PHL Audio M25 Specification Sheet

M25 professional series 10" - 25cm midrange driver, very high spl, very high sounding quality

Advertisement

Quick Links

10
25
cm
I
Midrange Driver
Very High Sounding Quality
Very High SPL
I
PROFESSIONAL SERIES
3450
Midrange transducer dedicated to the
reproduction of 150-4000Hz frequencies.
Equipped with a progressive wave
diaphragm for precise transcription of the
mid rnage band.
Usable either for direct radiation in small
volumes from 4L/6L or for horn loaded
application.
Power handling capacity
Reference efficiency
(1W @ 1m)
SPL max
(continuous)
Usable frequency range
Environmental withstanding
M25
8 Ω
APPLICATIONS
FEATURES
200 W AES
101 dB SPL
120 dB SPL
150-4000 Hz
Outdoor

Advertisement

loading
Need help?

Need help?

Do you have a question about the M25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PHL Audio M25

  • Page 1 Midrange Driver Very High Sounding Quality Very High SPL PROFESSIONAL SERIES 3450 APPLICATIONS Midrange transducer dedicated to the reproduction of 150-4000Hz frequencies. Equipped with a progressive wave diaphragm for precise transcription of the mid rnage band. Usable either for direct radiation in small volumes from 4L/6L or for horn loaded application.
  • Page 2 Air volume occupied by the driver Speaker net mass Recommended reflex box Electrical polarity PHL Audio S.A. provides these specifications as representative of current production after conditioning. Because of our continuous research, they are subject to change without notice. 3450 150-4000 (AES)
