The advanced technology Car Navigator in the global market
equipped with SiRF Star III super high sensitivity chipset
NAV-51 Car Navigator
Highlights
With SiRFstarIII super high
sensitivity chipset.
Whether you are in the
downtown areas with many
high-rise buildings or in the
forest with numerous tall
trees, the NAV-51 is capable
of providing accurate
navigation. Advanced MP3
function can provide you
audio fun for your life. Its
user friendly interface allows
you to operate your
navigation easily and
delightedly.
Enjoy it
your personal navigator
and fun maker
Integrated GPS flip-up antenna, ultra
thin and compact case, does not take
too much space in your car.
Touch pad screen makes it very
convenient for configuring and
operating the device while driving.
Most advanced MP3 function for audio .
Independent audio volume adjustment
(VR) Function.
With SD interface to provide user to
download map from computer easily.
IrDA for data transfer with PC, Laptop,
Printer.... to output data and map.
3.5" TFT LCD screen with 262K colors,
perfect for reading
Elegant, stylish design, free-adjustable car
holder suitable for all models of vehicles.
Rechargeable and removable Lithium-ion
battery, can easily buy and change.
Build-in larger speakers.
2 colors LED for the status display of
battery status.
Applications:
Car Navigation
(Turn-by-turn with voice guidance)
Personal/Portable Navigation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NAV-51 and is the answer not in the manual?

Questions and answers

Summary of Contents for Holux NAV-51

  • Page 1 Rechargeable and removable Lithium-ion trees, the NAV-51 is capable battery, can easily buy and change. of providing accurate Build-in larger speakers. navigation. Advanced MP3...
  • Page 2: Specifications

    Tel: 886-3-668 7000 Fax: 886-3-668 7111 www.holux.com Holux 2005. All rights, including rights created by patent grant or registration of a utility model or design are reserved. Specifications subject to change for technical reasons. Delivery subject to availability. All other product, service and company Datasheet 2005DS0002v.01...
  • Page 3: Music Playback Function

    In addition to the navigation system, this unit also provides functions for music playback, image browsing, and system settings. You can control and operate the system on screen with a stylus, or by using the directional keys located on the right hand side of the unit. Control the menus by moving up, down, left and right.
  • Page 4 3. The Music Playback Window. 4. Use the buttons in the Music Playback Window to control each playback function. 5. For functions of different buttons in the Music Playback Window, please refer to the illustration below: Previous Exit Play/Pause To Song Increase Volume Selection Window Volume Display...
  • Page 5: Create Custom Playlist

    Create Custom Playlist The Create Custom Playlist function lets you create a personalized playlist, specifying which songs to play and in what order. Adding/removing a song from the playlist will not copy or delete the actual file. It will only add/remove the path and position of the music file from the playlist.
  • Page 6: Image Browsing Function

    3. After loading the list of MP3 files contained in the directory, select the desired file to be played and double click to add to playlist. Or click the [ Add ] button to add to playlist. 4. The file will be added to the panel/playlist on the right. 5.
  • Page 7 3. The Image Browsing Window. 4. Double click a directory in the lower right panel that stores the image files. 5. Double click the image/photograph file to be displayed. 6. Click the expand/shrink button to expand or shrink the viewed image.
  • Page 8: System Settings

    Setting The setting function gives you the ability to adjust the basic system options, including time settings, volume control, screen calibration, startup message, backlight setting, version info etc… You can modify the settings to your personal preference. System Settings [Time] 1.
  • Page 9: Startup Message

    [Volume] 1. Under the settings window, control the volume directly with the scroll bar. There are six levels of volume in total. Scroll bar [Startup Message] 1. Under the settings window, select the Warning Voice [Off] or [On] squares for whether the startup message is to be broadcast.
  • Page 10 [Align Screen] Control of this unit is accomplished primarily through the stylus by touching/writing on the screen. If the system cannot correctly identify your stylus’ input, please run through the screen calibration procedure. 1. From the settings window, select the [Stylus Adjustment] option to start the screen calibration procedure.
  • Page 11: Backlight Settings

    5. Follow the procedures and finish touching on the forth and fifth positions. 6. To finish the screen calibration procedure, select to confirm or select to keep the original settings. 7. Go back to the settings window and select to go back to the main menu screen.
  • Page 12 5. Select to confirm or select to keep the original settings. 6. Go back to the settings window and select to return to main menu screen.
  • Page 13 Help/Tips 1. Under the setting window, select [Help] to enter the help window. 2. The screen display will show instructions for operation of music playback and image browsing functions. ※ For instructions on the navigation software, please refer to the [Navigation Software Operation Manual].
  • Page 14 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.
