- Page 1 Video Cassette Recorder VCA631AT VCA431AT Owner’s Manual Important! Return your Warranty Registration Card within 10 days. See why inside.
- Page 2 Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to. Once your PHILIPS MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your purchase at once.
-
Page 3: Introduction 3
This VCR is equipped with a High Quality (HQ) system and is compatible with existing Video Home System (VHS) equipment. Philips Consumer Electronics Company recommends that you use only video cassette tapes which are labeled with the The use of other tapes may result in poor picture quality and excessive deposits on the video heads, which may not be covered by the warranty if damage occurs. -
Page 4: Table Of Contents
4 Table of Contents Setting Up Your VCR Introduction ............3 Table of Contents . -
Page 5: Before Using Your Vcr 5
Removing the Plastic Cover from the Front Panel A thin, plastic cover may protect the front panel of your VCR. Before using the VCR, lift a corner of the plastic, then peel it off. Putting Batteries in the Remote Control Remove the battery compartment lid on the bottom of the remote control by sliding it in the direction of the arrow. -
Page 6: Hookups Without A Cable Box/Direct Broadcast System
6 Hookups without a Cable Box/Direct Broadcast System The basic VCR/TV connection – antenna/cable to VCR to TV – is shown below. If you have a Cable Box or a Direct Broadcast System, please see pages eight-nine. If you have a Stereo TV, please see page 10. -
Page 7: Hookups Without A Cable Box/Direct Broadcast System
Hookups without a Cable Box/Direct Broadcast System (cont’d) 7 Connect the RF coaxial cable (supplied) to the OUT Jack on the back of the VCR and to the ANTENNA IN Jack on the TV. (You may use either a snap-on type (supplied) or screw-on type of coaxial cable, whichever you prefer.) Antenna or Cable... -
Page 8: Hookups With A Cable Box/Direct Broadcast System
8 Hookups with a Cable Box/Direct Broadcast System There are two ways to connect your Cable Box/DBS to the VCR. With this connection: You may view any channel. You must select channels at the Cable Box/DBS. Channels cannot be changed at the VCR. You may not view a channel other than the one you are recording. - Page 9 Hookups with a Cable Box/Direct Broadcast System (cont’d) 9 With this connection: You may watch one channel while recording another. You may not record scrambled channels. Cable Signal RF coaxial cable Connections Connect a Cable signal to the VCR’s ANT(enna) IN Jack. Use an RF coaxial cable (supplied) to connect the OUT Jack on the VCR to the IN Jack on the Cable Box/DBS.
-
Page 10: Hookups With A Stereo Tv
10 Hookups with a Stereo TV VCA631 VIDEO (yellow) and AUDIO (red and white) OUT Jacks VCA431 VIDEO (yellow) and AUDIO (white) OUT Jacks Audio and Video cables are not supplied. Connect the antenna or cable to the ANT(enna) IN Jack on the back of the VCR. Connect a video cable to the yellow VIDEO OUT Jack on the back of the VCR. -
Page 11: Turning On Your Vcr 11
Before turning on your VCR, make sure there are batteries in the remote control and the VCR and TV are connected correctly. Follow the steps on this page only when you plug the VCR power cord into the wall outlet for the first time. You can not program channels if you are using a Cable Box or a Direct Broadcast System. -
Page 12: Automatic Channel Setup
12 Automatic Channel Setup Although your VCR may automatically memorize the channels you receive when you turn it on for the first time, this function lets you set up the channels again. Press the VCR button. Press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP... -
Page 13: Adding/Deleting Channels
Adding/Deleting Channels Press the VCR button. Press the MENU button. Press the PLAY/o button or the STOP/p button to select TUNER SET UP, then press the F.FWD/B button. Press the PLAY/o button or the STOP/p button to select ADD/DELETE CH, then press the F.FWD/B button. SELECT op ADD/DELETE B DELETED DELETED... - Page 14 14 Automatic Channel Setup (cont’d) Reviewing Memorized Channels Press the VCR button. Press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP TUNER SET UP SET CLOCK TO END PUSH EXIT Press the PLAY/o button or the STOP/p button to select TUNER SET UP, then press the F.FWD/B button.
-
Page 15: Setting The Clock 15
There are two ways to set the clock. With manual clock setting, you tell the VCR the current time. With automatic clock setting, the VCR gets the current time from your local PBS station. It keeps track of the time by constantly referring to the time broad- casted by your PBS station. - Page 16 16 Setting the Clock (cont’d) Press two Number buttons for the hour(s) and two Number buttons for the minute(s). Then press 1 for AM or 2 for PM. For example, for 2:15 PM, press 02, 15, 2. Enter a 0 before a single-digit number. Entries that do not match the VCR’s internal calendar will cause a question mark (?) to appear on the screen.
