PHL Audio 5100 Specifications

15" Bass Midrange Driver
High Sound Pressure Level
High Efficiency
APPLICATIONS
Built according to the same concepts as SP5050, this model which
belongs to our sound reinforcement Contact Class is equipped with
a classical two layer coil, which allows it to be used in larger Reflex
enclosures (80L to 110L tuned at 40Hz) with the same sound
qualities as the SP5050.
SP5100 can also be X-overed up to 800Hz, and exhibits a good
quality to price ratio.
DESIGN CONCEPT
DEFLECTION CONTROLLED DIAPHRAGM optimized for dynamic
damping.
DEFLECTION CONTROLLED DIAPHRAGM
in optimizing the shape and material of the diaphragm so that it
works as a mechanical transmission line, to avoid breaking modes
as well as mechanical threshold which destroy sound quality.
This leading edge technology offers substantial sonic advantages.
Among them: sound coherency, fast transients, stable sound
imaging, high sensitivity, wide frequency range and reduced
directivity pattern.
VENTED COMPACT MAGNET SYSTEM. It has been carefully
optimized to obtain maximum transducing efficiency while
avoiding unlinear behavior such as coil inductance variation with
position, flux modulation, harmonic distortion, rest position offset,
air compression and off-axis voice-coil pushing.
Its design incorporates a T-shaped and vented pole piece, and
a flux stabilization ring. It also takes into consideration
demagnetization at cold temperatures.
INTERCOOLER SYSTEM (patented). Entirely integrated into the
loudspeaker itself, the
INTERCOOLER SYSTEM
produced by Joule effect in the voice-coil by the means of an air
flow directed through the heatsink rims of the basket by the
motion of the dust-cap and the spider.
The gain brought about by this technology is over 20 % of extra
power, so for example, a 3"coil according to this design has
the same power handling capacity as a classical 4"one.
5100
Contact Class
I
technology consists
extracts the heat
8 Ω
PROFESSIONAL SERIES
FEATURES
Power handling capacity
Reference efficiency
SPL max
(continuous)
Usable frequency range
Environmental withstanding
ARCHITECTURAL SPECIFICATIONS
NOMINAL DIAMETER
: High tensile alloy pressure
FRAME
die-cast basket with patented
INTERCOOLER SYSTEM
MAGNET SYSTEM
heat extracting design with vented
pole piece and flux stabilizing ring.
: High-temperature
VOICE COIL
stabilized copper wire wound on
high-strength glass polyimide former.
CONE ASSEMBLY
cellulose fiber cone and central
dome impregnated and front-coated
with damped resins, fitted with high
compliance treated double-roll fabric
surround.
SPEAKER MASS
B38
400 W AES
98 dB SPL
(1W @ 1m)
120 dB SPL
40-1500 Hz
Outdoor
: 380 mm.
.
: 3" highly energized,
: High-strength
: 9.10 kg
