- Page 1 Video Cassette Recorder VRA451 VRA651 Owner’s Manual I m p o r t a n t ! R e t u r n y o u r Wa r r a n t y R e g i s t r a t i o n...
-
Page 2: Warranty
Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to. Once your PHILIPS MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your purchase at once. -
Page 3: Safety Precautions
Welcome to your VCR owner’s manual. This manual describes the VRA451 and the VRA651. The VRA451 is a monaural (single sound source) sys- tem, while the VRA651 is a stereo system. Otherwise, the two models are exactly the same. In this manual, the VRA651 is illustrated. -
Page 4: Table Of Contents
Recording One Channel/Watching Another ....... .31 Setting Up the VCR Plus+ Programming System ......32-33 Timer Recording with the VCR Plus+ Programming System . -
Page 5: Before Using Your Vcr 5
Removing the Plastic Cover from the Front Panel A thin, plastic cover may protect the front panel of your VCR. Before using the VCR, lift a corner of the plastic, then peel it off. Putting Batteries in the Remote Control To remove the battery compartment lid, push in the tab, then pull up the lid. -
Page 6: Hookups Without A Cable Box
Direct Broadcast System, please refer to pages 8-9. After you hook up the VCR, please go to page 10 to turn on the VCR. (The VRA651 is illustrated here. The VRA451 has single AUDIO IN/OUT Jacks.) Disconnect the antenna or cable from your TV. - Page 7 Set the CH3/CH4 switch on the back of the VCR to CH3 or CH4, whichever channel is not used or least used in your area. To operate your VCR with your TV, set the TV to the same channel. For example, when playing a tape, if the CH3/CH4 switch is set to CH3, the TV should be on channel 3.
-
Page 8: Hookups With A Cable Box/Direct Broadcast System
03 or 04 (the Cable Box/DBS output channel). (This is step 3 on page 36.) Leave the Cable Box/DBS on for a timer recording. (The VRA651 is illustrated here. The VRA451 has single AUDIO IN/OUT Jacks.) -
Page 9: Helpful Hint
CH3/CH4 switch. Set the TV to the Cable Box/DBS output chan- nel (03 or 04). Then, with the VCR in VCR position (the VCR light will appear on the display panel), use the CH(annel) 8/9 button to select the channel you want to record at the VCR. Start the recording. -
Page 10: Turning On Your Vcr
Press the VCR button, then press the POWER button. Turn on the TV. Set it to channel 3 or 4, whichever chan- nel the CH3/CH4 switch on the back of the VCR is set to. The menu shown below will appear. -
Page 11: Automatic Channel Setup 11
GRAMMING, then press the FF :/OK button. AUTO CH. SET PROCEEDING PLEASE WAIT and a scale that shows the progress of channel setup will appear on the screen. The VCR will memorize all the channels you receive. Wait for a few minutes while the VCR sets up channels. -
Page 12: Automatic Channel Setup
12 Automatic Channel Setup (cont’d) Adding/Deleting Channels Press the VCR button, then press the MENU button. SELECT , 9 CHOOSE >/OK VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select TUNER SET UP, then press the FF :/OK button. -
Page 13: Manual Clock Setting
Before you set the clock, make sure: • The VCR power is on. • The VCR light appears on the display panel. If it does not, press the VCR/TV button once. • Channels are set up. •... - Page 14 Press the PLAY 8 or STOP 9 button to set D.S.T. to ON or OFF. If AUTO CLOCK is OFF, you may set D.S.T. to ON or OFF only. For more information, please see page 18. Press the EXIT/STATUS button. CBL / DBS VCR/TV POWER EJECT QUICK PROGRAMMING START...
-
Page 15: Helpful Hints
VCR turned off until the time appears on the display panel. If – – : – – appears on the display panel after you turn off the VCR, the VCR could not find the time. Use a different method to set the clock. -
Page 16: Manual Pbs Channel Selection
If – – : – – appears on the display panel after you turn off the VCR, the VCR could not find the time. Repeat steps 1 - 6 above, entering a different PBS channel at step 5. Or, use a different method to set the clock. - Page 17 Auto will flash in the display panel until the clock is set. Leave the VCR power off until the clock is set. If – – : – – appears on the display panel after you turn off the VCR, the VCR could not find the time.
