Note: This operating manual refers to buttons on the "remote control" for
operating the lights. If using a Smart Phone (Wi-Fi) to operate the lights, the
Mi-Light Smart Phone App has the same control buttons so you must read
this "User Control Manual" to learn how to operate the lights.
To use your Smart Phone (Wi-Fi), a Wi-Fi Controller is required (sold
separately). You will also need to read the "WiFi Controller Setup Manual".
Contents:
2. First Operation
2.1
2.2
LED Downlight Installation
2.3
LED Downlight and Remote Programming
3. Replacement and Renew
3.1
3.2
Downlight Replacement or Addition
3.3
Remote Control Replacement or Addition
4. Frequently Asked Questions
Please Note: Only GEOLED CTA products will operate on this system. This Wi-Fi Dimming
and Colour Temperature control system does not work with other luminaires. Other Incandescent,
Halogen, Fluorescent, LED, etc products CANNOT be controlled by this system.
CTA LED Downlights
- User Control Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTA LED Downlights and is the answer not in the manual?

Questions and answers

Summary of Contents for GEO LED CTA LED Downlights

  • Page 1 CTA LED Downlights - User Control Manual Note: This operating manual refers to buttons on the “remote control” for operating the lights. If using a Smart Phone (Wi-Fi) to operate the lights, the Mi-Light Smart Phone App has the same control buttons so you must read this “User Control Manual”...
  • Page 2 1. Product Instruction This remote control is used to control either individual or Channel of CTA (Colour Temperature Adjustable) LED Downlights.  The remote control can be used to adjust brightness (dimming) or adjust colour temperature (warm white - cool white - day light). ...
  • Page 3 The remote control must be code matched to the CTA LED Downlight(s) before operation. The remote can control up to 4 Channels of CTA LED Downlights. Recommended maximum of 10 lights per Channel. Therefore one remote can control 40 lights in total.
  • Page 4 2.3.2 Group Control: After grouping into channels and Code Matching is complete, the following wireless control options can be performed (with the mains power switched on to the CTA LED Downlights):  Press the main ON button at the top of the remote. All lights should now turn on.
  • Page 5  When the main power switch to the CTA LED downlights is on and the lights are turned off by the remote control, the lights are in a standby state which uses 0.3W power per light. Note – Power Cut: If there is a Power Cut or the wall switch is turned off, after 20 seconds you can restore the power and the CTA LED downlights will return to the last brightness/colour temperature setting.
  • Page 6 Replacing the batteries in the remote does not affect memory of previous settings. 3.2 Replacement or addition of CTA LED Downlights When adding or replacing CTA LED Downlights, please follow steps 2.2 – 2.3. 3.3 Replace or Add Remote Controller ...
  • Page 7 10-15m of the downlights. 5. Trouble shooting The CTA LED Downlights do not respond to the remote control.  Check the mains (wall) power supply to the downlights is switched on.  Replace the batteries in the remote control.
