Assembly
This product is fi tted with
toughened safety glass. The
glass is stronger than regular
glass and if it breaks it will form
small pieces of cubed glass, not
dangerous shards of glass. These small
pieces are still sharp, so care must be
taken to handle broken glass with care.
If the glass is put under stress or is chipped
it will break.
DO NOT ALLOW THE GLASS TO IMPACT
HARD SURFACES OR OBJECTS AS
THIS MAY CHIP/WEAKEN THE GLASS.
WEAKENED GLASS THAT IS CHIPPED OR
UNDER TENSION MAY SHATTER AT ANY
TIME, NOT ALWAYS IMMEDIATELY.
Do not fi t the shower into locations where you do
not have at least 40cm access all around the cabin
both for installation and for future service access.
We advise you do not fi t sinks, toilets etc that
restrict access behind the shower.
You must ensure you can slide the cabin away from
the wall/corner for service access.
Smooth and level walls and fl oor are required for
ideal installation conditions. Avoid carpet or vinyl
fl oors.
Please ensure you have correctly water tested the
tub before you continue.
NOTE: Instructions shown based on quadrant
model, The assembly and operation is identical
for off set models except for the rear panels
being diff erent sizes.
Please inspect all parts carefully before
assembly.
BY COMMENCING ASSEMBLY OF THIS SHOWER
YOU ACCEPT THAT THE PARTS HAVE ALL BEEN
CHECKED AND ARE UNDAMAGED.
REMOVE THE WHITE PLASTIC COVER ON
THE BACK OF THE TOWER PANEL IF YOU
WISH FOR BETTER FITTING TO THE WALL
6
Fitted to the rear
of the tower panel
is a white plastic
protective cover.
This part is fi tted to
protect the valve
and pipes during
transport.
You may choose to
REMOVE and
DISPOSE of this part
as it is not needed.