-
Page 18: Daylight-Savings Time
Leave the VCR power off until the clock is set. If – – : – – appears on the display panel after you turn off the VCR, the VCR could not find the time. Use a different method to set the clock. -
Page 19: Language Selection 19
Follow the steps below to change the language of the on-screen displays and menus. Press the VCR button, then press the MENU button. SELECT , 9 CHOOSE >/OK VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select INITIAL SET UP, then press the FF :/OK button. -
Page 20: Remote Control Buttons
Details are on page 48. Press to select an item in the VCR menu. For some PHILIPS or PHILIPS MAG- NAVOX TVs only: After pressing the TV button, press this button to select an item in the TV menu. -
Page 21: Remote Control Buttons
During tape playback, press repeat- edly to see the current time or the real-time counter on the display panel. For some PHILIPS and PHILIPS MAG- NAVOX TVs only: Press the TV button, then press this button to access the TV on-screen displays or to exit the TV menu. -
Page 22: Display Panel
A/V IN FRONT. Your audio and video cables should be connected to the AUDIO/VIDEO jacks on the front of the VCR if you are dubbing tapes. When L-1 appears here, you have selected A/V IN REAR. Your audio and video cables should be con- nected to the AUDIO/VIDEO jacks on the back of the VCR if you are dubbing tapes. -
Page 23: Front Panel 23
TV Position: Use to watch TV or to watch one program while recording another. Details are on page 31. The VCR light will not appear on the display panel when the VCR is in TV position. FF (Fast Forward) Button When tape playback is stopped, press to fast forward the tape at high speed. -
Page 24: Rear Panel
Connect cables coming from the AUDIO OUT jacks of a cam- corder, another VCR, or an audio source here. Details are on page 41. The VRA451 has a single AUDIO IN Jack. The VRA651 (pic- tured) has Right and Left AUDIO IN Jacks. -
Page 25: On-Screen Status Displays 25
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 26: Setting The Remote Control To Operate A Tv
MITSUBISHI ... .13 PANASONIC ..07, 17 PHILIPS ....01 PHILIPS MAGNAVOX .. -
Page 27: Setting The Remote Control To Operate A Cable Box/Dbs 27
Setting the Remote Control to Operate a Cable Box/DBS 27 Your VCR remote control may operate your Cable Box/DBS. Follow these steps to set the remote control code. Turn on your Cable Box/DBS. Point the remote control at your Cable Box/DBS. Press the CBL/DBS button, then press the POWER button. -
Page 28: Playing
Insert a tape in the VCR. The power will come on. The VCR will place itself in VCR position automatically (the VCR light will appear on the display panel of the VCR). If the VCR light does not appear, press the VCR/TV button once. If the tape’s record tab has been removed, playback will start automatically. -
Page 29: Recording 29
Insert a tape with its record tab intact (details are on page 5) in the VCR. The power will come on. Press the VCR button. If the VCR light appears on the display panel of the VCR, go to step 5. If the VCR light does not appear, press the VCR/TV button once. -
Page 30: One-Touch Recording
SPEED button. Details are on pages 37 and 52. • There is a tape in the VCR. Make sure the tape’s record tab is intact (see page 5) and the tape is long enough to record the program(s). If the end of the tape is reached during an OTR, recording will stop. -
Page 31: Recording One Channel/Watching Another 31
To return to the channel being recorded, use the TV remote control to select channel 03 or 04 (whichever chan- nel the CH3/CH4 switch on the back of the VCR is set to). Or, if the VCR remote control operates your TV, press the TV button, then use the CH(annel) 8/9 button to select channel 03 or 04. -
Page 32: Setting Up The Vcr Plus+ Programming System
32 Setting Up the VCR Plus+ Programming System First, fill in the boxes on this page. It will only take a few minutes, and you must do it if you want the VCR Plus+ programming system to work properly. Since the channel numbers of the stations you receive may not be the same as the station numbers, and since channel numbers differ from area to area, you must program the VCR with your local channel infor- mation. -
Page 33: Setting Up The Vcr Plus+ Programming System
VCR Plus+ and Cable/TV channel numbers that are the same, and other stations have channel numbers that do not match. You must tell the VCR the VCR Plus+ and Cable/TV channel numbers according to the following steps. -
Page 34: Timer Recording With The Vcr Plus+ Programming System
• The clock is set. Details are on pages 13-17. • There is a tape in the VCR. Make sure the tape’s record tab is intact and the tape is long enough to record the program(s). • The VCR is in VCR position (the VCR light will appear on the display panel). - Page 35 Press the FF :/OK button. If the VCR PLUS+ and CABLE/TV channel lists appear on the screen, the CABLE/TV channel has not been set for the VCR PLUS+ channel of the program you have set in step 4. Press the Number buttons to enter the CABLE/TV channel number from your list on page 32, then press the FF :/OK button.
-
Page 36: Quick Programming
CLOCK MUST BE SET appears on the screen, followed by the menu. • There is a tape in the VCR. Make sure the tape’s record tab is intact and the tape is long enough to record the program(s). • The VCR is in VCR position. The VCR light will appear on the display panel when the VCR is in VCR position. - Page 37 This chart shows the recording/playback time for T160, T120, and T60 video cassettes. There are three playback speeds: SP, LP, and SLP. This VCR will play tapes recorded in LP, but LP will not appear on the display panel. This VCR will record only in SP and SLP.
