- Page 1 2.5HP 40L DIRECT DRIVE COMPRESSOR For service, spare parts or product information, MODEL NO. please contact Smart Marketing Group Pty. Ltd. AC6168 AUST. 1300 660 457 N.Z. 0800 474 876 03290 05/17...
-
Page 2: Table Of Contents
SUGGESTED APPLICATIONS CONTENTS You may use most light duty air tools with this compressor. Some examples Section Page of light duty tools are: • Tyre Inflator Contents • Blow Gun Suggested Applications • Engine Cleaning Gun Introduction • C Bradder •... -
Page 3: Introduction
INTRODUCTION How to claim under this warranty. • Call customer service, phone number at the top. Dear Customer, • Ensure you have the following: Original purchase receipt, Model of Thank you for purchasing this compressor which has passed through compressor, Serial number of compressor. our extensive quality assurance processes. - Page 4 COMPLETE WARRANTY STATEMENT – COMPRESSOR GROUP As soon as you have purchased the compressor, we recommend that If a warranty fault is found the freight cost will be credited to the owner. you check to make sure it is intact and that you read the operating If no fault is found the product will be returned and any costs associated instructions carefully before using it.
-
Page 5: Work Area
LUBRICATION OF COMPRESSOR Work areas and benches should be kept tidy. Cluttered benches and work areas can cause accidents. Floors should be kept clean and free Before attempting to operate this air compressor the transport plug must from rubbish. Special care should be taken when the floor is slippery be removed, thrown out and replaced with the oil breather. - Page 6 DO NOT ABUSE THE POWER CORD AND WRENCHES Never yank or pull on the power cord to disconnect it from the mains Form the habit of always checking to see that any adjusting keys or supply socket. Never carry or pull your air compressor by its power wrenches have been removed from the air compressor or attached air cord.
-
Page 7: Personal Safety
CHECK DAMAGED PARTS PERSONAL SAFETY Before using the air compressor it should be carefully checked to Clothing determine that it will operate properly and perform its intended function. Do not wear loose clothing, jewelry or anything that could get caught in Check for the correct alignment of moving parts ensuring that they do moving machinery. -
Page 8: Electrical Data
ELECTRICAL DATA IMPORTANT This air compressor is fitted with a sealed electrical connection plug that is compatible with the mains power supply for Australia / New Zealand and meets the requirements of Australian Standards. This air compressor must be connected to a supply voltage that is equal to that stated on the rating label. -
Page 9: Components And Controls
PIC. 1 COMPONENTS AND CONTROLS Pic. 1 1. Oil fill and breather 2. Oil sight glass 3. Oil drain bolt 4. Rear handle 5. Tank 6. Wheels 7. Tank drain tap 8. Twin rubber stoppers 9. Tank pressure gauge - large 10. -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS PIC. 2 Unpacking Carefully unpack your air compressor. This air compressor is bulky and heavy, two (2) person lift required. Dispose of all packing material in an Screw in oil environmentally responsible manner. breather Assembly Your air compressor requires minor assembly before initial operation. Check that you have all required components required for assembly and initial use. - Page 11 RUBBER STOPPER PIC. 5 To attach the rubber stoppers to the bracket located on the bottom of the tank; 1. Undo the nut and remove the washers. 2. Push through the bracket and replace the washer. 3. Tighten the nut, Pic. 5. WHEELS PIC.
-
Page 12: Air Filter
AIR FILTER PIC. 8 The supplied air filter must be used. Failure to do so may result in irreparable damage and will void the warranty, Pic. 8 To install: 1. Carefully screw supplied air filter into the threaded hole on the top of the pump head. - Page 13 RUNNING IN YOUR NEW AIR COMPRESSOR USING THE AIR COMPRESSOR Before running in ensure that the following has been Before starting run through this simple list: completed: 1. Transport plug removed and discarded, see Pic. 2, page 10. 1. The transport plug has been removed and discarded, 2.
- Page 14 PIC. 10 The configuration of tools and accessories can be varied to suit your particular requirements. A basic recommended set up is shown in Pic. 10 (accessories not included). When you have finished using your air compressor follow these simple steps: 1.
-
Page 15: Safety Valve
ADJUSTING THE PRESSURE PIC. 11 To adjust the outlet air pressure, use the red coloured regulator knob and check the pressure on the outlet pressure gauge, Pic. 11. If the pressure needs to be lower, turn anti clockwise. Regulator If the pressure needs to be higher, turn clockwise. Use the gauge to ensure you set the correct working pressure. - Page 16 AIR TAP PIC. 13 Rotate tap handle to open/close start/stop the air supply to your attached tool Pic. 13 The air tap will need to be opened to allow the air to flow to the attached Closed tap Open tap air tool.
-
Page 17: Maintenance
MAINTENANCE PIC. 15 Daily Before use 1. Seal the tank drain tap, see Pic.14. 2. Check the oil level, see page 10, Pic. 4. Remove oil drain 3. Check safety valve operation, see page 14, Pic. 12. bolt and drain used After use oil into funnel. -
Page 18: Parts Diagram
PARTS DIAGRAM Part Description SMG Part No. Part Description SMG Part No. Cylinder Head 95 BRC95CH Washer 95 BRC95RS Oil Breather 95 BRC95OB Screw 95 BRC95RS Sight Glass Seal 95 BRC95OLSG Unloading Tube Nut 95 AC6168UT Sight Glass 95 BRC95OLSG Unloading Tube 95 AC6168UT Exhaust Elbow... -
Page 19: Technical Information
TECHNICAL INFORMATION SUGGESTED APPLICATIONS You may use most light duty air tools with this compressor. Specifications Some examples of light duty tools are; Air Compressor AC6168 • Tyre Inflator Voltage 240V AC ~ 50Hz • Blow Gun Motor Electric 2 ½ Hp •... - Page 20 For any queries or assistance call Customer Service AUST. 1300 660 457 NZ 0800 474 876 Hours of operation: Monday to Friday 8.00am - 5.00pm AEST Do not return to place of purchase. Keep your purchase receipt, this will be required to make any claims under the 24 month warranty.
