installation menu. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ 03LAN\SetupYukonWin.exe and click 2. Click Next. 3. Click the button to accept the license and click Next. 4.

  • Page 91: Ap-Key (Winxp)

    Ap-Key (WinXP) 1. Double-click Ap-key from the Driver Instal- lation menu. Click Start (menu) > Run... and navigate (Browse..) to D:\Drivers\ 05Ap-key\Setup.exe and click OK. 2. Choose the language you prefer, and click 3. Click Next. 4. Click Finish to restart your computer. TouchPad (WinXP) 1.

  • Page 92: Pc Camera (Winxp)

    Drivers & Utilities PC Camera (WinXP) See install procedure in stallation” on page 7 - Latest PC Camera Driver Information Check the PC Camera CD, and any accompanying insert pages, for the latest updated information on the PC Camera driver, which may override the infor- mation provided here.

  • Page 93: Chapter 5: Bios Utilities

    Chapter 5: BIOS Utilities Overview This chapter gives a brief introduction to the computer’s built-in software: Diagnostics: The POST (Power-On Self Test) Configuration: The Setup utility If your computer has never been set up, or you are making important changes to the system (e.g.

  • Page 94: The Power-On Self Test (Post)

    BIOS Utilities POST Screen 1.BIOS information 2.CPU type 3.Memory status 4.Enter Setup prompt appears only during POST Note: POST screen as pictured is for guideline purposes only. POST screen on your com- puter appear slightly different. Figure 5 - 1 POST Screen 5 - 2 The Power-On Self Test (POST) The Power-On Self Test (POST)

  • Page 95: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 96: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually...

  • Page 97: Setup Screens

    Setup Screens The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with five (5) menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup.

  • Page 98: Main Menu

    BIOS Utilities Figure 5 - 2 Main Menu 5 - 6 Main Menu Main Menu PhoenixBIOS Setup Utility Main Main Advanced Security System Time: [22:11:05] System Date: [09/22/2004] IDE Channel 0 Master [20004MB] IDE Channel 0 Slave [CD-ROM] System Memory: 640 KB Extended Memory: 522240 KB...

  • Page 99: Ide Channel 0 Master/Slave

    BIOS Utilities IDE Channel 0 Master/Slave Pressing Enter here opens the sub-menu to show the configuration of either a CD/DVD type Device or HDD on the computer’s IDE Channel 0. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: This item contains information on the system memory, and is not user config- urable.

  • Page 100: Advanced Menu

    BIOS Utilities Figure 5 - 3 Advanced Menu 5 - 8 Advanced Menu Advanced Menu PhoenixBIOS Setup Utility Main Advanced Advanced Security Advanced Chipset Control National 383 SIO Control Sub-Menu Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled] Reset Configuration Data: [No] Power on Boot Beep [Disabled]...

  • Page 101: National 383 Sio Control Sub-Menu (Advanced Menu)

    BIOS Utilities National 383 SIO Control Sub-Menu (Advanced Menu) Pressing Enter here will provide a sub-menu that controls the configuration of various National 383 SIO devices. Legacy USB Support (Advanced Menu) Use this menu item to enable/disable the support for Legacy Universal Serial Bus.

  • Page 102: Security Menu

    BIOS Utilities Figure 5 - 4 Security Menu 5 - 10 Security Menu Security Menu PhoenixBIOS Setup Utility Security Main Advanced Security Supervisor Password Is: Clear Set Supervisor Password [E E nter] Password on boot: [Disabled] Fixed disk boot sector: [Normal] Help Select Item...

  • Page 103: Password On Boot: (Security Menu)

    Password on boot: (Security Menu) Specify whether or not a password (supervisor or user password) should be entered to boot the computer. If “Enabled” is selected, only users who enter a correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

  • Page 104: Boot Menu

    BIOS Utilities Figure 5 - 5 Boot Menu IDE 0/2 Channel IDE channel 0 is for par- allel hard disks, and IDE channel 2 is for serial hard disks. 5 - 12 Boot Menu Boot Menu PhoenixBIOS Setup Utility Main Advanced Security Boot priority order:...
  • Page 105 Boot devices usually are hard drives, floppy drives, and CD-ROMs/DVD- ROMs and Networks (LANs). When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”.

  • Page 106: Exit Menu

    BIOS Utilities Figure 5 - 6 Exit Menu 5 - 14 Exit Menu Exit Menu PhoenixBIOS Setup Utility Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes Help Select Item Exit Select Menu Enter Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup.

