- Page 1 VPZ210/VPZ215 4/3/99 3:16 PM Page 1 Video Cassette Player VPZ210AT VPZ215AT Owner’s Manual Important! Return your Warranty Registration Card within 10 days. See why inside. PHOTOGRAPH OF VPZ210 PHOTOGRAPH OF VPZ215...
- Page 2 Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to. Once your PHILIPS MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your purchase at once.
-
Page 3: Introduction 3
This VCP, equipped with a High Quality (HQ) system, is compati- ble with existing Video Home System (VHS) equipment. Philips Consumer Electronics Company recommends that you use only video cassette tapes that have been tested and inspected for use in two, four, six, and eight hour VCRs, and which are labeled with the mark. -
Page 4: Table Of Contents
VPZ210/VPZ215 4/3/99 3:16 PM Page 4 4 Table of Contents Setting Up Your VCP Introduction ............3 Table of Contents . -
Page 5: Before Using Your Vcp 5
VPZ210/VPZ215 4/3/99 3:16 PM Page 5 Putting Batteries in the Remote Control Remove the battery compartment lid on the bottom of the remote control by sliding the lid in the direction of the arrow. Insert two AA batter- ies inside the battery compartment with their + and –... -
Page 6: Hookups Without A Cable Box
VPZ210/VPZ215 4/3/99 3:16 PM Page 6 6 Hookups Without a Cable Box The basic VCP/TV connection – antenna/cable to VCP to TV – is shown below. If you have a Cable Box or a descrambler box, please refer to pages eight-nine. If you have a Stereo TV, please go to page 10. - Page 7 VPZ210/VPZ215 4/3/99 3:16 PM Page 7 Connect the RF coaxial cable (supplied) to the ANT(enna) OUT jack on the back of the VCP and to the ANTENNA IN Jack on the TV. (You may use either a snap-on type or screw-on type of coaxial cable, whichever you prefer. A snap-on type is supplied.) ANT OUT ANT IN...
-
Page 8: Hookups With A Cable Box
VPZ210/VPZ215 4/3/99 3:16 PM Page 8 8 Hookups With a Cable Box This connection allows you to view any channel. After you connect the Cable Box, VCP, and TV as shown below, the features described on this page will be available. 1. -
Page 9: Hookups With A Cable Box
VPZ210/VPZ215 4/3/99 3:16 PM Page 9 This connection allows you to view any channel. After you connect the VCP, Cable Box, and TV as shown below, the features on this page will be available. 1. Connect a Cable signal to the VCP’s ANT(enna) IN Jack. -
Page 10: Hookups With A Stereo Tv
VPZ210/VPZ215 4/3/99 3:16 PM Page 10 10 Hookups With a Stereo TV antenna or cable to ANT(enna) IN Jack ANT OUT ANT IN VIDEO (yellow) and AUDIO (white) OUTPUT Jacks Audio and Video cables are not supplied. Connect the antenna or cable to the ANT(enna) IN Jack on the back of the VCP. -
Page 11: Mobile Connections (Vpz215At Only) 11
VPZ210/VPZ215 4/3/99 3:16 PM Page 11 When passengers in your vehicle want to watch a video program, hook up the VCP by following the steps below. Back of VCP ANT OUT ANT IN AC Power Cord Car Battery Cord (supplied) •... -
Page 12: Remote Control Buttons
VPZ210/VPZ215 4/3/99 3:16 PM Page 12 12 Remote Control Buttons TRACKING (Up/Down) Buttons During tape playback, press to adjust the tracking manually. When in Still mode, press to stabilize the still picture. When tape playback is stopped, press to fast forward the tape at high speed. -
Page 13: Display Panel 13
VPZ210/VPZ215 4/3/99 3:16 PM Page 13 VIDEO CASSETTE PLAYER DIGITAL AUTO TRACKING POWER POWER Light This light indicates that the power is turned on. When moisture has accumu- lated in your VCP, this light will blink (only on the VPZ215AT). REW(ind) Light This light appears when the tape is rewinding. -
Page 14: Front Panel
VPZ210/VPZ215 4/3/99 3:16 PM Page 14 14 Front Panel PLAY Button Press to play a tape. Also, press to release Search mode or Still mode and return to normal playback. Details are on page 17. REW(ind) Button When tape playback is stopped, press to rewind the tape at high speed. -
Page 15: Rear Panel 15
VPZ210/VPZ215 4/3/99 3:16 PM Page 15 CH3/CH4 Switch Set to channel 3 or 4 to use your TV with your VCP. Details are on pages six-nine. ANT OUT ANT IN ANT(enna) IN Jack Connect your antenna or cable here. Details are on pages six-10. AC Power Cord Connect to a standard AC outlet to supply power to the VCP. -
Page 16: Playing
VPZ210/VPZ215 4/3/99 3:16 PM Page 16 16 Playing Before playing a tape, make sure the VCP and TV are connected (see pages six-11). Then, follow the steps below. Turn on the TV. Set it to the same channel as the CH3/CH4 switch on the back of the VCP. -
Page 17: Playback Options 17
VPZ210/VPZ215 4/3/99 3:16 PM Page 17 PICT(ure) PICT(ure) CONT(rol) Light CONTROL Button VIDEO CASSETTE PLAYER DIGITAL AUTO TRACKING PLAY AC/DC POWER SYSTEM AUTO HEAD CLEANER FULL AUTO SYSTEM POWER REPEAT PICT.CONT REPEAT Button REPEAT Light FF/SEARCH Button EJECT POWER PLAY Button REW(ind)/ TRACKING SEARCH... -
Page 18: Playback Features
VPZ210/VPZ215 4/3/99 3:16 PM Page 18 18 Playback Features Direct Button Operation When a tape is in the VCP and the VCP power is off, press the PLAY, REW(ind), or FF button on the VCP. The VCP will turn on automatically, and playback, rewinding, or fast forwarding will start immediately. -
Page 19: Helpful Hints 19
VPZ210/VPZ215 4/3/99 3:16 PM Page 19 If you are having problems with your product, check this list of problems and possible solutions before requesting service. You may be able to solve the problem yourself. If you need to call a customer service representative, please know the model number and serial number of your product before you call. -
Page 20: Limited Warranty
Philips Consumer Electronics Company. In countries where Philips Consumer Electronics Company does not dis- Philips Service Solutions Group, P.O. Box 555, Jefferson City, Tennessee 37760, VIDEO CASSETTE PLAYER This product must be carried in for repair. -
Page 21: Specifications/Glossary 21
VPZ210/VPZ215 4/3/99 3:16 PM Page 21 Specifications Video Heads Two heads Video Signal EIA standards; NTSC color Antenna VHF/UHF – 75 ohm external anten- na/cable terminal VHF Output Signal Channel 3 or 4 (switchable) 75 ohms unbalanced Power Requirement AC 120V ± 10%, 60Hz ± 5%, DC 13.2V ±... - Page 22 VPZ210/VPZ215 4/3/99 3:16 PM Page 22...
-
Page 23: Index 23
VPZ210/VPZ215 4/3/99 3:16 PM Page 23 ac power cord ......15 accessories ......24 ant(enna) in jack . -
Page 24: Supplied Accessories
One-Piece Car Battery Cord VPZ215AT only (4835 321 57008) If any of these items are not included, or if you need to replace an item, contact Philips Service Solutions Group at the address below. Philips Service Solutions Group P.O. Box 967 Greeneville, TN 37744-0967 Or, call 1-800-851-8885.