-
Page 17: Automatic Clock Setting
Automatic Clock Setting Press the VCR button, then press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP TUNER SET UP SET CLOCK TO END PUSH EXIT Press the PLAY/o button or the STOP/p button to select SET CLOCK, then press the F.FWD/B button. If OFF appears to the right of AUTO CLOCK, press the F.FWD/B button to select ON. - Page 18 18 Setting the Clock (cont’d) Time Zone When using the AUTO CLOCK function, you can specify your time zone. That way, the VCR will update the clock according to your time zone. Press the VCR button, then press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP...
-
Page 19: Daylight-Savings Time 19
You may program the VCR so its clock will automatically move forward one hour in April and turn back one hour in October. Daylight-Savings Time is set to ON when you receive your VCR. Turn Daylight-Savings Time ON or OFF by following the steps below. -
Page 20: Language Selection
20 Language Selection Follow the steps below to change the language of the on-screen displays and menus. Press the VCR button. Press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP TUNER SET UP SET CLOCK TO END PUSH EXIT Press the PLAY/o button or the STOP/p button to select VCR SET UP, then press the F.FWD/B button. -
Page 21: Child Lock 21
Child Lock prevents use of the VCR by deactivating the VCR fea- ture buttons on the VCR and the remote control. To set the Child Lock, turn on the VCR power, then follow the steps below. Press the VCR button. Press and hold the POWER button on the remote con- trol until PL appears on the display panel. -
Page 22: Setting The Remote To Operate A Tv
TV. PHILCO ....14 PHILIPS ....01 PHILIPS MAGNAVOX. .01, 02, 03 QUASAR . -
Page 23: Setting The Remote To Operate A Cable Box/Direct Broadcast System 23
Setting the Remote to Operate a Cable Box/Direct Broadcast System 23 Your VCR remote control may operate your Cable Box or Direct Broadcast System (DBS). If the remote control doesn’t operate your Cable Box or DBS now, follow the steps below. Turn on the Cable Box/DBS. -
Page 24: Remote Control Buttons
VCR menu. Or, if you have a Magnavox, Philips, or Philips Magnavox TV, press when in TV mode to select an item in the TV menu. Press to access the VCR menu. Or, if you have a Magnavox, Philips, or Philips Magnavox TV, press the TV button, then press the MENU button Press to select channels at the VCR, TV, Cable Box, or Direct Broadcast System;... - Page 25 During playback, press to fast forward the tape while the picture stays on-screen. Details are on page 46. Or, if you have a Magnavox, Philips, or Philips Magnavox TV, use to adjust the controls in the TV Press to operate the Cable Box or Direct Broadcast System. Details •...
-
Page 26: On-Screen Status Displays
26 On-Screen Status Displays A status display will appear when you press the STATUS/EXIT but- ton or certain function buttons. The contents of the status display will vary. To choose the status display mode, follow the steps below. If you select STATUS ON, then select COUNTER ONLY Whenever you press the STOP/p button or the PLAY/o button, the status display will appear for five seconds. -
Page 27: Vcr Display Panel 27
VCA631 PWR.(power) Light This light appears when the power is on. Cassette-Inside Light This light appears when there is a tape in the VCR. VCR Light This light appears when the VCR is in VCR position. This light does not appear when the VCR is in TV position. -
Page 28: Front Panel
28 Front Panel Remote Sensor Receives a signal from your remote control so you can oper- ate your VCR from a distance. POWER Button Press to turn the VCR power on and off. VIDEO In Jack Connect a cable coming from the video out jack of a camcorder, another VCR, or an audio-visual source... -
Page 29: Rear Panel 29
VCA631 VIDEO OUT Jack Connect a cable going to the VIDEO IN Jack of a camcorder, another VCR, or an audio-visual system (monitor, laser disc player, video disc player, etc.) here. Details are on pages 42 and 48. VIDEO IN Jack Connect a cable coming from the VIDEO OUT Jack of a cam- AC Power Cord... -
