- Page 1 Installation guide Billi Quadra & Quadra Plus XL, XT, XR tap options...
- Page 2 Installation requirements. XL, XT, XR. Components for Billi Quadra Compact, Do not install with water that is 420, 440, 460, 4100 & 4180 Models microbiologically unsafe or with water of Before commencing installation, unknown quality without adequate disinfection ensure you have identified the following. before or after the system.
- Page 3 Installing the dispenser. XL, XT, XR. IMPORTANT: This Billi appliance is to be installed by a licensed trades person in accordance with AS/NZS 3500.1 and AS/NZ 3500.2 and in compliance with applicable state regulatory requirements. For correct operation of this appliance, it is essential to observe the manufacturer’s instructions. 1.
- Page 4 Additional installation – XR. Flush mount remote panel. Determine Remote Panel Location Plaster and Paint 70mm Dimensions and layout are shown in Start plastering as required. BRACKET diagram 9. Panel can be installed on a Wait for the plaster to dry before cleaning PANEL wall, benchtop or even inside a cupboard the bracket.
- Page 5 Connect all tubing and electrical plug as Top View Top View shown. For Quadra Compact – refer to Diagram 8. For Quadra 420 to 4180 – refer Quadra Compact Quadra 17a to Diagram 9. For Quadra Plus 5, Plus 9 and Plus 15, refer to Diagram 17b and...
- Page 6 Installing Quadra Plus mixer tap. XL, XT, XR. Additional Components for Billi Quadra 3. Fit braided coupling marked ‘Hot Inlet’ to Plus 5, Plus 9 and Plus 15 Models matching port. Join to braided coupling Before commencing installation, identify marked ‘Water Out’ using ½” joining Extended barb the following components:...
- Page 7 Commissioning XL, XT, XR. Turn on Water Supply 1. Press SELECT. Display changes to menu selection mode. Turn on the water supply tap and check there 2. Press 4 times. Shaded cursor shows ‘INITIAL SETUP’ . are no leaks. Remove font panel of unit and 3.
- Page 8 Commissioning WARNINGS. XL, XT, XR. INSTALLATION AND For continued safety of this appliance COMMISSIONING CHECKLIST it must be installed, operated and Filter packing foam removed maintained in accordance with the from under filter cannister. manufacturer’s instructions. Dispenser mounted securely – M4 —...
