- Page 1 Video Cassette Recorder VCB411AT VCB611AT Hookup Pages Important! Return your Warranty Registration Card within 10 days. See why inside.
-
Page 2: Hookups Without A Cable Box/Direct Broadcast System
6 Hookups without a Cable Box/Direct Broadcast System The basic VCR/TV connection – antenna/cable to VCR to TV – is shown below. If you have a Cable Box or a Direct Broadcast System, please see pages eight-nine. If you have a Stereo TV, please see page 10. - Page 3 Hookups without a Cable Box/Direct Broadcast System (cont’d) 7 Connect the RF coaxial cable (supplied) to the OUT Jack on the back of the VCR and to the ANTENNA IN Jack on the TV. (You may use either a snap-on type (supplied) or screw-on type of coaxial cable, whichever you prefer.) Antenna or Cable...
-
Page 4: Hookups With A Cable Box/Direct Broadcast System
8 Hookups with a Cable Box/Direct Broadcast System There are two ways to connect your Cable Box/DBS to the VCR. With this connection: You may view any channel. You must select channels at the Cable Box/DBS. Channels cannot be changed at the VCR. You may not view a channel other than the one you are recording. -
Page 5: Recording One Channel/Watching Another
Hookups with a Cable Box/Direct Broadcast System (cont’d) 9 With this connection: You may watch one channel while recording another. You may not record scrambled channels. AUDIO VIDEO CH3 CH4 Cable Signal RF coaxial cable Connections Connect a Cable signal to the VCR’s ANT(enna) IN Jack. Use an RF coaxial cable (supplied) to connect the OUT Jack on the VCR to the IN Jack on the Cable Box/DBS. -
Page 6: Hookups With A Stereo Tv
10 Hookups with a Stereo TV VCB611 VIDEO (yellow) and AUDIO (red and white) OUT Jacks VCB411 VIDEO (yellow) and AUDIO (white) OUT Jacks Audio and Video cables are not supplied. Connect the antenna or cable to the ANT(enna) IN Jack on the back of the VCR. Connect a video cable to the yellow VIDEO OUT Jack on the back of the VCR. -
Page 7: Front Panel
Remote Sensor Receives a signal from your remote control so you can oper- ate your VCR from a distance. POWER Button Press to turn the VCR power on and off. VIDEO In Jack Connect a video cable coming from the video out jack of a camcorder, another VCR, or an audio-visual source (laser... -
Page 8: Rear Panel
28 Rear Panel AUDIO IN Jack(s) Connect audio cables coming from the AUDIO OUT Jacks of a camcorder, another VCR, or an audio source here. Details are on page 37. The VCB611 is shown here. The VCB411 has only one AUDIO IN jack. AUDIO OUT Jack(s) Connect audio cables going to the AUDIO IN Jacks of a camcorder, another VCR, or an audio system here. -
Page 9: Helpful Hints
The instructions on this page show you how to copy tapes. The illustration uses two VCB611 VCRs. Different VCRs may operate differently. To duplicate a tape, make the connections shown, then follow steps 1-7. 1. Audio cables from AUDIO OUT Jacks of VCR 1 to AUDIO IN Jacks of VCR 2 VCR 1 Playing VCR...