Page 30: Playing
30 Playing Read and follow the steps below to play a tape. Turn on the TV and set it to channel 3 or 4, whichever channel the CH3/CH4 switch on the back of the VCR is set to. Insert a tape in the VCR. The PWR., VCR, and Cassette-Inside lights will appear on the display panel. -
Page 31: Recording 31
Read and follow the steps below to record a television program. Turn on the TV and set it to channel 3 or 4, whichever channel the CH3/CH4 switch on the back of the VCR is set to. Insert a tape with its record tab intact in the VCR. Press the VCR button. -
Page 32: Recording One Channel/Watching Another
32 Recording One Channel/Watching Another Press the VCR button. Press the REC(ord)/OTR button to start a recording of the current channel. (See page 31.) Press the VCR/TV button to put the VCR in TV position. The VCR light will disappear from the VCR’s display panel. Press the TV button, then press the CH(annel) o/p or Number buttons to select the channel you want to watch at the TV. -
Page 33: One-Touch Recording 33
The One-Touch Recording (OTR) feature allows you to set an immediate timed recording 30 minutes to eight hours long. Before you begin: Set up the channels at the VCR. Select a recording speed (SP, SLP) with the SPEED button. Put a tape in the VCR. Make sure the tape’s record tab is intact and the tape is long enough to record the program(s). -
Page 34: Timer Recording
34 Timer Recording Follow the steps below to program your VCR to record TV pro- grams while you’re away from home. The VCR will turn itself on, record, and turn itself off automatically. Before you begin: Set up the channels at the VCR. Set the clock. -
Page 35: Helpful Hints
Use the Number buttons (1 - 8) to select a slot in which to store the timer recording. There are eight slots. Numbers for open slots will flash on the screen. NOTE: If you enter a number for a slot that has already been used to store a timer recording, PREVIOUSLY SET PROGRAM will appear on the screen briefly. -
Page 36: The Vcr
36 Timer Recording (cont’d) Press the Number 1 button to record in SP speed or the Number 2 button to record in SLP speed. (See the chart below.) You cannot use the SPEED button at this time. ONE TIME PROGRAM PROGRAM CHANNEL TIME ON... - Page 37 Checking or Cancelling Timer Recordings With the VCR on and in VCR position (the VCR light will appear on the display panel), press the VCR button, then press the MENU button. Press the PLAY/o button or the STOP/p button to select PROGRAM, then press the F.FWD/B button.
-
Page 38: Setting Up The Vcr Plus+ Programming System
38 Setting Up the VCR Plus+ Programming System First, fill in the boxes on this page. It will only take a few minutes, and you must do it if you want the VCR Plus+ programming system to work properly. Since the channel numbers of the stations you receive may not be the same as the station numbers, and since channel numbers differ from area to area, you must program the VCR with your local channel infor- mation. - Page 39 Setting Up the VCR Plus+ Programming System (cont’d) 39 Now, compare the channel numbers you have written in the VCR PLUS+ CH. and CABLE/TV CH. columns. For stations whose VCR Plus+ and Cable/TV channels do not match, you must tell the VCR the VCR Plus+ and Cable/TV channel numbers by following steps 3-7.
-
Page 40: Timer Recording With The Vcr Plus+ Programming System
40 Timer Recording with the VCR Plus+ Programming System Follow these steps to set a timer recording with the PlusCode programming numbers in your TV guide. Before you begin: Set up the channels at the VCR (page 12). Set up the VCR Plus+ and Cable/TV channel numbers (pages 38-39). - Page 41 Timer Recording with the VCR Plus+ Programming System (cont’d) 41 Press the Number 1 button to record in SP speed or the Number 2 button to record in SLP speed. Your selection will appear beside REC SPEED on the screen; SP=1 SLP=2 will continue to flash.
