Philips MASTER TL-D Super 80 HF Specifications

Fluorescent lamps
Dimensions in mm
Type A
max.
TL-D HF 16W 589.8
TL-D HF 32W 1199.4
TL-D HF 50W 1500.0
Commercial
name
/830
MASTER TL-D Super 80 HF TL-D HF 16W /830
MASTER TL-D Super 80 HF TL-D HF 32W /830
MASTER TL-D Super 80 HF TL-D HF 50W /830
/840
MASTER TL-D Super 80 HF TL-D HF 16W /840
MASTER TL-D Super 80 HF TL-D HF 32W /840
MASTER TL-D Super 80 HF TL-D HF 50W /840
/850
MASTER TL-D Super 80 HF TL-D HF 32W /850
/865
MASTER TL-D Super 80 HF TL-D HF 32W /865
*) HF gear
1
Ø 28 max.
A
B
C
B B
min. max.
594.5 596.9
1204.1 1206.5
1504.7 1507.1
Type Cap/ Lamp
base voltage
G13 64
G13 128
G13 142
G13 64
G13 128
G13 142
G13 128
G13 128
MASTER TL-D Super 80 HF
Fluorescent lighting is efficient
and economical.The efficacy
(lumen/watt) of all fluorescent
lamps is high compared to most
other light sources.
Different luminaires are available
for various purposes.
TL-D lamps are low-pressure
mercury discharge lamps with a
clear tubular 26 mm envelope.
The tube wall is internally
covered with a mixture of
fluorescent powders.
MASTER TL-D HF Super 80
colour lamps are produced with
special fluorescent powder
(/80 colours), which leads to a
good colour rendering index
(C.R.I. > 80) and a high efficacy.
MASTER TL-D HF Super 80
colour lamps are used in 'human
applications' like schools, offices,
shops, factory halls and so on.
The use of /80 colour phosphors
also results in a high initial lumen
output and a excellent lumen
maintenance.
The initial efficacy and the
efficacy during lifetime is relatively
high.
Green cap
C
min.
604.0
1213.6
1514.2
Lamp Colour
*) current *) designation
temperature
V A
0.26 WARM WHITE
0.26 WARM WHITE
0.36 WARM WHITE
0.26 COOL WHITE
0.26 COOL WHITE
0.36 COOL WHITE
0.26 DAYLIGHT
0.26 COOL DAYLIGHT
MASTER TL-D HF Super 80
colour lamps have an argon gas
filling.They can be used on
special HF gear.
The efficacy of a HF system is
higher than conventional gear.
The colour designation of
MASTER TL-D lamps creates a
certain atmosphere. It varies
from warm white to cool
daylight.
The colour designation is
determined by the colour
temperature of the lamp.
MASTER TL-D HF Super 80 is a
breakthrough in TL lighting.
Advanced coating technology
reduces the mercury absorption
by the glass wall and the
fluorescent powders.
As a result the lumen
maintenance has been improved.
MASTER TL-D HF Super 80
lamps contain only 3 mg of
mercury.
Recyclable
MASTER TL-D HF Super 80
lamps are recyclable: materials
(glass, metal,
fluorescent powder, mercury)
from end-of-life lamps can be
recycled in the production of
new TL lamps if the right
disassembly technology is used.
All MASTER TL-D HF Super 80
lamps are produced with an end-
cap with a green bottom plate to
highlight the environmental
benefits of these lamps, especially
recyclability.
Correlated Lumen Average
colour output *) luminance *)
K lm cd/cm 2
3000 1400 1.04
3000 3200 1.19
3000 5000 1.44
4000 1400 1.04
4000 3200 1.19
4000 5000 1.44
5000 3010 1.10
6500 2920 1.10
Nett EOC
weight
g
100 631442
186 631503
233 631565
100 631473
186 631534
233 631596
186 641830
186 559302