  • Page 107: Chapter 6: Upgrading The Computer

    Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- lems you can contact your service representative for further help. Before you begin you will need: •...

  • Page 108: When Not To Upgrade

    Upgrading The Computer Power Safety Warning Before you undertake any upgrade proce- dures, make sure that you have turned off the power, discon- nected all peripherals and cables (including telephone lines). It is advisable to also re- move your battery in order to prevent acci- dentally turning...

  • Page 109: Removing The Battery

    Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Turn the computer off, and turn it over. Locate the battery bay at point Slide the battery lock in the direction of the arrow (towards the unlock symbol ), and hold it in place.

  • Page 110: Upgrading The Hard Disk Drive

    Upgrading The Computer HDD System Warning New HDD’s are blank. Before you begin make sure: You have backed up any data you want to keep from your old HDD. You have all the CD- ROMs and FDDs re- quired to install your oper- ating system programs.
  • Page 111 Slide the hard disk assembly in the direction of the arrow Carefully lift the hard disk assembly Remove screws and separate the cover from the hard disk Reverse the process to install a new hard disk (pay careful attention to the orientation of the disk under the cover).

  • Page 112: Upgrading The System Memory (Ram)

    Upgrading The Computer Figure 6 - 4 RAM Cover Removal & Release Latches 6 - 6 Upgrading the System Memory (RAM) Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO-DIMM) - DDRII (DDR2) 400/533 MHz - type memory modules (see “Memory”...
  • Page 113 The RAM module (see Figure 6 - Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go.

  • Page 114: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Figure 6 - 6 CD/DVD Device Removal Procedure 6 - 8 Upgrading the Optical (CD/DVD) Device Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Remove the screw at point Remove CD/DVD device screw cover Apply pressure at point to push the CD/DVD Device...

  • Page 115: Upgrading The Processor

    Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- tive. We recommend that you do not do this yourself, since if it is done incor- rectly you may damage the processor or mainboard.
  • Page 116 Upgrading The Computer 6 - 10...

  • Page 117: Chapter 7: Wireless & Pc Camera Modules

    Wireless & PC Camera Modules Chapter 7: Wireless & PC Camera Modules Overview This chapter contains the information on the optional Wireless LAN, option- al Bluetooth and optional PC Camera modules which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative.

  • Page 118: Wlan/Bluetooth Toggle Power Order

    Wireless & PC Camera Modules Wireless Device Operation Aboard Aircraft The use of any porta- ble electronic trans- mission devices aboard aircraft is usu- ally prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft. Check taskbar icons, and the WLAN LED status indi-...

  • Page 119: Intel Pro/Wireless Mini Pci Wlan Module

    Intel PRO/Wireless Mini PCI WLAN Module Either an Intel PRO/Wireless 2200BG (802.11b/g) or 2915ABG (802.11a/ b/g) Mini-PCI WLAN module is supplied as a optional feature for the com- puter, depending on your purchase configuration. You will be provided with the appropriate software CD for your module. Before installing the Intel PRO/Wireless 2200BG or 2915ABG Mini-PCI WLAN driver, make sure that the Wireless LAN module is on (the will be green).

  • Page 120: Intel Wlan Driver Installation

    Wireless & PC Camera Modules User Guide You can view the User Guides by inserting the Intel PROSet/ Wireless CD-ROM and clicking View User Guides (but- ton) as per “Installation Screens” on page 7 - Figure 7 - 2 Intel PROSet/ Wireless 7 - 4 Intel PRO/Wireless Mini PCI WLAN Module Intel WLAN Driver Installation...

  • Page 121: Bluetooth Module

    Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth module is on. Use the Ap-Key Button (see 13) to toggle power to the Bluetooth module. Make sure you install the drivers in the order indicated in Bluetooth Driver Installation 1.
  • Page 122 Wireless & PC Camera Modules Figure 7 - 3 Bluetooth Control Panel & User Guides 7 - 6 Bluetooth Module...

  • Page 123: Pc Camera

    PC Camera Before installing the PC Camera driver, make sure that the optional PC Cam- era module is on. Use the Fn + F8 key combination (see Numeric Keypad” on page 2 - 14) to toggle power to the PC Camera module (make sure you install the drivers in the order indicated in page 4 - Latest PC Camera Driver Information...

