Installation and
Operation Manual
BVR-25
Wall Mountable Component Video/Digital
Audio Receiver
T
hank you for choosing an AudioControl Active-
Balanced product for your video and audio distribu-
tion needs. You are installing one of the most innovative
custom installation products available. This unit will allow
you to receive video and audio signals over standard
Category 5 wiring by using the highest quality active
circuitry. Please note that these products are primarily
designed for installation by professional audio video com-
panies. Therefore if any part of this manual is not clear ...
STOP WHAT YOU ARE DOING! Contact your nearest
audio video installation company or call us and we will
refer you to one. Plasma monitors, projectors and some
DVD players are too expensive to damage so don't attempt
anything you are unfamiliar with.
Now sit back, grab yourself a cold beverage and take a
moment to read through this manual before you charge off
into the installation. Once you cut a hole in the wall, you
are committed.
For Those Who Consider Perfection Possible
®
S
ERIES
™
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AudioControl BVR-25
Summary of Contents for AudioControl BVR-25
-
Page 1: Operation Manual
Plasma monitors, projectors and some DVD players are too expensive to damage so don’t attempt ©2006, AudioControl, a division of Electronic Engineering and anything you are unfamiliar with. Manufacturing, Inc. All rights reserved. - Page 2 CTIVE ALANCED Balanced Video Series BVR-25 Specifications Here are some of the cool features of your new BVR-25 All specifications are measured with supplied 110 VAC balanced video and audio receiver: to 12 VDC wall transformer. As technology advances, AudioControl reserves the right to change our specifica- •...
- Page 3 ERIES ERIES CTIVE ALANCED CTIVE ALANCED EIA-568 RJ-45 Pin Connection Diagram The First Step In Your Installation Procedure Pair 1 White-Blue (W-BL) Video 4 – : Audio/Video FILL OUT AND SEND IN THE WARRANTY CARD! Blue (BL) Video 4 + : Audio/Video Also, save the invoice or sales slip as proof of purchase.
- Page 4 ERIES ERIES CTIVE ALANCED CTIVE ALANCED A Quick Tour of the BVR-25 Block Diagrams BVR-25 ① ⑥ ② ③ ④ ⑦ ⑤ ⑧ ① Video Calibration ⑤ 12 volt trigger output Indicator Light ⑥ Component Video Outputs ② Video Signal Gain Control ⑦...
-
Page 5: Repair Information
ALANCED Repair Information In the unlikely instance that you ever need to have your AudioControl component repaired. Please contact our fac- tory for return instructions. Repairs are handled quickly at our factory. You are responsible for paying the freight ⑩... -
Page 6: Installation Information
5. The warranty is also void if the serial number is altered will be connected to the BVR-25. You will want to keep the or removed, or if the BVR-25 has been used improperly. - Page 7 AudioControl dealer in the Unit- ed Sates. Otherwise your warranty is one year. You will be System 1: Basic system using BVD-20 sending unit and BVR-25 receiver happy to know that our warranty returns are rigorously tracked and very few of the units we build ever need to be repaired.
- Page 8 1. Measure output with voltmeter. 2.Confirm amperage required for automation system. Install relay if necessary. 3.The video signal feeding the BVR-25 is too low or un- calibrated. Re-adjust gain and calibration controls. System 3: Satellite receiver feeding a BVH-20 and distributed to multiple BVR- 25’s...
-
Page 9: Troubleshooting
Ethernet Router or hub. It is alright to run the signal through a passive patch bay. 4. Make certain display or monitor is compatible with System 4: Video signal being fed into BVD-20 and routed to multiple BVR-25’s format of choice, i.e. 480P; 1080i; etc. via daisy chain wiring Power Wiring “No Power Light.”... - Page 10 Image Compensation: The Image Compensation control Please note that the striped wire is positive (+) and the solid on the BVR-25 equalizes the video signal to counteract the wire is negative (-). effect of wire capacitance. In most cases the COMPENSA- TION control should be set the same as the GAIN control.
-
Page 11: Adjusting The Controls
Signal Wiring nal enhancements at optimum levels, we have no way of The BVR-25 operates using standard unshielded twisted- knowing the exact length of pair (UTP) Category 5 (or better) wiring. Good wiring cable that you will be using. - Page 12 BVR-25 that is routing the signal to another BVR-25. The use any existing 10/100 Base-T network cabling and patch last BVR-25 in the signal path MUST have the “R37” resis- bays in an installation as long as it does not run through a tor network inserted for the system to function properly.
