INSTRUCTION MANUAL
5122
0197

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-200 IHB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Diagnostic DM-200 IHB

Summary of Contents for Diagnostic DM-200 IHB

  • Page 1 INSTRUCTION MANUAL 5122 0197...

  • Page 7: How To Use The Device

    Wrap the cuff approximately 1-2 cm above the elbow. For best results, wrap the cuff on bare skin, at heart level. The compression of arm caused by tucked up sleeve may prevent accurate reading. HOW TO USE THE DEVICE GROUP / USER SELECTION With the power supply turned off, press the  ...
  • Page 8 MEASUREMENT TURN ON THE POWER Press and hold the ON/OFF button until you hear a long beep. All symbols will appear on the screen for 1 second, and the unit will carry out a display test. The device is ready for use. If there is air remaining in the cufffrom the previous measurement, the device will not work.The symbol REMEMBER...
  • Page 9 IRREGULAR HEART RATE INDICATOR If the pressure monitor detects irregular heart rhythm two or more times during the measurement, together with the measurement results the indicator of irregular heart rate will appear on the screen "  ". ". Irregular heart rate is the one that is 25% slower or faster than the average rhythm measured when taking a reading of systolic and diastolic pressure.

  • Page 10: Deleting Memory

    Only the results of previous measurements in the last used memory groupwill be displayed. To see the results of measurements in other REMEMBER groups, first select the desired group, and then turn off the pressure monitor. DELETING MEMORY The memory for the selected group may be deleted in the memory check mode.

  • Page 11: Problem Solving

    PROBLEM SOLVING PROBLEMS POSSIBLE CAUSE SOLUTION The cuff is too tight or Place the cuff 1-2 cm above improperly wrapped on the elbow (see page 6). the arm. Blood pressure Invalid measurement Sit in a relaxed position with the is beyond the due to body or pressure arm close to the heart.

  • Page 12: Blood Pressure Information

    BLOOD PRESSURE INFORMATION BLOOD PRESSURE Blood pressure is the force of blood pushing on artery walls. It is usually measured in millimeters of mercury (mmHg). Systolic pressure is the maximum pressure exerted on blood vessel walls at each contraction of the heart.
  • Page 13 BLOOD PRESSURE INFORMATION PRESSURE CLASSIFICATION INDICATOR ACCORDING TO WHO It DM-300 IHB is equipped with blood pressure classification indicator on the basis of the guidelines of the World Health Organization (WHO). The illustration below shows measurement results (color-coded on the monitor screen).

  • Page 14: Blood Pressure

    BLOOD PRESSURE WHAT IS THE DIFFERENCE BETWEEN BLOOD PRESSURE MEASUREMENT AT HOME AND MEASUREMENTS MADE IN THE DOCTOR'S OFFICE? Pressure measurements in hospital or doctor's office may cause anxiety (also called "white coat hypertension") and result in pressure increase up to 2530 mmHg in comparison with measurement made at home.
  • Page 15 AINTENANCE Avoid dropping, hitting, or throwing the device. Avoid extreme temperatures. Do not expose the device to direct sunlight. To clean the device, use a soft cloth and gently wipe with a mild detergent. Use a damp cloth to remove dirt and detergent residues.

  • Page 16: Technical Data

    TECHNICAL DATA Product Description Arm- type fully automatic digital blood pressure monitor Model DM-200 IHB Display LCD Digital Display Oscillometric Method Measuring Method Measurement Range 0-300 mmHg Pressure 30-180 Pulses/min Pulse Accuracy Pressure ±3 mmHg ±5% Pulse Inflation Automatic by Internal Pump...

  • Page 17: Specification

    WARRANTY The DM-200 IHB blood pressure monitor is covered by a 2-year warranty starting from the purchase date. If the device does not work properly, due to damaged elements or defective manufacturing, we will repair it or replace it for free. This warranty does not cover damage to the pressure monitor resulting from improper operation.
  • Page 18 NOTES...
  • Page 19 NOTES...

  • Page 20: Warranty Card

    DATE OF SALE ..........WARRANTY TERMS 1. Diagnosis S.A. grants a warranty: 24 months for DIAGNOSTIC blood pressure monitors and cuffs (excluding pump assembly)  12 months for nebulizer and pressure monitor accessories ...