  • Page 124: Pc Camera Audio Setup

    Wireless & PC Camera Modules 7 - 8 PC Camera PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 125 Wireless & PC Camera Modules Figure 7 - 4 Audio Setup PC Camera 7 - 9...

  • Page 126: Amcap

    Wireless & PC Camera Modules Pre-Allocating File Space You may pre-allocate the file size for the cap- ture file in the AMCAP program. choose to ignore this by clicking Cancel. Pre-allocating space on the hard disk can im- prove the capture quali- ty (particularly of large capture files), by reduc- ing the amount of work...
  • Page 127 Eliminating Screen Flicker If you find that the video screen in the AMCAP program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the AMCAP program from the Start > Programs/All Programs > CMM PC Camera menu.
  • Page 128 Wireless & PC Camera Modules 7 - 12...

  • Page 129: Chapter 8: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 130: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 131: Backup And General Maintenance

    Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wallet.

  • Page 132: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 133: Upgrading And Adding New Hardware/Software

    Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 134 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.

  • Page 135: Problems & Possible Solutions

    Problems & Possible Solutions Power Problem You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.

  • Page 136: Display

    Troubleshooting Problem The computer feels too hot. Display Problem Nothing appears screen. 8 - 8 Problems & Possible Solutions Possible Cause - Solution Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see 19).

  • Page 137: Boot Password

    Problem No image appears on the You haven’t installed the video driver and configured it appropriately from the Control external monitor I have Panel. See plugged in and powered “NVIDIA Display Properties” on page 3 - 3 driver. Boot Password Problem forget boot...

  • Page 138: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem The sound cannot be heard or the volume is very low. The compact disc cannot be read. The compact disc tray will not open when there is a disc in the tray. The DVD regional codes longer changed.

  • Page 139: Keyboard

    Keyboard Problem Unwelcome numbers If the LED appear when typing. (see “Numeric Keypad” on page 2 - If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.

  • Page 140: Modules

    Troubleshooting Modules Problem Wireless LAN/ Bluetooth module(s) cannot be detected. Wireless LAN/ Bluetooth module(s) cannot be configured. Camera module(s) cannot detected. Camera module(s) cannot configured. 8 - 12 Problems & Possible Solutions Possible Cause - Solution The module(s) are off. Check the LED indicator (see “LED Status Indicators”...

  • Page 141: Appendix A: Specifications

    Appendix A: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds) may be changed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 142: Processor Types

    Feature Processor Types Intel® Pentium® M Processor (478-pin) Micro-FCPGA Package 730/ 740/ 750/ 760/ 770/ 780 Intel® Pentium® M Processor (478-pin), Micro-FCPGA Package 715/ 725/ 735/ 745/ 755/ 765 Core Logic Intel 915PM + ICH6-M 15.4" WXGA (1280*800)/ WSXGA+ (1680*1050)/ WUXGA (1920*1200) TFT LCD (16:10 Wide Screen Aspect Ratio) Memory 64-bit DDR Dual Channels...

  • Page 143: Security

    Feature Security Security (Kensington® Type) Lock Slot BIOS One 512KB Flash ROM Storage One Changeable 12.7mm (h) Optical Device (CD-ROM/ DVD-ROM/ Combo/ DVD-Dual/ DVD Super-Multi) One Changeable Primary 2.5" 9.5mm (h) Parallel (PATA) Hard Disk Drive Supporting LBA Mode Supports ATA 33/ 66/ 100 Audio Integrated AZALIA Compliant Interface (HDA);...

  • Page 144: Interface & Communication

    Feature Interface & Three USB 2.0/1.1 Ports Communication One Mini IEEE1394a Port One External Monitor Port One S-Video-Out Port for TV Output One Serial Port One Headphone-Out /Speaker-Out Jack One Microphone-In Jack One S/PDIF Out Jack One DC-In Jack 300K Pixel CMOS VIdeo Camera Module (Factory Option) Bluetooth 1.2 Module - (WPN) Wireless Personal Network (Option)

  • Page 145: Power

    Feature Power Universal AC Adapter - AC-In 100~240V, 50~60Hz, DC Output 20V 4.5A (90W) Easy Changeable Main Battery Smart Lithium-Ion, 4400mAh (6 cells) Easy Changeable Optional Second Battery Smart Lithium-Ion, 8800mAh (12 cells) Environmental Temperature Spec Operating: Non-Operating: Physical 360mm (w) * 273mm (d) * 29.5mm (h) Dimensions &...
  • Page 146 A - 6...

Table of Contents