- Page 38 (The r light and the Cassette- Inside light will flash when you turn off the VCR if there is not a tape in the VCR.) The VCR must be turned off for a timer recording to take place.
- Page 39 Checking, Editing, or Clearing Timer Recordings Press the VCR button, then press the TIMER button. SELECT , 9 CHOOSE >/OK VCR PLUS+ QUICK PROGRAMMING PROGRAM REVIEW TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select PRO- GRAM REVIEW, then press the FF :/OK button.
-
Page 40: Timer Recording Speed Setting
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 41: Playing
The instructions on this page show you how to copy tapes. The illustration uses two VRA651 VCRs. Different VCRs may operate differently. To duplicate a tape, make the connections shown, then follow steps 1-6. (You may use the AUDIO and VIDEO In jacks on the front of VCR 2 instead if you prefer.) VCR 1 Playing VCR ANT.IN... -
Page 42: Index Search
Press the VCR button. Make sure the VCR is in VCR position. (The VCR light will appear on the display panel when the VCR is in VCR position.) If the VCR light does not appear, press the VCR/TV button once. -
Page 43: Multi-Channel Television Sound System (Vra651 Only) 43
It can also play back tapes recorded in stereo or second audio. These features are not available with the VRA451. • Second Audio You can program your VCR so you can hear a program that is being broadcast in second audio or a tape that was recorded in second audio. -
Page 44: Multi-Channel Television Sound System (Vra651 Only)
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 45: Hi-Fi Stereo Tape Playback (Vra651 Only) 45
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 46: Video Stabilizer
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 47: Smartpicture 47
You can make the tape playback picture softer, sharper, more nat- ural, or more distinct by adjusting the SmartPicture setting. SmartPicture is set to NATURAL when you receive the VCR. Follow the steps below to adjust the SmartPicture setting. Press the VCR button, then press the SMARTPICTURE button. -
Page 48: Playback Options
Press and hold the PLAY : button until the 3 light flash- es on the display panel. Now, when a tape has finished playing, the VCR will rewind it and start playback again. The VCR will play the tape 50 times. The 3 light on the display panel will flash dur- ing tape playback and while rewinding. -
Page 49: Child Lock 49
The dash (-) will reappear on the display panel when the timer recording is finished. • If you press the POWER button on the VCR to stop a timer recording that is in progress, recording will stop and Child Lock will be reactivated immediately. -
Page 50: Blue Background
VCR SET UP TUNER SET UP INITIAL SET UP TO END PUSH EXIT Press the PLAY 8 or STOP 9 button to select VCR SET UP, then press the FF :/OK button. SELECT , 9 CHOOSE >/OK ON SCREEN MODE... -
Page 51: Automatic Operation Features 51
Automatic Playback When you put a tape in the VCR, the power will come on auto- matically. If the tape’s record tab is missing, playback will begin. Automatic Rewind When a tape is played, fast forwarded, or recorded to its end, the VCR will rewind the tape to the beginning, then stop. -
Page 52: Glossary
(IN) or to send audio to another source (OUT). The VRA451 has single AUDIO IN/OUT Jacks on the front and back of the VCR. The VRA651 has Right and Left AUDIO IN/OUT Jacks on the front and back of the VCR. -
Page 53: Specifications 53
Specifications 53 Video Heads Four heads (VRA451) Four heads with Hi-Fi stereo (VRA651) Video Signal EIA standards; NTSC color Antenna VHF/UHF – 75 ohm external antenna terminal VHF Output Signal Channel 3 or 4 (switchable) 75 ohms unbalanced Power Requirement 120V AC;... -
Page 54: Helpful Hints
• If the VCR power is turned off for a timer recording and there isn’t a tape in the VCR, the Cassette-Inside lights will blink on the display panel. • If the record tab on a tape is missing and you turn off the VCR to set a timer recording, the VCR will eject the tape. The and Cassette-Inside lights will blink on the display panel. - Page 55 The Number buttons won’t work for channels above 69; channels above 13 cannot be received. • Select CABLE at the TUNER SET UP menu, then let the VCR set up the channels. Details are on page 11. A TV program cannot be recorded.
-
Page 56: Limited Warranty
RENEWED 90 DAY LIMITED WARRANTY... -
Page 57: Index 57
6-9, 44 position remote control code button light position vcr plus+ channels 32-33 vcr plus+ programming system setting up 32-33 timer recording 34-35 vcr/tv button 21, 23 video in/out jacks 23-24,41,44,52 stabilizer tapes 5, 37... -
Page 60: Accessories
UPPLIED The following items are supplied with your VCR; they are provided to help you use or set up your VCR. Remote Control 4835 218 37245 Two AA Batteries 4835 138 17012 PTIONAL The following additional items are not provided with your VCR, but they are designed for use with your new VCR.