-
Page 42: Rerecording (Tape Duplication)
42 Rerecording (Tape Duplication) The instructions on this page show you how to copy tapes. The illustration uses two VCA631 VCRs. Different VCRs may operate differently. To duplicate a tape, make the connections shown, then follow steps 1-7. 1. Audio cables from AUDIO OUT Jacks of VCR 1 to AUDIO IN Jacks of VCR 2 VCR 1 Playing VCR... -
Page 43: Repeat Play 43
Follow the steps below to make the VCR play a tape over and over. Press the VCR button. Press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP TUNER SET UP SET CLOCK TO END PUSH EXIT Press the PLAY/o button or the STOP/p button to select VCR SET UP, then press the F.FWD/B button. -
Page 44: Real-Time Counter Memory
44 Real-Time Counter Memory Follow the steps below to reset the real-time counter to zero at a tape location you want to refer to later. Press the VCR button. Play, fast forward, or rewind a tape to the location that you would like to refer to later. -
Page 45: Time Search 45
Follow the steps below to program the VCR to search forward or backward on a tape a specific length of time. There must be a tape in the VCR. Press the VCR button. Press the TIME SEARCH button. TIME SEARCH 0:00 ENTER SEARCH TIME Within 10 seconds, use the Number buttons to enter the... -
Page 46: Special Effects Playback
46 Special Effects Playback Forward and Reverse Searching (SP/LP/SLP) During tape playback, press and release the F.FWD/B button or the REW(ind)/{ button. A fast forward or reverse picture search will begin. To return to playback, press the PLAY/o button. Super High Speed Searching (LP/SLP) During tape playback, press the F.FWD/B button or the REW(ind)/{ button, then press again. -
Page 47: Automatic Operation Features 47
The following playback features will always operate. Automatic Playback When you put a tape in the VCR, the power will come on auto- matically. If the tape’s record tab is missing, playback will begin. If a timer recording is set, the power will not come on automati- cally when you insert a tape with the record tab intact. -
Page 48: Multi-Channel Television Sound System (Vca631 Only)
48 Multi-Channel Television Sound System (VCA631 only) Your VCR can play recordings broadcast in Hi-Fi (high fidelity) stereo, which produces a crisp, clear sound from two sources. Your VCR also can play tapes recorded in a second audio (usually, that means your program is recorded in a second language). - Page 49 Multi-Channel Television Sound System (VCA631 only) (cont’d) 49 Press the VCR button, then press the MENU button. SELECT op CHOOSE B PROGRAM VCR SET UP TUNER SET UP SET CLOCK TO END PUSH EXIT Press the PLAY/o button or the STOP/p button to select TUNER SET UP, then press the F.FWD/B button.
-
Page 50: Hi-Fi Stereo Sound System (Vca631 Only)
50 Hi-Fi Stereo Sound System (VCA631 only) Multi-Channel Television Sound system broadcasts are automati- cally recorded in Hi-Fi stereo sound. To play in Hi-Fi stereo the tapes recorded in Hi-Fi stereo, however, you’ll need to follow steps 1-5. Press the VCR button, then press the MENU button. Press the PLAY/o button or the STOP/p button to select VCR SET UP, then press the F.FWD/B button. -
Page 51: Hi-Fi Stereo Sound System (Vca631 Only)
Hi-Fi Stereo Sound System (VCA631 only) (cont’d) 51 Press the PLAY/o button or the STOP/p button to select HIFI. ON will appear to the right of HIFI on the screen. SELECT op HIFI MONO TO END PUSH EXIT Press the STATUS/EXIT button. POWER VCR/TV EJECT... -
Page 52: Helpful Hints
52 Helpful Hints If you are having problems with your product, check this list of problems and possible solutions before requesting service. You may be able to solve the problem yourself. If you need to call a customer service representative, please know the model number and serial number of your product before you call. -
Page 53: Helpful Hints
The Number buttons won’t work for channels above 69. • Select CABLE TV at the TUNER SET UP menu (page 12), then let the VCR set up the channels. • Enter channel numbers as a two-digit number. If you want to select channels 100 and above, enter chan- nel numbers as a three-digit number. -
Page 54: Glossary
54 Glossary AUDIO IN/OUT Jacks: jacks located on the front and back of the VCR which are used to record audio from another source (IN) or to send audio to another system (OUT). The VCA431 has a single AUDIO IN jack on the front and back of the VCR. -
Page 55: Specifications 55
Specifications 55 Video Heads Four heads – Hi-Fi (VCA631) Four heads (VCA431) Video Signal EIA standards; NTSC color Antenna VHF/UHF – 75 ohm external antenna terminal VHF Output Signal Channel 03 or 04 (switchable) 75 ohms unbalanced Power Requirement 120V AC; 60Hz Power Consumption 16W (VCA631) 14W (VCA431) -
Page 56: Limited Warranty
Philips service organization will attempt to provide service Philips Service Solutions Group, P.O. Box 2976, Longview, Texas 75606, (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available). -
Page 57: Index 57
ac power cord...29 accessories ...60 alt.ch button...25 ant(enna) in jack ...6-10, 29 audio in/out jacks10, 28, 29, 42, 54 automatic playback ...47 rewind, eject, off...47 batteries ...5 blue background...13 cassette compartment...27 cassette-inside light ...27 cbl/dbs button...5, 23, 25 o/p button ch(annel) ...25 ch3/ch4 switch ...6-9, 29... -
Page 60: Accessories
The following additional items are not provided with your VCR, but they are designed for use with your new VCR. To order these optional accessories, contact us at: Philips Parts & Accessories Marketing Department 401 East Old Andrew Johnson Highway Jefferson City, TN 37760...
